i80

SERVICE

MANUAL

Canon

shallberetainedforreferencepurposesbyAuthorizedServiceFacilitiesofCanonU.S.A.Its unauthorized useisprohibited.

PIXUS 80i

i80

REFERENCE MANUAL

(Differences from the base model, PIXUS 50i / i70, only)

1. MAINTENANCE

1-1. Error Display / Warning Indication

(1) Operator call errors (by LED blinking in orange)

2. REPAIR

2-1. Notes on Service Part Replacement (and Disassembling / Reassembling)

2-2. Adjustment / Repair

(1) Service mode

3. TECHNICAL REFERENCE

3-1. FAQ (Specific Problems and Solutions)

3-2. Cleaning Mode and Amount of Ink Purged

4. APPENDIX

4-1. Block Diagrams

Inkjet SFP Quality Assurance Div.

February 16, 2004

Rev. 01

QY8-1396-000

( 2 / 12 )

(1) Features (Major differences from the i70 / PIXUS 50i)

• Upgraded print quality and faster print speed

1) High image quality: Upgraded photo quality with the new 2pl-droplet print head.

2) Enhanced throughput: High-speed printing at 14ppm in black and 10ppm in color. (Draft

mode)

(i70 / PIXUS 50i: 13ppm in black and 9ppm in color)

• Increased stylishness by the Print Head Cover color change from blue to black

• Enhanced interfaces

1) The Camera Direct Printing standard of PictBridge is supported, in addition to Bubble Jet

Direct.

2) Enhanced infrared printing function

a. Supports direct image printing via IrDA function from a camera-equipped mobile phone.

- Pictographic symbols (icons) are printed.

- Setup Utility allows users to select paper type, size, text layout, etc.

<Paper type> Photo Paper Plus Glossy, Photo Paper Pro

<Paper size> i80: 4” x 6”, 5” x 7”, A4, LTR

PIXUS 80i: L, 2L, Name card,A4, A5, Postcard, Sticker, Organizer

refill (Bible, Mini)

(PIXUS 50i: Printing mode fixed to PR, supporting only

name card and L-size papers.)

b. Setup Utility new adoption

After a PC and a printer are connected with the USB cable, Setup Utility allows users to

change print settings for infrared printing and Bluetooth printing.

3) Printing via Bluetooth function (Option)

a. Enables printing via Bluetooth by installing the Bluetooth Unit, BU-10 (optional).

b. Through Setup Utility, allows users to make various settings, similar to IrDA

communication.

• Sticker media supported

In the PIXUS 80i, using the prepackaged application, Petit Print, or Setup Utility (via Bluetooth /

IrDA connection), print layout can be set easily.

• Enhanced mobility

TheAutomobile Power Unit, PU-100U, is newly adopted. (also supports the i70 / PIXUS 50i.)

Enables printing and charging from a cigarette lighter socket in automobiles.

• Enhanced user-friendliness in user troubleshooting

1) The flow chart for maintenance operations in the printer driver’s Maintenance tab is

changed.

The driver user interface screen of cleaning and nozzle check pattern printing are

integrated as a sequence of flow. They will guide users into the next step on the screen.

2) The Quick Troubleshooting is added to the end of the Quick Start Guide (Japanese

version only).

Easy troubleshooting methods regarding frequent problems are included.

( 3 / 12 )

(2) Printer Specifications (Differences from the i70 / PIXUS 50i only. Difference in red.)

Throughput

(Target value)

Draft Standard

Black (New): 14ppm 11ppm

Color (New): 10ppm 4.9ppm

Photo (SCID N5 8” x 10”): --- 0.38ppm (using A4-sized PR-101)

Interface

1) USB 2.0 full speed

2) Camera Direct Printing:

Digital camera and digital video camera supporting Bubble Jet Direct or PictBridge.

