Canon PIXMA TS6240 Manuel utilisateur





Посібник для початку

роботи

Спершу прочитайте документ Інформація щодо

безпеки й важливі відомості (додаток).

Руководство по началу

работы

В первую очередь прочтите документ Информация

о безопасности и важные сведения (приложение).

Démarrage

Commencez par lire Sécurité et informations

importantes (addendum).

Getting Started

Read Safety and Important Information

(addendum) rst.





4  ......................................................................

1 .....................................................................................................................................

Установлення принтера........................................................................................................стор. 1

Підключення до комп’ютера та смартфона або планшета...........................стор. 4

Відеоінструкції

Як тримати принтер

Установка принтера....................................................................................................................стр. 1

Подключение к компьютеру и смартфону или планшету...............................стр. 4

Видеоинструкции

Как держать принтер

Installation de l'imprimante..................................................................................................page 1

Connexion avec un ordinateur et un smartphone ou une tablette............page 4

Instructions vidéo

Manipulation de l'imprimante

Installing the Printer...................................................................................................................page 1

Connecting with Computer and Smartphone/Tablet .........................................page 4

How to Hold Printer

Instructional Videos

ENGLISH

1. Box Contents

•

Power cord •

Ink tanks for setup

•

Safety and Important Information

•

Getting Started (this manual)

•

Setup CD-ROM

2. Removing Packing Materials

1 Remove and dispose of the packing materials

from the device.

• Operating the printer while the orange tape and

protective lm are still on it causes malfunctions. Be

sure to remove them.

2 Open the scanning unit / cover and remove the

orange tape.

3 Close the scanning unit / cover.

• Lift up the scanning unit / cover briey, and then

close it.

Caution

Watch your ngers.

3. Turning on the Printer

1 Connect the power cord.

Back

Important

At this time, do not connect any other cables.

2 Open the operation panel and press the ON

button.

3 Scroll and tap to select your language, and then

tap OK.

4. Installing the Ink Tanks

1 Open the scanning unit / cover.

Caution

Do not touch the print head holder until it stops moving.

2 Remove the tape and lm on the ink tanks.

• Check that no tape is left over.

Setting up the printer

Web Setup

Setting up the printer

3 Slowly remove the orange cap.

Important

• Do not push both sides of the ink tank

with the Y-shape air hole blocked.

• Do not touch the red areas shown in the

gure.

4 Install the ink tanks.

• Insert the ink tank into the print head and press it

from above until it clicks.

5 Make sure that the color of the ink tank you

installed appears on the screen.

Important

If the color is not displayed on the screen even though you

have installed the ink tank, the color of the ink tank may be

wrong or you may have installed an ink tank, such as one

with a dierent model number, that is not supported by this

printer. Either install an ink tank for the correct color or use the

provided ink tank for setup.

6 Repeat steps 2 through 5 to install all the ink

tanks.

• Make sure that all the colors appear.

7 Close the scanning unit / cover.

• When you close the scanning unit / cover, the

internal operations start.

Caution

Watch your ngers.

5. Loading Paper / Aligning

Print Head

1 Tap OK.

2 Pull the cassette out of the device.

3 Remove the cassette cover and slide apart the

paper guides.

• Slide the right paper guide to the right edge. Align

the front paper guide with the LTR or A4 mark.

4 Load paper.

• Load plain LTR or A4 size paper with the print side

facing down.

ENGLISH

• Place the paper against the front paper guide, and

align the right paper guide to the width of the paper.

5 Load the cassette.

• Attach the cassette cover and put the cassette back

in.

• Look at it from the side to conrm it looks like the

diagram.

6 Pull out the paper output tray.

7 Tap OK.

• The Print Head Alignment pattern starts printing.

8 Make sure that the pattern is printed.

• Printing nishes in about 2 minutes.

Printed Print Head Alignment pattern

9 Place the pattern on the Platen.

• Open the document cover and place the print side

facing down.

Align the arrow mark

engraved on the device

and the on the

pattern

10 Close the document cover and tap OK.

11 When the following screen appears, tap OK.

12 Tap Next.

• Next, follow the onscreen instructions to continue

operations. During these operations, you will need

to make selections related to sending information.

Read "Sending Information To Canon" in Safety and

Important Information.

13 Tap Next.

6-a

6-b

page 6

Setting up the printer

Press the Stop button,

and then select Do not

connect > Yes, in this

order.

Computer Computer and

smartphone

Smartphone

No device

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer. There are

two methods, " Online Setup" and " Using the Setup CD-ROM (Windows Only)

Provided".

1 Access the Canon website from a

computer.

2 Select Set Up.

3 Enter your printer's model name and

click Go.

4 Click Start.

5 Click If you have already prepared

your printer, go to Connect.

Note

When you are using a computer with Windows

(except for Windows 10 S) or macOS, proceed to

the next step. When you are using a computer with

another OS, continue the setup by following the on-

screen instructions.

6 Click Download.

• The setup le is downloaded to your

computer.

7 Run the downloaded le.

8 Proceed to step 9 on page 5.

Online Setup

What device are you connecting?

Select a device and follow the relevant section.

ENGLISH

1 Insert the Setup CD-ROM

into your computer.

2 Follow the instructions for your version

of Windows.

Windows 10/Windows 8.1

aClick on the following message when it

appears on the right-hand side of your

computer screen.

