CAMBRIONIX ModIT-MAX Manuel utilisateur

User Manual

ModIT-MAX

ModIT-MAX Page 1 of 33

1.Table of Contents

1.Table of Contents 1

2.Your ModIT-MAX at a glance 3

2.1.Key Features 3

3.Safety 4

3.1.Signal word panel 4

3.2.Safety alert symbol 5

3.3.Pictograms 5

3.4.Product modification 5

3.5.Power supply 6

3.6.Storage and Installation 7

4.Getting Started 8

4.1.Opening your product 8

4.2.What's Included 8

4.3.Connecting to the mains 8

4.4.Connecting to Host 9

4.5.Keys 9

4.6.Registration 9

4.7.Help and Support 9

5.Using your ModIT-MAX 11

5.0.1 LED Configuration 11

5.1.Using without connecting to host 11

5.2.Using when connected to host 12

5.2.1 Connecting the Hub to a host computer 12

5.2.2 Authorising Thunderbolt hubs on Linux 12

5.2.3 Charging 13

5.2.4 Data Transfer 13

5.2.5 Communication Interface and Protocol 13

5.3.Scalability 14

5.4.Manage Ports & Your ModIT-MAX 15

5.4.1 Port Modes 15

5.4.2 Charging Profiles 15

5.4.3 Firmware 15

5.5.Software 17

5.5.1 Installing-Software 17

5.5.2 LiveViewer 17

5.5.3 Cambrionix API 19

5.5.4 Updating Software 19

5.5.5 Removing Software 20

5.5.6 Command Line Instructions (CLI) 21

ModIT-MAX Page 2 of 33

5.6.User adjustments 23

5.6.1 Changing the cables 23

5.6.2 Adjusting-the-backstop 23

5.7.Cleaning your ModIT-MAX 24

6.Product Specifications 25

6.1.Input Power Requirements 25

6.2.Output Power 25

6.3.Physical specifications 25

6.4.Consumables and Placing Orders 25

7.Troubleshooting 28

7.1.Device connection. 28

7.2.Hub connection issues 29

8.Disposal 30

9.Returns and Damaged Products 31

9.1.What do I do if my order arrives and something the product is faulty or is phys-

ically damaged? 31

9.2.What happens after I have requested a Return? 31

10.Compliance and Standards 32

ModIT-MAX Page 3 of 33

2.Your ModIT-MAX at a glance

The ModIT-MAX has been designed to provide high-speed data transfer to USB 3.2 compliant

devices without being constrained by endpoint limits.

The ModIT-MAX can charge attached USB devices without using a local computer. The ModIT-

MAX allows almost any device to be charged at its optimum rate (up to 2.4A). The firmware can

be up-dated to ensure the ModIT-MAX can charge the latest devices. It is ready to charge out-

of-the-box and to sync devices when attached to a host computer.

When a local (host) computer is attached the host can control the operation of each individual

port using software provided by Cambrionix. Device charging and synchronisation can be

monitored through Cambrionix’s LiveViewer App, the Application Programming Interface (API)

or Command Line Interface (CLI). Cambrionix’s free monitoring and control software can be

downloaded from www.cambrionix.com/products/api

With your ModIT-MAX there is a Thunderbolt™ connection to the host which is capable of up to

40Gbps, meaning your upstream speeds to the host will be capable of this data transfer rate.

The upstream data transfer rate will be shared amongst the downstream 16 x USB3.2 Type-A

connections.

2.1.Key Features

Up To

40 Gbps

per Port

Up To

2.4A

per Port

Up To

Devices

Transfer Data Seamlessly Power Scalability

Each high speed port can

transfer data up to 40 Gbps

Each port can charge devices up

to 2.4A (12W)

Up to 96 devices can be con-

nected at once using multiple

hubs

ModIT-MAX Page 4 of 33

3.Safety

This user manual is for informational purposes only, it contains information for start-up and

operation of this product. Note: the contents and the product described are subject to change

without notice. To avoid injuries and damage observe the safety instructions of the user

manual.

This manual has been arranged to follow IEC/ICEE 82079-1 standards. This is to facilitate the

easier understanding and location of information relating to the ModIT-MAX. Any errors or

omissions can be reported back using our support ticket system (see"Help and Support") this

way any issues can be collected and fixed.

Understanding and observing the instructions in this user manual are prerequisites for

hazard-free use and safety during operation. This user manual cannot cover all conceivable

applications. If you would like additional information or if problems arise that are not

sufficiently addressed in this manual please ask your distributor or contact us directly using the

means preferred which are located on the back cover of this manual.

CAUTION

Personal Injury and Damage to the product

lObserve the safety instructions in this user manual

3.1.Signal word panel

Depending on the probability of serious consequences, potential dangers are identified with a

signal word, the corresponding safety colour, and if appropriate, the safety alert symbol.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in moderate or

minor (reversible) injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in damage to the

product and/ or its functions or of a property in its proximity.

ModIT-MAX Page 5 of 33

3.2.Safety alert symbol

Use of the safety alert symbol indicates a risk of injury.

Observe all measures that are marked with the safety alert symbol in order to

avoid injury

3.3.Pictograms

Warning Signs

Electrical hazard Fire Hazard

Mandatory action signs

Read operating instructions Mandatory regulation

3.4.Product modification

Cambrionix products are designed and manufactured to meet the requirements of UK and

International safety regulations. Modifications to the product could affect safety and render the

product non-compliant to relevant safety standards, which could result in injury or damage to

the product.

