Canon MF465dw Manuel utilisateur

Setup Guide

• After you finish reading this guide, store it in a safe

place for future reference.

• The information in this guide is subject to change

without notice.

1Important Safety Instructions

Be sure to read these instructions before using

the machine.

2Setup Guide (this document)

https://oip.manual.canon/

3User's Guide

This section explains all the ways this machine

can be used.

FAQ

This section describes problems that may arise

and how to resolve these problems.

See p. 8“Accessing the Online Manual”for details.

Unless otherwise stated, illustrations used in this

document are for the MF465dw.

Checking the Items

Included

* May not be

included with

some models.

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

Provide a space of 100 mm or more around

the machine when installing.

2. Remove all packing material.

Remove all tapes.

Do not remove the sticker that covers the USB port

until you actually use the USB port.

Rear

1234567 11

Loading Paper

A5/A4

Ensure that the amount

of paper loaded is not

above this line

3Installing the Optional

Part

If you are not using optional part, proceed to

step .

Before Installing the Optional Part

After the machine has been installed, perform the

following before installing the optional part:

1. Turn OFF the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Cassette Feeding Module

1. Install the cassette feeding module in the

location where it will be used.

1 2 3 4 5 6 7 11

Handset

* The handset cannot be used with some models.

Rear

Insert the attached

pin halfway (Do not

insert it all the way in

here).

Insert the pin all

the way in.

Connecting the Power Cord

Rear

45678 111

Specifying the Basic

Settings

When you turn on the machine for the first time, the Setup

Guide appears on the operation panel. Perform the initial

machine setup by following the on-screen instructions.

Operation panel

1. Select the language, the country or region,

and then the time zone.

2. Set the current date/time.

Specifying the Security

Settings

To prevent unauthorized access to the machine, set access

restrictions for Remote UI.

What is Remote UI?

Remote UI allows you to use your computer’s Web

browser to check the machine’s operating status,

change settings, and save items to the Address

Book.

1. To use the Remote UI, select <Yes>.

To continue without using the Remote UI, select

<No> and proceed to step 8.

2. To use General User mode, select <Yes>.

• Set the PIN to be used by general users to access

the Remote UI.

• To continue without using General User mode,

select <No> and proceed to step 8.

3. Set the Remote UI Access PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

* Do not forget your PIN.

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

• You cannot use a wired LAN and a wireless LAN at the

same time.

Wireless LAN

1. Check the router's "SSID" and "Network

ke y."

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. To configure the settings, select <Yes> on

the operation panel.

3. Select the network with a matching SSID.

4. Enter the password (network key) and select

<Apply>.

Wired LAN

Connect the router to the machine with a LAN cable and

then select <No> in the screen for choosing how to

connect to the network.

Rear

5 6 7 8 109111

Ending the Setup Guide

Check the description in the Application Library and then

select <End>.

Installing the Software/

Drivers

To use the print, fax, and scan functions of the machine,

you must install the respective drivers.

Downloading from the Canon website

1. Search for“(model name) download.”

Example: MF465dw download

XXXXXXX download

If you cannot find the download site, go to

https://global.canon/en/support/

2. Download the software and drivers, and

install them on your computer.

To use the scan function, install the “MF Scan Utility”

scanning application and the scan driver.

Installing from the Bundled CD/DVD-

ROM

1. Load the CD/DVD-ROM into your computer,

and install the software and drivers.

For normal installation, select “Easy Installation.”

Selecting “Easy Installation” installs the drivers along

with the standard software and manuals.

If a problem arises during the installation, see

“Questions Related to Drivers”in “FAQ.”

Accessing the FAQ

p. 8“Accessing the Online Manual”

On models with a fax function,

configure the fax settings next.

5678 109111

Fax Setup

The first time you select <Fax> in the Home screen, the Fax Setup Guide starts.

Setup Procedure

11 * These settings do not appear on models without a fax function.

1. Select <Fax> on the Home screen.

2. Select <Set Up Now>.

3. Select <Next>.

4. Enter the Unit Telephone Number and

select <Apply>.

5. Select <Next>.

6. Enter the Unit Name (name and company

name, etc.) and select <Apply>.

7. Select <Next>.

8. Select the receive mode that best suits your

telephone connection and the way you

receive calls.

Refer to the illustration below and select <Yes> or

<No>. Finally, select <Apply> to set the receive

mode.

9. Connect the machine to a telephone line.

Rear

Telephone line jack

Telephone

Handset

(optional part)

10. When you have completed the connection,

select <End>.

11. Select <Yes>.

Selecting the Receive Mode

Do you want to

connect a telephone?

Do you want to use

an answering machine?

For fax use only. Receives faxes automatically.

Can be used for both fax and phone. Uses an

answering machine function to record phone

messages while you are away. Receives faxes

automatically.

Can be used for both fax and phone. Receives faxes

automatically.

Can be used for both fax and phone. Allows you to

check for incoming faxes and receive them manually.

Auto

Answering Machine

Fax/Tel (Auto Switch)

Manual

Do you want to receive

faxes automatically?

Yes

Start

5 6 7 8 109111

Useful Functions and Helpful Information

Accessing the Online Manual

1. Scan the QR code to open the website to the

Canon online manual.

If the site does not open, go to

https://oip.manual.canon/

2. Select the manual.

User’s Guide

This section lists the functions of the machine,

including machine operations, settings, and

operating procedures.

FAQ

This section lists frequently asked questions and

their answers.

If a problem arises during driver installation,

see “Questions Related to Drivers.”

Questions Related to Drivers

Using this Machine from a

Mobile Device (Linking with

Mobile Devices)

This machine can be used from mobile devices such as

smartphones. This makes it easy to print documents or

photos from a mobile device and to save data scanned

on this machine on a mobile device.

User’s Guide

See “Linking with Mobile Devices.”

Managing the Machine from

a Computer (Remote UI)

Remote UI allows this machine to be managed using the

Web browser on a computer. You can use it to check the

machine’s operating status, change settings, and save

items to the Address Book.

User’s Guide

See “Managing the Machine from a

Computer (Remote UI).”

• Après avoir lu ce guide, rangez-le dans un

endroit sûr pour information.

• Les informations figurant dans ce guide sont

sujettes à modifications sans préavis.

Consignes de sécurité importantes

Veillez à lire ces instructions avant d'utiliser l'appareil.

2Guide de configuration

(ce document)

Guide de

configuration

https://oip.manual.canon/

3Guide de l’utilisateur

Cette section explique toutes les façons dont

cette machine peut être utilisée.

FAQ

Cette section décrit les problèmes qui peuvent

survenir et la manière de les résoudre.

Voir p. 16 «Accès au manuel en ligne» pour plus de détails.

Sauf indication contraire, les illustrations utilisées

dans ce document sont pour le modèle MF465dw.

Vérification des articles

inclus

* Non inclus

avec certains

modèles.

Retrait du matériel

d'emballage

1. Installez l'appareil là où il sera utilisé.

Laissez un espace d’au moins 100 mm

autour de l’appareil lors de son installation.

2. Retirez tout le matériel d'emballage.

Retirez tous les rubans adhésifs.

Ne retirez l’autocollant qui recouvre le port USB qui

si vous avez besoin d’utiliser le port USB.

Arrière de

l’équipement

1234567 11
