Canon Pixma G3020 Series Manuel utilisateur

請首先閱讀「安全與重要資訊」(附錄)。

入門指南

Hướng dẫn bắt đầu

Trước tiên đọc Thông tin an toàn và quan trọng

(phụ lục).

Mari Memulai

Baca Keamanan dan Informasi Penting (lampiran)

terlebih dahulu.







Getting Started

Read Safety and Important Information

(addendum) rst.

安裝印表機......................................................................................................................................第1頁

連接至電腦、智慧型手機或平板..................................................................................第4頁

握持印表機

說明視訊

Cài đặt máy in..........................................................................................................................trang 1

Kết nối với máy tính, smartphone hoặc máy tính bảng......................trang 4

Video hướng dẫn

Giữ máy in

Memasang Pencetak.........................................................................................................halaman 1

Menghubungkan ke Komputer, Ponsel Pintar atau Tablet.......................halaman 4

Video Instruksi

Memegang Pencetak

..................................................................................................................1

......................................4

 



Installing the Printer................................................................................................................... page 1

Connecting to a Computer, Smartphone or Tablet ...............................................page 4

Instructional Videos

Holding the Printer

ENGLISH

Setting Up the Printer

1. Box Contents

•

Print Heads •

Ink Bottles

•

Power Cord

•

Setup CD-ROM

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

3. Installing the Print Heads

1 Open the print head locking cover.

2 Take out each print head from the package and

remove the label.

3 Remove the protective tape.

4 Insert the C (color) print head on the left and the

B (black) print head on the right.

5 Close the print head locking cover and press

down until it clicks.

6 Press down both joint buttons completely until

they click.

Check!

7 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ﬁngers.

Setting Up the Printer

4. Turning on the Printer

1 Connect the power cord.

Back

2 Press the ON button.

3 When the following screen appears, use the [

and ]buttons to select a language, and then

press the OK button.

Important

If an error appears on the screen, see "If an error message

(support code) appears on the screen" on page 3 and

follow the instructions.

5. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are ﬁlled with ink. If ink gets on your clothes or

belongings, it may not come oﬀ.

1 Open the scanning unit / cover.

2 Open the tank cap on the left of the printer.

3 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

PGBK

4 Align the nozzle of the ink bottle with the inlet.

5 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

6 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

ENGLISH

7 Replace the tank cap securely.

8 Repeat steps 2 through 7 to pour all ink into the

corresponding ink tanks on the right.

CMY

Check!

9 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ﬁngers.

10 When the following screen appears, use the [

and ]buttons to select Yes, and then press the

OK button.

• Please wait momentarily until the following screen

appears. Follow the on-screen instructions, and then

press the OK button.

If you will use the printer without connecting any other

devices, setup is now complete.

Select the connection method that best matches how you

will use the printer.

• To use the printer without connecting to any other

devices

Setup is now complete.

• To use the printer connecting to a computer or

smartphone

Proceed to the next page.

Check the support code, and then follow the

instructions if the displayed code is written below.

• 1890

Protective material remaining.

"2. Removing Packing Materials" on page 1

• 1470

Print heads are not installed correctly.

"3. Installing the Print Heads" on page 1

• 1471

Print heads cannot be recognized.

"3. Installing the Print Heads" on page 1

• 5200

Ink system preparation was not completed successfully.

Press the ON button to restart the printer, and then see "5.

Pouring Ink" on page 2.

For all other cases, refer to the Online Manual.

If an error message (support code) appears on

the screen

Support code

6-a

Setting Up the Printer

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from your computer.

2 Select Set Up.

3 Enter your printer's model name and click Go.

4 Click Start.

5 Click (B) Connecting to a Computer/Smartphone.

• The following steps are for Windows users.

6 Click Download.

7 Run the downloaded le.

• Follow the on-screen instructions.

• This may take some time.

• To connect to a smartphone as well, see "6-b. Connecting to a Smartphone" on page 5.

What device are you connecting?

6-a. Connecting to a Computer

Using the Setup CD-ROM

Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an

internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install

the printer driver.

6-b

ENGLISH

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Search for "Canon PRINT" in App Store, or Google Play.

• Access the Canon website to download the app.

2 Open your smartphone's Wi-Fi settings. Check that the network name (SSID) that starts

with "Canon_ij_" appears.

(Example of iOS screen)

The network name (SSID) that starts with "Canon_ij_"

• If "Canon_ij_" appears Proceed to step

• If "Canon_ij_" does not appear Proceed to step

3 Tap the network name (SSID) that starts with "Canon_ij_".

4 Open the installed app, and follow the on-screen instructions in the app to add your

printer.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

6-b. Connecting to a Smartphone

Once you have added your printer, you can print from your smartphone.

To print photos, see "Loading Paper" on page 6.

1 Extend the paper support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of paper with the print side

facing up and slide the side paper guide against

the edge of the paper stack.

4 Close the feed slot cover.

5 When Save the rear tray paper information

appears on the printer's screen, press the OK

button.

6 Select the paper size and type, and press the OK

button.

7 Extend the paper output tray.

Transporting Your Printer

When relocating the printer, check the following. Refer to the Online Manual for details.

Check that both joint buttons are pressed down

completely to avoid ink leaks.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using suﬃcient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains ﬂat

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

Loading Paper

ภาษาไทย



1

•

 •



•



•



•

 

•

 

2. 

1  

 

2  



 

a b

3 

1  

2 

3 

4   

B

 

5  

 

6    



7  

•  

a 





4.

1 

 

2  

3   

 []

 OK



  

  

3

5



  



  

 



1  

2    



3 





PGBK

4  

5  



•  



6 

•  