3) IrDA 1.1

- Computer: IBM PC /AT machines or their compatible machines

- Mobile phones: IrMC Ver. 1.1 compliant

- PDA (overseas only): IrOBEX protocol compliant

4) Bluetooth 1.1 (option)

- Computers satisfying the following conditions:

-- PCs with Windows XP Service Pack 1 or later, with Microsoft "Support for Bluetooth

Wireless Devices"

-- Toshiba Windows XP computers with Bluetooth Settings Version 3.00.10 or later

- Mobile phones supporting SPP / OPP / BIP / HCRP (overseas only)

- PDAs supporting SPP / OPP / BIP / HCRP (overseas only)

Note: SPP (Serial Port Profile) / OPP (Object Push Profile ) / BIP (Basic Imaging Profile) /

HCRP (Hardcopy Cable Replacement Profile)

Newly supported

paper type (ASF

stacking capacity)

Glossy Photo Paper GP-401 (A4, LTR: 10 sheets)

Photo Paper Plus Glossy PP-101 (Panorama*3: 10 sheets)

Photo Paper Plus Semi-Gloss SG-101 (A4, LTR: 5 sheets)

Envelope (120 x 235mm, 90 x 205mm: 10 sheets with longer edge in vertical orientation)

Organizer refill size*2(Bible, Mini,A5: 1 sheet)

[Japanese only]

Return postcards (10 sheets)

PIXUS Petit Seal PS-101*1 (1 sheet)

Photo Seal Set PSHRS*1 (1 sheet)

*1: Only connection wirelessly (IrDA / Bluetooth) and using prepackaged application “Petit Print.”

*2: For direct printing from a camera-equipped mobile phone

*3: Using PictBridge only

Power supply

(1) AC Adapter

Input voltage Frequency Power consumption Standby Power-off

AC 100 to 120V 50 / 60Hz Approx. 14W (max.) Approx. 1W Approx. 0.1W

AC 220 to 240V 50Hz Approx. 15W (max.) Approx. 1W Approx. 0.1W

(2) Battery (Option)

Voltage level: 10.8V 24Ah

(3) Automobile Power Unit (Option)

Input: DC 12 to 24V Output: DC 16V, 2A

(3) Print Head / Ink Tanks Specifications

- Print head: QY6-0052 (incompatible regardless of the same shape as the print head for the

i70 / PIXUS 50i)

- Ink tanks: BCI-15Bk, BCI-15Cl (same as the i70 / PIXUS 50i)

( 4 / 12 )

(4) Bluetooth Unit BU-10 Specifications (Option)

Certification Bluetooth V1.1 compliant

Maximum speed 721kbps

Transmit power Bluetooth Class 2

Operating Range

Sight distance approx. 10m

May vary due to obstacles, radio status, magnetic field around microwave

ovens, locations where radio interference occur, software / OS used, device

sensitivity, antenna performance, etc.

Supporting profiles

SPP (Serial Port Profile)

OPP (Object Push Profile)

BIP (Basic Imaging Profile)

HCRP (Hardcopy Cable Replacement Profile)

Dimensions 21 (W) x 58 (D) x 8 (H)mm

Weight 5g

Frequency band 2.4GHz

Power supply DC 5V + / - 0.25V (Supplied by the i80 / PIXUS 80i)

Power consumption 500mW (MAX)

Operating temperature 5 to 35C, 10 to 90% RH with no condensation

OS supported PCs with Windows XP Service Pack 1 or later with Microsoft "Support for

Bluetooth Wireless Devices", or Toshiba Windows XP computers with Bluetooth

Settings Version 3.00.10 or later (HCRP only)

Installation: Performed by users.

The printer must be connected to the computer via USB cable for installation and

changing settings.

Repair: By product exchange.

The Bluetooth Unit operation should be confirmed after repair (printing test using

Bluetooth unit). The servicing sites should prepare a computer supporting Bluetooth.

( 5 / 12 )

1. MAINTENANCE

1-1. Error Display / Warning Indication

Service call errors are common to the i70 / PIXUS 50i.

(1) Operator call errors (by LED blinking in orange)

A new type of error indicated by LED blinking in orange 11 times has been added to the i70 /

PIXUS 50i errors (in red in the table below).

LED

blinking in

orange Error Solution Remarks

2 times No paper. Set the paper, and press the

Resume/Cancel button.

3 times Paper jam. Remove the jammed paper, and

press the Resume/Cancel button.

6 times The print head is not

installed. Install the print head, and close the

print head cover.

7 times The print head is not

installed properly.

(EEPROM data of the print

head is faulty.)

Re-install the print head, or with the

print head installed, turn the printer off

and on.