CAUTION

Electric shock or personal injury may occur

lDo not modify the product in any way

lDo not dismantle the product

ModIT-MAX Page 6 of 33

CAUTION

Fire or personal injury may occur

lDo not obstruct air vents on the product

lDo not cover the product in combustible material

CAUTION

Damage to your product may occur

lDo not bend or compress any part of the product

3.5.Power supply

This section describes safety precautions you must follow when using the power supply.

CAUTION

Electric shock or personal injury may occur

lDo not use a damaged power cord or plug, or a loose power socket

lDo not touch the power plug with wet hands

lDo not allow liquids to come into contact with the unit or power supply

CAUTION

Damage to your product may occur

lDo not short circuit the Power Supply Unit (PSU) supplied with your

product

lDo not disconnect the power cord while the product is being used

lDo not bend or pull the power cord with excessive force

ModIT-MAX Page 7 of 33

3.6.Storage and Installation

This section describes safety precautions you must follow when installing and storing your

ModIT-MAX.

CAUTION

Electric shock or personal injury may occur

lDo not place the power cord near heat sources

lConnect the plug to an earthed socket

CAUTION

Damage to your Cambrionix product may occur

lOperate the product only in an environment where the ambient

temperature is inside the operating temperature range

lOperate the product only in an environment where the relative humidity is

inside the operating range

lBe careful not to leave the power cord underneath a heavy object

CAUTION

Overheated power sockets may cause a fire

lDo not overload the power socket that your hub is connected to

lInsert the power plug all the way into the socket so that it is not loose

ModIT-MAX Page 8 of 33

4.Getting Started

This manual provides a reference for end-users who are installing for the first time and using

their hub thereafter. As well as a guide for product safety-related information.

The ModIT-MAX is intended to be used in an indoor static environment in which the

environment falls within the tested specifications to provide charge, sync and management

functionality. For information on the environment specifications please see the physical

specifications section of this manual.

4.1.Opening your product

When you have received your product please check the packing slip to ensure all products and

quantities of them are correct before opening. This is to avoid retesting and repackaging any

items which are not required.

When opening the packaging use a suitable method to open the box i.e. do not use a knife. This

is to ensure the product is not damaged.

4.2.What's Included

lThunderbolt™ 3 Cable (to provide communication between host system and the hub)

lModIT-MAX Hub

l2m Mains power cable (Country specified on order including fuse for UKplugs)

lKey for Locking mechanism

4.3.Connecting to the mains

Making sure you adhere to local safety regulations, connect the power cable to the socket and

switch the power supply on. The hub is now ready to charge attached devices.

Periodic inspection should be made to power supply cables and any USB cables for any signs of

damage. If any damage is found then replace damaged cord before further use.

ModIT-MAX Page 9 of 33

4.4.Connecting to Host

Once the power is connected connect the ModIT-MAX to your host system using a

Thunderbolt™ 3 cable, this is provided with your hub. Using an incorrect host cable may result

in the hub and all subsequent ports not being recognised by your host.

Cambrionix would recommend using the Thunderbolt™ cable that is provided with our ModIT-

MAX. If you are looking at purchasing your own cable then to achieve 40Gbps a suitable cable

would be either:

lup to 0.8m passive

lup to 2m active.

Cambrionix recommend using cables certified by Intel® , all cables with the Thunderbolt™ logo

should have certification.

Please note that USB specifications require a minimum 100 mA charge current to be delivered

during data transfer. As indicated in above, if the attached device has a BC1.2 compliant CDP

port, the device can draw up to 2.4A while transferring data.

4.5.Keys

Your ModIT-MAX comes with a set of keys which can be used to manually close and open the

locking mechanisms on all of the slots at once. This will override any other functions on the hub

so that you can secure devices away or make them available to remove.

These keys are provided with your ModIT-MAX but if you need any replacement's or spares you

can contact Cambrionix to organise a new set to be sent out.

4.6.Registration

You may register your product at www.cambrionix.com/product-registration

4.7.Help and Support

FAQs and help can be found on the Help page here

lwww.cambrionix.com/help_pages/help.

You can raise a support ticket for more in depth support here

lhttps://cambrionix.atlassian.net/servicedesk/customer/portals

You can also download any of our manuals and keep up to date at the link here

lwww.cambrionix.com/product-user-manuals

Autres manuels pour ModIT-MAX

Table des matières

Autres manuels CAMBRIONIX Alimentation

CAMBRIONIX

CAMBRIONIX TS3-C10 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PP15S Manuel utilisateur

CAMBRIONIX

CAMBRIONIX SyncPad54 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX SP54 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX ModIT-Boss Manuel utilisateur

CAMBRIONIX

CAMBRIONIX OEM PDS-C4 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PP8S Manuel utilisateur

CAMBRIONIX

CAMBRIONIX SP54 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX MC14-2.4A Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PP15C Manuel utilisateur

CAMBRIONIX

CAMBRIONIX SS15 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PP15C Manuel utilisateur

CAMBRIONIX

CAMBRIONIX SP54 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PDS-C4 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX TS2-16 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PD-Sync4 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX TS3-C10 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX TS3-16 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX ModIT Manuel utilisateur

CAMBRIONIX

CAMBRIONIX SP54 Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PP15S Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PP15S Manuel utilisateur

CAMBRIONIX

CAMBRIONIX U8S Manuel utilisateur

CAMBRIONIX

CAMBRIONIX PDS-C4 Manuel utilisateur

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur
