Canon Laser Shot LBP-1910 Manuel utilisateur

TableofContents

1TurningthePoweronandoff ........................................................ 2

TurningthePoweron ........................................................................................ 2

TurningthePoweroff ....................................................................................... 3

2Paper ............................................................................................. 4

CompatiblePaper .............................................................................................. 4

IncompatiblePaper............................................................................................ 6

PrintableAreas .................................................................................................. 7

3PrintingfromthePaperCassette .................................................. 8

4PaperJams(HowtoRemoveJammedPaper) ...................................12

RemovingJammedPaper................................................................................ 13

5CancelingPrinting ....................................................................... 35

OutputtingtheData(ForcedPrinting) ..................................................................... 35

CancelingOperationsCurrentlyinProgress(SoftReset) ................................... 37

CancelingAllOperations(HardReset) .................................................................. 38

6CheckingOperations ................................................................... 39

TestPrint ......................................................................................................... 39

StatusPrint ...................................................................................................... 41

TurningthePoweronandoff

Whenyouturnthepoweron,thestatusoftheprinterandoptionaldevice(s)ischeckedbefore

printingisenabled.Whenthepoweristurnedoff,alloftheprintingdatainthememoryis

lost.Alwayscheckthattheジョブindicatorisoffbeforeturningthepoweroffinorderto

avoiddeletingimportantprintingdatabyaccidentordeletingprintingdatafromanother

computerwhenconnectedtoanetwork.

TurningthePoweron

Toturnonthepowerfollowtheinstructionsbelow.

Pressthepowerbuttonontheprinter.

▼ Thepowerbuttonwillnowbeinapressed-downstate.

Theoperationpanelindicatorsandthedisplaycomesonandthestatusoftheprinterandoptional

device(s)isself-diagnosed.

▼

Iftheresultsoftheself-diagnosisarenormal,theオンラインindicator,the印刷

可indicatorandtheselectedpaperfeedindicatorcomeonandprintingis

enabledwhenthemessage[00 インサツカノウ]appearsonthedisplay.

印刷可

メッセージ

ジョブ

オンライン

排出

リセット/実行

両面

給排紙選択

ユーティリティ

動作モード

セットアップ

00ｲﾝｻﾂｶﾉｳ A4

ﾊｲｼﾄﾚｲ

Thefollowinginformationappearsonthedisplay.

Currentlyselected

paperfeedsize

Printingenabled,no

printingdatabeing

processed

Currentlyselected

outputtray

00ｲﾝｻﾂｶﾉｳ A4

ﾊｲｼﾄﾚｲ

TurningthePoweroff

Toturnoffthepowerfollowtheinstructionsbelow.

•Iftheprinterisconnectedtoanetwork,checkthatothercomputersarenot

printingbeforeyouturnoffthepower.

•

Ifyouturnoffthepowerwhentheジョブindicatorison,anyprintingdata

remainingintheprinter’smemorywillbelost.Gooff-line,pressthe 排出

keytooutputtheprintingdataandthenturnoffthepower.

(→ p.35)

•Donotturnofftheprinterwhileprinting.

•Donotturnofftheprinterduringtheself-diagnosiscarriedoutimmediately

afterturningthepoweron.

Checkthattheジョブindicatorisoff.

Off

印刷可

メッセージ

ジョブ

オンライン

排出

リセット/実行

両面

給排紙選択

ユーティリティ

動作モード

セットアップ

00ｲﾝｻﾂｶﾉｳ A4

ﾊｲｼﾄﾚｲ

Pressthepowerbuttonontheprinter.

▼ Thepowerbuttonwillpopup.

Powersaving(Sleepmode)

Theprintercanbesettosleepmodeinordertoreducethepowerconsumed.

Whentheprinterissettosleepmode,alloftheindicatorsexceptthe印刷可

indicatorgooffifnooperationsarecarriedoutandnodataissentfromthe

computerforasettime.

Thesleepmodeisautomaticallycanceledifdataissentfromthecomputeror

anoperationpanelkeyispressed.

Thesleepmodeissetusingthemenufunction.

Paper

Theprinterhasthreepossiblepapersources,thepapercassette,thepapertrayandthe2000-

sheetpaperdeck(option).Thepaperthatcanbeloadedwilldifferaccordingtothepaper

source.Makesurethatyouloadtheproperpapertypeintotherespectiveholders.

CompatiblePaper

Usethecorrectpaperinordertogetthebestperformancefromyourprinter.Using

incompatiblepapercanleadtoreducedprintingqualityandpaperjamming.

●Standardstatus

Papersource Papertype Size Weight(g/m2) Max.sheetno.

Uppercassette Plainpaper A4,B4,Letter,Legal 64-105 approx.500

(64g/m2)

Lowercassette Plainpaper A4,B4,A3,Letter,Legal, 64-105 approx.500

Ledger (64g/m2)

Papertray Plainpaper width:100-297mm 64-105 approx.100

length190.5-432mm (64g/m2)

Thickpaper width:100-297mm 106-128 approx.50

length190.5-432mm (128g/m2)

Transparencies

A4(CanondomesticLBP − approx.50

transparencies:8.7g)

Labelsheet A4(Canondomesticlabel − approx.40

sheet:7.8g)

●Whenusingoptionaldevices

Papersource Papertype Size Weight(g/m2) Max.sheetno.

