CanMore GPORTER GP-102+ Manuel utilisateur
CanmoreCorporation www.canmore.com.tw
G-PORTER
Portable GPS Tracker
GP-102+ User’s Manual
CanmoreCorporation www.canmore.com.tw
Chapter 1 GP-102+ Overview
The GP-102+ is the best available portable GPS tracker and sports analyzer with the most
functions with the simplest operations.
The SiRFstarIV™ navigation processor is equipped to deliver the best positioning quality.
The GP-102+ sports tracker provides a wide variety of sports modes to support analysis
with different software analyzers.
The GP-102+ allows users to retrieve previous tracks.
The GP-102+ provides route planning or sports tracking functions.
The GP-102+ comes with versatile additional functions, such as pedometer, barometer,
weather station, level, etc.
Functions of Keys
5V Charger Input
Press once: Previous page
Press and hold for 2-3 seconds:
Exit Press and hold for 2-3 seconds for the first time:
Turn the GP-102+ on.
Press once: Next page
Press and hold for 2-3 seconds: Enter that page.
CanmoreCorporation www.canmore.com.tw
Chapter 2 Function Tree Diagram of GP-102+
Using the GP102 for the first time, press and hold the right key to turn the GP-102+ on and
the following screen will appear:
GPS clock synchronization: Place the GP-102+ in open sky.
Set time:
Press and hold the LEFT key for
2-3 seconds to call out. Press and hold the RIGHT key for 2-3
seconds to enter.
Function mode:
2 screens
Press UP/DN
Sports Mode and Tracker
Trip Planning Mode (from PC software)
Geotag Mode
Historical Data Mode
Additional Functions (Pedometer, Pressure Gauge, Weather Station, Level)
Setup PowerOFF(Press and hold the right key for 2-3
seconds)
CanmoreCorporation www.canmore.com.tw
Chapter 3 Sports Mode and Tracker (Options: Press and hold the
right key for 2-3 seconds to enter the following pages)
Press and hold the right key for 2-3 seconds to enter the Sports Mode.
SportsandTravelOptions
The following examples are based on the jogging mode .
Press and hold the right key for 2-3 seconds to enter the jogging mode :
█Data 1 :
Jogging Mode. GPS Signal Meter. Charging
As shown on the left screen, Distance is 320m, Average Speed is
4.5km/h and the sports Duration is 4 minutes and 14 seconds.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup and
the following screens will appear:
AvailabletypesofPOIs.
After selecting a POI, press and hold the right key to go to
the previous page.
CanmoreCorporation www.canmore.com.tw
Select Stop Log and press and hold the right for 2-3 seconds to enter Stop Log setup.
Switch screen to
Jogging Mode off
GPS off
█Data 2 :
Press the right key once to switch screen.
As shown on the left screen, Speed is 0 km/h, Average Speed is 8km/h
and Maximum Speed is 9.2 km/h.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup
and the following screens will appear:
AvailabletypesofPOIs.
After selecting a POI, press and hold the right key to
go to the previous page.
CanmoreCorporation www.canmore.com.tw
Select Stop Log and press and hold the right key for 2-3 seconds to enter Stop Log setup
Switch screen to
Jogging Mode off
GPS off
█Data 3 :
Press the right key once to switch screen
As shown on the left screen, Pace is hours/km, Average Pace is 7.5
hours/km and Minimum Pace is 6.5 hours/km.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup
and the following screens will appear:
AvailabletypesofPOIs.
After selecting a POI, press and hold the right key to
go to the previous page.
CanmoreCorporation www.canmore.com.tw
Select Stop Log and press and hold the right key for 2-3 seconds to enter Stop Log setup.
Switch screen to
Jogging Mode off
GPS off
█Data 4:
Press the right key once to switch screens
As shown on the left screen, Altitude is 60.3m, Total Ascend is 8.4 and
Gradient is 0%.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup
and the following screens will appear:
Available types of POIs.
After selecting a POI, press and hold the right key to
go to the previous page.
CanmoreCorporation www.canmore.com.tw
Select Stop Log and press and hold the right key for 2-3 seconds to enter Stop Log setup.
Switch screen to
Jogging Mode off
GPS off
█Data 5
Press the right key once to switch screens
As shown on the left screen, Calories consumed is 57.1, Steps are 25
and Temperature is 28°C.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup
and the following screens will appear:
Available types of POIs.
After selecting a POI, press and hold the right key to
return to the previous page.
CanmoreCorporation www.canmore.com.tw
Select Stop Log and press and hold the right key for 2-3 seconds to enter Stop Log setup.
Switch screen to
Jogging Mode off
GPS off
█Data 6 :
Press the right key once to switch screens.
APOIhasbeenselected.
As shown on the left screen, the object is moving.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup,
and the following screens will appear:
Available types of POIs.
Select Stop Log and press and hold the right key for 2-3 seconds to enter Stop Log setup.
Switch screen to
Jogging Mode off
GPS off
CanmoreCorporation www.canmore.com.tw
After selecting, press and hold the right key to return to the previous page.
Select Map Scale and press and hold the right key for 2-3
seconds to enter Map Scale.
After selecting, press and hold the right
key to go to the previous page.
█Data 7
Press the right key once to switch screens.
The GPS status is as shown on the left screen.
Select Save as POI. (Press and hold the right key for 2-3 seconds to enter POI setup)
Select Save as POI and press and hold the right key for 2-3 seconds to
enter POI setup.
Select Save as POI and press and hold the right key for 2-3 seconds to enter POI setup
and the following screens will appear:
Available types of POIs.
After selecting, press and hold the right
key to go to the previous page.
