Features

Related Products

ITEM#

PROJECT

DATE

For current speciﬁcation sheets and other information, go to www.bunn.com.

Patents Apply

INTERNATIONAL

7/09 A6.2a

International models may vary in appearance.

Liquid Coffee Refrigerated

Dispenser with 2 heads - Multi-Phase

LCR-2A, PC Multi-Phase

Dimensions: 38” H x 12.2” W x 24.9” D

(96.5 cm H x 31 cm W x 63.2 cm D)

Easy Clear®EQHP-10

Product No. : 39000.0004

Easy Clear®EQHP-10L

Product No.: 39000.0001

Easy Clear®EQHP-25

Product No. : 39000.0005

Easy Clear®EQHP-25L

Product No.: 39000.0002

Scholle BIB connector

Product No. : 35057.0000

1⁄8" Replacement tube kits

Product No. : 34728.1000

3⁄16" Replacement tube kits

Product No. : 34727.1000

50ml Graduated Cylinder Kit

Product No. : 34843.1000

For use in calibration of pumps.

LiquiBox QC/D II

BIB connector

Product No. : 35055.0000

Liquid Coffee Refrigerated Dispenser

• Refrigeratedproductcabinetextendsproductavorprole,maintains

38º-42ºF(3.3º-5.5ºC)inproductcompartment.

• Attractiveappearanceandnarrow12"(30.48cm)width.

• Accommodatesall1⁄2gallon(1.9litre)andmost1gallon(3.8litre)bag-in-

box(BIB)containers.

• RellorrinseLEDlightsalerttheoperatorwhenmoreconcentrateor

cleaningisneeded.

• FlavorGard™technologycontinuouslymonitorsextract-to-waterratioand

assuresavorconsistency.

• Easy-to-program,one-touchportioncontrolmodelforself-serve

applications.

• Dispenseshotwaterondemand.

• Dispensercanbeeldconvertedtooperationeithersingleorthreephase.

BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such

revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.

All dimensions shown in centimeters.

Dimensions & Speciﬁcations

Bunn-O-Matic®Corporation-1400StevensonDriveSpringeld,Illinois62703•USA•+1-217-529-6601•Fax+1-217-529-2827•www.bunn.com

Model Product Dispense Rate/Sec. Connector Shipping Cord Agency

Number 1.8 oz. 2.5 oz.* Type Weight Attached

Product Ratios

LCR-2A,PCMulti-Phase 36500.0054 45:1-100:165:1-100:1 1/8”Scholle1910 85lbs.(38.6kg) No

LCR-2A,PCMulti-Phase 36500.0055 25:1-45:125:1-65:1 3/16”Scholle1910 85lbs.(38.6kg) No

Phase Volts Amps Watts *Cups/hr *Litres/hr

 Single 230 13 3000 311 39

Single(2tankheaters) 230 26 6000 620 78

 Three 400/230 13 9000 932 116

*Unit shipped with dispense rate set at 1.8 oz./sec. Dispense rate increases to 2.5 oz./sec. if restrictor plug is removed.

Brewing Capacity: Measured with 5oz/125mL cup. Based on incoming water at 68˚F (20˚C) and minimum cup temperature at 185˚F (85˚C).

Electrical: SinglePhasecongurationrequires2-wiresplusgroundservicerated230V,singlephase,50/60Hz.

 ThreePhasecongurationrequires4-wiresplusgroundservicerated400/230V,threephase,50/60Hz.

Plumbing: 20-90psi(138-621kPa)froma3⁄8"orlargersupplyline.Unitrequiresa2.2gpm(8.3litreperminute)lineowcapacity.A

shut-offvalveshouldbeinstalledinthelinebeforetheunit.Installaregulatorinlinewhenpressureisgreaterthan90psi

(621kPa)toreducepressureto50psi(345kPa).Suppliedwith3⁄8"malearetting.

7/09 © Bunn-O-Matic Corporation
