S500™

Color Bubble Jet™Printer

Quick Start Guide

S500_Front Matter.QXD 5/12/01 1:49 PM Page 1

Canon S500 Color Bubble Jet Printer Quick Start Guide.

CCooppyyrriigghhtt

manual may not be reproduced in any form, in whole or in part, without the prior written consent of Canon

U.S.A. Inc.

DDiissccllaaiimmeerr

Canon U.S.A. Inc. has reviewed this manual thoroughly in order that it will be an easy to use guide to your

Canon S500 Color Bubble Jet Printer. All statements, technical information and recommendations in this

manual and in any guides or related documents are believed reliable, but the accuracy and completeness

thereof are not guaranteed or warranted, and they are not intended to be, nor should they be understood to

be, representation or warranties concerning the products described.

Specifications are subject to change without notice.

All print speeds based on draft mode. Print speed will vary depending on system configuration, software,

document complexity, print mode and page coverage.

As an Energy Star partner, Canon U.S.A. Inc., has determined that this product meets the

Energy Star guidelines for energy efficiency.

All information regarding non-Canon products was compiled from publicly available information. No

representation is made regarding the accuracy thereof.

TTrraaddeemmaarrkkss

Canon and BJ are registered trademarks and Bubble Jet and S500 are trademarks of Canon Inc.

Canon U.S.A. Inc.

Digital Home and Personal Systems Division

2995 Redhill Avenue

Costa Mesa, CA 92626

PRINTED IN THAILAND

Part number 6861A002AA

S500_Front Matter.QXD 5/12/01 1:49 PM Page 2

CCoonntteennttss

Chapter 1: Basic Printing

Turning Your Printer On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

What Is a Printer Driver? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Selecting the S500 Printer for Use . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Recommended Paper Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Loading Paper and Other Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Cancelling a Print Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 2: Advanced Print Features

Improving Printed Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Adjusting Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Adjusting Color Balance, Intensity and Brightness . . . . . . . . . . . . . 12

Changing the Page Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Saving and Recalling Driver Settings . . . . . . . . . . . . . . . . . . . . . . . . 17

Chapter 3: Printing Maintenance

Monitoring Ink Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Replacing Ink Tanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Printing a Nozzle Check Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Cleaning the Printhead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Aligning the Printhead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Chapter 4: Troubleshooting

Tips for Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Customer Care Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Chapter 5: The BJ Solution Software–Downloading Images

Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Installing the BJ Solution Software . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Accessing the Online Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Windows Users: Using Your Software . . . . . . . . . . . . . . . . . . . . . . . . .36

Windows Users: Uninstalling the Software . . . . . . . . . . . . . . . . . . . .38

Macintosh Users: Using Your Software . . . . . . . . . . . . . . . . . . . . . . . .38

Macintosh Users: Uninstalling the Software . . . . . . . . . . . . . . . . . . .40

iii

S500_TOC.QXD 5/12/01 1:51 PM Page iii

Appendix

Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Uninstalling the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Registering Your Canon Product . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Limited Warranty—U.S. Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Contents

S500_TOC.QXD 5/12/01 1:51 PM Page iv

CChhaapptteerr11::BBaassiiccPPrriinnttiinngg

Congratulations on purchasing your new Canon®S500 Color Bubble Jet™

Printer!

With this printer, you can print basic business documents in color or black and

white, as well as print on a variety of specialty media, such as Canon High

Resolution Paper (ideal for business documents such as presentations that

include large numbers of color illustrations), Canon Glossy Photo Paper or

Canon Photo Paper Pro (for digital photographs) and Canon Transparencies (for

presentations). For a full list of the Canon specialty media that can be used with

your S500 printer, see “Specialty Media” on page 3.

This quick start guide describes some of the features of your S500

printer and how to use them. For more information, view and/or

print the S500 User’s Guide on the Setup Software & User’s Guide

CD-ROM.

Driver features and screen shots described in this guide reflect

Windows®98 and may be different for Windows NT®4.0 and

Windows 2000 users.

TTuurrnniinnggYYoouurrPPrriinntteerrOOnnaannddOOffff

To turn your printer on or off, press the

POWER button.

The POWER lamp will flash green when

warming up or when a print job is

being sent to the printer. It will glow a

steady (non-flashing) green when the

printer is ready for use or when the

print job is complete.

If the POWER lamp

flashes orange, see

“Handling Error

Messages” beginning

on page 30.

S500_Chapter1.QXD 5/12/01 1:55 PM Page 1

Basic Printing

WWhhaattIIssaaPPrriinntteerrDDrriivveerr??

