C&T Solution BCO-1000-J1900 Series Manuel utilisateur

USER’S

MANUAL

BCO-1000-J1900 Series

Basic Fanless Embedded System

BCO-1000-J1900 lUser’s Manual

Please note, the BCO-1000 is now

referred to as “BCO-1000-J1900" due

to a model name change. All product

features and functionality remain the

same. If any questions, please

Name Change Guide:

LEGACY Model Name

NEW Model Name

BCO

-1000

BCO

-1000-J1900

BCO

-1010

BCO

-1000-J1900-10

BCO

-1010A

BCO

-1000-J1900-10A

BCO

-1010B

BCO

-1000-J1900-10B

BCO

-1010U

BCO

-1000-J1900-10U

BCO

-1020C

BCO

-1000-J1900-20C

BCO

-1020D

BCO

-1000-J1900-20D

BCO-1000-J1900 lUser’s Manual

Table of Contents

Prefaces …………………………………………………….……………………………………………. 04

Revision …………………………………………………………………………………………..……………….………..04

Disclaimer ………………………………………………………..…….…….………………………….………………..04

Trademarks Acknowledgment …………..………………………………………………………...................04

Environmental Protection Announcement …………………………….………………….……………….. 04

Safety Precautions ………………………………………….……………………………….…………….…………..05

Technical Support and Assistance …………………………………….…………….…………….…………….06

Conventions Used in this Manual ………………………………………………………………….….………..06

Package Contents …………………………………………………………………………………………….…………07

Ordering Information …………………………………….……………………………………….……….…………07

Optional Accessory …………...…………………………………….....................................................07

