Canon ImagePROGRAF iPF825 MFP Basic Guide No.1 Guide de l'utilisateur

Printer Operations

Troubleshooting 2

Be sure to read " Safety Precautions" in the ﬁrst

booklet, Printer Operations.

Basic Guide

Read this manual before attempting to operate the printer.

Keep this manual in a handy location for future referencing.

This Basic Guide includes three booklets.

Large-Format Printers

ENG

Printer Relocation

Printer Driver Installation

Troubleshooting

Safety Precautions........................................2

Types of Manuals .............................................5

Documentation Conventions ............................6

Parts .................................................................8

Attaching the Roll Holder to Rolls...................12

Loading Rolls in the Printer ............................14

Removing the Roll from the Printer ................18

Loading Sheets in the Printer .........................22

Removing Sheets ...........................................24

Consumables..................................................25

Replacing Ink Tanks .......................................26

Replacing the Maintenance Cartridge ............32

Replacing the Printhead .................................37

Menu Map.......................................................42

Troubleshooting................................................2

If Roll Paper Jams ..........................................18

If a Sheet Jams...............................................21

If Paper is Soiled ............................................23

If Printing is Faint............................................25

If Vertical Lines are Warped or Colors are

Misaligned ..................................................26

If Banding Occurs...........................................28

If Line Length Does Not Match.......................30

Error Messages ..............................................32

Preparing to Transfer the Printer ......................2

Reinstalling the Printer .....................................8

Installing the Printer Driver (Windows) ...........12

Installing the Printer Driver (Mac OS X) .........14

Convenient Printer Driver Features................16

Paper Problems

Phenomenon

Roll paper cannot be inserted into

the paper feed slot

The roll paper is warped. Straighten out curls and reload the roll.

Cannot load sheets Press the Feeder Selection button to activate the Cut

Sheet lamp.

The paper source selection is

incorrect.

Paper is not cut straight The paper is bent or curled at the

cut position.

Straighten out any curling by the edges of the paper.

Reload the paper correctly.Paper rises by the ends of the cut

position before it is cut.

Paper is not cut In the printer driver, No or Print

Cut Guideline is specified in Auto

Cut.

In MAIN MENU, Eject or Manual

is specified in Cutting Mode.

Specify Yes in Auto Cut in the printer driver.

Specify Automatic in Cutting Mode in MAIN MENU.

Cause Corrective Action

Troubleshooting

This section gives troubleshooting tips in case of problems.

The Media Take-up Unit continues

rotating

There is a foreign object in the

path of the Media Take-up

Sensor.

The Media Take-up Sensor cord

is not connected to the Right

Media Take-up Unit correctly.

Remove the foreign object from the Media Take-up

Sensor path. Arrange the Basket Cloth and Basket

Rod so they do not interfere with the Media Take-up

Sensor.

Reconnect the Media Take-up Sensor cord as

follows.

(→"Using the Media Take-up Unit," User Manual)

If the Media Take-up Unit continues rotating, contact

your Canon dealer for assistance.

1. Turn the printer off.

2. Disconnect the Media Take-up Sensor cord from

the Right Media Take-up Unit and reconnect it

firmly, all the way in.

3. Turn the printer on.

Rolls are not cut when you are

using the Media Take-up Unit.

Either execute Paper Cutting in the Control Panel or

lift the Release Lever and cut the roll with scissors.

(→"Removing Printed Documents from the Media

Take-up Unit (Optional)," User Manual)

The size of clear film cannot be

detected

The Platen is soiled with ink or

other substances.

Open the Top Cover and clean the entire Platen.

(→, If Paper is Soiled)

If paper cannot be advanced from

Roll 2 (Lower), the Roll Unit

Cable is disconnected.

Connect the Roll Unit Cable firmly to the Roll Unit

Power Supply Inlet and the inlet on the roll unit.

Troubleshooting

Printing Does Not Start

Phenomenon

The Data lamp on the Control

Panel does not light up

The printer does not respond even

if print jobs are sent

Ink Filling.. is displayed

Make sure the power cord is securely plugged in, all

the way. Press the Power button to turn on the printer.

Press the Online button on the Control Panel to

bring the printer online.

In Windows, select the printer by clicking Select

Printer or Printer in the printing dialog box and try

printing again.

