Candy CIV60 Manuel utilisateur

CIV60

Reverse Action

User Instructions

05651180 22/6/01 11:46 am Page 1

Ofrecido por www.electromanuales.com

Safety reminders

User’s manual. This machine should only

be used for its intended purpose as

described in this manual. Ensure that it is

fully understood before operating.

Installation. This machine should not be

installed in a bathroom or shower room.

Never install the dryer against curtains

and be sure to prevent items from falling

or collecting behind the dryer.

Ventilation. Check regularly that the air

flowing through the dryer is not restricted:

Check the fluff filter after use, and clean,

if necessary.

The venting hose or duct should be

checked periodically and any

accumulation of fluff removed.

The inlet and outlets should be kept free

from obstructions.

If the dryer is used frequently the period

between checks should be reduced

accordingly.

Dryness. Clothes should be spin dried or

thoroughly wrung before they are put into

the tumble dryer. Clothes that are dripping

wet should NOT be put into the dryer.

Lighters and matches must not be left in

pockets and NEVER use flammable

liquids near the machine.

Foam plastic, foam rubber and rubber-

like material are not suitable for tumble

drying. Articles made from these

materials MUST NOT be placed in the

dryer.

Glass fibre curtains should never be put

in this machine. Skin irritation may occur

if other garments are contaminated with

the glass fibres.

Garments treated with flammable

cleaning sprays or liquids such as petrol,

must not be put in this machine.

Lint or fluff must not be allowed to

collect on the floor around the outside of

the machine.

Cool down period. The drum inside may

be very hot. Always allow the dryer to

complete the cool down period before

removing the laundry.

Faults. Do not continue to use this

machine if it appears to be faulty.

After use. Remove the plug from the

electricity supply. Always remove the

plug before cleaning the appliance.

Supply cord. If the supply cord on this

appliance is damaged, it must be replaced

by a special cord which is only available

from GIAS Service or an authorised

Dealer.

GIAS Service. To ensure the continued

safe and efficient operation of this

appliance we recommend that any

servicing or repairs are only carried out

by an authorised GIAS service engineer.

05651180 22/6/01 11:46 am Page 2

Ofrecido por www.electromanuales.com

Installation

Before using the tumble dryer for the

first time:

●please read this instruction book

thoroughly.

●remove all items packed inside drum.

●wipe the inside of the drum and door

with a damp cloth to remove any dust

which may have settled in transit.

IMPORTANT: This dryer must only be

used for drying household textiles and

garments where a water solution has

been used for the cleaning process.

DO NOT tumble dry fabrics treated

with dry cleaning fluids.

Electrical requirements

This appliance is fitted with a moulded-on

non-rewireable plug (in the UK fitted with

a 13 Amp fuse).

The plug should be accessible for

disconnection after the appliance has been

installed.

WARNING!

ELECTRICITY CAN BE

EXTREMELY DANGEROUS.

THIS APPLIANCE MUST BE

EARTHED.

IMPORTANT: The wires in the mains

lead are coloured in accordance with the

following code:

Blue - NEUTRAL

Brown - LIVE

Green-and-yellow - EARTH

If the supply cord on this appliance is

damaged, it must be replaced by a

special cord which is only available from

GIAS Service or an authorised Dealer.

Contents

Safety reminder 2

Electrical requirements 3

Ventilation requirements 4

Preparing the load 5

Clothes preparation 5

Maximum drying weight 5

Sorting the load 5

Do not tumble dry 5

Energy saving 5

Opening the door 6

Filter 6

Drying guide 7

Controls & indicators 8

Operation 9

Cleaning the dryer 10

Technical specifications 10

Troubleshooting 11

05651180 22/6/01 11:46 am Page 3

Ofrecido por www.electromanuales.com

Installation

Installation and

Ventilation requirements

IMPORTANT: This dryer must be

installed such that the air inlets and

outlet are not restricted (fig. 1).

There should be a gap of at least 12mm

(0.5 inches) between the sides and rear of

the machine and the surrounding walls and

cabinets.

To ensure adequate ventilation the space

between the bottom of the machine and the

floor must not be obstructed.

NEVER install the dryer up against

curtains.

Prevent items from falling or collecting

behind the dryer as these may obstruct the

air inlet and outlet.

