Chapter 1
Preface
Notes for the reader
Introduction
This manual helps you to use the Two-Knife Booklet Trimmer-A1. The manual contains
a description of the product and guidelines to use and operate the Two-Knife Booklet
Trimmer-A1.
Definition
Attention-Getters
Parts of this manual require your special attention. These parts can provide the following:
•Additional general information, for example, information that is useful when you
perform a task.
•Information to prevent personal injuries or property damage.
Warning, Caution and Note
The words Warning, Caution and Note draw your attention to important information.
Overview of the attention-getters#
IndicatesIconWord
Ignoring this warning could cause serious injury or
even death.
The Warning indication has several icons that warn
against various hazards. The icons are shown below.
Warning
General hazardWarning
Hot surfaceWarning
Electric shockWarning
Moving partsWarning
Chapter 1 - Preface6
Notes for the reader
IndicatesIconWord
Laser beamWarning
Ignoring this warning could cause injury or damage to
property.
Caution
Indicates additional important information.Note
The use of heat-resistant gloves is mandatory when you
carry out these actions.
Important safety instructions
Warning:
Do not remove the safety covers or deactivate the sensor switches for the safety covers.
Otherwise, the machine may start suddenly without warning, leading to severe injury.
Warning:
When removing jammed booklets from the infeed section, do not put your hands and
fingers close to the belt. Otherwise, if the belt moves suddenly without warning, your
hands and fingers may be caught.
Warning:
This machine weighs 145 kg (319 lb). When you operate the machine, consider the ma-
chine weight and use the machine safely.
Chapter 1 - Preface 7
Notes for the reader
Naming conventions for finishers (commercial naming and
naming in User Interfaces)
Hardware and hardware naming in User Interfaces
To improve the readability of texts in User Interfaces of operator panels and software,
the finishers are generally referred to by their function. The table below shows the naming
conventions for finishers (commercial product names and the way these are referred to
in User Interfaces).
Note:
In some cases, there is only 1 name for several modules. The reason is that a configuration
can only contain 1 of the available types of modules.
Conversion table for commercial names versus user-friendly names in User Interfaces#
In UI, printer driver and software re-
ferred to as:
Commercial product name:
'Stacker/stapler'Finisher-AF1
'Stacker/stapler'Saddle Finisher-AF2
'Puncher'Puncher Unit-BP1/BQ1/BR1
'Folder'Paper Folding Unit-F1
'Inserter'Document Insertion Unit-F1
'Stacker'High-Capacity Stacker-E1
'Trimmer'Booklet Trimmer-D1
'Trimmer'Two-Knife Trimmer-A1
'Perfect Binder'Perfect Binder-C1
'Scanner'Duplex Color Image Reader Unit-D1
Chapter 1 - Preface8
Naming conventions for finishers (commercial naming and naming in User Interfaces)
Chapter 2
Parts and their functions
