Canon Ivy Manuel utilisateur

Mini Photo Printer

User Manual

READ BEFORE USE

Please read the following instructions and safety precautions before using the Printer.

For regulatory and additional safety information, refer to the Regulation and Warranty

Information sheet included in your printer package contents.

CONTENTS

SAFETY INFORMATION

PRINTER OVERVIEW

PRINTER SETUP

A) Charge Printer

B) Power On

C) Load Paper

SPECIFICATIONS

INSTALLING APP

PAIRING DEVICE & PRINTFER

USER INTERFACE

Home Screen / Main Menu

Printer Setting

Photo Album

Send a Photo to Mini Print App

Edit Photos

Using Tile Print

Using Collage Print

Pre-cut Sticker Print

Smartphone Camera

Print Quene

ABOUT SYMBOLS

SAFETY INFORMATION

• Do not use or leave the product under direct sunlight. Also avoid areas subject to

rapid temperature changes, high humidity, dust and dirt.

• When operating in extreme weather, the printer might not print. Let the printer

temperature adjust to recommended operating temperature of 59º to 90ºF (15º

to 32ºC), before attempting to print again.

• When charging, please charge the printer at the recommended temperature of

59º to 90ºF (15º to 32ºC).

READ BEFORE USE

Please read the following instructions and safety precautions before using the Printer.

For regulatory and additional safety information, refer to the Regulation and Warranty

Information sheet included in your printer package contents.

• In areas with low humidity, the printer may build up a static electric charge.

Take precautions before handling the printer.

• Keep the printer away from liquids or containers of liquids.

• Keep the ventilation openings clear of any objects that could block them.

• Do not under any circumstances dismantle the printer. If the product is not

functioning properly, please contactthe dealer you purchased this product from or

Canon Service & Support at 1-800-652-2666.

• Do not improperly dispose of the product as it may cause personal injury or harm.

Please dispose of the product in accordance with local regulations.

• Do not handle near Medical Electrical Equipment. Weak magnetism is emitted by

this product. Do not stand near implanted electronic devices, such as a cardiac

pacemaker. Please see your doctor if the printer does come close to such a device.

•

Disassembling the battery may cause leakage, explosion, damage or personal

injury.

• Do not use the printer if the battery or product has swelled.

•

Never expose the battery to high temperature, direct heat, or dispose by incineration.

Instructions or content are impor-

tant and must be followed accord-

ingly.

NOTE

CAUTION

Indicates information that if ignored, could

result in accidental injury caused by improper

use of the equipment. These must be

observed for safe operation.

CAUTION

ABOUT SYMBOLS

PRODUCT FEATURES

READ BEFORE USE

Please read the following instructions and safety precautions before using the Printer.

For regulatory and additional safety information, refer to the Regulation and Warranty

Information sheet included in your printer package contents.

Quick Start GuideMini Photo Printer USB Cable Regulation and

Warranty

Information sheet

CANON ZINK®

Photo Paper

(10 sheets)

Mini Print

PRINTER OVERVIEW

② Power button① Power LED light ③ Top cover ④ Paper output slot

⑥ Charging LED light⑤ Reset button ⑧ Paper tray

(visible with top cover open)

⑨ Wristband eyelet

⑦ USB port

(for charging)

ABOUT SYMBOLS

SUPPLIED ITEMS

PRODUCT FEATURES

POWER CHARGING

White – Printer is powered on

White ashing – Printing /

Processing / Cooling

Red ashing – No paper /

Cover open / Paper jam /

Low battery / storage full /

other errors

Red - Firmware updating

Red - Charging

Green - Charge completed

Red & Green ashing alter-

natively - Charging error

MAINTAINING YOUR CANON MINI PRINTER

• Use a soft, dry cloth to clean the product. Do not clean with a damp cloth or

volatile liquids such as paint thinner.

• Keep the top cover closed to avoid dust and other particles from entering the

inside of your printer.

• Use and keep your printer in the recommended environment of

59º to 90º F

(15º to 32º C) and 40-55% relative humidity.

• Keep your printer rmware up-to-date. Connect your device with the Canon Mini

Print App. "Firmware Upgrade" icon will be appeared on the menu bar if new

rmware is available.

− Make sure your mobile device has a internet connection before checking. If

you need to upgrade/update the rmware, your printer must be charged to 50%

or higher or connected to a power source.

• Make sure you’re using the latest Canon Mini Print app version. If your apps don’t

automatically update, go to your app store to check if you need to update.