In Windows, restart the print job as follows.

In Mac OS X, open the dialog box of the printer driver,

select the printer from the list of Printer, and try

printing again.

Select the printer icon in the Printers and Faxes (or

Printers) window.

Clear Pause Printing in the File menu to restart the

print job.

In Mac OS X, restart the print job as follows.

Open the Printer Setup Utility (or the Print

Center).

Select the printer, and then Resume Printer (or

Start Jobs) in the Printers menu to restart the print

job.

Wait until the system has been filled with ink. This

process may take about ten minutes.

The printer is not on.

The printer is offline.

The target printer was not selected

when printing. (The printer is in

Sleep mode.)

The print job is paused. (The

printer is in Sleep mode.)

The printer was forced off during

operation.

Cause Corrective Action

Print the job saved on the printer's hard disk.You have selected Save in mail

box in Output Method on the

printer.

The display screen indicates

Agitating

The time for agitation varies depending on how long

the printer has been turned off. (Between about a

minute and a half to twenty minutes.) During agitation,

you can print or do other operations after the printer

goes Online.

Ink agitation is in progress.

(→"Printing Saved Jobs," User Manual)

Troubleshooting

The printer stops during a print job

Phenomenon

The printer ejects blank, unprinted

paper

This operation is normal.

Print a test pattern to check the nozzles and make

sure the Printhead is in good condition for printing.

Use the correct imagePROGRAF printer driver for the

printer and try printing again.

The printer cuts the leading edge of the roll to

straighten it and ejects the scraps when Trim

Edge First in the printer menu is On or when Trim

Edge First is Automatic and the leading edge is

slanted. The printer is ready to print after this initial

preparation.

When Off is selected under Trim Edge First, the

edge is not cut and scraps are not removed.

Clean the Printhead if the nozzles are clogged.

Contact your Canon dealer for assistance.

The leading edge of the roll paper

was cut to straighten it.

The Printhead nozzles are

clogged.

A print job was received from an

incompatible printer driver.

The printer is damaged.

(→"Checking for Nozzle Clogging," User Manual)

(→, If Printing is Faint)

An error message is shown on the

Display Screen

Check the error message and take action as

necessary.

Remove the used roll and insert a new roll.

An error message is displayed

during printing.

The last portion of roll paper was

used during a print job, and paper

could not be advanced because

the trailing edge is taped to the roll.

Status Corrective Action

(→, Error Messages)

(→, Removing the Roll from the Printer)

(→"Removing the Roll Holder from Rolls," User

Manual)

(→"Loading and Printing on Rolls," User Manual)

Set Auto Rotate to Off before attempting to print

again.

The printer has received print data

that includes HP RTL commands

when Auto Rotate is On. (→"Main Menu Settings," User Manual)

Troubleshooting

Problems with the Printing Quality

Phenomenon

Printing is faint

You may be printing on the wrong

side of the paper.

During borderless printing, the ink

was not dry enough before cutting.

The Printhead nozzles are

clogged.

Because the printer was left

without ink tanks installed for some

time, ink has become clogged in

the ink supply system.

Paper is jammed inside the Top

Cover.

Printing may be faint if Print

Quality in Advanced Settings

in the printer driver is set to

Standard or Draft.

Print on the printing surface.

Remove any scraps of paper inside the Top Cover.

Close the Top Cover.

Specify a longer drying period in the printer menu, in

Roll DryingTime in Paper Details.

Print a test pattern to check the nozzles and see if

they are clogged.

After the ink tanks have been installed for 24 hours,

run Head Cleaning B.

Follow the steps below to remove the jammed piece

of paper inside the Top Cover.

Press the Online button to bring the printer offline.

Open the Top Cover and make sure the Carriage

is not over the Platen.

In Advanced Settings of the printer driver, choose

Highest or High in Print Quality.

Cause Corrective Action

(→"Checking for Nozzle Clogging," User Manual)

(→, If Printing is Faint)

(→, If Roll Paper Jams)

(→, If a Sheet Jams)

(→"Main Menu Settings," User Manual)

Printing in Draft or Standard mode is faster and

consumes less ink than in Highest or High modes,

but the printing quality is lower.

