Canon MX330 series Manuel utilisateur
Make sure to read this manual before using the machine. Please keep it in hand for future reference.
Getting Started
Symbols■
The following symbols are used to mark important instructions. Observe
these instructions.
Model Number: K10332 (MX330)
Macintosh and Mac are trademarks of Apple Inc., registered in the U.S. and other
countries.
•
Microsoft is a registered trademark of Microsoft Corporation.•
Windows is a trademark or registered trademark of Microsoft Corporation in the U.S.
and/or other countries.
•
Windows Vista is a trademark or registered trademark of Microsoft Corporation in the
U.S. and/or other countries.
•
8
After Installing the Machine
Install the Software
7
Install the FINE Cartridges
5
Turn the Power On
4
Remove the Protective Material
2
Loading Paper
Connect the Telephone Line
3
Set Up for Fax Reception
6
Preparation
1
Contents
Additional explanations.
Instructions that, if ignored, could result in personal injury or
material damage.
Instructions that must be observed for safe operation.
Descriptions for operations that take some time to complete.
Caution
1
1234567812345678
1Preparation
Before turning on the machine, remove all the orange tapes and the protective sheets.
power cordFINE cartridges
Color Black
A USB cable is necessary to connect the machine with your computer.•
Manuals•
Setup CD-ROM (containing the drivers, applications and on-screen manuals)•
Warranty•
Check the Included Items■
Choosing a Location□
Do not install the machine where an object may fall on it. The
object may fall into the Rear Tray, resulting in malfunction.
•
Do not place any object on the Document Cover. It may
fall into the Rear Tray when opening the Document Cover,
resulting in malfunction.
•
telephone line cable
2
123 4 5 6 7 8
2
C
EB
D
B
A
C
1234
Remove the Protective Material
Open the Paper Output
Tray (A).
Lift the Scanning Unit (Cover) (B) until it
locks into place.
Then, lift the Scanning Unit (Cover) (B) slightly
and fold the Scanning Unit Support (C), then
gently close the Scanning Unit (Cover) (B).
Pull the orange protective tape
(D) and remove the protective
material (E).
The Scanning Unit Support (C) is xed
automatically.
3
1 2 345678
B
A
12
3Connect the Telephone Line
This section describes the basic method of
telephone line connection.
Connect the machine with a telephone line using the
supplied telephone line cable (A).
Do not connect the machine and a telephone in parallel
to the same telephone line using a distribution adapter.
The machine may not operate properly.
•
Remove the telephone connector cap (B), then
connect a telephone with the telephone line
cable.
To use the machine as a fax, a telephone
line needs to be connected.
If you cannot send faxes after installing the
machine, check the telephone line type. For
details, refer to "Conrming the Telephone Line
Connection" in the on-screen manual: Basic
Guide.
•
For other connection methods, refer to the on-
screen manual: Basic Guide.
When using as a fax only:
Go to "4 Turn the Power On" on page 4.
When not using
as a fax:
When using as
both a fax and
telephone:
When using as
a fax only:
Go to "4 Turn
the Power On"
on page 4.
only
Only when connecting a telephone:
4
4
2
1
12
12345 6 7 8
C
D
B
A
34
Turn the Power On
Plug the power cord into the
left side of the machine, then
connect the other end to the wall
outlet.
Turn on the machine
(A).
Do NOT connect the USB cable at
this stage.
•
Make sure that the
Document Cover (B) is
closed.
•
Use the {or }button (C) on the
Operation Panel to select the language
for the LCD, then press the OK button.
If an unintended language is displayed on the LCD, press the Back button (D) to return to the Language
selection screen.
•
The standby screen is displayed.
Use the {or }button (C) on the Operation Panel
to select the country or region of use, then press
the OK button.
5
1 2 3 4 56 7 8
E
AD
F
1
5Install the FINE Cartridges
Be sure to use the supplied FINE Cartridges.•
Lift the Scanning Unit (Cover) (A) until it locks into place.
Handle the FINE Cartridges carefully. Do not
drop or apply excessive pressure to them.
•
The Scanning Unit Support (E) is xed automatically.
If the FINE Cartridge Holder returns to the right, close the Scanning Unit (Cover) and reopen it.•
The FINE Cartridge Holder (F) comes out. (This is where you install the cartridges.)
If the FINE Cartridge Holder does not come out, make sure that the machine is turned on.•
Close the Document Cover (D) and lift it with the Scanning Unit (Cover).
6
5
H
3
2
G
4
Open the Ink Cartridge Locking Cover on the right side.
Pinch (G) rmly and pull up the cover.
Remove the Black FINE Cartridge
from its box.
Be careful not to stain your hands or surrounding work area with ink on the removed protective tape.•
Pull the orange protective tape (H) in the direction of
the arrow and remove it gently.
7
1 2 3 4 56 7 8
65
Push down of the Ink Cartridge Locking Cover until you hear a click to
close it completely.
View the Ink Cartridge Cover straight on and check that it is locked correctly (not
at an angle).
Insert the Color FINE Cartridge into the left FINE Cartridge Holder in the same
way.
Place the Black FINE Cartridge into the right slot .
Do not knock the FINE Cartridge against the sides of the holder.•
Install the Black FINE Cartridge into the right slot, and the Color FINE Cartridge into the left
slot.
•
Install in a well-lit environment.•
8
5
E
A
1 2 3 4 56 7 8
7
Wait until the standby screen appears on the LCD (about 1-2 minutes) and go to the next step.•
Once you have installed the FINE Cartridges, do not remove them unnecessarily.•
Lift the Scanning Unit (Cover) (A) slightly and fold the Scanning Unit Support (E), then gently close the Scanning Unit (Cover) (A).
If an error message is displayed on the LCD, make sure that the FINE Cartridges are correctly installed.•