NOTE

SUPPLIED ITEMS

PRODUCT FEATURES

POWER & CHARGING - LED Indicator Lights

A) CHARGE PRINTER

Battery Status Icon (shown in App)

About USB Cable

HANDLE THE USB CABLE WITH CARE WHILE CHARGING

• Do not place any heavy objects on top of the cable.

• Do not place the USB cable near heat.

• Do not scratch, damage, twist or pull hard on the cable.

• Do not plug or unplug the cable with wet hands.

• Avoid too high/too low temperature or humid condition.

• Please unplug the USB cable from power source after charging.

• Please use supplied USB cable for charging.

PRINTER SETUP

NOTE

Printer uses a built-in battery. Before using the printer, fully charge the battery

using the USB cable provided.

①Insert the smaller end of the supplied USB cable into the Printer and the other

end into a chargeable USB adapter.

②The charging LED light will turn red to indicate charging.

③Once fully charged, the charging LED will turn green.

− Operating time may vary depending on the battery status, operational status

and environment conditions.

* If you don’t use the IVY / IVY CLIQ / IVY CLIQ+ for a long time, charge the battery

once every 3 months.

POWER & CHARGING - LED Indicator Lights

A) CHARGE PRINTER

FULL MID LOW

①Remove the top cover by sliding it forward in the direction of the arrow.

②Open a single pouch of photo paper (10 sheets + blue SMART SHEET®).

③Place all 10 photo paper sheets and the one blue SMART SHEET® into the photo

paper compartment.

− Stack the photo paper on top of the blue SMART SHEET®, making sure the

barcode and the photo paper logos are facing down.

④Place the top cover back onto the printer. It should click into place when

closed properly.

− The blue SMART SHEET® will be sent through the printer automatically before

the rst print.

①Press and hold the Power button ( ) until the LED

indicator light turns on.

− The LED indicator will ash as the printer is powering on.

②When the LED indicator turns to a steady white light,

the printer is ready to print.

Blue SMART SHEET®

on bottom with

photo papers on top.

All logos facing down.

B) POWER ON

C) LOAD PAPER

WHEN USING PAPER

• Only load 10 ZINK® photo paper sheets and 1 blue SMART SHEET®. Do not load

more as it can result in paper jams or printing errors.

• For optimal print results, use ZINK® photo paper for Canon IVY printers.

−

You may purchase additional photo papers within the Canon Mini Print App by

tapping "Buy Paper" in the main menu.

• If there is a paper jam, simply turn the printer OFF and ON to automatically clear

the paper jam. Don’t try to pull the paper out.

• While the printer is printing, don’t pull or tug on the photo paper.

• Handle photo paper carefully to avoid damage or bending.

• Keep the paper clean when loading. If paper is dirty or damaged it may result in a

paper or print error.

• Don’t open a new pouch of paper until you are ready to load into your printer.

• Don’t expose photo paper to direct sunlight or moisture.

• Don’t leave your photo paper in an area where the temperature or humidity is out

of the suggested conditions indicated on the pouch. It may reduce the quality of

the printed photo.

ABOUT THE BLUE SMART SHEET®

• Each pouch of photo paper contains 10 sheets of photo paper and

1 blue SMART SHEET®.

• Load the blue SMART SHEET® and photo paper from within the same pouch for

optimal print quality. Each blue SMART SHEET® is specically tuned for the pouch

of paper it is contained in.

• The blue SMART SHEET® will be sent through the printer automatically before the

rst print to clean and the printer and optimize print quality for that specic paper

pouch (10 sheets).

• Keep the blue SMART SHEET® and only discard after you have printed all 10 sheets

of photo paper in the pouch. If print quality is not as expected, you can reuse the

blue SMART SHEET® if the paper is still from the same pouch. Simply slide the blue

SMART SHEET® with its barcode-side down underneath the remaining photo

paper.

• Using a blue SMART SHEET® from another pouch may result in reduced print

quality.

NOTE

B) POWER ON

C) LOAD PAPER

WHEN USING PAPER

• Only load 10 ZINK® photo paper sheets and 1 blue SMART SHEET®. Do not load

more as it can result in paper jams or printing errors.

• For optimal print results, use ZINK® photo paper for Canon IVY printers.

− You may purchase additional photo papers within the Canon Mini Print App by

tapping "Buy Paper" in the main menu.

• If there is a paper jam, simply turn the printer OFF and ON to automatically clear

the paper jam. Don’t try to pull the paper out.

• While the printer is printing, don’t pull or tug on the photo paper.

• Handle photo paper carefully to avoid damage or bending.

• Keep the paper clean when loading. If paper is dirty or damaged it may result in a

paper or print error.