(→"Giving Priority to Particular Graphic Elements and

Colors for Printing," User Manual)

Troubleshooting

Phenomenon Cause Corrective Action

Paper rubs against the printhead

The type of paper specified in the

printer driver does not match the

type loaded in the printer.

The Printhead is set too low.

Paper has been loaded incorrectly,

causing it to wrinkle.

You are printing on heavyweight

paper or paper that curls or

wrinkles easily after absorbing ink.

Load paper of the same type as you have specified in

the printer driver.

Make sure the same type of paper is specified in the

printer driver as you have loaded in the printer.

Hold down the Stop button for a second or more to

cancel printing.

Change the type of paper in the printer driver and

try printing again.

In Head Height, choose Automatic.

Reload the paper.

When printing on CAD Tracing Paper or other film-

based media, choose a VacuumStrngth setting of

Standard, Strong, or Strongest. If paper still rubs

against the printhead, try raising the Printhead by

setting Head Height to Highest.

When printing on Heavyweight Coated Paper or

other paper-based media, choose a VacuumStrngth

setting of Strong or Strongest. If paper still rubs

against the printhead, try raising the Printhead by

setting Head Height to Highest.

When printing on paper 0.1 mm (0.004 in) thin

or thinner, choose a VacuumStrngth setting of

Weakest. If paper still rubs against the printhead,

try raising the Printhead by setting Head Height to

Highest.

(→, Loading Rolls in the Printer)

(→, Loading Sheets in the Printer)

(→, Loading Rolls in the Printer)

(→, Loading Sheets in the Printer)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

(→"Adjusting the Vacuum Strength (VacuumStrngth),"

User Manual)

(→"Adjusting the Vacuum Strength (VacuumStrngth),"

User Manual)

(→"Adjusting the Vacuum Strength (VacuumStrngth),"

User Manual)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

Be sure to select the correct type of paper in the

printer menu when loading paper.

(→, Loading Rolls in the Printer)

(→, Loading Sheets in the Printer)

When you have loaded paper, the

paper you have loaded does not

match the type selected on the

Display Screen.

Troubleshooting

Phenomenon Cause Corrective Action

When printing on CAD Tracing Paper or film-

based media, choose a VacuumStrngth setting of

Standard, Strong, or Strongest. If paper still rubs

against the printhead, try raising the Printhead by

setting Head Height to Highest.

Straighten out the wrinkles or curls and reload the

paper. Do not use paper that has been printed on

previously.

Make sure the same type of paper is specified on the

printer as in the printer driver.

Make sure the same paper type is specified in the

printer driver as on the printer.

Hold down the Stop button for a second or more to

cancel printing.

Change the type of paper in the printer driver and

try printing again.

If this function is not needed, deactivate

CutDustReduct. through the printer menu.

Clean the Ejection Guide.

In Head Height, choose Automatic.

When printing on Heavyweight Coated Paper or

other paper-based media, choose a VacuumStrngth

setting of Strong or Strongest. If paper still rubs

against the printhead, try raising the Printhead by

setting Head Height to Highest.

The edges of the paper are dirty Open the Top Cover and clean the Platen.The Platen has become dirty after

borderless printing or printing on

small paper.

The paper is wrinkled or warped.

The type of paper as specified on

the printer does not match the type

specified in the printer driver.

A cut line is printed because the

function to reduce cutting dust has

been activated.

The Ejection Guide is soiled.

The Printhead is set too low.

You are printing on heavyweight

paper or paper that curls or

wrinkles easily after absorbing ink.

(→, If Paper is Soiled)

(→"Selecting the Paper Type (Roll)," User Manual)

(→"Selecting the Paper Type (Sheet)," User Manual)

(→, Loading Rolls in the Printer)

(→, Loading Sheets in the Printer)

(→"Main Menu Settings," User Manual)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

(→"Adjusting the Vacuum Strength (VacuumStrngth),"

User Manual)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

(→"Adjusting the Vacuum Strength (VacuumStrngth),"

User Manual)

(→"Troubleshooting Paper Abrasion and Blurry

Images (Head Height)," User Manual)

(→"Cleaning the Printer Exterior," User Manual)

Troubleshooting

Phenomenon Cause Corrective Action

Printed colors are inaccurate

The Platen has become soiled due

to printing on the Platen because

width detection is deactivated.