A venting hose is supplied with this

tumble dryer.

The use of the venting hose to exhaust hot

air to the external atmosphere is strongly

recommended to ensure maximum drying

efficiency. Protect the external outlet from

prevailing winds to ensure back-draughts

do not reduce the drying performance.

If the dryer is installed under a worktop or

built-in, it is essential to use the venting

hose to carry the hot moist air away from

the dryer otherwise re-circulation of the

moist air will prevent the dryer from

working efficiently.

The hose may be fitted through a wall or

through an open door or window (fig.2).

The hose is 95mm (3.75 inches) in

diameter and will extend up to 1.8 metres

(6 feet).

Venting hoses longer than 1.8 metres

(6 feet) are not recommended as the dryer

performance will be reduced.

Ensure that the venting hose is not

kinked as this will prevent the dryer

from working efficiently.

Where it is not practical to fit a venting

hose, condensation can be reduced by

operating the dryer close to an open

window or an extractor fan.

AIR INLET

VENTS

SUPPLY CORD

HOTAIR

OUTLET

05651180 22/6/01 11:46 am Page 4

Ofrecido por www.electromanuales.com

Preparing the load

Before using the dryer for the first time

wipe the inside of the drum and door with a

damp cloth.

Make sure that the laundry you are going to

dry is suitable for drying in a tumble dryer,

as shown by the care symbols on each item.

Clothes preparation

Check that all fastenings are closed and that

pockets are empty. Turn the articles inside

out. Place clothes loosely in the drum to

make sure that they don’t get tangled.

Do not overload the drum, particularly

when drying large items, otherwise, the

laundry may stick to the drum and not dry

evenly.

Maximum drying weight

●Cottons Max. 6 kg

●Synthetics Max. 3 kg

Sort the load as follows:

A) By care symbols

On the collar or inside seam:

Suitable for tumble drying.

Tumble drying at high temperature.

Tumble drying at low temperature only.

DO NOT tumble dry.

B) By amount and thickness

Whenever the load is bigger than the

dryer capacity, separate clothes

according to thickness (e.g. towels from

thin underwear).

C) By type of fabric

Cottons/linen: Towels, cotton jersey, bed

and table linen.

Preparing the load

Synthetics: Blouses, shirts, overalls, etc.

made of polyester or polyamid, as well

as for cotton/synthetic mixes.

D) By drying level

●Sort into: Iron dry, cupboard dry, etc.

●For delicate articles press the ‘HEAT

SETTING’ button to select low drying

temperature.

Do not tumble dry:

Woollens, silk, delicate fabrics, nylon

stockings, delicate embroidery, fabrics

with metallic decorations, garments

with PVC or leather trimmings,

training shoes, bulky items such as

sleeping bags, etc.

IMPORTANT: Do not dry articles

which have been treated with a dry

cleaning fluid or rubber clothes

(danger of fire or explosion).

Energy saving

Only put into the tumble dryer laundry

which has been thoroughly wrung or

spin-dried. The drier the laundry the

shorter the drying time thus saving

electricity.

ALWAYS try to dry the maximum

weight of laundry, this will save time

and electricity.

NEVER exceed the maximum weight,

this will waste time and electricity.

ALWAYS check that the filter is clean

before every drying cycle.

NEVER put dripping wet items into

the tumble dryer, this may damage the

appliance.

05651180 22/6/01 11:46 am Page 5

Ofrecido por www.electromanuales.com

Press the textured panel to open the door.

The pushing action on the door is a safety

feature to prevent entrapment of miners in

the drum.

To restart the dryer, close the door and

press the ‘ON’ button.

Door Filter

Opening the door

WARNING!

WHEN THE TUMBLE DRYER IS

IN USE THE DRUM AND DOOR

MAY BE VERY HOT.

Filter

IMPORTANT: To maintain the efficiency

of the dryer check that the fluff filter is

clean before each drying cycle.

1. Gently remove lint using a soft brush or

your fingertips (fig. 4).

Clean Filter Indicator lights when the

filter needs cleaning. If the laundry is not

drying check that the filter is not clogged.

The indicator will also light when the

venting hose is blocked or kinked.

05651180 22/6/01 11:46 am Page 6

Ofrecido por www.electromanuales.com

Drying guide

The table shows approximate drying times, depending on the type of fabric and dampness

of the clothes.

