Canon BS1 Manuel utilisateur

4321

Puncher Unit-BS1

Service Manual

August 22, 2012

Revision 0

Product Outline

Technology

Parts Replacing and Cleaning

Installation

Application

This manual has been issued by Canon Inc. for qualied persons to learn technical theory,

installation, maintenance, and repair of products. This manual covers all localities where the

products are sold. For this reason, there may be information in this manual that does not

apply to your locality.

Corrections

This manual may contain technical inaccuracies or typographical errors due to improvements

or changes in products. When changes occur in applicable products or in the contents of this

manual, Canon will release technical information as the need arises. In the event of major

changes in the contents of this manual over a long or short period, Canon will issue a new

edition of this manual.

The following paragraph does not apply to any countries where such provisions are

inconsistent with local law.

Trademarks

The product names and company names used in this manual are the registered trademarks

of the individual companies.

not be copied, reproduced or translated into another language, in whole or in part, without the

consent of Canon Inc.

Caution

Use of this manual should be strictly supervised to avoid disclosure of condential

information.

Explanation of Symbols

The following symbols are used throughout this Service Manual.

Symbols Explanation Symbols Explanation

Check. Remove the claw.

Check visually. Insert the claw.

Check the noise. Use the bundled part.

Disconnect the connector. Push the part.

Connect the connector. Plug the power cable.

Remove the cable/wire

from the cable guide or wire

saddle.

Turn on the power.

Set the cable/wire to the

cable guide or wire saddle.

Remove the screw.

Tighten the screw.

The following rules apply throughout this Service Manual:

1. Each chapter contains sections explaining the purpose of specic functions and the

relationship between electrical and mechanical systems with reference to the timing of

operation.

In the diagrams, represents the path of mechanical drive; where a signal

name accompanies the symbol, the arrow indicates the direction of the

electric signal.

The expression "turn on the power" means ipping on the power switch, closing the

front door, and closing the delivery unit door, which results in supplying the machine with

power.

2. In the digital circuits, '1' is used to indicate that the voltage level of a given signal is

"High", while '0' is used to indicate "Low". (The voltage value, however, differs from

circuit to circuit.) In addition, the asterisk (*) as in "DRMD*" indicates that the DRMD

signal goes on when '0'.

In practically all cases, the internal mechanisms of a microprocessor cannot be checked

in the eld. Therefore, the operations of the microprocessors used in the machines

are not discussed: they are explained in terms of from sensors to the input of the DC

controller PCB and from the output of the DC controller PCB to the loads.

The descriptions in this Service Manual are subject to change without notice for product

improvement or other purposes, and major changes will be communicated in the form of

Service Information bulletins.

All service persons are expected to have a good understanding of the contents of this Service

Manual and all relevant Service Information bulletins and be able to identify and isolate faults

in the machine.

0 Safety Precautions

Notes Before Servicing ------------------------------------------------------0-2

Points to Note at Cleaning --------------------------------------------------0-2

1 Product Outline

Specications ------------------------------------------------------------------1-2

Hole Locations ------------------------------------------------------------------------------- 1-2

Names of Parts ----------------------------------------------------------------1-3

Cross Section ----------------------------------------------------------------------- 1-3

2 Technology

Feed Drive System -----------------------------------------------------------2-2

Overview ----------------------------------------------------------------------------- 2-2

Moving the Paper ------------------------------------------------------------------ 2-3

Checking the Condition of the Punch Chip Case -------------------------- 2-4

3 Parts Replacing and Cleaning

Removing from the Host Machine ----------------------------------------3-2

Removing Punch Unit ------------------------------------------------------------- 3-2

Drive System -------------------------------------------------------------------3-4

Remove the punch unit ----------------------------------------------------------- 3-4

Preparations --------------------------------------------------------------------------------- 3-4

Procedure ------------------------------------------------------------------------------------- 3-4

4 Installation

How to check this Installation Procedure -------------------------------4-2

When Using the Parts included in the package ---------------------------- 4-2

Symbols in the Illustration ------------------------------------------------------- 4-2

Points to Note at Installation -----------------------------------------------4-2

Checking the Contents ------------------------------------------------------4-3

Check Items when Turning OFF the Main Power ---------------------4-3

Contents

Installation Procedure --------------------------------------------------------4-4

Adjustments --------------------------------------------------------------------4-9

Punching Operation Settings --------------------------------------------------- 4-9

Adjustment of Paper Stop Positiom. -----------------------------------------4-10

Afxing the Labels ---------------------------------------------------------- 4-11

■Notes Before Servicing

■Points to Note at Cleaning

Safety Precautions

0Safety Precautions

Safety Precautions

0-2

Safety Precautions > Points to Note at Cleaning

Notes Before Servicing

Caution:

At servicing, be sure to turn off the power source according to the specied steps and

disconnect the power plug.

Caution:

Do not turn off the power switch when downloading is under way.

Turning off the main power switch while downloading is under way can disable the

machine.

Points to Note at Cleaning

Caution:

When performing cleaning using organic solvent such as alcohol, be sure to check that

the component of solvent is vaporized completely before assembling.

1Product Outline

Product Outline

■Specications

■Names of Parts

1-2

Product Outline > Specications

Specications

Item Description Remarks

Punching

method

spin punch

Paper size 2/4 hole(Puncher Unit-BT1)

A3,B4,A4,A4R,B5,B5

indeterminate form

2 hole) 182 to 432 x 182 to 297

4 hole) 182 to 432 x 257 to 297

For FRA, "A" series paper size

only

2/3 hole(Puncher Unit-BS1)

LDR,LTR, LGL,LTRR,EXE

indeterminate form

2 hole) 182 to 432 x 182 to 297

3 hole) 182 to 432 x 240 to 297

4 hole(Puncher Unit-BU1)

A3,A4

indeterminate form

182 to 432 x 257 to 297

Paper weight 52g/m2 to 300g/m2Transparency and tracing paper

cannot be used.

* In the case of coated paper, 80

to 209 g/m2

Punch hole

diameter

2hole: 6.5 mm

2/3hole: 8 mm

4hole: 6.5 mm

Punch chip

case

equivalent of 6,000 sheets equivalent of 80 g/m2 paper

Dimensions 78mm x 655mm x 131xmm (WxDxH)

Weight 3 kg (approx.)

Power supply 24/5 VDC from nisher

T-1-1

■Hole Locations

[3] Puncher Unit-BT1 (2/4穴(FR))

80±1mm

12±1mm

A4 / A3 : 108.5±1mm

B4 / B5 : 88.5±1mm

A4R : 65±1mm

B5R : 51±1mm

[2] Puncher Unit-BS1 (2/3穴)

69.85±1mm

12±1mm

LGL / LTRR : 73±1mm

108±1mm 108±1mm

12±1mm

LTR / 11”x17” : 31.5±1mm

[1] Puncher Unit-BU1 (4穴)

70±1mm21±1mm 21±1mm

12±1mm

A4 / A3 : 92.5±1mm

80±1mm80±1mm 80±1mm

12±1mm

A4 / A3 : 28.5±1mm

F-1-1

1-3

Product Outline > Names of Parts > Cross Section

Names of Parts

Cross Section

[1]

[2]

[3]

[4]

[5]

[1] Punch Motor

[2] Punch chip case full sensor

[3] Punch chip case

[4] Stopper

[5] Pin

F-1-2