Most computers require special software to link the software applications you

use to create documents or images with your printer. This software, called a

printer driver, converts information from the application into a format that the

printer can understand. The Canon S500 printer driver also provides other

features such as monitoring the printer’s paper supply and ink levels.

SSeelleeccttiinnggtthheeSS550000PPrriinntteerrffoorrUUssee

If the S500 is the only printer connected to your computer, it will automatically

be set as the default (main) printer. However, if your computer has access to

multiple printers, you can set the S500 as the default printer.

TToosseetttthheeSS550000aasstthheeddeeffaauullttpprriinntteerriinnWWiinnddoowwss®::

1. Click SSttaarrtt, then SSeettttiinnggss, then PPrriinntteerrss.

2. Right-click the Canon S500 printer icon, then click SSeettaassDDeeffaauulltt. The Canon

S500 printer icon will display a check mark indicating it is the default

printer.

TToosseelleecctttthheeSS550000ffrroommwwiitthhiinnaaWWiinnddoowwssaapppplliiccaattiioonn::

Even if another printer is set as the default printer, you can still select the Canon

S500 for a specific print job from within most Windows applications.

Menus vary between applications. Consult your application user

documentation if the Print option is not listed.

1. From the FFiilleemenu, click PPrriinntt.

2. Select CCaannoonnSS550000from the Name drop-down list, then click OOKK.

TToosseelleecctttthheeSS550000iinnMMaacc®OOSS::

1. Click AAppppllee, then CChhoooosseerr.

2. Click the SS550000printer icon. The S500 will remain the default printer until

another is selected.

S500_Chapter1.QXD 5/12/01 1:55 PM Page 2

RReeccoommmmeennddeeddPPaappeerrUUssee

There are two steps recommended for getting the best output for your printed

documents:

• Set the printer thickness lever for the media used. (See “Load Limit and

Paper Thickness Lever Position” on page 4.)

• Select the correct media setting in the printer driver. (See “Chapter 2:

Advanced Print Features” on page 9.)

GGeenneerraallBBuussiinneessssPPrriinnttiinngg

For everyday paper printing, use plain paper (17 to 28 lb.). Use standard #10

envelopes with your S500 printer.

SSppeecciiaallttyyMMeeddiiaa

For optimum results, Canon recommends that you use genuine Canon media

with your S500 printer. Follow the instructions that come with any specialty

media on storing, handling and printing.

The specialty media available for use with the S500 include:

• Canon High Resolution Paper

• Canon Transparencies

• Canon Banner Paper

• Canon Glossy Photo Paper

• Canon Photo Paper Pro

• Canon Glossy Photo Cards

• Canon High Gloss Photo Film

• Canon T-Shirt Transfers

For instructions on loading and handling specialty media, see the

instructions that come with that media type or see the S500

User’s Guide on the Setup Software & User’s Guide CD-ROM.

Handle media carefully by its edges. Dirt or fingerprints on the

print surface will adversely affect print quality.

Basic Printing

S500_Chapter1.QXD 5/12/01 1:55 PM Page 3

MMeeddiiaattooAAvvooiidd

Do not use the following types of media with your S500 as they could produce

poor quality print images, or jam or damage the printer:

• Paper that is folded, excessively curled, wrinkled or wrapped

• Damp paper

• Excessively thin or thick paper

• Paper with pasted photos, stickers, etc.

• Envelopes with overlapping flaps or self-sealing flaps

• Tractor feed paper, perforated paper or 3-hole punched paper, or paper with

any type of attached fasteners, ribbons, etc.

LLooaaddiinnggPPaappeerraannddOOtthheerrMMeeddiiaa

LLooaaddLLiimmiittaannddPPaappeerrTThhiicckknneessssLLeevveerrPPoossiittiioonn

Basic Printing

PPaappeerrTThhiicckknneessss

LLeevveerrPPoossiittiioonn

up to to 100 sheets (17 lbs.)

High Resolution Paper

Photo Paper Pro

Photo Paper Pro (4 x 6)

High Gloss Photo Film

Glossy Photo Paper

Glossy Photo Cards

Transparencies

#10 envelopes

Banner paper

T-Shirt Transfers

MMeeddiiaaTTyyppeePPaappeerrRReessttLLooaaddLLiimmiitt

Plain paper Left

up to 10 sheets Left

up to 80 sheets Left

Left

up to 20 sheets Left

1 sheet

1 sheet Left

up to 20 sheets Left

up to 30 sheets

up to 10 envelopes

1 sheet (print up to 6 connected sheets)

1 sheet

Left

Right

S500_Chapter1.QXD 5/12/01 1:55 PM Page 4
