Candy CTP6SC4/E1 Manuel utilisateur

Instructions Manual For Induction Hob ENGLISH

CTP6SC4/E1

Thank you for purchasing the CANDY induction hob. Please read this instruction manual carefully

before using the hob and keep it in a safe place for future reference.

Návod k použití pro indukční varnou desku ČEŠTINA

Εγχειρίδιο οδηγιών για επαγωγικές εστίες ΕΛΛΗΝΙΚΑ

Návod na obsluhu indukčnej varnej dosky SLOVENČINA

УКРАЇНСЬКА

Інструкція з експлуатації для індукційної варильної поверхні

EN-2

EN-3

EN-4

59cm 52cm

6.2cm 5.8cm

EN-5

1. On/Off c lortno

2. Flexible Area control

3. Boost

4. Heating zone selection controls

5. Keylock control

lortnocremiT.6

four

1. Max. 1400W/1500W zone

2. Max. 2400W/2600W zone

3. Max. 3000W/3600W zone

7. Control panel

7. Power / Timer slider touch control

4. Max. 1800W/2000W zone

5. Max. 1800W/2000W zone

6. Glass plate

EN-6

EN-7

How to use

Start cooking

Touch the ON/OFF control.After power on, the buzzer beeps

once, all displays show “–” or “– –”, indicating that the induction

hob has entered the state of standby mode.

Place a suitable pan on the cooking zone that you wish to use.

• Make sure the bottom of the pan and the surface of the

cooking zone are clean and dry.

Touching the heating zone selection control, and an indicator

next to the key will flash

Select a heat setting by touching the slider control

• If you don’t choose a heat setting within 1 minute, the

Induction hob will automatically switch off. You will need to

start again at step 1.

• You can modify the heat setting at any time during

cooking.

If the display flashes alternately with the heat setting

This means that:

• you have not placed a pan on the correct cooking zone or,

• the pan you’re using is not suitable for induction cooking or,

• the pan is too small or not properly centered on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.

The display “ ”will automatically disappear after 1 minute if no suitable pan is placed on it.

power up

power down

EN-8

Finish cooking

Touching the heating zone selection control that you wish

to switch off

Turn the cooking zone off by touching the slider to “|”.

Make sure the displayshows”0”

Turn the whole cooktop off by touching the ON/OFF

control.

Beware of hot surfaces

H will show which cooking zone is hot to touch. It will

disappear when the surface has cooled down to a safe

temperature. It can also be used as an energy saving

function if you want to heat further pans, use the

hotplate that is still hot.

Using the Boost function

Activate the boost function

Touching the heating zone selection control.

Touching the boost control , the zone indicator show

“P” and the power reach Max.

Cancel the Boost function

Touching the heating zone selection control that you wish

to cancel the boost function

EN-9

•The function can work in any cooking zone.

•The cooking zone returns to its original setting after 5 minutes.

•If the original heat setting equals 0, it will return to 9 after 5 minutes.

FLEXIBLE AREA

• This area can be used as a single zone or as two different zones, accordingly

to the cooking needs anytime.

• Free area is made of two independent inductors that can be controlled

separately.

As big zone

1. To activate the free area as a single big zone, Touching the Flexible Area control .

2. As a big zone, we suggest the used as the follow:

Cookware: 250mm or 280mm diameter cookware (Square or Oval

cookware are acceptable)

We don’t recommend other operations except for above mentioned three

operations because it might effect the heating of appliance

As two independent zones

To use the flexible area as two different zones, you can have two choices of

heating.

(a) Put a pan on the right up side or the right down side of the flexible zone.

Touching the "Boost" control to cancel the Boost

function, then the cooking zone will revert to its original

setting.

EN-10
