Candy Washing machine Manuel utilisateur

Washing machine Instructions for use

Introduction

Please read these instructions for use carefully and all other information enclosed with the

washing machine.

Keep all documentation in a safe place for future reference or for any future owners.

Note: this machine is solely for domestic use.

Notes on disposal

All packaging material used is environmentally-friendly and recyclable. Please help dispose of

the packaging via environmentally-friendly means.

Your supplier or local council will be able to give you

details of current means of disposal.

Valuable materials can be salvaged from an old appliance via scrap reprocessing.

Note: pull out the mains plug from any old appliance.

Cut the power cable and dispose of it, together with the

plug.

When disposing of an old washing machine, please ensure that the door lock is rendered

inoperable to prevent children shutting themselves in the appliance.

Contents Page

Introduction 2

General delivery notes 4

Safety notes 4

Quick start 5

Description of controls 6

Programme Table 12

Programme selector 14

Detergent drawer 17

Detergents, washing aids and amounts to use 18

Useful advice for the user 20

The main wash 21

Cleaning and routine maintenance 23

Investigating malfunctions 25

Technical data 27

Setting up + installation 28

BEFORE SWITCHING ON THE APPLIANCE MAKE SURE

IT IS CORRECTLY INSTALLED AND THAT THE TRANSIT

SCREWS ARE REMOVED AS SHOWN IN PAGE 28.

General delivery notes

Please check that the following items are delivered with the appliance:

- Instruction manual

- Certificate of guarantee

- Inlet hose

Check that no damage has occurred during transit, and if so, call your nearest Authorised

Technical Support Service agent.

Safety notes.

Note:

for cleaning or maintenance of the washing machine.

A) Pull out the plug

B) Turn off the tap

C) Candy equips all its appliances with earthing. Ensure that the mains supply is earthed,

and if it is not, seek assistance from a qualified person.

D) Do not touch the appliance when hands or feet are wet or damp. Do not use the appliance

with bare feet.

E) The use of adapters, multiple connectors and/or extensions is not recommended.

Note:

water temperature can reach 90°C during the wash cycle.

F) Check there is no water left in the drum before opening the door.

G) This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

H) Do not pull the power cable or the appliance itself to remove the plug from the socket.

I) The appliance must not be exposed to weather conditions (rain, direct sun, etc...)

L) When moving the appliance never lift it by the controls or by the detergent drawer.

When in transit never rest the door against the trolley or transport the appliance without

the polystyrene base.

M) N.B!

If the appliance is installed on a carpeted floor ensure that the ventilation holes on the

base of the appliance are not obstructed.

N) If the appliance is not running properly or breaks down, switch it off, turn off the tap and do

not tamper with the appliance.

Consult only the Authorised Technical Support Service for possible repair and ask them to

use original spare parts.

Failure to comply with the above can compromise the safety of the appliance.

O) If the appliance’s power cable should ever need replacing, consult theAuthorised

Technical Support Service

Quick start

Washing

- Open the door by using the handle “A” (Fig. 1, page 6)

- Select laundry and put it in the machine

- Close the door

- Put detergent in the compartments as indicated in the programme guide in this instruction

manual

- Select programme

- Wait that a “SPIN” indicator light will go on.

Press additional function buttons (if required)

- Press the “Start/Pause” button (page 7)

- After few seconds the appliance starts working.

After washing

- All the wash stage indicator lights will illuminate.

- Wait for the door lock to be released

(about 2 minutes after the programme has finished).

The “Door Security” indicator light will go out.

- Switch off the washing machine by turning the

selector to “OFF” position.

- Open the door and remove the laundry.

Ensure that the machine is correctly installed in line with the instructions found on page 28.

Description of controls

Door handle A

"Door Security" indicator light B

"Start/Pause" button C

"Cold wash" button D

"Allergy Care" button E

"Delay Start" button F

"Spin Selection" button G

Spin speed indicator light H

"Wash stage" indicator lights L

Buttons indicator lights M

Programme selector with "OFF" position N

Detergent drawer P

CHG

B M

Fig. 1

Door handle

Press the finger-bar inside the door handle to open the door.

DOOR SECURITY indicator light

The “Door Security” indicator light is illuminated when the door is fully closed and the machine is ON.

When "Start/Pause" is pressed on the machine with the door closed the indicator will flash

momentarily and then illuminate.

If the door is not closed the indicator will continue to flash.

