Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

Diverse 4010 Executive

Digital Cordless Telephone

User

Guide

*YOU MUST

SUBSCRIBE TO A

CALLER DISPLAY AND

CALL WAITING SERVICE

BEFORE YOUR DIVERSE 4010

EXECUTIVE WILL DISPLAY T IS

INFORMATION. A QUARTERLY

FEE IS PAYABLE.

This equip ent is not designed for aking e ergency telephone calls when the power fails.

Alternative arrange ents should be ade for access to e ergency services.

This product is intended for connection to analogue public switched telephone networks

and private switchboards in the United Kingdo .

The Art of Communication

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

Please open this page for an ‘At a glance’ guide

to your Diverse 4010 Executive.

WXYZ

PQRS

8TUV

GHI

3DEF

5JKL

2ABC

6MNO



 INT M 



At a glance

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

Hash/Keyguard

Hold down to switch the

keypad guard on and off.

Recall

Press for use with switchboards and certain

Network Services. Press and hold down to access an

extra directory for storing 10 names and numbers.

Calls list

Lets you access your

lists – calls, text and

voice mail.

Keypad

Red phone

Press to end a call,

return the display to idle

or turn the power on and

off.

Options buttons

Lets you select from the

menu options shown in

the display.

Display

Displays the status of

your handset.

Star/bell

Switches the handset

ringer on and off.

Microphone

One button

Apart from being the

number one button hold

down to access your

Voice Mail service or

answering machine.

Handsfree

Use to answer calls or

make a call in handsfree

mode.

Green phone

For making and

answering calls.

Directory

Used to store numbers,

names and birthdays in

the directory.

Navigation button

Let you display and

select on-screen

options.

n use light

Lights up when the

handset is in use and

flashes to indicate calls,

messages, alarm calls or

appointment reminders.

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

andset display

Display option buttons

Navigation button

Idle Screen



 INT M 



Base Base underside

Page button

Power socket

Telephone line cord socket

Contact points

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

In this guide

At a glance 1

Main menu structure 4

Directory 5

Messages 5

Quick guide 6

Quick guide to handset

display icons

Introduction 8

Unpacking your

Diverse 4010 Executive 8

For your records 8

Safety instructions 9

Setting up 10

Using the telephone 15

Making and ending calls 15

Handsfree 1

Using the directory 17

Character map 18

Redial 22

Secrecy 23

Paging and internal calls 23

Caller Display and other

Select Services 26

Calls list 2

Call Waiting 30

Other Select Services 30

Additional features 33

Voice mail 33

Alarm clock and appointments 34

Walk and Talk 37

Room monitor 38

Handset settings 41

Call Barring 4

Base Station settings 4

Base Station PIN 47

Using additional handsets

and bases 50

Registering additional handsets 50

Help 54

General information 5

Guarantee 57

Technical information 57

Switchboard compatibility 58

Index 62

Hints and tips boxes

In this user guide, we’ve included

helpful tips and important notes.

They are shown in boxes like this.

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

Main menu

1 Text essage 1-1 Write essage

1-2 Inco ing

1-3 Outgoing

1-4 Service Centre.

Service Centre.

2 Select Services 2-1 Withhold No.

2.2 Call Waiting

2.3 Ringback off

2.4 Call Divert

3 Additional Features 3-1 Roo Monitor

3-2 Walk and Talk

4 Calendar Clock 4-1 Set Appoints. [entry]

4-2 Alar Clock [entry]

4-3 Missed Dates [entry]

4-4 Date/Ti e [entry]

5 Sound Settings 5-1 Handset Volu e [entry]

5-2 Ringer Settings [entry]

5-3 Advisory Tones [entry]

6 Handset Settings 6-1 Auto Answer

6-2 Language [list]

6-3 Register H/Set [list]

6-4 Select Base [list]

6-5 Reset Handset

7 Base Settings 7-2 Syste -PIN [entry]

7-3 Base Reset

7-4 Add.Features 7-4-1 Dialling ode 7-4-1-1 Tone

7-4-1-2 Pulse

7-4-1-3 DTMF

Earth

7-4-2 TBR 7-4-2-1 80 s

8-4-2-2 etc

until

8-4-2-8 600 s

7-4-3 Repeater ode

7-4-4 Access Code

7-4-5 Add. E erg. No

7-4-6 Listening in

8 Voice ail 8-1 Set key 8-1-1 Mailbox

Note

If your handset is registered to a Diverse 4000 answering machine base, you will

have additional menu’s in No.8 Voice Mail. Please refer to your Diverse 4016

guide to see what further menus are now available.

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

directory

to name or number you want to dial

Dial from Calls list

to display Caller List to display the number you want

Adjust handsfree

to display Sound settings display shows Handset volume

volume

to decrease volume to increase volume

Adjust earpiece

to display Sound settings display shows Handset volume

volume

to decrease volume to increase volume

ake internal call

to display the list of internal users

Call all handsets

to Call All

Transfer call to

another handset

caller is on hold to display Internal Users

Put caller on hold

while you make

to put caller on hold to display Internal Users

an internal call

Set date and time

to display Calendar/Clock to display Date/Time

enter settings

Set alarm clock

to display Calendar/Clock to display Alarm clock

enter settings

Save

OK OK Menu

Save

OK OK Menu

End OK

Save OK

OK Menu

Save OK

OK Menu

Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

Quick guide to handset

display icons

Redial, lists up to the last 5 dialled nu ber.

Indicates essages in the Calls list.

Flashes to indicate new essages.

For calling other handsets.

Opens the enu.

Shows the status of the handset battery.

Shows the range status.

Displayed when the handset ringer is set to off.

Confir s the function displayed.

Deletes nu bers/characters (fro left to right).

Keypad locked.

Displayed when the Alar clock and appoint ents are set.

Displayed when a birthday date is set.

INT

enu

WXYZ

PQRS

TUV

GHI

DEF

JKL

ABC

MNO





INTM





Diverse 4010 Executive ~ 9th Edition ~ 17th July ~ 3662

Introduction

Unpacking your

Diverse 4010 Executive

If anything is missing, please contact

your place of purchase immediately.

One Diverse 4010

Executive base station

One Diverse 4000

Executive handset

One power supply

for the base station

One telephone

line cord

Two AA rechargeable

batteries

One belt clip

Battery compartment

cover

For guarantee purposes proof of

purchase is required so please keep

your receipt.

Enter your system PIN code here:

For more information on your system

PIN, see page 52.

For your records

Date of purchase:

Place of purchase:

INTRODUCTION
