Calculated Industries 8525 Manuel utilisateur
PROJECTCALC
®
PLUS
4840 Hytech Drive
Carson City, NV 89706 U.S.A.
1-800-854-8075 or 1-775-885-4900
Fax: 1-775-885-4949
E-mail: [email protected]
www.calculated.com
Model 8525/8526
TABLE OF CONTENTS
Key Definitions ................................1
Basic Dimensional Math....................10
Linear Conversions ................................10
Square and Cubic Conversions ..............11
Basic Dimensional Math ........................11
“Square-up”/Diagonal ............................12
Project Examples-Using Default Values..12
Paint: Gallons, Quarts, or Pints of ..........12
Wallpaper: Rolls of..................................13
Tiles: Number of ....................................13
Custom Tiles: Number of - Using Other
Than Default Custom Size....................14
Deck: Number of Boards ........................15
Fence: Number of Fence Boards,
Posts and Rails....................................15
Board Feet: Lumber Estimation ..............16
Studs: Number of ..................................16
Roofing: Bundles of Roof Shingles ........17
Drywall: Number of 4’ x 8’ Sheets ..........17
Carpet: Length of ....................................17
Concrete: Bags of ..................................18
Bricks/Blocks: Number of, for a Wall......18
Gravel: Tons of........................................19
Mulch: Number of Bags..........................19
Finding the Cost of Materials ..............20
Auto Shut-Off and Batteries ................20
Repair and Return ..........................21
POCKET REFERENCE GUIDE - 1
o-On/Clear Key
Turns power on. Pressing once
clears the display. Pressing twice
clears all temporary values.
Ç o - Off
Turns all power off, clearing all non-
permanent registers.
r- Recall
Recalls stored values.
+ – x ÷ =
Arithmetic operation keys.
0- 9and
•
Digits used for keying in numbers.
Dimensional Unit Keys
y- Yards Key
Enters or converts to Yards.
f- Feet Key
Enters or converts to Feet as whole
or decimal numbers. Also used with
the i and /keys for entering
Feet-Inch-Fraction values (e.g., 6
f 9 i 1 / 2 ). Repeated
presses during conversions toggle
between Feet-Inch-Fractions and
Decimal Feet.
KEY DEFINITIONS
POCKET REFERENCE GUIDE - 2
i- Inch Key
Enters or converts to Inches. Entry
can be whole or decimal number.
Also used with the /key for entering
Fractional Inch values (e.g., 9i
1 / 2 ). Repeated presses during
conversions toggle between
Fractional and Decimal Inches.
/- Fraction Bar Key
Used to enter fractions. Fractions
can be entered as proper (1/2, 1/8,
1/16) or improper (3/2, 9/8).
m- Meter Key
Enters or converts to Meters.
Convert Key Functions
Ç-Convert Key
Used with the dimensional unit keys
to convert between dimensions, the
Project Keys to calculate material
quantities, or with other keys to
access special functions.
Ç x - Clear All
Clears all stored values and sets cal-
culator back to defaults.
Ç / - Percent (%)
Four-function (+, -, x, ÷) percent.
POCKET REFERENCE GUIDE - 3
Ç – - Change Sign (+ / -)
Toggles displayed value to positive or
negative. (Repetitive presses of Ç
–will change sign from positive or
negative.)
Ç ÷ - Square Root
Finds Square Root of value in display.
Ç + -x2
Finds Square of value in display.
Ç s - Pi (π)
Constant 3.141593.
Memory
s m (M+) - Adds or stores a value
in the semi-permanent memory (e.g.,
1 5 0 s m). Semi-permanent
means the value is cleared when the
calculator is turned off.
Ç – s m (M-) - Subtracts a
value from the semi-permanent
Memory (e.g., 1 5 0 Ç – s
msubtracts 150 from the memory).
r m (M-R/C) - Recalls Memory value
(e.g., if 150 has been stored in Memory,
pressing r m will display 150).
r r - Displays and clears Memory
value.
POCKET REFERENCE GUIDE - 4
Entering Square or Cubic
To label a dimension as “Square” or
“Cubic,” enter the value, then press the
desired dimension key twice for
Square and three times for Cubic. For
example, to enter 25 Cubic Yards,
press 2 5 y y y.
Fraction Resolution
Your calculator is set to display Fractional
values to the nearest 16th of an Inch
(default setting). Press r / to access
the fraction resolution setting. Repeated
presses of /will then revolve through
the available settings: 1/16, 1/32, 1/64,
1/2, 1/4 and 1/8. Press oto exit.