8 times Warning: The waste ink

absorber becomes almost

full (to approx. 95% of the

maximum capacity).

Pressing the Resume/Cancel button

will exit the error, and enable printing.

In repair servicing, replace the 4-item

set of the drain pack ass’y

(QL2-0194) and the 3 ink absorbers

(QC1-1210 / 1211 / 1212) at the same

time.

The service call error,

indicating the waste

ink absorber is full, is

likely to occur soon.

9 times The black or color ink tank

is not installed, or not

installed properly.

Install both the black and color ink

tanks. If they are installed, reseat

them properly.

If the error persists

after the ink tanks are

seated properly, the

ink tank sensor is

likely to be faulty.

10 times Low battery Charge the battery, or connect the AC

adapter to resume printing.

11 times A certain period of time

has elapsed without any

communication with a

connected digital camera /

video camera, or the

connected camera is not

supported.

Remove the cable(s), press the

Resume/Cancel button, and

re-connect the cable(s).

( 6 / 12 )

2. REPAIR

2-1. Notes on Service Part Replacement (and Disassembling / Reassembling)

Notes when replacing the carriage unit or purge unit are given in this section. For other service

part replacement, the same cautions as those for the i70/PIXUS 50i apply.

Service part Notes on replacement Adjustment/settings Operation check

Carriage unit

(QM2-1116) - The slit ring (QC1-1163,

QA4-0121) is not reusable.

Use a new slit ring in

reassembling the unit.

- The carriage belt (QC1-1205)

is not reusable. Use a new

belt in reassembling the unit.

- The LF roller is easily

damaged (dented) if dropped

on the desk, etc., causing

faulty printing. Handle it with

care.

After replacement:

- Before reassembling the

carriage guide shaft and

guide rail, clean the residual

grease off the shaft, and

then apply new grease.

Carriage shaft guide: 50mg

Guide rail: 15mg

- Service test print

Purge unit

(QM2-0304) - The slit ring (QC1-1163,

QA4-0121) is not reusable.

Use a new slit ring in

reassembling the unit.

- In reassembling the purge

unit, while pressing the unit

toward the back of the

printer unit, fasten the

screw.

- Service test print

2-2. Adjustment / Repair

(1) Service mode

The basic operations are the same as those of the i70/PIXUS 50i. (Refer to the PIXUS 50i / i70

Service Manual.)

In this section, destination settings, which differs from those of the i70 / PIXUS 50i, are detailed

(difference in red).

1) Turn off the printer. While pressing the Resume/Cancel button, press the Power button.

(Do not release the buttons. The LED lights in green to indicate that a function is selectable.)

2) While holding the Power button, release the Resume/Cancel button. (Do not release the

Power button.)

3) While holding the Power button, press the Resume/Cancel button 3 times, and then release

the Power and Resume/Cancel buttons. (Each time the Resume/Cancel button is pressed,

the LED lights alternately in either orange or green, starting with orange.)

4) When the LED lights in green, press the Resume/Cancel button the specified number of

time(s) according to the function listed in the table below. (Each time the Resume/Cancel

button is pressed, the LED lights alternately in either orange or green, starting with orange.)

Time(s) LED Function Remarks

0 times Green Power off When the print head is not installed, the carriage

returns and locks in the home position.

1 time Orange Service test print

2 times Green EEPROM information print

3 times Orange EEPROM initialization

4 times Green Waste ink counter resetting Both the main and borderless printing waste ink

counters are reset.

5 times Orange Destination settings Proceed to the following steps 5) and 6), to set

the destination (different from the i70 / PIXUS

50i).

( 7 / 12 )

6 times Green USB serial number reset Set the USB serial number to “000000.”

7 times Orange USB serial number setting to

default shipment value

8 times Green Not used in servicing

9 times Orange Not used in servicing

10 times Green Return to the menu selection

5) After the function (menu) is selected, press the Power button. The LED lights in green, and

the selected function is performed. (When the operation completes, the printer returns to the

menu selection mode automatically.)

To set the destination:

6) Press the Resume/Cancel button the specified number of time(s) according to the destination

listed in the table below, and press the Power button.