REMEMBER: During the last 15 minutes the load is always tumbled in cool air.

05651180 22/6/01 11:46 am Page 7

Ofrecido por www.electromanuales.com

Controls and indicators

1. ‘ON’ button and indicator – press to switch on, the indicator will light.

2. ‘HEAT SETTING’ button - press to reduce the heat level for delicate items, press

again to select high temperature.

3. ‘DRYING TIME’ dial - selects drying time.

Control panel and indicator lights

Heat setting

05651180 22/6/01 11:46 am Page 8

Ofrecido por www.electromanuales.com

6. The load is dried by tumbling in

thermostatically controlled warm air.

Cool air is used for the last 15 minutes

to reduce creasing and cool the load

ready for handling.

7. When the program is fully completed

the drum will stop rotating and the dial

will point to the symbol (▼).

Open the door and remove the load.

8. Clean the filter after every drying cycle

to ensure maximum dryer efficiency.

(See ‘Filter’ section.)

Operation

WARNING!

THE DRUM, DOOR AND LOAD

MAY BE VERY HOT.

Operation

1. Open the door and load the drum with

laundry. Ensure that garments do not

hinder closure of the door.

2. If drying delicate items press the

‘HEAT SETTING’ button to reduce the

heat level. Press again on completion, to

select high temperature.

3. Turn ‘DRYING TIME’ dial until the

required drying time aligns with the

symbol (▼).

4. Gently close the door pushing it slowly

until you hear the door ‘click’ shut.

5. Press the ‘ON’ button. The indicator

will light and the drying cycle begins.

Heat setting

05651180 22/6/01 11:46 am Page 9

Ofrecido por www.electromanuales.com

Cleaning Technical Data

Cleaning the dryer

IMPORTANT: Always switch off and

remove the plug from the electricity

supply before cleaning this appliance.

Clean the filter after every drying cycle.

After each period of use, wipe the inside of

the drum and leave the door open for a

while to allow circulation of air to dry it.

Wipe the outside of the machine and the

door with a soft cloth.

DO NOT use abrasive pads or cleaning

agents.

To prevent the door sticking, periodically

clean the door gasket with a ‘non- scratch

cream cleaner.’

Technical

specifications

Drum capacity 115 litres

Maximum load 6 kg

Height 85cm

Width 60cm

Depth 60cm

Energy Label Band C

Note: For electrical data refer to the rating

label on the front of the dryer cabinet (with

the door open).

05651180 22/6/01 11:46 am Page 10

Ofrecido por www.electromanuales.com

Table des matières

Autres manuels Candy Séchoir

Candy

Candy GCH 970NA2T Manuel utilisateur

Candy

Candy GOC 781B Manuel utilisateur

Candy

Candy GCH 970 NA1T-S Manuel utilisateur

Candy

Candy GODC38T/1 Manuel utilisateur

Candy

Candy GO DV58F Manuel utilisateur

Candy

Candy Grand O Vita GVH D913A2 Manuel utilisateur

Candy

Candy GO DV58GF Manuel utilisateur

Candy

Candy CS4 H7A1DE-S Manuel utilisateur

Candy

Candy GO DC 38T Manuel utilisateur

Candy

Candy Grand'O GO DV 38 Manuel utilisateur

Candy

Candy GCC 581NB Manuel utilisateur

Candy

Candy Grand Evo EVOH 971NA2T Manuel utilisateur

Candy

Candy CV116-S Manuel utilisateur

Candy

Candy CTDB H7A1TBE-80 Manuel utilisateur

Candy

Candy CDC 268EX Manuel utilisateur

Candy

Candy CC2 66T Manuel utilisateur

Candy

Candy GVC 71013NB Grand O Vita Manuel utilisateur

Candy

Candy GCH 970NA1T Manuel utilisateur

Candy

Candy GCC 570NB Manuel utilisateur

Candy

Candy Grand O comfort GCH 980NA1T Manuel utilisateur

Candy

Candy Grand O Evo Easy Case Manuel utilisateur

Candy

Candy GrandO GO DC56F Manuel utilisateur

Candy

Candy GO DC 36 T Manuel utilisateur

Candy

Candy CIC209X Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
