Canon PIXMA MP495 Series Manuel utilisateur

Installing Your Multifunction

to Your Network for the First Time

PIXMA MP495

Mac OS

<< Previous Next >>

Installing Your Multifunction

to Your Network for the First Time

PIXMA MP495

Mac OS

Preparing to Connect My Multifunction to My Network 3

Network Requirements 3

Notes on Wireless Connection 4

Installing the Drivers & Software 5

Registering the Printer & Scanner 14

<< Previous Next >>

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

Wireless Connection

Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that

configuration of the computer and access point or router is complete.

Preparing to Connect My Multifunction

To My Network << Previous Next >>

Preparing to Connect My Multifunction

To My Network

Notes on Network Connection

The configuration, router functions, setup procedures and security settings of the network device vary depending on your system

environment. For details, refer to your device's instruction manual or contact its manufacturer.

The machine cannot be used over a wireless and wired connection at the same time.

An "Ad-hoc connection," which establishes a direct

connection to the computer over a wireless connection

without using an access point, is not supported.

<< Previous Next >>

Software Installation

To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The installation time varies depending on the computer environment or the number of application

software to be installed.)

Installing the Drivers & Software

IMPORTANT

•Log on as the administrator (or a member of the Administrators group).

•Quit all running applications before installation.

•Do not switch users during the installation process.

•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.

•It may be necessary to restart your computer during the installation process. Follow the on-screen instructions and do not remove the

Setup CD-ROM during restarting. The installation resumes once your computer has restarted.

•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access

the network. If such a warning message appears, set the security software to always allow access.

<< Previous Next >>

Software Installation

Do not connect the wireless LAN setup cable yet. Software installation requires temporary use

of the wireless LAN setup cable.

Installing the Drivers & Software

Step One

Turn on the computer, then insert the Setup CD-

ROM into the CD-ROM drive.

Step Two

Double-click the Setup icon of the CD-ROM folder to proceed to the

following screen.

<< Previous Next >>

Step Four

Click Easy Install. Click Install.

The drivers, application software, and on-screen manuals are installed.

Note: If you want to select particular items to install, click Custom Install.

Step Three

Enter your administrator name and password. Click OK.

If the CD-ROM folder does not open automatically, double-click

the CD-ROM icon on the desktop.

If you do not know your administrator name or password, click

Help , then follow the on-screen instructions.

Installing the Drivers & Software << Previous Next >>

Step Six

When the Printer Detection screen appears, click Next.

IMPORTANT

If the Printer Connection screen appears instead of the screen above, the connection

method is not correctly selected in 5.

Follow on-screen instructions and proceed with the installation. Click Exit on the

installation complete screen, then start again from 2 and be sure to select Use the

printer on network in 5.

Step Five

Select Use the printer on network, then click Next.

Follow any on-screen instructions to proceed with the

software installation.

Installing the Drivers & Software << Previous Next >>

Step Eight

When the Set Up New Printer screen appears, click Next.

Note:

If the Detected Printers List screen appears, click Set Up New Printer.

Step Seven

Make sure the machine is turned on, then click OK.

Installing the Drivers & Software << Previous Next >>

Installing the Drivers & Software

Step Nine

When the Connect Cable screen appears, connect the machine to the computer with the wireless LAN setup cable.

Follow the on-screen instructions and click Next.

<< Previous Next >>