Chapter 1 Product Introductions ………………………………………………………..… 08

1.1 Overview ……………………….………………………………..………….…………………………..09

1.1.1 Key Feature ………….……………………………………….……….…..…………….......09

1.2 Hardware Specification ….………………………….....…………….…………..………………10

1.3 System I/O ……………………………..……………………..…………………………………………11

1.3.1 BCO-1000 ………………….…………......................……………………………………11

1.3.2 BCO-1010 / BCO-1010A / BCO-1010B / BCO-1010U .……………………... 13

1.3.3 BCO-1020C / BCO-1020D ……………………..……………..……….………………...15

1.3.4 BCO-1030 ………………………………..…………..……………………...………………...17

1.4 Mechanical Dimension …………………………..…………………………..………….………. 19

1.4.1 RCO-1000 ………………….….......................……………………………………….… 19

1.4.2 RCO-1010 / RCO-1010A / RCO-1010B / BCO-1010U …………..…….…....20

1.4.3 RCO-1020C / RCO-1020D ……………………..……………….………………………..21

1.4.4 RCO-1030 ………………………………..…………..……………….………………………..22

Chapter 2 Switches and Connectors ………………….…………………………………. 23

2.1 Switch and connector Locations ………………………………………..…….……………....24

2.1.1 Top View ………………………………………………………………………..……………… 24

2.1.2 Bottom View ………………………………………………………………………..………..25

2.1.3 Daughterboard view …………………………………………………………………..…. 25

2.2 Connector / Switch Definition ……………………………….……….…….……….............26

2.3 Switch Definitions ………….……………...............................................................27

2.4 Connector Definitions ………………………….......................................................27

Chapter 3 System Setup …………………………..……………………………………………36

3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and

unscrewing …………………………………………………………………….……………………….. 37

3.2 Removing chassis bottom cover ………………….…..…….…………….……………….… 37

3.3 Installing SODIMM .………………………………..…………………………….….................. 38

3.4 Installing SATA HDD/SSD ………………….………………….…………………….………….... 40

3.5 Installing Mini PCIe card / mSATA …….…………..……….……..….……………….…….. 42

3.6 Installing antenna ……………………………………….…………..……………………………... 43

3.7 Assemble chassis bottom cover …..……………………………………………………........45

3.8 Installing SIM card ….…………..……………………..….………………………..………..….... 46

BCO-1000-J1900 lUser’s Manual

Chapter 4 BIOS Setup …………………………………………………………………………… 47

4.1 BIOS Introduction …….……….……………………………………..….…….…..….…………...48

4.2 Main Setup ……..……….………………….…………………………..…….….………………......49

4.2.1 System Date …….……………………………………………..……..……………………....49

4.3 Advanced Setup ………………………………………………………..…………………………….. 50

4.3.1 Trusted Computing ………………………………………………………………………… 50

4.3.2 ACPI Settings ……..…………………………………………………………..……………….51

4.3.3 Super IO Configuration …………………………….………..…………………..……... 52

4.3.4 Hardware Monitor ………………………………………….………………………..…....56

4.3.5 Serial Port Console Redirection …………………………………....……..…….....56

4.3.6 CPU Configuration ……………………………..……………….………….….…….…....57

4.3.7 PPM Configuration ..……………………………………………..…………..………..... 58

4.3.8 SATA Configuration ……..………………………………..………………………….......59

4.3.9 OS Selection ……………………………………………………………………..…………....59

4.3.10 Network Stack Configuration…………………………………………….……….…. 60

4.3.11 CSM Configuration…………………………………………………………………..……..61

4.3.12 USB Configuration…………………………………………………………………..…….. 62

4.4 Chipset …………...……….………………….…..….…..………………………………………..…....63

4.4.1 North Bridge ………….…………………………………………………..………………….. 63

4.4.2 South Bridge ………….………………………………………………..…………………….. 65

4.5 Security …………...……….………………….…..….…..………………………………..…………...66

4.5.1 Administrators Password …….…………………………………..……………………..67

4.5.2 Users Password …….……………………………….………………..…………………….. 67

4.6 Boot …………...……….….………………….…..…………………………..…………..……………...70

4.6.1 Setup Prompt Timeout ………………………..…………..……………………………..70

4.6.2 Bootup NumLock State ………………………………………………..………………… 70

4.6.3 Full Screen Logo Show ………………………….…………………………..…...……….70

4.6.4 Boot Option Priorities …………………………..………………………..……………... 70

4.7 Save & Exit …...……….….………………….…..….…..……………………………..………….....71

4.7.1 Save Changes and Reset ……………..………………………………..……..……......71

4.7.2 Discard Changes and Reset …………………………………............……………….71

4.7.3 Restore Defaults ……………………………………………………………..……………...71

4.7.4 Save as User Defaults ………………………………………………………………………71

4.7.5 Restore User Defaults ……………………………………………………………..………71

Appendix WDT & GPIO …………………………………………………………………………… 72

WDT Sample Code …….……………….………….…….……………………..….…….…….…………... 72

GPIO Sample Code ………………………………..…………………………………………………………. 73

BCO-1000-J1900 lUser’s Manual

Revision

Disclaimer

All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T

Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading.

The information in this document is subject to change without notice and does not represent a

commitment on the part of C&T Solution Inc.

C&T Solution Inc. disclaims all warranties, express or implied, including, without limitation, those of

merchantability, fitness for a particular purpose with respect to contents of this User’s Manual. Users must

take full responsibility for the application of the product.

electronic or mechanical, including photocopying, recording, or information storage and retrieval systems,

Trademarks Acknowledgment

Intel®, Celeron® and Pentium® are trademarks of Intel Corporation.

Windows® is registered trademark of Microsoft Corporation.

AMI is trademark of American Megatrend Inc.

IBM, XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation

All other products and trademarks mentioned in this manual are trademarks of their respective owners.

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. Please recycle to minimize pollution

and ensure environment protection.