Project Keys
p- Paint
Calculates volume of paint, based on
an entered area and a stored Paint
Coverage per Gallon (see below).
Finds quantity in Gallons, Quarts or
Pints upon repeated presses.
s p - Stores Paint Coverage
Stores Paint Coverage per Gallon. To
recall this setting, press r p.
Default is 350 sq.ft. per gallon.
POCKET REFERENCE GUIDE - 5
w- Wallpaper
Calculates number of rolls of wallpaper,
based on an entered area and a stored
Wallpaper Roll Coverage Area (see
below).
s w - Stores Wallpaper Roll
Coverage Area
Stores Coverage Area (in Square
Feet) per Wall-paper Roll. To recall
this setting, press r w. Default
is 56 Square Feet per roll.
t - Tile
Finds the number of tiles, based on
an entered area and a user-stored
Grout Width (see below). Repeated
presses will scroll between numbers
of tiles for various “standard” tile
sizes (18”, 16”, 13”, 12”, 10”, 8”, 6”,
4”, 2”, 1” and 24”).
Note: Tile sizes shown in Inches, not Square
Inches (as used in custom tile size calculations).
In other words, a 6” tile is really 6” x 6”, or a 36
Square-Inch tile, but it is labeled as a 6” size.
s t - Stores Grout Width
Stores Grout Width in Inches; used in
calculating the number of tiles (see
above). To recall this setting, press
r t. Default is 0 (no grout width).
d- Deck
Finds the number of boards for a deck,
based on an entered area and a stored
Board Width or Board On-Center
(see below). Repeated presses will
scroll between numbers of boards for
various “standard” board lengths
(12’, 10’, 8’, 20’, 18’, 16’ and 14’).
s d - Stores Board Width/O.C.
Stores Board Width or Board On-center
for deck or fence calculations. To recall
this setting, press r d. Also used
to store the board On-center for Fence
Spacing. Default is 5-11/16 Inches.
F- Fence
Multi-function key that finds the
number of fence boards, number of
posts and number of rails based on
an entered distance, Board
Width/O.C. and post spacing.
s F - Stores Post Spacing
Stores Post Spacing On-center for
fence in Feet-Inches. To recall this set-
ting, press r F. Default is 8 Feet.
Ç 7 - Board Feet
Calculates number of board Feet
based on entered volume. One board
foot equals 144 Cubic Inches.
POCKET REFERENCE GUIDE - 6
POCKET REFERENCE GUIDE - 7
Ç8- Studs
Calculates number of studs, based on
an entered linear distance and a stored
On-Center Spacing (see below).
Note: Automatically adds one stud to the calcu-
lated answer to account for one on the end.
s 8 - Stores On-Center for Studs
Stores On-center spacing for studs in
Inches. To recall this setting, press
r8. Default is 16”.
Ç 9 - Roof Bundles
Calculates number of bundles of roof
shingles, based on an entered roof
area and a stored Area per Roof
Bundle (see below).
s 9 - Stores Area per Roof Bundle
Stores the Coverage Area per Roof
Bundle. To recall this setting, press
r 9. Default is 33.33 sq.ft.
Ç 4 - 4x8 Sheet
Calculates number of 4’ x 8’ sheets
(for drywall, paneling), based on
entered linear distance or area.
Ç 5 - Carpet
Calculates carpet length required (of
either 12’, 13’ or 15’-wide carpet rolls),
based on entered area. Repeated
presses of 5will scroll between values
for 12’, 13’, and 15’ rolls.
POCKET REFERENCE GUIDE - 8
Ç 6 - Custom Tile
Calculates number of tiles based on an
entered area and a stored Custom Tile
Size (see below). This is used sepa-
rately from the regular Tile Key ( t).
Note: Calculation does not account for grout width
for custom tiles, so you will need to adjust for this.
s 6 - Stores Custom Tile Size
Stores Custom Tile Size in Square
Inches. To recall this setting, press
r 6. Default is 24 Square Inches.
Ç 1 - Concrete
Calculates the number of bags of con-
crete required, based on an entered vol-
ume (e.g., cubic feet or cubic yards) and
a stored Volume per Bag (see below).
s 1 - Stores Concrete Volume per Bag
Stores the Volume per Bag of
concrete. To recall this setting, press
r 1. Default is 0.67 Cubic Feet
per bag (80 lbs.).
Ç 2 - Brick
Calculates the number of standard
eight Inch-size U.S. bricks (with 3/8”
mortar) based on entered linear
distance (or area, volume) for both
“face” (21-Square Inch) and “paver”
(32-Square Inch) brick applications.
