Canon Ivy REC Manuel utilisateur

USER MANUAL

CONTENT

SAFETY INFORMATION

Read Before Use

Maintaining The Device

Waterproof Cautions

OVERVIEW

Supplied Items

Product Features

GETTING STARTED

Charging

Inserting/Removing MicroSD Card

Power ON/OFF

First Time Pairing With Your Smartphone

Camera Default Settings

OPERATIONS

Wireless Mode

Photo Mode

Video Mode

Multi Mode

LED INDICATIONS

ACCESSORY

TROUBLESHOOTING

SPECIFICATIONS

P3-4

P6-9

P10-11

P12

P13

P14

P15

READ BEFORE USE

SAFETY INFORMATION

WARNING Used to indicate a potentially hazardous situation which,

if not avoided, could result in death or serious injury.

• Keep away from children and infants. Improper use of this product may cause suocation

or accident.

• Stop using the device immediately if it emits smoke or a strange smell, or otherwise

behaves abnormally.

• A strap wound around a child’s neck may result in asphyxiation. If your product uses a

power cord, mistakenly winding the cord around a child’s neck may result in asphyxiation.

• Turn the device o in places where camera use is prohibited. The electromagnetic waves

emitted by the camera may interfere with the operation of electronic instruments and

other devices. Exercise adequate caution when using the product in places where use of

electronic devices is restricted, such as inside airplanes and medical facilities.

• This product is embedded with magnets. Please be careful if implant electronic devices

(such as cardiac pacemaker) nearby, as magnets may cause malfunctions. If this happens,

please distance the magnet from the implant electronic device and consult the doctor at

once.

Please read the following instructions and safety precautions before using the device.

For regulatory and additional safety information, refer to the Regulation and Warranty

Information sheet included in your package contents.

RMN: PG1001

Regulatory Model Identication Number is assigned for regulatory identication purpose.

CAUTION

Used to indicate the level of a hazard or damage which,

if product is handled erroneously, may result in injury or

property damage other than product faults.

• Electromagnetic interference or electrostatic discharge may cause the device to

malfunction or the MicroSD card memory to be lost or altered. Should this occur, use a

pin with blunt end to press the [RESET] button at the backside of the device for more

than 10 seconds. See Diagram A on page 6 for exact location of reset button.

• Never expose the battery to high temperatures, direct heat, or dispose by incineration.

Do not dry the device with an external heat source such as microwave oven or hair dryer.

This could cause overheating, explosion of battery, re, burns or other injuries.

• The device has a clip for easy carrying. Do not use the clip for any other purpose. Do not

use for climbing.

• Be careful not to pinch your ngers when using the clip and do not to bend the hook, this

may cause injury.

• Do not attempt in disassemble the device to avoid electric shock and injury.

• Dispose the product in accordance with local regulations.

• Please charge the device at the recommended temperature of 59º to 90ºF (15º to 32ºC).

• Use and keep the device in the recommended environment of 59º to 90º F (15º to 32ºC).

Avoid using or storing the device in humid or dusty place.

• After the device is exposed to dirty water, rinse it with fresh water and dry it completely

with a soft cloth.

• The device has a shockproof to 2M (6.6 ft.). However, strong impacts could scratch the

device and cause it to malfunction. Be careful to avoid expose it to excessive shocks.

• Avoid sitting down with device in your pants pocket. This may damage your device and

cause it to malfunction.

• IP68 water resistance test is performed under IEC standard using freshwater.

• Use with a water depth up to 2M (6.6 ft.) with the Side Cover closed tightly for up

to 30 minutes. (See NOTE and Diagram B on pages 7 and 9 for Side Cover closing

instructions).

• Do not open the side cover of device under water, this may cause the device to

malfunction.

• Rinse the device with clean water and dry it with a soft cloth completely after using the

device in salt water or chlorinated water, otherwise it may cause corrosion, discoloration

or deterioration of material or aect waterproof performance.

• Do not expose to chemicals, soap, detergents, alcohol, or other non-freshwater

liquids. If exposed to non-freshwater liquids, rinsing immediately with freshwater is

recommended.

• Keep away from sun oil or sun screen. Doing so may cause discoloration or deterioration

of material.

• The waterproof performance is not guaranteed if the camera is subjected to strong

impacts or excessive shocks.

MAINTAINING THE DEVICE

WATERPROOF CAUTIONS

SUPPLIED ITEMS

PRODUCT FEATURES

OVERVIEW

Camera Tips Regulation and

Warranty Information

Sheet

USB Cable

Camera Lens Mode LED

Detachable Faceplate Status LED

Side Cover MicroSD Card Slot (up to 256GB)

Latch Release Button Micro USB Port

Wristband Eyelet Shutter Button

Tripod Screw Hole Microphone

Clip *To reset all parameters into default setting, turn on the

device, then use a pin with blunt end to press the reset

button, and press shutter button at the same time. The

device will restart automatically.