Time(s) LED Destination

1 time Orange Japan: PIXUS 80i

2 times Green Overseas (A4): i80

3 times Orange Overseas (LTR): i80 (LTR)

Note: After destination settings, print the EEPROM information as shown below, and

confirm the model name.

Print sample:

80i P=V1.01 Dest=01 D=010.3 Ds=001.3 Page=00699 TIC=04012312 Bk=(+00) C=(+00)

HeadT=(28.5 28.5) EnvT=27.5 FA=03 1B 95 USB=(104A2S) CH=0001 TNK=(0003 0001)

PC(A=0008 B=0005 C=0001 L=0000 R=0001) Bk=06093 C=02371 M=02241 Y=024712 LB=630

WP=0340 IC(BK=1 C=1 M=1 Y=1) I/F(IrDA=0000 DSC=0000 BT=0039) Regi=(Page=0000)

ER(TIME=2004/01/13-11:50 ER0=1000 ER1=5100 ER2=1000 ER3=5C00)

TotalINK(Bk=00020830 C=00002829 M=00002880 Y=00002669)

DotCountReset Level01(BK=0000 Cl=0000 NO=0000) Level123(BK=0003 Cl=00010 NO=0004)

UR1(A:Bkeo=000 B:Ceo=+01 C:Meo=+01(Yeo=+01) D:LCeo=000 E:LMeo=000 (LYeo=000))

UR2(F:BkBi=000 G:ClBi=000 H:BkCl=000 I:LCBi=-02 J:C_LC=000 K:M_LM=000)

FirstSetTime=2003/11/15-16:56 PowerON=00024 PowewrOFF=00023 PE=0216

Media(Plain=00638 BP=00048 PP=00051 Card=00000) BATprint=0001 BAT(000 000 000)

Printed items:

1. Model name 2. ROM version 3. Destination 4. Waste ink amount (D: Main, Ds: Borderless) 5. Number of print

pages 6.Timer IC 7. Bidirectional registration

8. Print head temperature 9. Inside temperature 10. Line inspection information 11. USB serial number 12. Number

of times of print head installation and removal 13. Number of times of ink tank installation and removal

14. Number of times of cleaning 15. Ink consumption (Bk, C, M, Y) 16. Low battery threshold

17. Number of times of wiping 18. Number of pages printed by I/F (IrDA, DSC, BT) 19. Number of times of camera port

connection and removal 20. Number of pages printed in print head alignment

21. Latest time with no error / error record (The same errors occurring consecutively are counted as 1 error.)

22. Total ink consumption

23. Dot count reset

24. User print head alignment values

25. Installation date 26. Number of times of power-on/off 27. PE value

28. Number of pages printed by paper type (plain paper, borderless, photo paper, postcard) 29. Number of pages printed

when the battery is used 30. Battery value

( 8/ 12)

3. TECHNICAL REFERENCE

3-1. FAQ (Specific Problems and Solutions)

(1) New items specific to i80 / PIXUS 80i

No. * Function Symptom Condition Cause Solution Possible call or

complaint

1. B

Communication

Status Monitor does not

display printer status

(remaining ink amount,

printer error, etc.).

- When printing is attempted via

infrared communication under

Windows 2000 / XP (the problem

can occur also in the i70 / PIXUS

50i).

- When printing via Bluetooth

connection is attempted (only

with Microsoft Bluetooth stack, as

of January, 2004).

Because the printer supports

uni-directional communication in

the specified conditions.

- With regard to printer errors, identify

the error by LED indication.

- Regarding remaining ink amount, no

detection is available.

- The remaining ink

amount is not detected

in infrared or Bluetooth

printing.

2. C

Communication

“This document failed to

print,” etc. is displayed. - When printing is attempted via

infrared communication under

Windows 2000 / XP (the problem

can occur also in the i70 / PIXUS

50i).

- When printing via Bluetooth

connection is attempted (only

with Microsoft Bluetooth stack, as

of January, 2004).

a. As the printer supports

uni-directional communication

in the specified conditions, the

message will be displayed

unless the printer is ready for

data reception.

The printer is NOT ready for

data reception:

- during power-off.

- when a printer error occurs.

- while performing another print

job.

- during cleaning.

- when the print head cover is

open.

b. Because the HCRP print

service is not enabled.

a. By LED indication, check the printer

status.