The Paper Retainer is soiled.

Color adjustment has not been

activated in the Advanced

Settings of the printer driver.

The Printhead nozzles are

clogged.

Adjust the settings of the color management software,

referring to the software documentation as needed.

Printhead characteristics gradually

change through repeated use, and

colors may change.

Colors have not been adjusted on

the computer or monitor.

In the Windows printer driver,

Application Color Matching

Priority is not selected.

Activate width detection, and open the Top Cover and

clean the Platen.

Set CarriageScanWdth to Fixed.

The back side of the paper is dirty The Platen has become dirty after

borderless printing or printing on

small paper.

Open the Top Cover and clean the Platen.

In the Advanced Settings of the printer driver, access

Color Settings in Color Mode to adjust colors.

Print a test pattern to check the nozzles and see if

they are clogged.

Adjust the Printhead alignment.

Refer to the computer and monitor documentation to

adjust the colors.

Click Special Settings on the Layout sheet of the

printer driver and select Application Color Matching

Priority in the dialog box.

(→, If Paper is Soiled)

(→"Checking for Nozzle Clogging," User Manual)

(→, If Vertical Lines are Warped or Colors are

Misaligned)

(→"Manual Straightening of Lines and Colors (Manual

Head Adj)," User Manual)

Color may change slightly even

on the same model of printer if

you use a different version of the

firmware or printer driver, or when

you print under different settings or

in a different printing environment.

Follow these steps to prepare the printing

environment.

Use the same version of firmware or printer driver.1.

Specify the same value for all settings items.2.

Open the Top Cover and clean the Platen. After this,

manually advance the roll onto the Platen before

printing.

Clean the Paper Retainer.

(→, If Paper is Soiled)

(→"Feeding Roll Paper Manually," User Manual)

The surface of the paper is dirty Clean the Paper Retainer.

In the Control Panel menu, set Roll DryingTime to

at least 1 min..

The Paper Retainer is soiled.

You are using a paper that does

not dry easily.

(→, If Paper is Soiled)

(→"Main Menu Settings," User Manual)

When paper that does not dry easily is used for

printing, it may curl during printing and touch the

Output Tray.

In this case, in the Control Panel menu, complete the

settings for Dry time and Area in Scan Wait Time.

However, note that printing will now take longer.

(→"Main Menu Settings," User Manual)

Troubleshooting

Phenomenon Cause Corrective Action

The Printhead is out of alignment. Adjust the Printhead alignment.

Make sure the same type of paper is specified in the

printer driver as you have loaded in the printer.

(→, If Vertical Lines are Warped or Colors are

Misaligned)

The Printhead nozzles are

clogged.

Print a test pattern to check the nozzles and see if

they are clogged.

(→"Checking for Nozzle Clogging," User Manual)

Streaks may occur if you set the

Print Quality too low.

Choose a higher level of Print Quality in the

Advanced Settings of the printer driver and try

printing again.

Printing in Draft or Standard mode is faster and

consumes less ink than in Highest or High modes,

but the printing quality is lower.

The type of paper specified in the

printer driver does not match the

type loaded in the printer.

Load paper of the same type as you have specified in

the printer driver.

(→, Loading Rolls in the Printer)

(→, Loading Sheets in the Printer)

Hold down the Stop button for a second or more to

cancel printing.

Change the type of paper in the printer driver and

try printing again.

Banding in different colors occurs The paper feed amount is out of

adjustment.

Adjust the feed amount.

(→"Adjusting the Feed Amount," User Manual)

Printing does not proceed

smoothly because print jobs are

interrupted during transmission.

Exit other applications and cancel other print jobs.

In the printer menu, Print Length

is specified in Feed Priority.

Selecting Band Joint may improve printing results.

Adjust the feed amount in the printer menu by

specifying Band Joint in Feed Priority and try

printing again.

(→"Adjusting the Feed Amount," User Manual)

(→"Giving Priority to Particular Graphic Elements and

Colors for Printing," User Manual)

Troubleshooting

Colors in printed images are

uneven

Line Drawing/Text is selected

when printing images in many solid

colors.

You are printing on paper that curls

easily.

Printed colors may be uneven if

you set the Print Quality too low.

Color may be uneven between

dark and light image areas.

