Caenrfid Easy2read qID R1240IE Document technique

TECHNICAL INFORMATION MANUAL

Revision 0 –05 April 2018

R1240IE/IU

Wearable Bluetooth UHF RFID/BARCODE Reader

Scope of Manual

The goal of this manual is to provide the basic information to work with the qID R1240IE/U Wearable Bluetooth UHF

RFID/BARCODE Reader.

Change Document Record

Date

Revision

Changes

Pages

5 Apr 2018

Preliminary release

Reference Document

[RD1] EPCglobal: EPC Radio-Frequency Identity Protocols Class-1 Generation-2 UHF RFID Protocol for

Communications at 860 MHz –960 MHz, Version 2.0.1 (April, 2015).

CAEN RFID srl

Via Vetraia, 11 55049 Viareggio (LU) - ITALY

Tel. +39.0584.388.398 Fax +39.0584.388.959

[email protected]

www.caenrfid.com

Preliminary Product Information

This document contains information for a new product. CAEN RFID reserves the right to modify this product without

notice.

“Preliminary” product information describes products that are ready for production, but for which full characterization

data is not yet available. CAEN RFID believes that the information contained in this document is accurate and reliable.

However, the information is subject to change without notice and is provided “AS IS” without warranty of any kind

(Express or implied). You are advised to obtain the latest version of relevant information to verify, before placing

orders, that information being relied on is current and complete. All products are sold subject to the terms and

conditions of sale supplied at the time of order acknowledgement, including those pertaining to warranty, patent

infringement, and limitation of liability. No responsibility is assumed by CAEN RFID for the use of this information,

including use of this information as the basis for manufacture or sale of any items, or for infringement of patents or

other rights of third parties.

Disposal of the product

Do not dispose the product in municipal or household waste. Please check your local regulations for

disposal/recycle of electronic products.

Visit qID R1240IE/IU web page, you will find the latest revision

of data sheets, manuals, certifications, technical drawings, software and firmware.

All you need to start using your reader in a few clicks!

Index

Scope of Manual...........................................................................................................................................................................2

Change Document Record............................................................................................................................................................2

Reference Document....................................................................................................................................................................2

Index ...........................................................................................................................................................................................3

List of Figures.................................................................................................................................................................................3

List of Tables..................................................................................................................................................................................3

1INTRODUCTION...................................................................................................................................................................5

Product Description......................................................................................................................................................................5

Front panel.......................................................................................................................................................................6

USB connector .................................................................................................................................................................7

Accessories ...................................................................................................................................................................................7

Installation Notice ........................................................................................................................................................................8

Ordering Options ..........................................................................................................................................................................9

2GETTING STARTED.............................................................................................................................................................10

Introduction................................................................................................................................................................................10

Installing the USB Virtual COM port driver.................................................................................................................................10

Bluetooth Communication Setup ...............................................................................................................................................12

Connecting the qID Reader.........................................................................................................................................................12

Connecting the qID using the Easy Controller for Windows ..........................................................................................12

3CONFIGURATION...............................................................................................................................................................15

Configuration file........................................................................................................................................................................15

Scripting capability .....................................................................................................................................................................17

4RESET THE READER............................................................................................................................................................18

5FIRMWARE UPGRADE .......................................................................................................................................................19

6BARCODE ..........................................................................................................................................................................22

Barcode Reader ..........................................................................................................................................................................22

7POWER CONSUMPTION AND BATTERY LIFE.......................................................................................................................24

Battery Life .................................................................................................................................................................................24

Inventory RFID by Bluetooth ......................................................................................................................................................25

Inventory RFID by Script Mode...................................................................................................................................................26

Scan Barcode by Bluetooth ........................................................................................................................................................26

Scan Barcode by Script Mode.....................................................................................................................................................26

8TECHNICAL SPECIFICATIONS ..............................................................................................................................................27

Technical Specifications Table ....................................................................................................................................................27

Reader –Tag Link Profiles...........................................................................................................................................................28

Radiation Patterns......................................................................................................................................................................28