- Turned off: Turn the printer on.

- Blinks in orange: Clear the error.

- Blinks in green: If other print

job(s) or cleaning is being

performed, wait until the operation

completes. After completion of the

operation, the message will

disappear and printing will start

automatically.

If the print head cover is open,

close it.

b. In Control Panel, select Printers and

Other Hardware, and Wireless Link.

In the Bluetooth tab, click the i80 /

PIXUS 80i printer icon, and

Properties. In the Services tab, check

the Printing (HCRP) option, and click

OK.

-“This document failed

to print” is displayed.

* Occurrence level:

A: The symptom is likely to occur frequently.

B: The symptom may occur under certain conditions, but likeliness is assumed very low in practical usage.

C: The symptom is unlikely to be recognized by the user, and no practical issues are assumed.

( 9/ 12)

(2) Problems in common with i70 / PIXUS 50i

No. * Function Symptom Condition Cause Solution Possible call or complaint

1. B Paper

feeding Paper jam

Paper edge creasing - Plain paper (soft paper)

- When about 30 sheets are

loaded.

- Paper condition (curled, or cut

edge orientation)

Depending on combination of the

above conditions, the first several

pages may not feed properly.

When many sheets of paper are

set, paper feed capability can be

slightly lowered.

Reduce the number of sheets to set on

the sheet feeder, to below the reference

mark.

-Paper jam

-Paper edge creasing

-Paper edge smeared

(due to contact with the

print head)

-Carriage error (service

call error) due to contact

of the print head to the

jammed paper

2. B Print speed Low throughput (approx.

1/2) in direct printing

from a digital camera

When the print head alignment has

never been performed via the

computer before direct camera

printing.

Because uni-directional printing is

performed to maintain the print

quality by avoiding possible

inaccurate dot placement in

bidirectional printing.

Connect the printer to the computer, and

perform the print head alignment. (The

print head alignment is available only

via the computer.)

-Print speed is low when

printing directly from a

digital camera.

3 C Installation,

Printing No infrared

communication When the printer is connected to a

certain computer (eg. NEC,

Windows 98) which does not

support Plug & Play infrared

communication.

With default settings, the Plug &

Play function is enabled. Disable the Plug & Play function, and

set the port manually.

For how to disable/enable Plug & Play

infrared communication, see the PIXUS

50i / i70 Service Manual, page 2-1, New

Technologies, (3).

-Infrared communication

is not available.

* Occurrence level:

A: The symptom is likely to occur frequently.

B: The symptom may occur under certain conditions, but likeliness is assumed very low in practical usage.

C: The symptom is unlikely to be recognized by the user, and no practical issues are assumed.

Autres manuels pour i80 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Imprimante

Canon

Canon iP5000 - PIXMA Color Inkjet Printer Mode d’emploi

Canon

Canon PIXMA MP950 Manuel utilisateur

Canon

Canon iPF650 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA MX310 series Manuel

Canon

Canon PIXMA MG8170 Manuel utilisateur

Canon

Canon Printing Using a Direct Camera/Printer Connection Guide Direct... Mode d’emploi

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon PIXMA E300 series Manuel utilisateur

Canon

Canon imagePROGRAF W2200 Manuel utilisateur

Canon

Canon PIXMA iP6000D Manuel utilisateur

Canon

Canon BJC-610 Manuel utilisateur

Canon

Canon LBP-2000 Manuel de service

Canon

Canon Pixma PRO-100S series Manuel utilisateur

Canon

Canon imagePROGRAF iPF6400 Manuel utilisateur

Canon

Canon MultiPASS F60 Manuel utilisateur

Canon

Canon LBP312 SERIES Manuel utilisateur

Canon

Canon PIXMA MP230 Manuel utilisateur

Canon

Canon Laser Shot LBP-950 Manuel utilisateur

Canon

Canon S4500 - BJC Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA PRO-10 Manuel utilisateur

Canon

Canon PIXMA Pro9000 Mark II Series Manuel utilisateur

Canon

Canon imagePROGRAF W7200 Manuel utilisateur

Canon

Canon ImagePROGRAF iPF680 Manuel utilisateur

Canon

Canon PIXMA G3910 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien

Canon i80 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques
