Cambridge Audio C11088 Manuel utilisateur
1
AXC25/35
Manual Generated: 22/11/2023 - 16:41
2
Table of Contents
AXC25/35 3 .....................................................................................................................................................................................................................
Introduction 4 ................................................................................................................................................................................................................
What's included with the AXC25/35? 5 ......................................................................................................................................................................
Front panel controls 6 ..................................................................................................................................................................................................
Rear panel connections 7 ............................................................................................................................................................................................
Remote control 8 ...........................................................................................................................................................................................................
Getting connected 9 .....................................................................................................................................................................................................
Operating instructions 10 ............................................................................................................................................................................................
Troubleshooting 13 .......................................................................................................................................................................................................
Technical specifications 14 ..........................................................................................................................................................................................
Frequently Asked Questions (FAQ) 16 .......................................................................................................................................................................
3
AXC25/35
Last updated: August 2, 2022 02:05. Revision #7158
Users Manual
4
Introduction
Last updated: July 29, 2022 10:27. Revision #7167
This guide is designed to make installing and using this product as easy as possible. Information in this document has been carefully checked for
accuracy at the time of printing; however, Cambridge Audio’s policy is one of continuous improvement, therefore design and specifications are
subject to change without prior notice.
This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without prior written permission of the manufacturer. All trademarks and registered trademarks
are the property of their respective owners.
© Copyright Cambridge Audio Ltd 2022
For upcoming news on future products, software updates and exclusive offers, make sure you register your product
at https://www.cambridgeaudio.com/register
5
What's included with the AXC25/35?
Last updated: July 29, 2022 10:27. Revision #7166
Inside the box of your AXC25/35 you will receive:
1. AXC CD player.
2. Remote control.
3. 2 x AAA batteries.
4. UK mains lead (Depending on which country the AXA35 was bought).
EU mains lead (Depending on which country the AXA35 was bought).
CU mains lead (Depending on which country the AXA35 was bought).
JP mains lead (Depending on which country the AXA35 was bought).
5. Quick start guide.
6. Safety guide.
6
Front panel controls
Last updated: August 9, 2022 02:50. Revision #7165
1. Power button - Switches the unit between Standby mode (indicated by dim power LED) and On (indicated by bright power LED). Standby mode
is a low power mode where the power consumption is less than 0.5 Watts. This product has APD (Auto Power Down) enabled as default. After
inactivity of 20 minutes, the product will automatically switch to Standby.
Auto Power Down (APD) You can enable and disable the unit’s APD setting. This can be adjusted by pressing and holding the Power button until
the LED flashes in sequence.
The two options below show which option is selected.
Standby flashes 5 times - APD disabled
Standby flashes 10 times - APD enabled
Note: Make sure the unit is On, before making changes to the APD function.
2. Infrared sensor - Receives IR commands from the supplied remote control. An unobstructed line of sight between the remote control and the
sensor is required.
3. Display - Alpha-numeric characters which display playback information. On inserting a disc, the CD player will take a few seconds to read the
Table of Contents (TOC) information from the disc. The display will then show the number of tracks on the CD and the total length of the CD.
4. Open/Close - Allows you to open and close the disc tray. After placing a CD in the tray, press Open/ Close to close the tray.
5. Play/Pause - Plays the CD and pauses play.
6. Stop - Stops the CD playing.
7. Skip/Scan - Enables you to skip between and search within tracks. Press briefly to skip a track. Press and hold to scan through a track.
7
Rear panel connections
Last updated: July 29, 2022 10:27. Revision #7164
1. S/P DIF CO-AXIAL DIGITAL OUTPUT (AXC35 ONLY) - For input to a separate DAC or digital recording machine. To obtain best results, use a
high quality 75 Ohm digital RCA interconnect cable (not one designed for normal audio use).
2. LINE OUTPUT - Use good quality interconnect cables from these sockets to any line level input on your amplifier. For best results and matched
performance, we recommend connection to a Cambridge Audio amplifier.
3. AC POWER CABLE - Once you have completed all connections to the amplifier, plug the AC power cable into an appropriate mains socket and
turn the unit on. Your compact disc player is now ready for use.
8
Remote control
Last updated: July 29, 2022 10:27. Revision #7163
The AXC25 and AXC35 are supplied with a remote control that operates the unit.The supplied AAA
batteries must be fitted before the remote control can be used.
1. POWER BUTTON - Switches the AXC35/AXC25 between On and low power eco-friendly Standby
mode.
2. OPEN/CLOSE - Opens and closes the disc tray.
3. NUMERICAL TRACK SELECT - Press the number of the desired track. The track will then play
automatically from the start of the track.
4. PROG - Allows you to program a unique sequence of up to 20 tracks. Refer to ‘Operating
Instructions’ section of this manual for more information.
5. PROG CLEAR - Clears a programmed sequence. See later section of this manual.
6. PAUSE/STOP/PLAY - Press the relevant button to pause, stop or play the CD.
7. SKIP
Right Skip – Press to skip forward by one track on the CD.
Left Skip – Press to skip backward by one track on the CD.
8. SCAN - Press and hold to scan within the selected track. Press the right button to fast forward, the
left button to rewind.
9. RANDOM, REPEAT, REMAIN - Read the ‘Operating Instructions’ section of this manual for
information on the functions of these buttons.
AXA35
The following controls on the remote are to operate the AXA35 unit only.
10. VOLUME - Increases or decreases the volume of the unit. Also used to change the bass, treble
and balance settings when these are selected.
11. MENU - Toggles between Bass, Treble and Balance options. Use the volume buttons to change
the level of the selected option.
12. SOURCE BUTTONS (CD, BD/DVD, MP3/AUX, TUNER, PHONO) - Press the relevant button to
select the desired music source.
13. MUTE – Mutes the output of an AXA35.
Note: These controls work on the AXA35 only and are not compatible with Cambridge Audio Azur
amplifiers/receivers or units from other manufacturers
9
Getting connected
Last updated: August 1, 2022 04:32. Revision #7162
Line Output connection
The line outputs are for connecting to the line level inputs on an amplifier. The diagram below shows a connection to an amplifier.
S/P DIF CO-AXIAL Digital Output connection (AXC35 ONLY)
The S/P DIF output is for connecting to the input of a separate digital device, such as a DAC or digital recording machine. The Diagram below shows
a connection to an external DAC.
10
Operating instructions
Last updated: August 1, 2022 04:31. Revision #7161
The AXC25/35 has been designed to only play:
Compact discs
Recordable CDs (CD-R)
Re-writable CDs (CD-RW) bearing the identification logo shown above.
Note: The CD-R/CD-RW discs should contain properly recorded TOC (Table of Contents) information so that they can be played back.
The AXC25/35 can only play the discs recorded in the CDDA format designed for music reproduction or those containing MP3 or WMA files. Do not
attempt to play a disc on this unit containing other data, such as a data CD-ROM for PCs.
LOADING AND UNLOADING DISCS
1. Using the front panel or remote control, press the ‘Open/Close’ button to open the disc tray.
2. Once the disc tray has fully opened, carefully place a disc into the tray with the label side facing upwards.
3. Close the disc tray by pressing the ‘Open/Close’ button again. When the tray has fully closed the AXC25/35 will read the disc and display the
content information.
4. The disc tray can be opened at any time during playback using either the front panel ‘Open/Close’ button, or the one located on the remote
control. Only remove an inserted disc after the disc tray has fully opened.
Important Information:
Do not put anything except for a compact disc into the disc tray as this can damage the mechanism.
Do not force the tray by hand during opening and closing operations.
To avoid dirt and dust entering the mechanism, keep the disc tray closed when not in use.
If the compact disc that you are attempting to load is badly scratched or dirty, the player may be unable to read or play it.
Never attempt to load multiple discs into the disc tray at any time.
Normal Disc Play
1. Switch on your amplifier and set its input selector to the correct position. Adjust the volume control to a minimum.
2. Press the Open/Close button to open the disc tray and load a disc.
