PIXMA PRO-100

Setup Guide

series

PIXMA PRO-10 series

Setup Guide

This guide provides information for setting up a network connection for the printer.

Network Connection

Wireless Connection

Preparation for Connection

Connection Using WPS

Wired Connection

Preparation for Connection

Cable Connection

Printer Setup

Troubleshooting

Network Connection

Wireless Connection

aPreparation for Connection

Before Starting Wireless Connection Setup

1. Make sure that the printer is turned on.

If the power is on, the POWER lamp (A) will be lit.

Notes on Wireless Connection

Make sure that the computer is connected to the access point (A) (or wireless network router) you want to connect your

printer to.

The conﬁ guration, router functions, setup procedures and security settings of the network device vary depending on your

system environment. For details, refer to the manual of your network device or contact its manufacturer.

Check if your device supports IEEE802.11n, 802.11g or 802.11b.

If your device is set to the "IEEE802.11 n only" mode, WEP or TKIP cannot be used as a security protocol. Change the

security protocol for your device to something other than WEP and TKIP or change the setting to something other than

"IEEE802.11 n only."

For ofﬁ ce use, consult your network administrator.

Take added care when connecting to a network that is not protected with security measures, as there is a risk of disclosing

data such as your personal information to a third party.

This printer cannot be used over wireless and wired connections at the same time.

An "Ad-hoc connection," which establishes a direct connection to the computer over a wireless connection without an

access point, is not supported. Be sure to prepare an access point.

•

bConnection Using WPS

1. Press and hold the Wi-Fi button (A) on the printer when you are ready to press the button on the

access point.

2. Make sure that the (blue) Wi-Fi lamp ﬂ ashes quickly and the POWER lamp is lit as shown in the

illustration above, then press and hold the button on the access point within 2 minutes.

3. Make sure that the (blue) Wi-Fi lamp and POWER lamp are lit.

The network connection setup is now complete.

Wired Connection

aPreparation for Connection

Before Starting Wired Connection Setup

1. Make sure that the printer is turned on.

If the power is on, the POWER lamp (A) will be lit.

Notes on Wired Connection

Make sure that the computer and router (A) (or access point) are connected.

The conﬁ guration, router functions, setup procedures and security settings of the network device vary depending on your

system environment. For details, refer to the manual of your network device or contact its manufacturer.

For ofﬁ ce use, consult your network administrator.

Take added care when connecting to a network that is not protected with security measures, as there is a risk of disclosing

data such as your personal information to a third party.

This printer cannot be used over wireless and wired connections at the same time.

When using a router, connect the printer and computer to the LAN side (same network segment).

bCable Connection

You will need an Ethernet cable (sold separately).

1. Remove the Cap (A) from the upper port located on the right side at the back of the printer.

•

2. Connect the printer and a network device (router, etc.) with an Ethernet cable (A).

Please make sure to use the correct port on the back of the printer. Do not connect it to the USB port.

cPrinter Setup

1. Hold down the RESUME/CANCEL button (A) on the printer until the POWER lamp ﬂ ashes 11 times,

then release the RESUME/CANCEL button after the eleventh ﬂ ash.

The wired connection setup is complete.

The network connection setup is now complete.

Troubleshooting

WPS

When the (blue) Wi-Fi lamp ﬂ ashes slowly and the (orange) Alarm lamp is lit:

Press the button on only one access point.

Check the security settings of the access point.

After checking the above points, wait for a while and conﬁ gure wireless connection setting again.

For details on how to check the security settings of the access point, refer to the manual supplied with the access

point or contact its manufacturer.

When the (blue) Wi-Fi lamp ﬂ ashes quickly and the (orange) Alarm lamp is lit:

Is the network device (router, etc.) turned on? If the network device is already turned on, turn it off, then turn it back

on.

Are the computer and network device conﬁ gured?

Are the access point and printer installed in an open space where wireless communications are possible?

Is the access point operating in IEEE802.11n (2.4 GHz), IEEE802.11g or IEEE802.11b?

Wait for a while, then bring the access point and printer close to each other, and conﬁ gure wireless connection

settings again within a speciﬁ ed time.

For details on how to check the settings of the access point, refer to the manual supplied with the access point or

contact its manufacturer.

To conﬁ gure wireless connection settings again

To conﬁ gure wireless connection settings again, press the RESUME/CANCEL button (A).



•



•