Optionallengthwise Plainpaper B5lengthwise 64-105 approx.500

upper(B5)cassette (64g/m2)

Optionallengthwise Plainpaper A5lengthwise 64-105 approx.500

upper(A5)cassette (64g/m2)

2000-sheetpaperdeck Plainpaper A4,B4,A3,Letter, 64-105 approx.2,000

(PD-82) Legal,Ledger (64g/m2)

● Plainpaper

Youcanuseplainpaperof100-297mmwidth,190.5-432mmlengthand64-105g/m2weight

withthisprinter.ThisincludesA5-,B5-,A4-,B4,A3,Executive,Letter,LegalandLedger-

sizepaper.Youcanloadstandard-sizeplainpaperintothepapercassetteand2000-sheet

paperdeck(exceptA5,B5andExecutive-size).Paperofothersizesshouldbeloadedintothe

papertray.Attachingtheoptionalduplexunitallowsyoutoautomaticallyduplexprinton

plainpaper.

● Thickpaper

Youcanusethickpaperof100-297mmwidth,190.5-432mmlengthand106-128g/m2

weightwiththisprinter.ThisincludesA5-,B4-,A3-,Letter-,Legal-andLedger-sizepaper.

Thickpapershouldbeloadedintothepapertray.

● Labelsheet

A4-sizelabelsheetcanbeusedinthisprinter.

Donotusethefollowingtypesoflabelsheet.Ifasheettypethatdoesnot

conformtospecificationsisused,paperjamsthatarehardtoremovemay

occurorprintermalfunctionsmaybecaused.

•Sheetwithlabelsthatarelikelytopeeloff,orsheetonwhichpartofthe

labelshavebeenused.

•Coatedsheetthatcaneasilypeelofffromthebackingsheet.

•Labelsheetwithsomeadhesivesurfacesexposed.

● Transparencies

A4-sizetransparenciescanbeusedinthisprinter.

•Sincetransparenciesarelikelytobedifficulttoseparate,usethemafter

fanningthemonesheetatatime.

•Whenoutputtingtransparenciesfaceup,removeeachtransparencyfrom

thetrayasitisoutput.Ifyouleavethetransparenciesonthetray,theywill

rollup,andapaperjamwilloccur.

IncompatiblePaper

Inordertoavoidpaperjamsanddamagingtheprinter,donotusethefollowingtypesof

paper.

Paperthatjamseasily

•Paperthatistoothickortoothin

•Non-standardsizepaper

•Wetordamppaper

•Tornpaper

•Coarseorextremelysmoothpaper

•Paperwithbinderholes,serratedpaper

•Curledpaper,creasedpaper

•Paperwithspecialcoatingsonit(suchascoatingsespeciallyforinkjet

printers)

•Labelsheetwithlabelsthatpeeloffeasily

•Paperthathasalreadybeenusedforphotocopyingorlaserprinting

(reversesidealsoincompatible)

Heat-sensitivepaper

•Paperwithinkthatmelts,burnsorgivesofftoxicvaporsintheheatofthe

fixingassembly(approx.180℃)

•Thermalpaper

•Colorpaperwithaprocessedsurface

•Speciallycoatedpaper(suchascoatingsespeciallyforinkjetprinters)

•Paperwithadhesiveonit

Paperthatcancauseprintermalfunctionordamage

•Carbonpaper

•Paperwithstaples,clips,ribbonsortapeattached

Paperonwhichtonercannotfixeasily

•CoarsepapersuchaspulppaperandJapanesewritingpaper,paperwith

roughfibers

•Paperwithspecialcoatingsonit(suchascoatingsespeciallyforinkjet

printers)

PrintableAreas

Theareasthatcanbeprintedonthepaperaregivenbelow.

● Plainpaper,thickpaper,transparencies,labelsheet

Plainpaper,thickpaper,transparenciesandlabelsheetcanbeprintedinareaswitha

minimummarginof5millimeters.

5mm

3PrintingfromthePaperCassette

Thepapercassetteholdsupto500sheets(64g/m2)ofplainpaper(60-105g/m2).Different

sizesofpapercanbeloadedintouppercassetteandlowercassettetoallowoperationsin

whichthepapersourceisautomaticallyswitched.

Loadingpaperintouppercassette,lowercassetteortheoptionallengthwiseuppercassetteis

doneinthesameway.Followtheinstructionsbelowtoloadpapercorrectly.

Thefollowingprecautionsshouldbetakentopreventpaperjams.

•Standardformpaperotherthanplainpaper,suchastransparenciesor

labelsheetandnon-standardformpapercannotbeloaded.

•Donotloadpaperthatiscreasedorseverelycurled.

•Donottouchtheblackrubberpadonthepapercassette.Thiswillcausea

paperfeedmalfunction.

Checkthattheジョブindicatorisnotflashing,pullthehandleofthepaper

cassettethatyouwanttoloadtopulloutthepapercassette.

Lineupthepapersizeguideswiththemarksindicatingthesizeofthepaperyou

wanttoload.

Papersizeguidesarelocatedontheleftandrightsidesofthepapercassettetray,atthefrontandback.

Liftthefrontoftheleftpapersizeguideandremovetheguidefromthepapercassette,thenlineupthe

guidewiththemarkindicatingthenewpapersize.

B4 LGL LTR A4

LTR A4 B4LGL

Fixthenewpapersizebyinsertingthepaper

sizeguideintothegrooveindicatingthenew

papersize.

Turnthelockleveroftherightpapersizeguidetotherighttounlockitq,thenlineuptheguide

withthemarkindicatingthenewpapersizew.Afteryouhavedonethis,turnthelocklevertothe

lefttolockthepapersizeguideintoposition.

A4/A3

LTR/11 17

LGL

Lock

Unlock

LockLever Ifyoumovethefrontpapersizeguidetolineitupwiththe

papersizemarkontherightsideofthepapercassette,

thiswillalsoadjusttherearpapersizeguide.

Fanthepaper,thenstraightentheedges.

Setthepaperonaflatsurfacetolineupitsedges.

•Ifthepaperisnotstraightenedbeforeloading,thiscouldleadtoapaper

feedmalfunctionorpaperjam.
