Canon ImageCLASS MF269dw Manuel utilisateur

Getting Started

Mise en route

Introducción

Introdução

Quick Operation P.23

Quick Setup NEXT PAGE

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

https://oip.manual.canon

Quick Setup

Getting Started

Please read "Important Safety Instructions" before

operating this product. P.32

After you finish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

Mise en route

Prenez connaissance des "Consignes de sécurité

importantes" avant toute utilisation de ce produit. P.46

Après en avoir pris connaissance, conservez ce guide dans

un endroit sûr en vue de consultations ultérieures.

Les informations contenues dans ce document peuvent

être modifiées sans avis préalable.

Introducción

Lea las "Instrucciones de seguridad importantes" antes de

usar este producto. P.60

Cuando termine de leer esta guía, guárdela en un lugar

seguro para futuras consultas.

La información de este documento puede ser modificada

sin previo aviso.

Introdução

Leia "Instruções de segurança importantes" antes de operar

este produto. P.74

Depois de ler este guia, guarde-o em um local seguro para

referência futura.

As informações contidas neste documento estão sujeitas a

alterações sem aviso prévio.

You can access

https://oip.manual.canon to read the User's Guide that

describes all functions of this machine.

Le guide de l'utilisateur,

qui décrit toutes les fonctions de cet appareil se trouve sur

https://oip.manual.canon.

Puede acceder a

https://oip.manual.canon para leer la Guía de usuario donde

se describen todas las funciones de este equipo.

Você pode acessar

https://oip.manual.canon para ler o Guia do usuário que

descreve todas as funções desta máquina.

Quick Setup

Installation of the Machine

× 1 × 1

* These items may not be

included depending on

the model of the machine.

A toner cartridge for

replacement comes

with MF269dw VP.

- Toner cartridge and drum cartridge (included with the

machine)

- The toner cartridge included with the machine varies

depending on the model you purchased.

Installation Requirements

Provide a space of 4" (100 mm) or more around

the machine.

MF269dw / MF269dw VP

MF267dw / MF264dw

1 1/2

(39 mm)

(128 mm)

(405 mm)

3 1/2

(87 mm)

15 3/8

(390 mm)

14 3/4

(375 mm)

11 5/8"

(295 mm)

1 3/4

(45 mm)

(128 mm)

(405 mm)

3 1/2

(87 mm)

15 3/8

(390 mm)

14 3/4

(375 mm)

10 5/8

(270 mm)

Items Included with the

Machine Installing the Machine

Quick Setup

Before starting the installation

• Remove all of the tape.

• Do not remove the sticker that covers the USB

port.

Sticker

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Quick Setup

Configuring the Machine

2. Configure the initial settings, according to the

screen.

• Set the language and country/region.

• Set the time zone and current date/time.

Before starting the configuration

• The machine cannot be connected to

both wired and wireless LANs at the same

time.

• If the machine is connected to an

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

• The machine does not come with a

router. Please have one ready, if

necessary.

• Even in an environment without wireless

LAN router, you can use Access Point

Mode to make a wireless connection to

the machine directly from your mobile

device (Direct Connection).

User's Guide

Specifying the connection method

Do you want to use the

wireless LAN to connect

to the network?

The settings can be

configured later.

Yes No

• To connect via wireless LAN : <Yes>

• To connect via wired LAN or USB : <No>

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

Configure the settings in the following order.

NOTE

Parts and functions of the operation panel

P.24 "Start the Operation from the Operation

Panel"

Configuring the Initial Settings

of the Machine Configuring the Method of

Connecting to a Computer

The design of the operation panel differs

depending on the model of your machine. The

descriptions of the operation panel in this guide

basically presumes that the model is MF269dw.

Quick Setup

2. Check the network settings on the computer.

3. Take note of the SSID and network key.

• Check the label on the router. User's Guide

• The setting operation is easier if the router is

provided with a WPS mark. User's Guide

4. Set the access point and network key

according to the screen below.

For more information, refer

to the manual.

1. Select <OK>.

2. Select <SSID Settings>.

3. Select <Select Access Point>.

4. Select the access point (SSID).

5. Enter a network key, and select <Apply>.

6. Select <Yes>.

• The IP address will be automatically

configured in a few minutes.

• "Connected." is displayed.

5. Install the driver and software.

P.8 "Installing the software"

To view a video guide on the process

You can find a video and guide to assist the

process for the Wireless Network connection

from the URL below. Viewing these guides will

ensure a smooth setup of the device into your

existing wireless environment.

http://www.usa.canon.com/WirelessHelp

Now you are finished with the

configuration of the initial settings.

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

• After connecting the cable, wait a few minutes

(until the IP address is set automatically).

• If a static IP address has been set on the

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.8 "Installing the software"

Now you are finished with the

configuration of the initial settings.

For details

"Setting Up Using the Setup Guide" in the User's Guide

Quick Setup

Installing the software

• The procedure described here is only applicable

when your computer runs on the Windows OS.

For more details on the software installation

procedure, see the driver's manual.

• For the installation when your computer runs on

the macOS, see the driver's manual.