9REGULATORY COMPLIANCE...............................................................................................................................................30

RoHS EU Directive.......................................................................................................................................................................30

List of Figures

Fig. 1.1: qID R1240IE/IU UHF RFID USB/Bluetooth Reader......................................................................................................................5

Fig. 1.2: qID R1240IE/IU UHF RFID USB/Bluetooth Reader with silicone cover.......................................................................................6

Fig. 1.3: qID R1240IE/IU Front Panel .......................................................................................................................................................6

Fig. 1.4: qID R1240IE/IU Accessories .......................................................................................................................................................7

Fig. 1.5: qID R1240IE/IU Inserting the strap ............................................................................................................................................8

Fig. 2.1: qID R1240IE/IU directory structure..........................................................................................................................................11

Fig. 4.1: qID R1240IE/IU Front Panel .....................................................................................................................................................18

Fig. 7.1: Easy Controller Software: Continuos Inventory Options window ............................................................................................25

Fig. 8.1: qID R1240IE/EB Radiation pattern H plane ..............................................................................................................................28

Fig. 8.2: qID R1240IE/EB Radiation pattern V plane ..............................................................................................................................28

Fig. 8.3: qID R1240IU/UB Radiation pattern H plane.............................................................................................................................29

Fig. 8.4: qID R1240IU/UB Radiation pattern V plane .............................................................................................................................29

List of Tables

Tab. 1.1: qID R1240IE/IU Front Panel LEDs and Buttons .........................................................................................................................6

Tab. 1.2: qID R1240IE/IU Power LED Status Table...................................................................................................................................7

Tab. 1.3: qID R1240IE/IU USB/Bluetooth LED status table ......................................................................................................................7

Tab. 3.1: qID R1240IE/IU Power LED Status Table.................................................................................................................................15

Tab. 8.1: qID R1240IE/IU Technical Specifications Table .......................................................................................................................27

Tab. 8.2: qID R1240IE/IU Reader to tag link profiles .............................................................................................................................28

INTRODUCTION - qID Technical Information Manual 5

1INTRODUCTION

Product Description

The qID (Model R1240IE, R1240IU), mobile reader of the easy2read©Family, is an UHF multiregional RFID reader with

integrated antenna for short to medium range applications. It is compliant with ISO 18000-6C/EPC C1G2 standards.

The reader hosts an internal rechargeable battery and can operate both in wired mode, using a USB cable, or in

wireless mode through the Bluetooth® interface.

Thanks to the Bluetooth® communication interface, the qID is a perfect add-on for any Bluetooth® enabled host such

as a PC, a smartphone, a PDA or a tablet for UHF RFID readings. The reader is compatible with Windows XP/7/8/10,

Windows CE/Mobile, Android, iPhone and iPad.

The reader can also operate in “Batch Mode”, allowing to store up to 500.000 EPC codes into the internal memory

when the communication links (USB or Bluetooth®) are not available.

An optional 1D/2D barcode imager enables the qID to read most of the barcode standards. This enables the qID to be

the perfect identification device in mixed barcode/RFID labels environment.

When paired to a smartphone or a tablet, the qID is a cost effective alternative to more expensive handheld devices.

Designed for mobile operators in indoor or outdoor areas, the qID is ideal for inventory management, field sales

mobility, service and maintenance applications.

Fig. 1.1: qID R1240IE/IU UHF RFID USB/Bluetooth Reader

INTRODUCTION - qID Technical Information Manual 6

Fig. 1.2: qID R1240IE/IU UHF RFID USB/Bluetooth Reader with silicone cover

Front panel

The qID R1240IE/IU front panel houses the following LEDs and buttons (see figure below):

Fig. 1.3: qID R1240IE/IU Front Panel

No.

Name

Description

1 Power LED

Indicates the reader status and battery level (see § Tab. 1.2: qID

R1240IE/IU Power LED Status Table)

2 Link LED

Indicates the USB/Bluetooth communication status (see § Tab.