Prefaces

Revision

Description

Date

1.0

Manual Released

2018/01/15

1.1

Added WDT and GPIO Sample Code

2018/02/09

1.2

Model Name and Installation Instruction Update

2020/07/09

BCO-1000-J1900 lUser’s Manual

Safety Precautions

Before installing and using the equipment, please read the following precautions:

⚫Put this equipment on a reliable surface during installation. Dropping it or letting it fall could

cause damage.

⚫The power outlet shall be installed near the equipment and shall be easily accessible.

⚫Turn off the system power and disconnect the power cord from its source before making any

installation. Be sure both the system and the external devices are turned OFF. Sudden surge

⚫of power could ruin sensitive components. Make sure the equipment is properly grounded.

⚫When the power is connected, never open the equipment. The equipment should be opened

only by qualified service personnel.

⚫Make sure the voltage of the power source is correct before connecting the equipment to the

power outlet.

⚫Disconnect this equipment from the power before cleaning. Use a damp cloth. Do not use

liquid or spray detergents for cleaning.

⚫Avoid the dusty, humidity and temperature extremes.

⚫Do not place heavy objects on the equipment.

⚫If the equipment is not used for long time, disconnect it from the power to avoid being

damaged by transient over-voltage.

⚫The storage temperature shall be above -30°C and below 70°C.

⚫The computer is provided with a battery-powered real-time clock circuit. There is a danger of

explosion if incorrectly replaced. Replace only with the same or equivalent type

recommended by the manufacturer.

⚫If one of the following situation arises, get the equipment checked be service personnel:

•The power cord or plug is damaged.

•Liquid has penetrated into the equipment.

•The equipment has been exposed to moisture.

•The equipment does not work well or it cannot work according the user’s manual.

•The equipment has been dropped and damaged.

•The equipment has obvious signs of breakage.

Preface

BCO-1000-J1900 lUser’s Manual

Preface

This indication alerts operators to an operation that, if not strictly observed,

may result in severe injury.

WARNING

This indication alerts operators to an operation that, if not strictly observed,

may result in safety hazards to personnel or damage to equipment.

CAUTION

This indication provides additional information to complete a task easily.

NOTE

Technical Support and Assistance

Contact your distributor, our technical support team or sales representative for technical support if you

need additional assistance. Please have following information ready before you call:

⚫Model name and serial number

⚫Description of your peripheral attachments

⚫Description of your software (operating system, version, application software, etc.)

⚫A complete description of the problem

⚫The exact wording of any error messages

Conventions Used in this Manual

BCO-1000-J1900 lUser’s Manual

Package Contents

Before installation, please ensure all the items listed in the following table are included in the package.

Item Description Q’ty

1BCO-1000 Series Embedded System 1

2Utility DVD Driver 1

3 Accessory Kit 1

4 DVI to VGA Adapter 1

Ordering Information

Preface

Model No. Product Description

BCO-1000-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 2x COM

BCO-1010-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 2x COM,

1x 2.5" SATA HDD Bay

BCO-1010A-J1900

Basic

Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 1x DP,

2x COM, 1x 2.5" SATA HDD Bay

BCO-1010B-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 4x COM, 1x

2.5" SATA HDD Bay

BCO-1010U-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 2x COM,

2x LAN, 8x USB, 1x 2.5" SATA HDD Bay

BCO-1020C-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 1x DP,

4x COM, 1x 2.5" SATA HDD Bay

BCO-1020D-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 6x COM, 1x

2.5" SATA HDD Bay

BCO-1030-J1900 Basic Fanless Embedded System with Intel® Celeron® J1900 Processor, 1x DVI-I, 1x DP,

6x COM, 1x 2.5" SATA HDD Bay

Optional Accessories

Model No. Product Description

-E09A06002

Adapter AC/DC 12V 5A 60W with 3pin Terminal Block Plug 5.0mm Pitch

SFICBL022

Power Cord, 3

-pin US Type, 180cm

-TPCD00002

Power Cord, European Type, 180cm

-TPCD00001

Power Cord, 3

-pin UK Type, 180cm

Chapter 1

Product Introductions

BCO-1000-J1900 lUser’s Manual

1.1.1 Key Features

⚫Intel® Celeron® processor J1900, up to 2.0GHz

⚫1x 204-pin DDR3L SODIMM. max up to 8GB

⚫Dual independent display supported by 1x DVI-I (BCO-1000, BCO-1010, BCO-1010B, BCO-1010U,

and BCO-1020D Only)

⚫Dual independent display supported by 1x DVI-I and 1x DisplayPort

⚫2x Intel® GbE supporting Wake-on-LAN and PXE

⚫1x mSATA (BCO-1000 Only)

⚫1x 2.5” SATA HDD bay, 1x mSATA

⚫2x full-size mini PCIe for communication or expansion modules, 1x SIM socket

⚫2x RS-232/422/485, 1x USB 3.0, 3x USB 2.0

⚫2x RS-232/422/485, 1x USB 3.0, 7x USB 2.0 (BCO-1010U Only)

⚫4x RS-232/422/485, 1x USB 3.0, 3x USB 2.0 (BCO-1010B and BCO-1020C Only)

⚫6x RS-232/422/485, 1x USB 3.0, 3x USB 2.0 (BCO-1020D and BCO-1030 Only)

⚫4x DI + 4x DO with isolation (BCO-1010A, BCO-1020C, and BCO-1030 Only)

⚫9 to 30VDC wide range power input supporting AT/ATX mode

⚫-20°C to 50°C extended operating temperature

1.1 Overview

BCO-1000 series powered by Intel® Celeron® Processor J1900 2.0GHz SoC, which delivers increased performance by up to

150% compared to previous Atom® platforms and low power consumption. The BCO-1000 series is compatible for

applications that need a basic and simple but dependable solution. It is an ideal preference as an economical entry-level for

diverse applications in computing functionality such as market application in industrial automation, industrial control, Kiosk &

retail and digital signage.

This price-friendly fanless embedded system supports system memory up to 8 GB with one DDR3L-1066/1333 SO-DIMM

socket and features an onboard DVI-I display interface to provide further VGA/DVI-D connection to deliver Ultra HD smooth

visual display. The BCO-1000 series is equipped with one internal 2.5” SATA HDD bays and one mSATA (shared by 1x Mini PCI

Express) to provide sufficient storage. It also comes with one full-size mini PCIe socket with USIM socket (PCIe + USB + SATA)

that satisfy customized needs. Its rich I/O connectors (up to 6x COM, 2x LAN, 8x USB) provide versatile I/O expandability.

In addition to its efficient CPU computing performance, the BCO-1000 series can be configured through its two antenna for

wireless communication. It adopts a wide range power input from 9V to 30V DC, increasing the reliability of the whole system

dramatically. Furthermore, the BCO-1000 series is designed to operate dependably in critical conditions with its anti-vibration,

anti-shock and wide operating ranging from -20°C to 50°C temperature range features. The built-in over voltage protection

(OVP) makes the BCO-1000 series a safe and secure system for all industrial applications.

The BCO-1000 series is housed in a sturdy and rugged housing that makes it feel exceptionally solid. By complying with

military grade endurance (MIL-STD-810G), the BCO-1000 series is designed to withstand significant shock, constant vibration,

and sealed to survive the harshest environments or conditions. The neat and compact design facilitates easy integration,

effortless expansion and trouble-free maintenance.

The BCO-1000 series is very competitive with its affordable price, but without compromising on performance. It is an optimal

solution to fit in various type of interface and variety of applications that requires low cost high performance fanless

computing. Aside from its rich I/O capabilities, the robust package of BCO-1000 series makes it an ideal choice for a cost-

effective, high performance fanless embedded system.

Chapter 1: Product Introductions

BCO-1000 BCO-1010

BCO-1010A

BCO-1010B

BCO-1010U

BCO-1020C

BCO-1020D BCO-1030