Color density may be uneven if

you use Glossy Paper, art paper,

or Coated Paper.

When borderless printing is used,

the edge of the paper is cut during

printing. Thus, ink density may be

slightly uneven at the edges.

The Printhead is out of alignment.

Drying documents stacked on

each other may cause uneven

colors.

Specify Image in the printer driver.

Printed colors may appear uneven on the leading

edge of paper that is susceptible to curling. Increase

the level of suction holding the paper against the

Platen or specify a margin of 20 mm (0.79 in.) or

more for the leading edge.

Choose a higher level of Print Quality in the

Advanced Settings of the printer driver.

Select Unidirectional Printing in the Advanced

Settings of the printer driver.

In Advanced Settings of the printer driver, choose

Highest or High in Print Quality.

Specify No in Auto Cut in the printer driver before

printing. In this case, the paper can be printed without

borders on the left and right sides only. Cut the printed

document ejected from the printer, then use scissors

to cut away the edges on the top and bottom.

Adjust the Printhead alignment.

Choose a higher level of Print Quality in the

Advanced Settings of the printer driver.

To avoid uneven colors, we recommend drying each

sheet separately.

Phenomenon Cause Corrective Action

Printing in Draft or Standard mode is faster and

consumes less ink than in Highest or High modes,

but the printing quality is lower.

(→"Giving Priority to Particular Graphic Elements and

Colors for Printing," User Manual)

(→, If Vertical Lines are Warped or Colors are

Misaligned)

The type of paper specified in the

printer driver does not match the

type loaded in the printer.

Load paper of the same type as you have specified in

the printer driver.

Make sure the same type of paper is specified in the

printer driver as you have loaded in the printer.

(→, Loading Rolls in the Printer)

(→, Loading Sheets in the Printer)

Hold down the Stop button for a second or more to

cancel printing.

Change the type of paper in the printer driver and

try printing again.

(→"Giving Priority to Particular Graphic Elements and

Colors for Printing," User Manual)

(→"Adjusting the Vacuum Strength (VacuumStrngth),"

User Manual)

Scan Wait Time > Area in the

Control Panel menu is set to

Leading edge.

When Scan Wait Time > Area is set to Leading

edge, colors may be uneven 110–160 mm from the

leading edge. (The position varies depending on the

Print Quality, setting.)

In this case, select Scan Wait Time > Area > Entire

area.

However, note that printing will now take longer.

(→"Main Menu Settings," User Manual)

Autres manuels pour imagePROGRAF iPF825 MFP Basic Guide No.1

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Imprimante

Canon

Canon LASER CLASS 2050P Manuel utilisateur

Canon

Canon Satera LBP-3920 Manuel utilisateur

Canon

Canon PIXMA G6000 Series Manuel utilisateur

Canon

Canon PIXMA MX432 Manuel utilisateur

Canon

Canon SELPHY CP740 Manuel utilisateur

Canon

Canon PIXMA TS702a Manuel utilisateur

Canon

Canon 0324B001 - SELPHY ES1 Photo Printer Guide de démarrage rapide

Canon

Canon PIXMA G2060 Series Manuel utilisateur

Canon

Canon Color Bubble Jet BJC-1000 Series Manuel

Canon

Canon iP6600D - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon mg6400 series Guide de configuration

Canon

Canon iP90 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon MAXIFY GX4070 Manuel utilisateur

Canon

Canon PIXMA MX860 series Manuel utilisateur

Canon

Canon i-SENSYS LBP236dw Manuel utilisateur

Canon

Canon imagePROGRAF iPF6200 Manuel utilisateur

Canon

Canon Color image RUNNER LBP5360 Manuel utilisateur

Canon

Canon PowerShot S95 Guide de configuration

Canon

Canon i-SENSYS MF6180dw Guide d'installation et d'utilisation

Canon

Canon MX490 Series Instructions d'utilisation

Canon

Canon iP100 - PIXMA Color Inkjet Printer Manuel

Canon

Canon PIXMA TS6340 Manuel utilisateur

Canon

Canon imageCLASS D1120 Instructions de montage

Canon

Canon imageCLASS LBP913w Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien

Canon imagePROGRAF iPF825 MFP Basic Guide No.1 Guide de l'utilisateur

Manuels Imprimante populaires d'autres marques