1.3: qID R1240IE/IU USB/Bluetooth LED status table)

3 Trigger LED

A green blink indicates a successfully executed operation, a red

blink a failure

4 Power button

Press the button to switch on the reader, press for at least 2

seconds to switch it off

5 Trigger button

A single press of the trigger button executes an inventory cycle,

pressing for more than 1 second starts a continuous inventory

process

Tab. 1.1: qID R1240IE/IU Front Panel LEDs and Buttons

INTRODUCTION - qID Technical Information Manual 7

Status

Description

Steady green

Reader is active and battery if fully charged

Blinking green

Reader is in std-by and battery is fully charged

Steady orange

Reader is active and battery is discharging

Blinking orange

Reader is in std-by and battery is discharging

Steady red

Reader is active and battery is almost empty

Blinking red

Reader is in std-by and battery is almost empty

Tab. 1.2: qID R1240IE/IU Power LED Status Table

For more information about qID battery life, please refer to § POWER CONSUMPTION AND BATTERY LIFE page 24.

Status

Description

OFF

No connection established

Steady orange

USB cable connected (both to a PC or to the AC power adapter)

Blinking orange

USB communication on going

Steady blue

Bluetooth connected

Blinking blue

Bluetooth communication on going

Tab. 1.3: qID R1240IE/IU USB/Bluetooth LED status table

USB connector

A micro USB Type B socket connector is located in the bottom side of qID R1240IE/IU and can be used to connect the

reader to an USB host port or to an AC/DC battery charger.

In case the reader is connected to a standard USB port the battery charge is performed at 500mA max. (slow charge

mode), in case it is connected to the AC/DC adapter charge current is 1A max. (fast charge mode).

Please consider that when the reader is attached to a PC via USB cable, the battery recharge is active only with device

in stand-by mode (power LED blinking orange).

Accessories

Check for the supplied accessories below:

No. 1 USB cable No. 1 Power supply

No. 1 strap

Fig. 1.4: qID R1240IE/IU Accessories

INTRODUCTION - qID Technical Information Manual 8

Installation Notice

To insert the qID strap, please follow the instructions shown in the following figures:

Step 1

Step 2

Step 3

Step 4

Step 5

Fig. 1.5: qID R1240IE/IU Inserting the strap

INTRODUCTION - qID Technical Information Manual 9

Ordering Options

Code

Description

Reader

WR1240IXEAAA

R1240IE - qID Wearable Bluetooth UHF RFID Reader (ETSI)

WR1240IXEBAA

R1240IEB - qID Wearable Bluetooth UHF RFID/BARCODE Reader (ETSI)

WR1240IXUAAA

R1240IU - qID Wearable Bluetooth UHF RFID Reader (FCC)

WR1240IXUBAA

R1240IUB - qID Wearable Bluetooth UHF RFID/BARCODE Reader (FCC)

Accessories

EACCESCDRF06

R1240I Silicone Cover

GETTING STARTED - qID Technical Information Manual 10

2GETTING STARTED

Introduction

This quickstart guide will help you to get started with your qID reader.

For more detailed information on reader configuration, connections and setup options please refer to the next

chapters.

Installing the USB Virtual COM port driver

The qID reader can be connected to a PC using the provided USB cable and it is detected by the PC as a composite USB,

that is as an emulated serial port (VCP) and as an USB MSC.

Power ON the reader and plug the USB cable into the qID USB port.

After a while, from one side, a new storage device should appear under the computer directory and, from the other

side, a dialog window appears informing you that the device is not recognized and you should be prompted for

inserting the reader's USB VCP driver (download the driver at qID R1240IE/IU web page, SW/FW section) in order to

correctly operate with the reader.

After installing the driver, the reader is detected by the PC as an emulated serial port (VCP) and as an USB MSC:

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels caenrfid Lecteur de codes-barres

caenrfid

caenrfid Quattro R4321P Document technique

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur

caenrfid easy2read qID R1240IE Document technique

Manuels Lecteur de codes-barres populaires d'autres marques
