Buchi NIRMaster Manuel utilisateur

11594031A en

NIRMaster™

08.2018

BÜCHI Labortechnik AG

Meierseggstrasse 40

Postfach

CH-9230 Flawil 1

E-Mail: [email protected]

Connecting a computer to a NIRMaster™ with no embedded PC and finalizing installation.

To initialize a NIRMaster™ and connect to a computer the basic steps are as follows:

uConnect the instrument to the computer using the ethernet cable supplied.

uConnect the mains cable to the instrument.

uUndo the transportation lock.

uSwitch on the instrument, by holding in the power switch on the left hand side.

uStart the computer and install the NIRWare software.

uSet up the network settings to allow communication between computer and NIRMaster™.

uOperate the NIRMaster™ as normal.

Connect the NIRMaster™ to the PC using the supplied ethernet cable

uRemove the cover from the top of the Instrument with

the key provided. (Two fixings on the left hand side,

two fixings on the right hand side)

uRoute the ethernet cable through the cable gland in the lower chassis.

uConnect the cable to the ethernet socket on the rear

of the cream colored optical bench.

Connect the mains cable.

üThe cover is removed.

uRoute the mains cable through the cable gland in the lower chassis.

uConnect the cable to the main socket at mounted on

the rear of the instrument lower chassis.

NIRMaster™

Supplement Installation Manual

Undo the transportation lock

üThe cover is removed.

uLocate the interferometer transport locking mechanism (note the position of

the red painted screw).

uRotate the lower part of the mechanism clockwise until it locks into the un-

locked position (note the position of the red painted screw).

uReinstall the instrument cover and secure fixings.

Install the BUCHI NIRWare software on the computer

Install BUCHI NIRWare software suite following the instruction in Chapter 4 “Software Installation” of the NIRWare

Quick Guide.

Note!

Activate the relevant licences for software and any pre-calibrations that are required.

NIRMaster™ Supplement Installation Manual BÜCHI Labortechnik AG

Setting up the network connection between computer and NIRMaster™

In this step the communication connection between the NIRMaster™ and computer is set up.

uStart the computer, and open the dialog box Ethernet Properties.

uHighlight the option [Internet Protocol Version 4 (TCP/IPv4)] from the

list.

uClick the button [Properties].

ðThe dialog box Internet Protocol Version 4 (TCP/IPv4) open.

uActivate the radio button next to [Use the following IP address].

uEnter the following values.

• IP address: 192.168.1.2

• Subnet mask: 255.255.255.0

uClick the button [OK].

ðThe dialog box Internet Protocol Version 4 (TCP/IPv4) close.

uClick the button [OK].

ðThe dialog box Ethernet Properties close.

The network settings are now correctly set up so communication between the NIRMaster™ and computer is possible.

Start NIRWare operator software and verify that the Computer is correctly connected to the NIRMaster™.

NIRMaster™ Supplement Installation ManualBÜCHI Labortechnik AG