• Don’t open a new pouch of paper until you are ready to load into your printer.

• Don’t expose photo paper to direct sunlight or moisture.

• Don’t leave your photo paper in an area where the temperature or humidity is out

of the suggested conditions indicated on the pouch. It may reduce the quality of

the printed photo.

ABOUT THE BLUE SMART SHEET®

• Each pouch of photo paper contains 10 sheets of photo paper and

1 blue SMART SHEET®.

• Load the blue SMART SHEET® and photo paper from within the same pouch for

optimal print quality. Each blue SMART SHEET® is specically tuned for the pouch

of paper it is contained in.

• The blue SMART SHEET® will be sent through the printer automatically before the

rst print to clean and the printer and optimize print quality for that specic paper

pouch (10 sheets).

• Keep the blue SMART SHEET® and only discard after you have printed all 10 sheets

of photo paper in the pouch. If print quality is not as expected, you can reuse the

blue SMART SHEET® if the paper is still from the same pouch. Simply slide the blue

SMART SHEET® with its barcode-side down underneath the remaining photo

paper.

• Using a blue SMART SHEET® from another pouch may result in reduced print

quality.

SPECIFICATIONS

Power Source Internal rechargeable battery 500 mAh Li-Polymer 7.4 V

Charging Speed Approximately 90 minutes (Full Charge)

Dimension

4.7"(L) x 3.2" (W) x 0.7" (H) / 118.3 mm (L) x 82.4 mm (W) x 18.7 mm (H)

Weight 5.4 oz (160 g)

Connectivity Bluetooth 4.0

Compatible OS iOS 9.0 or above & Android 4.4 or above

Print Technology ZINK®

Print Resolution 314 x 400 dpi (dots per inch)

Borderless Printing Yes

Compatible Paper Canon ZINK® Photo Paper: ZP-2030-20 (20 sheets)

ZP-2030-50 (50 sheets)

2” x 3” / Peel-and-stick back

Paper Capacity

Up to 10 sheets of ZINK® photo paper + 1 blue SMART SHEET®

Memory 512Mb

Environmental

Parameters

• Recommended Printer Operating, Charging, and Storage

Temperature: 59º to 90º F (15º to 32º C)

• Recommended Printer Operating, Charging, and Storage

Humidity: 40-55% RH

• Operating Temperature: 41º to 104ºF (5º to 40ºC)

• Operating Humidity: <70% RH

Automatic Power-o

None / 3 minutes / 5 minutes / 10 minutes (selectable in-app)

Power Adapter

* Subject to change without notice

Output current: 1A (min) Voltage: 5V

SEARCH FOR "Canon Mini Print" IN APP STORES

OPTION ②

USING QR CODE - SCAN THE QR CODE ON

THE "Quick Start Guide"

INSTALLING APP

For Android™ - from Google Play™

For iOS® - from the App Store®

OPTION ①

SEARCH FOR "Canon Mini Print" IN APP STORES

Autres manuels pour Ivy

Table des matières

Autres manuels Canon Imprimante

Canon

Canon PowerShot S330 Digital ELPH Manuel

Canon

Canon GX3000 Series Guide de configuration

Canon

Canon Laser Class 700 Series Manuel utilisateur

Canon

Canon PR-C151 Manuel utilisateur

Canon

Canon PIXMA TS8300 Series Guide de configuration

Canon

Canon Pixma G3110 Series Manuel utilisateur

Canon

Canon 2909B002 Manuel utilisateur

Canon

Canon imageRUNNER C6800 Manuel utilisateur

Canon

Canon iPF9000 series Manuel utilisateur

Canon

Canon iR7105 Fiche d'information produit

Canon

Canon LBP6310dn Manuel utilisateur

Canon

Canon imagePROGRAF iPF 755 Manuel utilisateur

Canon

Canon Satera LBP-5600SE Manuel utilisateur

Canon

Canon Pixma E3400 Series Manuel utilisateur

Canon

Canon imagePROGRAF PRO 1000 Mode d’emploi

Canon

Canon iPF8000S - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA PRO-10 Manuel utilisateur

Canon

Canon imageRUNNER 1750i Guide de sécurité

Canon

Canon imagePROGRAF GP-4600S Manuel utilisateur

Canon

Canon i 320 Manuel utilisateur

Canon

Canon BJC-70 Manuel utilisateur

Canon

Canon Color imageCLASS LBP633Cdw Manuel utilisateur

Canon

Canon MX470 Manuel utilisateur

Canon

Canon TS9500 Series Guide de configuration

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
