Canon MF267dw II Manuel utilisateur

Setup Guide

• After you finish reading this guide, store it in a safe

place for future reference.

• The information in this guide is subject to change

without notice.

1Important Safety Instructions

Be sure to read these instructions before using

the machine.

2Setup Guide (this document)

https://oip.manual.canon/

3User's Guide

This section explains all the ways this machine

can be used.

See p. 8“Accessing the Online Manual”for details.

Unless otherwise stated, illustrations used in this

document are for the MF267dw II.

Checking the Items

Included

× 1

* May not be

included with

some models.

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

2. Remove all packing material.

Remove all of the tape.

Do not remove the sticker that covers the USB port

until you actually use the USB port.

Rear

1234567 11

Loading Paper

Keep the paper stack within

the load limit guides.

36.

1 2 3 4 5 6 7 11

Installing the Optional

Part

If you are not using optional part, proceed to

step .

Before Installing the Optional Part

After the machine has been installed, perform the

following before installing the optional part:

1. Turn OFF the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Handset

* The handset cannot be used with some models.

Rear

Insert the attached

pin halfway (Do not

insert it all the way in

here).

43.

Insert the pin all

the way in.

45678 111

Connecting the Power

Cord

Rear

Specifying the Basic

Settings

When you turn on the machine for the first time, the Setup

Guide appears on the control panel. Perform the initial

machine setup by following the on-screen instructions.

Depending on your model, the items available for selection

and the procedure for making choices may differ from

those shown in this document. Proceed as directed in the

screens shown.

Control panel

1. Select the language, the country or region,

and then the time zone.

2. Set the current date/time.

Specifying the Security

Settings

To prevent unauthorized access to the machine, set access

restrictions for Remote UI.

What is Remote UI?

Remote UI allows you to use your computer’s Web

browser to check the machine’s operating status,

change settings, and save items to the Address

Book.

1. To use the Remote UI, select <Yes>.

• To continue without using the Remote UI, select

<No> and proceed to step 8.

• For MF264dw II, check the message and press

2. To use General User mode, select <Yes>.

• Set the PIN to be used by general users to access

the Remote UI.

• To continue without using General User mode,

select <No> and proceed to step 8.

3. Set the Remote UI Access PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

• You cannot use a wired LAN and a wireless LAN at the

same time.

5 6 7 8 109111

Wireless LAN

1. Check the router's "SSID" and "Network

key."

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. To configure the settings, select <Yes> on

the control panel.

3. Select the network with a matching SSID.

4. Enter the password (network key) and

select <Apply>.

5. Check the message and select <Yes>.

Wired LAN

Connect the router to the machine with a LAN cable and

then select <No> in the screen for choosing how to

connect to the network.

Rear

Ending the Setup Guide

For MF264dw II, follow the steps and instructions below,

but operate on the keys shown in parentheses ( ).

Check the description in the <Current Time Set.> and then

select <Close> ( ).

Installing the Software/

Drivers

To use the print, fax, and scan functions of the machine,

you must install the respective drivers.

Downloading from the Canon website

1. Search for“(model name) download.”

Example: MF267dw II download

XXXXXXX download

If you cannot find the download site, go to

https://global.canon/en/support/

2. Download the software and drivers, and

install them on your computer.

To use the scan function, install the “MF Scan Utility”

scanning application and the scan driver.

Installing from the Bundled CD/DVD-

ROM

1. Load the CD/DVD-ROM into your computer,

and install the software and drivers.

For normal installation, select “Easy Installation.”

Selecting “Easy Installation” installs the drivers along

with the standard software and manuals.

If a problem arises during the installation, see

“Troubleshooting (FAQ)” under “MF Driver” on the

Canon online manual site.

On models with a fax function,

configure the fax settings next.

5678 109111

Selecting the Receive Mode

Start

Do you want to

connect a telephone?

Yes

Do you want to use an

answering machine?

Do you want to receive faxes

automatically?

Manual

Auto

Answering Machine

Fax/Tel (Auto Switch)

Can be used for both fax and phone. Allows you to

check for incoming faxes and receive them manually.

Can be used for both fax and phone. Receives faxes

automatically.

Can be used for both fax and phone. Uses an

answering machine function to record phone

messages while you are away. Receives faxes

automatically.

For fax use only. Receives faxes automatically.

Fax Setup

The first time you select <Fax> in the Home screen, the Fax Setup Guide starts.

Setup Procedure

1. Select <Fax> on the Home screen.

2. Select <Set Up Now>.

3. Select <Next>.

4. Enter the Unit Telephone Number and

select <Apply>.

5. Select <Next>.

6. Enter the Unit Name (name and company

name, etc.) and select <Apply>.

7. Select <Next> and select the receive mode

that best suits your telephone connection

and the way you receive calls.

Refer to the illustration below and select <Yes> or

<No>. Finally, select <Apply> to set the receive

mode.

8. Select <Next>.

9. Connect the machine to a telephone line.

LINE

HAND

EXT.

SET

Telephone

Handset (optional part)

Telephone line jack

left side

10. When you have completed the connection,

select <Next>.

11. Select <Yes>.

11 * These settings do not appear on models without a fax function.

5 6 7 8 109111

Useful Functions and Helpful Information

Accessing the Online Manual

1. Scan the QR code to open the website to

the Canon online manual.

If the site does not open, go to

https://oip.manual.canon/

2. Open the User’s Guide.

This section lists the functions of the machine,

including machine operations, settings, and

operating procedures.

If a problem arises when using the machine,

see “Troubleshooting” from “Contents” of the

User’s Guide.

This section lists frequently asked questions

and their answers.

Troubleshooting

Contents

Using this Machine from a

Mobile Device (Linking with

Mobile Devices)

This machine can be used from mobile devices such as

smartphones. This makes it easy to print documents or

photos from a mobile device and to save data scanned

on this machine on a mobile device.

User’s Guide

See “Linking with Mobile Devices.”

Managing the Machine from

a Computer (Remote UI)

Remote UI allows this machine to be managed using the

Web browser on a computer. You can use it to check the

machine’s operating status, change settings, and save

items to the Address Book.

User’s Guide

See “Managing the Machine from a

Computer (Remote UI).”

Guide de

configuration

• Après avoir terminé la lecture de ce guide,

conservez-le dans un endroit sûr pour pouvoir

le consulter ultérieurement.

• Les informations contenues dans ce guide sont

susceptibles d'être modifiées sans préavis.

Consignes de sécurité importantes

Veillez à lire ces instructions avant d'utiliser la machine.

2Guide de configuration

(ce document)

https://oip.manual.canon/

3Guide de l'utilisateur

Cette section explique toutes les façons dont

cette machine peut être utilisée.

Voir p. 16 "Accéder au manuel en ligne" pour plus de détails.

Sauf indication contraire, les illustrations utilisées

dans ce document concernent le MF267dw II.

Vérification des éléments

inclus

× 1

* Peut ne pas

être inclus

avec certains

modèles.

Retrait du matériel

d'emballage

1. Installez la machine à l'endroit où elle sera

utilisée.

2. Retirez tous les matériaux d'emballage.

Retirez tout le ruban adhésif.

Ne retirez pas l'autocollant qui recouvre le port USB

avant d'avoir réellement utilisé ce dernier.

Arrière

1 2 3 4 5 6 7 11