• Your machine may not come with the driver for

the macOS, depending on the time of purchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly,

re-insert the CD-ROM/DVD-ROM or search

for "D:\MInst.exe" on the Windows platform

(This description assumes that "D:" is the

CD-ROM/DVD-ROM drive name).

To connect via USB

• The machine does not come with a USB cable.

Please have one ready, if necessary.

• Make sure that the USB cable you

use has the following mark.

• Do not connect the USB cable

before installing the driver. If you did, disconnect

the USB cable from the computer, close the

dialog box, and then perform the following

procedure from step 1.

1. Install the driver and software.

P.8 "Installing the software"

• When a screen with instructions for

connecting the USB cable to the machine is

displayed, remove the sticker that covers the

USB port.

Now you are finished with the

configuration of the initial settings.

Configuring the Machine

Quick Setup

Before starting the configuration:

If your machine does not come with a

telephone cable, have one ready, as

necessary.

Configure the fax settings, according to the

screen below.

Copy

Home

Fax

Scan

Addr. Book

1/5

1. Select <Fax>.

2. Select <Set Up Now>.

3. Register the machine's telephone number (fax

number) and abbreviated user name.

telephone number

for this device.

• The information below will be printed at the

top part of the paper output from the

destination machine as sender information.

02/02 2017 10:00AM FAX 123XXXXXXX CANON 0001

Sent Time

Number’s Type

Fax Number

Unit Name Page Number

Configuring Fax Settings

4. Set the reception mode.

• Make the setting by answering the questions

on your purposes of using the fax function.

5. Connect to a telephone line.

Connect to socket on back of de

Telephone line jack

Telephone

6. Select <Next>.

7. Select <Yes>.

Now you are finished with the

configuration.

For details

"Configuring Initial Settings for Fax Functions" in the User's Guide

Configuration rapide

Configuration de l'appareil

2. Configurez les réglages initiaux en suivant les

instructions à l'écran.

• Spécifiez la langue et le pays/la région.

• Spécifiez le fuseau horaire et réglez la date et

l'heure.

Avant commencer la configuration

• Cet appareil ne peut pas être connecté

simultanément par des réseaux sans fil et

filaires.

• Si l'appareil est connecté à un réseau non

sécurisé, vos informations personnelles

pourraient être divulguées à un tiers.

Soyez conscient de cette situation et

agissez prudemment.

• L'appareil n'est pas livré avec un routeur.

Vous devez vous en procurer un.

• Même dans un environnement sans

routeur de réseau sans fil, vous pouvez

utiliser le mode Point d'accès pour établir

directement une connexion sans fil entre

l'appareil et votre appareil mobile

(connexion directe).

Guide de l'utilisateur

Spécification de la méthode de

connexion

Souhaitez-vous utiliser le

réseau sans fil pour la

connexion au réseau ?

Les paramètres peuvent être

configurés ultérieurement.

Oui Non

• Connexion par réseau sans fil: <Oui>

• Connexion par réseau filaire ou USB: <Non>

Connexion par réseau sans fil

1. Assurez-vous que l'ordinateur est correctement

connecté à un routeur.

Configurez les réglages dans l'ordre suivant.

REMARQUE

Sections et fonctions du panneau de commande

P.38 "Démarrage à partir du panneau de

commande"

Configuration des réglages

initiaux de l'appareil Configuration de la méthode

de connexion à un ordinateur

Le dessin du panneau de commande diffère selon le

modèle de votre appareil. Les descriptions du

panneau de commande dans le présent guide se

rapportent au modèle MF269dw.

Autres manuels pour imageCLASS MF269dw

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Canon Imprimante tout-en-un

Canon

Canon ImageCLASS MF4690 Manuel utilisateur

Canon

Canon ImageRunner iR8500 Series Manuel utilisateur

Canon

Canon imageRUNNERC1028iF Guide de sécurité

Canon

Canon imageRUNNER ADVANCE 6275i Manuel utilisateur

Canon

Canon IMAGERUNNER ADVANCE C5051 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Instructions d'installation et d'entretien

Canon

Canon PIXMA MX860 series Instructions d'installation et d'entretien

Canon

Canon MX390 series Guide de configuration

Canon

Canon imageRUNNER ADVANCE DX C359i Manuel utilisateur

Canon

Canon imageRUNNER C3100 N Printer Manuel utilisateur

Canon

Canon mf6600 Series Manuel utilisateur

Canon

Canon TS6400 Series Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE 6055 Manuel d'utilisation

Canon

Canon SmartBase 1270D Manuel utilisateur

Canon

Canon 4204B019AA Manuel utilisateur

Canon

Canon imageCLASS MF6540 Guide de démarrage rapide

Canon

Canon PIXMA Q T 1 0 8 5 1 V 0 1 Manuel utilisateur

Canon

Canon PIXMA MP830 Manuel utilisateur

Canon

Canon MultiPASS L60 Guide de sécurité

Canon

Canon MF7280 - ImageCLASS B/W Laser Manuel utilisateur

Canon

Canon MX530 series Guide de configuration

Canon

Canon PIXMA MX860 series Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX C7780i Manuel utilisateur

Canon

Canon imageRUNNER 2320 Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur

Oce

Oce VarioLink 5022 Manuel utilisateur

Canon imageCLASS MF269dw Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques
