Campbell Hausfeld PW1520 Manuel utilisateur

Visit us online: www.chpower.com

Pressure Washers

• Great for small projects such as cars, SUVs, outdoor

furniture, and lawn equipment

• Instant start/stop system only runs the motor when

the trigger is pulled

• Includes adjustable pressure nozzle, adjusts from

100 to 1300 psi

• Includes rotating turbo nozzle, boosts

effective cleaning power

• Detergent applicator to improve

cleaning effectiveness

• PW1315 includes auto detail kit

• Sprays soap in high or low pressure

• Universal motor features instant start/stop system

• Built-in soap tank with new see-thru polymer to

monitor detergent level

• Includes high pressure soap lance with adjustable

fan nozzle - sprays up to 25 ft.

• Includes rotary turbo lance - boosts effective

cleaning power

• 20 ft. high pressure hose and 35 ft. GFCI power cord

1550 PSI / 1.5 GPM PW1520

Electric Pressure Washers

1300 PSI / 1.4 GPM PW1310/PW1315

1500 PSI / 1.5 GPM PW1510

• Perfect size for around the house cleaning

• 120 volt /13 amp universal motor with instant

start/stop

• Built-in accessory storage

• Adjustable fan lance adjusts from a narrow

stream to a wide pattern

• Includes rotary turbo lance and detergent applicator

• 20 ft. high pressure hose and 35 ft. GFCI power cord

Or call CH Pressure Washers at: 1- 800 - 330 -0712

Pressure Washers

Electric pressure washers provide more effective cleaning

power than a traditional garden hose, while using 80% less

water. With the addition of steam, you can clean, disinfect

and degrease projects. The portable designs offer storage

for accessories and tools. We have a wide range of prod-

ucts from 1300 to 1800 PSI pressure washers, and several

models include steam. Refer to page 56-57 for a complete

listing of accessories.

• 2640 Cleaning Units

• Convenient cart with built-in, 3 qt. detergent tank

• Heavy-duty 120 volt/14.5 amp induction motor

• Instant stop/start motor protection

• 25 ft. high pressure hose

• 35 ft. power cord

• Cast aluminum pump

1650 PSI / 1.6 GPM PW1686

Pressure Washer / Steamer Combos

1550 PSI / 1.5 GPM / 1450 Watt Steamer PW1587

• Innovative new cleaning system combines the

power of steam with a pressure washer

• 13 amp / 120 volt universal motor

• Built-in storage with hose /cord management

• Includes gun and 2 lances - adjustable fan lance

and turbo lance

• Includes 25 ft. high pressure hose

and detergent cup

BUILT-IN STEAMER MODULE

• Ready to use in 30 seconds

• 6 piece accessory kit

• 34 oz. capacity reservoir

• 6 ft. ultra flexible steamer hose

• Great for detailing cars, boats and more

1800 PSI / 1.6 GPM / 1400 Watt Steamer PW1690

• Innovative new cleaning system combines the

power of steam with a pressure washer

• Features dual detergent bottles with selector

- wash and wax!

• Includes new style quick connect lance with 2 inter-

changeable nozzles - turbo nozzle and adjustable fan

• 13 amp / 120 volt induction motor and cast aluminum pump

• Integrated storage for accessories, steamer, cord and hose

management, and mesh bag for

steamer accessories

• Includes 7-piece accessory set

• Pistol grip with trigger-activated steam

• Control moisture intensity with thumb dial

• Excellent for disinfecting and cleaning around the

home and shop

Why Use Pressure Washers & Steamers?

1400 WATT STEAMER

Visit us online: www.chpower.com

Pressure Washers

• Great for larger home projects such as

decks, driveways, siding, brick, tractors,

and RVs

• Powerful 6 HP Tecumseh®engine

• Durable cast aluminum pump with brass

manifold features automatic detergent

injection and thermal relief protection

for long life

• Compact vertical cart with 8” semi-

pneumatic wheels for easy transport

and storage

• Includes 25 ft. high pressure hose,

adjustable fan lance for high and low

pressure; features view through

1.5 gallon detergent tank

2500 PSI / 2.1 GPM PW2502

Gas Pressure Washers

• Great for larger home projects such as

decks, driveways, siding, brick, tractors,

and RVs

• Features built-in polymer soap tank

holds 1-5 gallons of liquid

• 4.5 HP Tecumseh®engine

• Durable pump features automatic detergent

injection and thermal relief protection for

long life

• Includes high pressure soap lance (sprays up

to 25 ft.) and rotary turbo lance to boost

effective cleaning power

• 25 ft. high pressure hose with spray gun

• Compact vertical cart with 8” semi-pneumatic

wheels for easy transport and storage

2200 PSI / 2.0 GPM PW2202

Or call CH Pressure Washers at: 1- 800 - 330 -0712

Pressure Washers

2800 PSI / 2.2 GPM PW2802

3000 PSI / 2.3 GPM PW3002

• Great for home and farm cleaning

projects such as decks, driveways, siding,

brick, tractors, barns and outbuildings

• 6.5 HP Tecumseh®OHV engine

• Durable cast aluminum axial pump with brass

head lasts 50% longer than typical wobble pump

and features thermal relief protection

• Semi-professional gun, lance with 25 ft. high pres-

sure hose.

• Zinc-plated lance with brass fittings includes

3 quick-connect spray tips

• Compact vertical cart design for easy transport and

storage

• 8” semi-pneumatic wheels will never go flat

• Ideal for heavy-duty home, shop and

farm cleaning projects such as driveways,

siding, brick, tractors, barns and equip-

ment

• 7 HP Tecumseh®OHV engine with pressurized

lubrication for long life and dependable opera-

tion

• Durable pump with brass manifold features

adjustable pressure-regulator and thermal relief

protection

• Professional gun with 25 ft. high-pressure hose

• Includes high pressure soap lance, sprays soap

up to 25 ft.

• Zinc-plated lance with brass fittings includes

3 quick-connect spray tips

• 8” semi-pneumatic wheels will never go flat

These gas powered pressure washers are designed for the more

demanding jobs; with increased performance and mobility you

can finish your task faster, and with less effort.

Gas Pressure Washers

Why Use a Gas Pressure Washer?

2600 PSI / 2.1 GPM PW2602

• Clean all around home projects including

driveways, outbuildings, machinery and

• 6.5 HP Tecumseh®OHV engine

• Durable cast aluminum pump with brass

manifold features automatic detergent

injection and thermal relief protection

for long life

• Compact vertical cart with 8” semi-pneu-

matic wheels for easy transport and storage

• 25 ft. high pressure hose with spray gun,

unit features 1.5 gallon detergent tank

• Includes high pressure soap lance (sprays up to 25 ft.)

and turbo lance to boost effective cleaning power

Visit us online: www.chpower.com

PW1071

Brushes

PW1060

PW1070

Pressure Washers

PW1024 - Gun

• For use with electric units

PW0725 - Pro Gun

• For use with gas units from 2400 to 3500 PSI

PW0744

Pressure Washer Tools & Accessories

Guns

Lances & Cleaning Tools

PW1060/PW1061 - High Pressure Soap Lance

with Adjustable Fan Nozzle

• Sprays soap up to 25 ft.

• Soap tank uses bleach and holds 1/2 gallon

• PW1060 works with most gas pressure washers

up to 3200 PSI

• PW1061 for use with electric pressure washers

PW1070/PW1071 - Adjustable Pressure Lance

• PW1070 for use with gas models

• PW1071 for use with electric models

• Provides perfect surface preparation for a wide

range of projects

• Made of durable, rust resistant materials

• Nozzle features fixed fan pattern that adjusts from

100 psi to maximum pressure of pressure washer

PW1022/PW1023 - Rotating Power Lance

• PW1022 for use with all electric models

with b

ayonet- style gun

• PW1023 for use with all gas models up to

2200 PSI with threaded gun

• Powerful rotating spray pattern cleans deeper

and wider than standard spray nozzles to save

time and effort

PW0744 - Quick-Connect Lance

• For use with all gas models

PW1022,

PW1023

PW1000 - Multi-Purpose Cleaning Brush

• Soft, compact brush head is perfect for tackling

a variety of home cleaning projects

• For use with all CH pressure washers

PW1009 - Deck and Siding Brush

• Wide brush head and stiff bristles clean decks

and siding faster and easier

• For use with all CH pressure washers

PW1011 - Rotating Vehicle Brush

• Rotating action of bristles breaks down tough

dirt and grime, yet is safe for delicate finishes

• For use with all CH pressure washers

PW1010 - Brush Extension

• Attaches to the cleaning brush to provide extra

reach for hard to clean places

• For use with all CH pressure washers

• Perfect for cleaning driveways, decks, patios

and fences

• Cleans area 8 times wider than a regular nozzle

• Works with any pressure washer rated up to

2500 PSI @ 2.2 GPM

• Includes lance extension and adapters

Deck ‘n’ Drive Rotary Surface Cleaner PW1091

PW1000

PW1009

PW1011PW1010

Or call CH Pressure Washers at: 1- 800 - 330 -0712

Pressure Washers

Quick-Connect Tips

PW1021 - 1/4” x 25’ Hose (up to 2300 PSI)

PW0722 - 3/8” x 25’ Hose (up to 3000 PSI)

PW0721 - 3/8” x 50’ Hose (up to 4000 PSI)

PW0047 - Concrete Cleaner

PW0049 - Car and Boat Wash

PW0050 - Deck and Fence Cleaner

PW0051 - General Purpose Cleaner

PW0052 - House and Siding Wash

PW0053 - Heavy-Duty Degreaser

Detergents

Hoses

PW1021

Pressure Washer Accessories

Quick-Connect Hose Fittings

DegreeModel No.

PSI

PW0746 0° 2200 - 3000

PW0740 0° 3100 - 3500

PW0747 15° 2200 - 3000

PW0741 15° 3100 - 3500

PW0748 25° 2200 - 3000

PW0742 25° 3100 - 3500

PW0749 40° 2200 - 3000

PW0743 40° 3100 - 3500

PW0745 Detergent nozzle 2200 - 3500

Model

No.

PW1027 1/4” Female Plug Gun to Hose 2200 PSI Elec. & Gas PW1028

Description Connection

Function

Hose

Pressure

Rating

Addtl.

Fittings

Required

Pressure

Washer

Compatibility

PW1028 1/4” Male Socket Hose to Gun 2200 PSI Elec. & Gas PW1027

PW0750 3/8” Male Plug Gun to Hose 2200 PSI Gas PW0751

PW1029 1/4” Male Socket Hose to Pump 2200 PSI Elec. & Gas PW1030

PW0751 3/8” Female Socket Hose to Gun 2200 PSI Gas PW0750

PW0760 3/8” Male Socket Hose to Pump 2200 PSI Gas PW0761

PW0830 Quick Connect Kit Hose to Pump Garden Hose Electric

PW1031 Female Coupler Hose to Pump Garden Hose Gas PW1032

PW1032 Male Nipple Pump to Hose Garden Hose Gas PW1031

Extension Poles

PW1085 - 6 ft. Extension Pole

PW1086 - 9 ft. Extension Pole

• Telescoping handle adjusts to desired length

• Brass fitting to change quick-connect spray tips

• Light weight fiberglass and aluminum

construction

• Ergonomic handle designed for maximum comfort

• Includes 2 quick-connect tips, detergent and

25° general purpose tip

Recommended Usage:

PW1085 - For use with most pressure washers up to 2400 PSI

PW1086 - For use with most pressure washers up to 3000 PSI

Autres manuels pour PW1520

Ce manuel convient aux modèles suivants

Autres manuels Campbell Hausfeld Nettoyeur haute pression

Campbell Hausfeld

Campbell Hausfeld PW1520 Fiche technique

Campbell Hausfeld

Campbell Hausfeld PW1308 Fiche technique

Campbell Hausfeld

Campbell Hausfeld IN468300AV Manuel de service

Campbell Hausfeld

Campbell Hausfeld PW2120 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PW2120 Manuel

Campbell Hausfeld

Campbell Hausfeld PW2120 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PW158010AV Fiche technique

Campbell Hausfeld

Campbell Hausfeld PW1345 Fiche technique

Campbell Hausfeld

Campbell Hausfeld PW1580 Fiche technique

Campbell Hausfeld

Campbell Hausfeld PW1676 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PW132000AV Fiche technique

Campbell Hausfeld

Campbell Hausfeld PW1380 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PM041804AV Guide d'application

Campbell Hausfeld

Campbell Hausfeld PW2575 Manuel de service

Campbell Hausfeld

Campbell Hausfeld PW2802 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PW1550 Manuel d'utilisation et d'entretien

Campbell Hausfeld

Campbell Hausfeld PW2575 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PW1625 Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld PW1350 Manuel d'utilisation et d'entretien

Campbell Hausfeld

Campbell Hausfeld pressure Washers Manuel utilisateur

Campbell Hausfeld

Campbell Hausfeld IN469403AV Manuel d'utilisation et d'entretien

Campbell Hausfeld

Campbell Hausfeld PW1825 Manuel de service

Campbell Hausfeld

Campbell Hausfeld IN469102AV Manuel d'utilisation et d'entretien

Campbell Hausfeld

Campbell Hausfeld PW1310 Manuel utilisateur

Manuels Nettoyeur haute pression populaires d'autres marques

Shark

Shark RG-232637 Manuel utilisateur

Shakti Technology

Shakti Technology S3 Manuel utilisateur

Kärcher

Kärcher K 4 Pure Manuel utilisateur

Porter-Cable

Porter-Cable D25806-025-2 Manuel utilisateur

REM POWER

REM POWER HDEm 662 Manuel utilisateur

Landa

Landa HS-3000 Manuel utilisateur

Craftsman

Craftsman 580.752270 Manuel utilisateur

HIKOKI

HIKOKI AW 100 Manuel utilisateur

Delco

Delco DC 1302 Manuel utilisateur

Kärcher

Kärcher K 3 Full Control Manuel utilisateur

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Manuel utilisateur

ARKSEN

ARKSEN 014-HG-14141-HR Manuel utilisateur

Black & Decker

Black & Decker PW1700SPX Manuel utilisateur

Kärcher

Kärcher 595 - SPARE Mode d’emploi

Kranzle

Kranzle B 10 200 Manuel utilisateur

Stihl

Stihl RE 90 Manuel utilisateur

Husky

Husky HU80911 Manuel utilisateur

PowR-Quip

PowR-Quip PQ-2600 Manuel utilisateur