Note

If the message does not appear (or is no longer

visible), click the File Explorer icon in the

taskbar. On the left-hand side of the window, click

This PC. Double click the CD icon that is

displayed on the right-hand side (when the

content of the CD is displayed, and then double

click Msetup4.exe). Proceed to c.

bClick Run

Msetup4.exe.

cIf the User Account Control dialog box

appears, click Yes.

Windows 7

aClick Run Msetup4.exe.

• When the AutoPlay screen appears, click

Run Msetup4.exe.

Note

If the AutoPlay screen does not appear, in the

Start menu, click Computer. On the right-hand

side of the window, double click the CD icon

(when the content of the CD is displayed, double

click Msetup4.exe).

bIf the User Account Control dialog box

appears, click Continue.

3 Proceed to step 9 below.

Using the Setup CD-ROM (Windows Only) Provided

9 Click Start Setup.

10 Follow the on-screen instructions.

• These operations may take some time.

11 When the following screen appears, click Exit.

Your printer is now connected to your computer.

To connect a smartphone as well, see

"6-b.

Connecting to a Smartphone" on page 6.

6-b

Setting up the printer

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

Note

You can also access the Canon website by scanning the QR code shown on the right to

download the app.

Search for "Canon PRINT" in the App Store.

Search for "Canon PRINT" in Google Play.

2 Check the printer's screen as you proceed through the steps.

• "Ready to connect."

• If appears,

• If does not appear,

Note

• The printer's screen turns o when the printer is idle for 10 minutes. Press one of the buttons on the operation panel (except

for the ON button) to turn on the screen.

• If appears, The printer cannot communicate by Wi-Fi connection. For details, see "Frequently Asked Questions" at

"http://ij.start.canon".

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

Prepare the following before starting.

aEnable the Wi-Fi setting on your smartphone*.

bConnect your smartphone to the wireless router* (if you have a wireless router).

* See your smartphone and wireless router manuals regarding these procedures for more details.

3 Open the installed app.

4 Follow the on-screen instructions to add

your printer.

5 Check that the following screen appears.

Your printer is now connected to your

smartphone. To print photos, see "Loading

Photo Paper" on page 8.

ENGLISH

3 Tap Settings on your smartphone's

home screen, and tap Canon_ij_XXXX

in the Wi-Fi settings.

Note

If Canon_ij_XXXX does not appear, follow the

procedure in , and then search for Canon_ij_

XXXX again.

4 Open the installed app.

• The printer is registered with the

most appropriate connection

method for the environment

you are using.

5 Check that the following screen appears.

3 Open the installed app.

• The printer is registered with the

most appropriate connection

method for the environment

you are using.

Note

If a message saying "No printer has been added.

Perform printer setup?" does not readily appear

after starting the application, follow the procedure in

, and then return to smartphone operations.

4 Check that the following screen appears.

Procedures vary for iOS and Android. Follow the instructions for your operating system.

3 Press the HOME button on the printer.

4 Press and hold the on the HOME

screen for about 3 seconds.

5 When "Follow the instructions on

the computer or smartphone, etc.

to perform the operation." appears,

proceed to .

Your printer is now connected to your smartphone. To print photos, see "Loading Photo Paper" on page 8.

Loading Photo Paper

1 Open the rear tray cover and extend the paper

support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of photo paper with the

print side facing up and slide the side paper

guide against the edge of the paper stack.

4 Close the feed slot cover.

• Follow the on-screen instructions to set information

for the loaded paper.

5 Open the operation panel and pull out the

paper output tray.

1 Turn on the printer.

2 Load several sheets of photo paper.

3 Tap Copy on the HOME screen.

4 Scroll and tap Photo copy.

5 Read the messages and tap OK.

6 Follow the on-screen instructions to load the

printed photo on the Platen, and then tap OK.

7 Specify print settings.

8 Press the Color button to start color copying.

Or, press the Black button to start black & white

copying.

Copying Photos

You can scan a printed photo and print it. You can also scan and print several photos at once.

Photo paper can only be loaded in the rear tray.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Canon Imprimante tout-en-un

Canon

Canon MF7280 - ImageCLASS B/W Laser Manuel utilisateur

Canon

Canon PIXMA TS5150 Guide de configuration

Canon

Canon Laser Class 700 Series Manuel utilisateur

Canon

Canon Color imageCLASS MF8580Cdw Manuel utilisateur

Canon

Canon imageRUNNER 1435iF Manuel utilisateur

Canon

Canon D1300 Series Manuel utilisateur

Canon

Canon MG7700 series Manuel utilisateur

Canon

Canon Saddle Finisher-AE2 Manuel utilisateur

Canon

Canon imageCLASS Series Manuel utilisateur

Canon

Canon PIXMA MP500 Manuel utilisateur

Canon

Canon MP560 - PIXMA Color Inkjet Manuel utilisateur

Canon

Canon LASERBASE MF3110 Manuel utilisateur

Canon

Canon PIXMA MG4220 Manuel utilisateur

Canon

Canon 2711B019AB Instructions de montage

Canon

Canon imageCLASS MF5870dn Manuel utilisateur

Canon

Canon image Runner 2206iF Manuel utilisateur

Canon

Canon LBP 3370 Manuel

Canon

Canon iR1018J Manuel utilisateur

Canon

Canon FAX-L2000 Manuel utilisateur

Canon

Canon PIXMA MX310 series Manuel utilisateur

Canon

Canon Image Runner 2000 Series Manuel utilisateur

Canon

Canon PIXMA MP610 Series Manuel utilisateur

Canon

Canon LiDE220 Guide de configuration

Canon

Canon MP980 series Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