Aspecial safety device prevents the door from being opened immediately after the end of the cycle.

Wait for 2 minutes after the wash cycle has finished and the “Door Security” light has gone out

before opening the door.At the end of the cycle turn the programme selector to "OFF" .

NOTE: When the "Start/Pause" button has been pressed,

the appliance can take few seconds before it starts

working.

START/PAUSE button

After selecting a programme wait that a “Spin” indicator

light is illuminate before pressing the START button.

Press to start the selected cycle (according to the selected cycle one wash stage indicator

lights will illuminate).

Changing the settings after the programmes has started (PAUSE)

The programme may be paused at any time during the wash cycle by holding down the

“START/PAUSE” button for about 4 seconds.

When the machine is in the paused mode, a “wash stage” indicator light and option buttons

will flash.

To restart the programme press the START button once again.

If you wish to add or remove items during washing, wait 2 minutes until the safety device

unlocks the door.

When you have carried out the manoeuvre, close the door, press "Start/Pause" button and

the appliance will continue working where it left off.

CANCELLING THE PROGRAMME

To cancel the programme, set the selector to the OFF position.

Select a different programme.

Re-set the programme selector to the OFF position.

COLD WASH button

By pressing this button it is possible to transform every programme into a cold washing one,

without modifying other characteristics (water level, times, rythmes, etc...).

Curtains, small carpets, man made delicate fabrics, non coulor fast garments can be safely

washed thanks to this new device.

The option buttons should be selected before pressing

the "Start/Pause" button.

“ALLERGY CARE” button

By pressing this button you can activate a special new wash cycle in the Cotton and Mixed

Fabrics programs, thanks to the new Sensor System. This option treats with care the fibres of

garments and the delicate skin of those who wear them.

The load is washed in a much larger quantity of water and this, together with the new combined

action of the drum rotation cycles, where water is filled and emptied, will give you garments which

have been cleaned and rinsed to perfection. The amount of water in the wash is increased so that

the detergent dissolves perfectly, ensuring an efficient cleaning action. The amount of water is also

increased during the rinse procedure so as to remove all traces of detergent from the fibres. This

function has been specifically designed for people with delicate and sensitive skin, for whom even

a very small amount of detergent can cause irritation or allergy.

You are advised to also use this function for children’s clothing and for delicate fabrics in general,

or when washing garments made of towelling, where the fibres tend to absorb a greater quantity of

detergent. To ensure the best performance for your wash, this function is always activated on the

Delicates and Woollens/Hand wash programs.

DELAY START button

Appliance start time can be set with this button, delaying the start by 3, 6 or 9 hours.

Proceed as follows to set a delayed start:

Select a programme (Wait that a “Spin” indicator light will go on).

Press "Delay Start" button (each time the button is pressed the start will be delayed by 3, 6

or 9 hours respectively and the corresponding light will blink).

Press "Start/Pause" to commence the Delay Start operation (the indicator light associated

with the selected Delay Start time stops blinking and remains ON).

At the end of the required time delay the programme will start.

To cancel the Delay Start function :

press the "Delay Start" button until the indicator lights will be off and the programme can be

started manually using the "Start/Pause" button or switch off the appliance by turning the

programme selector to "OFF" position.

Warning: If there is any break in the power supply while

the machine is operating, a special memory stores the

selected programme and, when the power is restored, it

continues where it left off.

SPIN SELECTION button

According to the selected cycle automatically will shows if the programme’s spin is maximum

(MAX), intermediate (MED) or zero ( ). By pressing this button, it’s possible to reduce or cancel

the spin speed shown.

To reactivate the spin cycle press the button until you reach the spin speed you would like to set.

To prevent damage to the fabrics, it is not possible to increase the speed over that which is

automatically suitable during the selection of the program.

It is possible to modify the spin speed without to pausing the machine.

Note:

The machine is fitted with a special electronic device, which

prevents the spin cycle should the load be unbalanced.

This reduces the noise and vibration in the machine and so

prolongs the life of your machine.

Spin speed indicator light

When you set a program, the maximum possible spin speed will be automatically shown by

the relevant indicator light.

Choosing a smaller spin speed by the appropriate button, the relevant indicator light will go on.

WASH STAGE indicator lights

= main wash

= rinse

= spin

Buttons indicator light

These light up when the relevant buttons are pressed.

If an option is selected that is not compatible with the selected programme then the light on

the button first flashes and then goes off.