*If your device is unresponsive, hold the reset button

for more than 10 seconds by a pin with a blunt end. The

device will force to power o. Switch the mode dial or

press the shutter button to restart.

Speaker

Reset Button

ON/OFF/Mode Dial Switch

DIAGRAM A

CHARGING

GETTING STARTED

MODE LED

Charging: Red

Fully Charged: Green

Once fully charged, the Mode LED will turn green.

- Operating time may vary depending on the battery status, operational status and

environment conditions.

The Mode LED will turn red to indicate charging.

Insert the smaller end of the supplied USB cable into the device and other end into a

chargeable USB adapter.

Press on the latch release button, and slide the Side Cover upward to open it.

ABOUT USB CABLE

HANDLE THE USB CABLE WITH CARE WHILE CHARGING

• Do not place any heavy objects on top of the cable.

• Do not place the USB cable near heat.

• Do not scratch, damage, twist or pull hard on the cable.

• Do not plug or unplug the cable with wet hands.

• Do not attempt to charge a wet device.

• Avoid too high/too low temperature or humid conditions.

• Please unplug the USB cable from power source after charging.

• Please use the supplied USB cable for charging.

NOTE

• Do not open the cover when the camera is wet or submerged in

water. If there is moisture on the camera, wipe it o with a soft,

dry cloth until it is completely dry.

• Be sure that the waterproof seals and the areas around them

are kept free from scratchesand foreign objects such as sand,

dirt, or hair. These may prevent a tight seal and cause leakage inside.

• When you close the cover, make sure the Side Cover returns

to the position shown in Diagram B.

DIAGRAM B

INSERTING/ REMOVING MicroSD CARD

INSERT AND REMOVE THE MicroSD CARD

• Press on the latch release button and slide the Side Cover upward to open it.

• Insert the MicroSD card into the MicroSD card slot inside the Side Cover. When the card

is fully inserted, you will hear a slight click and the card will not extend above the slot.

• Push on the top of the MicroSD card to release it. Gently pull it out to fully remove it

from the device.

• If there is an error reading /writing to the MicroSD card. Remove the MicroSD card and

restart the device.

• Connect the device to a computer by the USB cable provided. Double-click the external

drive image when it appears on the computer to view and save the photos.

NOTE

• The detachable faceplate can act as tool for inserting or removing the MicroSD Card.

By using a corner of faceplate to press down the MicroSD Card into the slot, or press

to release the MicroSD Card from the slot.

NOTE

• Remember to close the side cover rmly after charging/inserting or removing MicroSD

card. Water, dust and other particles entering inside the device could damage and cause

it to malfunction.

• Do not open the cover when the camera is wet or submerged in water. If there is

moisture on the camera, wipe it o with a soft, dry cloth until it is completely dry.

• Be sure that the waterproof seals and the areas around them are kept free from

scratches and foreign objects such as sand, dirt, or hair. These may prevent a tight seal

and cause leakage inside.

• When you close the cover, make sure the Side Cover

returns to the position shown in Diagram B.

An external MicroSD card (up to 256 GB) is needed for saving captured photos

and videos.

Only FAT16, FAT32 and exFAT formats are supported. Class 10 or above is

recommended for a satisfying user experience.

Use the following memory cards (sold separately)

• MicroSD memory cards *1

• MicroSDHC memory cards *1 *2

• MicroSDXC memory cards *1 *2

*1 Cards conforming to SD standards. However, not all memory cards have been veried to

work with the camera.

*2 UHS-I memory cards are also supported.

DIAGRAM B

FIRST TIME PAIRING WITH YOUR COMPATIBLE SMARTPHONE

NOTE

• Bluetooth® and Wi-Fi® are required. Wi-Fi connection performance may be aected by

operation environment and the distance between the camera and smartphone.

• Device will exit pairing mode if no new pairing request from compatible smartphone for

3 minutes.

• Pairing Mode will be terminated if switch to other operation modes during device

pairing.

• Keep your device rmware up-to-date. To check if your rmware needs to be upgraded,

- open the Canon Mini Cam app, go to the Main Menu > Settings > Device info, then tap

"Firmware Upgrade".

- Make sure your mobile device has an internet connection before checking. If you need to

upgrade the rmware, your camera must be charged to 50% or higher.

• Make sure you are using the latest version Canon Mini Cam app. If your app does not

automatically update, go to app store and check if you need to update.

POWER ON/OFF

AUTO POWER OFF

The device will power o automatically when idle for 3 minutes (by default).

• User can restart the device by pressing the Shutter Button or turning the Mode Dial to

any mode.

• User can change the time for Auto Power O (3 minutes / 5 minutes / 10 minutes) using

the Canon Mini Cam App.

• Turn the mode dial from OFF to any other modes, the device will turn on in around 4

seconds.

• Turn the mode dial to OFF to turn o the device.

The Status LED light will turn to Green color after the pairing is successfully done.

Follow the onscreen instructions for pairing.

Tap on the “Add Device” under the main menu of the Canon Mini Cam App.

Turn the mode dial to wireless mode.
