Canon PIXMA MP990 Manuel utilisateur

Network Setup Troubleshooting

This manual mainly describes problems you may encounter when setting up a network, and the possible

causes and solutions.

Find a description related to your problem and follow the solution.

If you cannot nd a description for your problem or if you encounter a problem after setup, refer to the on-

screen manual: Basic Guide/Advanced Guide.

Names of functions, etc. may differ from this manual depending on your network device (router, access

point, etc.) or application software.

•

The following symbols are used in this manual.

Description for Windows users.

Description for Macintosh users.

Instructions as notes for operation or additional explanations.

Other Troubleshooting Tips

The Target Access Point is Not Displayed (Detected) P.1

P.1

Failed to connect to the access point. is Displayed P.2

Forgotten or Do Not Know the Access Point Name/Network Name (SSID), Security

Protocol (encryption standard), and Network Key

The Machine is Not Displayed (Detected)

Cannot connect. Multiple access points are enabled. is Displayed

Connection failed. is Displayed

Access point was not detected is Displayed

P.4

P.3

The Machine is Not Detected after the Network Environment is Changed

P.6

Connection Checklist P.11

Multiple access points with the same name exist. is Displayed

P.3

P.4

P.5Check Printer Settings dialog box is displayed

Problems during Network Setup

Problems during Software Installation

Reference Information

Specifying the Machine's IP Address (IPv4 only) P.9

P.7

Restoring the Machine's Default LAN Settings to Perform Setup Again P.10

WPS Settings

Easy Settings

P.6

Entering the Access Point's Wireless LAN Settings Directly on the Machine P.7

Specications P.13

Description for wireless connection.

Description for wired connection.

Problems during Network Setup

Check

The Target Access Point is Not Displayed (Detected)

Make sure that you follow Check 1, 2, 5 and 6 of

"Connection Checklist" on page 11, then press the left

FUNCTION button (A) on the machine to search for the

access point again.

Unplug the access point from the power outlet and plug it in,

wait for a while, then press the left FUNCTION button (A) on

the machine to search for the access point again.

Is SSID broadcast (connection via "ANY" SSID, etc.)

disabled or is the stealth mode enabled on the access

point?

For details on how to check the settings of the access point,

refer to the manual supplied with the access point or contact its

manufacturer.

•

Enable SSID broadcast (connection via "ANY" SSID, etc.)

or disable the stealth mode, then press the left FUNCTION

button (A) on the machine to search for the access point

again.

For details on how to change the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

To establish a connection without changing the access point settings, refer to "Entering

the Access Point's Wireless LAN Settings Directly on the Machine" on page 7.

Check 3

Check 2

Check 1

Easy Settings

Is the MAC address ltering enabled on the access point?

Set the access point to accept the MAC address of the

machine.

Check 4

For details on how to change the settings of the access point,

refer to the manual supplied with the access point or contact its

manufacturer.

•

To check the MAC address of the machine, press the HOME

button, then using the Easy-Scroll Wheel and OK button, select

Settings > Device settings > LAN settings > Conrm LAN

settings > Wireless LAN setting list, then check MAC address.

•

For details on how to check the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

Is "WPA/WPA2 Enterprise" set as a security protocol (encryption standard) on the

access point?

Check 5

"WPA/WPA2 Enterprise" is not supported on the machine.

Change the security protocol (encryption standard) for the access point, then congure

settings again.

For details on how to change the security protocol (encryption standard) for the access point, refer

to the manual supplied with the access point or contact its manufacturer.

•

For the procedure to congure settings of the machine, refer to "Wireless Setup" on page 23 in the

printed manual: Getting Started.

•

SSID•

An identier to identify the specic access point.

An access point's periodic transmission of a signal revealing its SSID.

Stealth mode•

A function to hide SSID in wireless connection.

SSID broadcast•

Glossary

A function to block access from unauthorized wireless devices by saving the MAC addresses of specic

wireless devices (computers, printers, etc.) to the access point beforehand.

MAC address ltering•

A unique number assigned to each network device.

MAC address•

Check

Glossary

DHCP function•

A function that automatically assigns required information (IP address, etc.) to computers connected to

the Internet.

Failed to connect to the access point. is Displayed

Check 1

Is WEP key number 2, 3 or 4 of the access point in use?

For details on how to check the WEP key number of the access

point, refer to the manual supplied with the access point or

contact its manufacturer.

•

Set to use WEP key number 1 of the access point, or select

a WEP key number by entering wireless connection settings

of the machine directly.

For details on how to change the WEP key number of the access point, refer to the manual

supplied with the access point or contact its manufacturer.

•

For details on how to select a WEP key number by entering wireless connection settings of the

machine directly, refer to "Entering the Access Point's Wireless LAN Settings Directly on the

Machine" on page 7.

•

Check 2

Make sure that the DHCP function of the access point is active.

For details on how to check the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

Enable the DHCP function of the access point, then congure settings again.

For details on how to change the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

Are you using an access point that automatically creates WEP keys?

Check the WEP key (hexadecimal) created automatically on the access point, then enter

it on the machine.

