Canon GM2000 Series Manuel utilisateur

 



Посібник для початку

роботи

Спершу прочитайте документ Інформація щодо

безпеки й важливі відомості (додаток).

Руководство по началу

работы

В первую очередь прочтите документ Информация

о безопасности и важные сведения (приложение).

Démarrage

Commencez par lire Sécurité et informations

importantes (addendum).

Para Começar

Leia Informações Importantes e Sobre Segurança

(adendo) primeiro.

Guía de inicio

Lea primero Información de seguridad e

información importante (apéndice).

Getting Started

Read Safety and Important Information

(addendum) ﬁrst.





4  ..............................................................

1 ......................................................................................................................................

Установлення принтера........................................................................................................стор. 1

Підключення до комп’ютера, смартфона або планшета................................стор. 4

Відеоінструкції

Як тримати принтер

Установка принтера....................................................................................................................стр. 1

Подключение к компьютеру, смартфону или планшету ..................................стр. 4

Видеоинструкции

Удерживание принтера

Installation de l'imprimante..................................................................................................page 1

Connexion à un ordinateur, un smartphone ou une tablette.........................page 4

Instructions vidéo

Manipulation de l'imprimante

Instalando a impressora......................................................................................................página 1

Conectando a um computador, smartphone ou tablet.................................página 4

Vídeos instrucionais

Segurando a impressora

Instalación de la impresora ...............................................................................................página 1

Conexión con un ordenador, teléfono inteligente o tableta.......................página 4

Vídeos instructivos

Cómo sujetar la impresora

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet ...............................................page 4

Holding the Printer

Instructional Videos

ENGLISH

Setting Up the Printer Online Setup

1. Box Contents

•

Print head •

Ink bottle

•

Power cord

•

Setup CD-ROM

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the top cover, remove and dispose of the

orange tape and protective material inside.

3. Installing the Print Heads

1 Open the print head locking cover on the right.

2 Take out the print head from the package and

remove the label.

3 Remove the protective tape.

4 Insert the print head into the print head holder.

5 Close the print head locking cover and press

down until it clicks.

6 Press down the joint button completely until it

clicks.

Check!

Setting Up the Printer

4. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are ﬁlled with ink. If ink gets on your clothes

or belongings, it may not come oﬀ.

1 Open the ink tank cover and the tank cap.

2 Hold the ink bottle upright and gently twist the

bottle cap to remove.

3 Align the nozzle of the ink bottle with the inlet.

4 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

5 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

6 Replace the tank cap securely, and then close

the ink tank cover.

7 Close the top cover.

5. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

ENGLISH

2 Press the ON button.

• The ON lamp lights.

Lit

Important

If the Alarm lamp ﬂashes or lights, see "If the Alarm lamp

ﬂashes or lights" on page 3 and follow the instructions.

Flashing

6. Loading Paper

1 Remove the cassette from the printer.

2 Slide apart the paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the Letter or A4 mark.

3 Load paper.

• Load 2 or more sheets of Letter or A4 sized plain

paper with the print side facing down.

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

4 Replace the cassette.

5 Pull out the paper output tray.

Count the number of ﬂashes.

• 4 times

The print head is not installed correctly.

"3. Installing the Print Heads" on page 1

• 5 times

The print head is not installed.

"3. Installing the Print Heads" on page 1

• 9 times

Some protective material was not removed.

"2. Removing Packing Materials" on page 1

• Lit

There may be insuﬃcient black ink.

"4. Pouring Ink" on page 2

For all other cases, refer to the Online Manual.

If the Alarm lamp ﬂashes or lights

7-b

page 6

7-a

Setting Up the Printer

Computer Computer and

smartphone

Smartphone

No device

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer. There are

two methods, " Online Setup" and " Using the Setup CD-ROM (Windows Only)

Provided".

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and click

Go.

4 Click Start.

5 Click If you have already prepared your

printer, go to Connect.

Note

The following steps are for Windows (except Windows

10 in S mode). For other operating systems, continue

setup by following the on-screen instructions instead.

6 Click Download.

• The setup ﬁle is downloaded to your

computer.

7 Run the downloaded ﬁle.

8 Proceed to step 9 on page 5.

Online Setup

What device are you connecting?

Select a device and follow the instructions in the relevant section.

Oﬀ

Turn Online lamp oﬀ, if lit or

ﬂashing.

ENGLISH

1 Insert the Setup CD-ROM

into your computer.

2 Follow the instructions for your version of

Windows.

Windows 10/Windows 8.1

aClick on the following message when it

appears on the right-hand side of your

computer screen.

Note

If the message does not appear (or is no longer

visible), click the File Explorer icon in the

taskbar. On the left-hand side of the window, click

This PC. Double click the CD icon that is

displayed on the right-hand side. When the

content of the CD is displayed, double click

Msetup4.exe. Proceed to c.

bClick Run

Msetup4.exe.

cIf the User Account Control dialog box

appears, click Yes.

Windows 7

aClick Run Msetup4.exe.

• When the AutoPlay screen appears, click

Run Msetup4.exe.

Note

If the AutoPlay screen does not appear, in the

Start menu, click Computer. On the right-hand

side of the window, double click the CD icon.

When the content of the CD is displayed, double

click Msetup4.exe.

bIf the User Account Control dialog box

appears, click Continue.

3 Proceed to step 9 below.

Using the Setup CD-ROM (Windows Only) Provided

9 Click Start Setup.

10 Follow the on-screen instructions.

• These operations may take some time.

11 When the following screen appears, click

Exit.

Your printer is now connected to your computer.

To connect to a smartphone as well, see "7-b.

Connecting to a Smartphone" on page 6.

7-b

Setting Up the Printer

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Scan the QR code shown on the right to access the Canon website, and then download

the app.

2 Check the state of the printer's lamps and proceed as instructed.

If the Online lamp, and the Wi-Fi lamp or

Wired LAN lamp are on

LitLit

If the Online lamp is

ﬂashing

Flashing

If the Online lamp is oﬀ

Oﬀ

Note

If the Online lamp is on, and the Wi-Fi lamp is oﬀ, the printer cannot communicate by Wi-Fi connection. For details, refer to

"Frequently Asked Questions" at "https://ij.start.canon".

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone.

bConnect your smartphone to the wireless router (if you have a wireless router).

Refer to your smartphone and wireless router manuals for more details.

3 Open the installed app. 4 Follow the on-screen instructions to add

your printer.

Once you have added your printer, you can print

from the smartphone.

ENGLISH

3 Tap Settings on your smartphone's home

screen, and tap Canon_ij_XXXX in the

Wi-Fi settings.

Note

If Canon_ij_XXXX does not appear, follow the

procedure in , and then search for Canon_ij_XXXX

again.

4 Open the installed app, and then

follow the on-screen instructions

to add your printer.

• The printer is added with the most

appropriate connection method for

the environment you are using.

3 Open the installed app, and then

follow the on-screen instructions

to add your printer.

• The printer is added with the most

appropriate connection method for

the environment you are using.

Note

If a message saying "No printer has been added.

Perform printer setup?" does not appear after

starting the application, follow the procedure in ,

and then return to smartphone operations.

Procedures vary for iOS and Android. Follow the instructions for your operating system.

3 Press and hold the Wireless connect

button for about 3 seconds.

• The Online lamp will start ﬂashing.

Flashing

4 Proceed to .

Once you have added your printer, you can print from the smartphone.

Loading Paper into the Rear Tray

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of paper with the print side

facing up and slide the side paper guide against

the edge of the paper stack.

4 Close the feed slot cover.

Transporting Your Printer

When relocating the printer, make sure of the following. Refer to the Online Manual for details.

Check that the joint button is pressed down completely to

avoid ink leaks.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using suﬃcient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains ﬂat

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

Autres manuels pour GM2000 Series

Table des matières

Langues :

Autres manuels Canon Imprimante

Canon

Canon imagePRESS C850 Manuel utilisateur

Canon

Canon TS8200 Series Guide de configuration

Canon

Canon imageCLASS LBP161dn+ Manuel utilisateur

Canon

Canon Color imageCLASS X MF1538C Manuel utilisateur

Canon

Canon E200 Series Guide de configuration

Canon

Canon SELPHY SQUARE QX10 Manuel utilisateur

Canon

Canon PIXUS IP3100 Mode d’emploi

Canon

Canon MAXIFY MB2320 Mode d’emploi

Canon

Canon TS700 Series Manuel utilisateur

Canon

Canon imageRUNNER 1750i Manuel utilisateur

Canon

Canon imagePROGRAF iPF8300S Guide de l'utilisateur

Canon

Canon Pixma MG3550 Guide de configuration

Canon

Canon imageRUNNER 1643iF Manuel utilisateur

Canon

Canon imageCLASS MF543dw Manuel utilisateur

Canon

Canon imagePASS-G1 Manuel d'utilisation et d'entretien

Canon

Canon imagePROGRAF GP-4600S Manuel utilisateur

Canon

Canon 8996A001 - i 455 Color Inkjet Printer Guide de configuration

Canon

Canon CX-G6400 Manuel utilisateur

Canon

Canon Pixma PRO-100S series Guide de configuration

Canon

Canon iP6700D - PIXMA Color Inkjet Printer Guide de configuration

Canon

Canon imagePROGRAF iPF6450 Manuel utilisateur

Canon

Canon PIXMA iP7260 Series Manuel utilisateur

Canon

Canon PIXMA MP130 Manuel

Canon

Canon TS9150 Guide de configuration

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