For details on how to check the WEP key of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

Check 3

For details on the access point, refer to the manual supplied with the access point or contact its

manufacturer.

•

Check

Multiple access points with the same name exist. is Displayed

The message appears when multiple access points with the

same name are found.

Select Use multiple APs.

When you have only one access point

For details on how to check the MAC address of the access

point, refer to the manual supplied with the access point or

contact its manufacturer.

•

Select Use one AP only, then select the MAC address of

the target access point.

When using multiple access points

Glossary

A unique number assigned to each network device.

MAC address•

For subsequent operations, go to step in "Entering the Access Point's Wireless LAN Settings

Directly on the Machine" on page 7.

•

For subsequent operations, go to step in "Entering the

Access Point's Wireless LAN Settings Directly on the Machine"

on page 7.

•

Check

Access point was not detected is Displayed

The message appears when no access point is found.

Refer to "The Target Access Point is Not Displayed

(Detected)" on page 1.

Action

Check

Cannot connect. Multiple access points are enabled. is Displayed

The message appears when multiple access points are

detected.

Check the access point settings, then congure WPS

settings again.

For details on how to check the settings of the access point,

refer to the manual supplied with the access point or contact its

manufacturer.

•

The message appears when an error occurs.

Connection failed. is Displayed

Wait for a while, then congure the settings again.

For the procedure to congure WPS settings of the machine, refer

to "Wireless Setup Using WPS (Wi-Fi Protected Setup)" on page

27 in the printed manual: Getting Started.

•

When using an access point that does not support WPS, congure settings manually. For the

procedure to congure settings of the machine manually, refer to "Wireless Setup" on page 23 in

the printed manual: Getting Started.

•

WPS Settings

Check

The Machine is Not Displayed (Detected)

Is the machine connected to a network?

For details on how to check if the machine is connected to a network, refer to "Conrm Connection

Status" on page 33 in the printed manual: Getting Started.

•

For a wireless connection, make sure that you follow Check 1, 2, 3, 4, 5 and 6 of

"Connection Checklist" on page 11, then click Update (A).

Check 2

Check 1

If the machine is not connected to a network, perform setup again by following the

procedures in "Wireless Setup" on page 23 and onward or "Wired Setup" on page 30

and onward in the printed manual: Getting Started.

Check 3

Problems during Software Installation

Is the IP ltering feature enabled on the network device (router, access point, etc.)?

Set the network device to accept the IP address of the machine.

For details on how to check settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

For details on how to change settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

To check the IP address of the machine, press the HOME button, then using the Easy-Scroll

Wheel and OK button, select Settings > Device settings > LAN settings > Conrm LAN

settings > Wireless LAN setting list or Wired LAN setting list, then check IP address.

•

For a wired connection, make sure that you follow Check 1, 2, 3, 7 and 8 of "Connection

Checklist" on page 11, then click Update (A).

Check

Check Printer Settings dialog box is displayed

The message appears when the machine cannot be

detected.

Is the machine connected to a network?

For details on how to check if the machine is connected to a network, refer to "Conrm Connection

Status" on page 33 in the printed manual: Getting Started.

•

For a wireless connection, make sure that you follow

Check 1, 2, 3, 4, 5 and 6 of "Connection Checklist" on

page 11, then click Back (A).

Check 1

Check 2

Proceed with the setup.

If the machine is not connected to a network, perform setup again by following the

procedures in "Wireless Setup" on page 23 and onward or "Wired Setup" on page 30

and onward in the printed manual: Getting Started.

Is the IP ltering feature enabled on the network device (router, access point, etc.)?

Check 3

For details on how to check settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

Set the network device to accept the IP address of the machine.

For details on how to change settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

To check the IP address of the machine, press the HOME button, then using the Easy-Scroll

Wheel and OK button, select Settings > Device settings > LAN settings > Conrm LAN

settings > Wireless LAN setting list or Wired LAN setting list, then check IP address.

•

Is the privacy separator feature enabled on the access point?

Disable the privacy separator feature.

Check 5

Check 4

For details on how to change the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

For details on how to check the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

When obtaining an IP address automatically, make sure that the DHCP function of the

network device (router, access point, etc.) is active.

For details on how to check settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

Activate the DHCP function of the network device, then click Update (A).

For details on how to change settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

Glossary

A function to control trafc to/from specic IP addresses.

IP address ltering•

A function to prevent communication between multiple wireless devices connected to an access point.

Privacy separator feature•

DHCP function•

A function that automatically assigns required information (IP address, etc.) to computers connected to

the Internet.

(* Wireless connection only) For a wired connection, make sure that you follow Check

1, 2, 3, 7 and 8 of "Connection Checklist" on page 11, then

click Back (A).

Is the privacy separator feature enabled on the access point?

Disable the privacy separator feature.

Check 5

Check 4

For details on how to change the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

For details on how to check the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

When obtaining an IP address automatically, make sure that the DHCP function of the

network device (router, access point, etc.) is active.

For details on how to check settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

Activate the DHCP function of the network device, then click Back (A).

For details on how to change settings of the network device, refer to the manual supplied with the

network device or contact its manufacturer.

•

Glossary

A function to control trafc to/from specic IP addresses.

IP address ltering•

A function to prevent communication between multiple wireless devices connected to an access point.

Privacy separator feature•

DHCP function•

A function that automatically assigns required information (IP address, etc.) to computers connected to

the Internet.

Check

Other Troubleshooting Tips

The Machine is Not Detected after the Network Environment is Changed

IP address•

A numerical identication assigned to each computer or network device connected to a network.

Glossary

Wait until the IP address is assigned to the computer. You may need to restart your

computer.

Search for the machine again after conrming a valid IP address is assigned to the computer.•

Forgotten or Do Not Know the Access Point Name/Network Name

(SSID), Security Protocol (encryption standard), and Network Key

Check the access point settings.

For details on how to check the settings of the access point, refer to the manual supplied with the

access point or contact its manufacturer.

•

(* Wireless connection only)

Select Directly enter the access point name, then

press the OK button.

If you are living in an apartment, nearby access points in use

may be detected.

•

Enter the access point name/network name (SSID)

using the Easy-Scroll Wheel, then press the OK button.

For details on how to check the access point name/network

name (SSID), refer to the manual supplied with the access

point or contact its manufacturer.

•

Enter the same access point name/network name (SSID) as

that of the access point on the machine.

•

Enter upper and lower case letters of the alphabet correctly. Letters are case sensitive.•

Go to either of the following steps according to the selected

security protocol.

•

Disable

WEP

WPA/WPA2

Select a security protocol for the access point, then

press the OK button.

When WEP 40 bit is selected in AirPort Utility (AirPort Admin Utility), select WEP (64 bit).•

When WEP (Transitional Security Network) is selected in AirPort Utility, select WEP (128

bit) or WPA2-PSK (AES).

•

Use the Easy-Scroll Wheel to select the character. Use the ]

button to move the cursor to the right.

Action

Reference Information

Select Easy settings, then press the OK button.

Select Yes, then press the OK button.

Select Wireless LAN setup, then press the OK button.

Use the Easy-Scroll Wheel to select Settings, then

press the OK button.

Enter the access point name/network name (SSID) and security setting (WEP, WPA,

etc.) on the machine directly.

Follow the procedure below.

When wireless connection is enabled, the Wi-Fi lamp lights

blue.

•

Entering the Access Point's Wireless LAN Settings Directly on the

Machine

8-A 8-B

WEP

Make sure that the network key is correct, then

press the OK button.

Enter the network key, then press the OK button.

Enter upper and lower case letters of the alphabet

correctly when the key input format is characters.

Letters are case sensitive.

Letters are not case sensitive if the format is

hexadecimal.

•

Select the network key format.

Select Characters when the network key is 5 or 13

characters.

Select Hexadecimal when it is 10 or 26 characters

(digits).

•

Select the WEP key number you want to use,

then press the OK button.

Make sure that the network key is correct, then

press the OK button.

Select the network key format.

Select Characters when the network key is between

8 and 63 characters.

Select Hexadecimal when it is 64 characters (digits).

•

Enter the network key, then press the OK button.

Enter upper and lower case letters of the alphabet

correctly when the key input format is characters.

Letters are case sensitive.

Letters are not case sensitive if the format is

hexadecimal.

•

When the completion screen appears, press the OK

button.

The Settings screen returns.

When using AirPort, select WEP key 1 in the

screen. Selecting other key numbers will disable the

connection between the machine and AirPort.

•

WPA/WPA2

Disable

Autres manuels pour PIXMA MP990

Table des matières

Autres manuels Canon Imprimante tout-en-un

Canon

Canon MultiPASS F30 Manuel utilisateur

Canon

Canon LBP352 Manuel utilisateur

Canon

Canon imageRUNNER 2202N Manuel utilisateur

Canon

Canon PIXMA MG3150 Manuel utilisateur

Canon

Canon 3747B003 Manuel utilisateur

Canon

Canon PIXMA MP190 Manuel utilisateur

Canon

Canon IMAGEPRESS C7010VPS Manuel du propriétaire

Canon

Canon imageCLASS MF4450 Guide de sécurité

Canon

Canon MP-C545 Manuel utilisateur

Canon

Canon ImageRunner C1225if Manuel utilisateur

Canon

Canon PIXMA MG5220 Series Manuel utilisateur

Canon

Canon ImageCLASS D420 Instructions de montage

Canon

Canon Color imageCLASS MF8580Cdw Manuel de service

Canon

Canon C3220 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Instructions d'installation et d'entretien

Canon

Canon PIXMA MG3120 Manuel utilisateur

Canon

Canon MF7280 - ImageCLASS B/W Laser Manuel d'installation et d'exploitation

Canon

Canon imageCLASS Mf6160dw Manuel utilisateur

Canon

Canon PIXMA MP460 Manuel utilisateur

Canon

Canon Staple Finisher-S1 Manuel utilisateur

Canon

Canon iR1600 Series Manuel utilisateur

Canon

Canon image runner 3025 Manuel utilisateur

Canon

Canon Color imageRUNNER C5185 Manuel utilisateur

Canon

Canon Color imageCLASS MF8180c Guide de sécurité

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur
