User Manual and Guide to professional battery
testing
WARNING
• This manual includes guidelines on the operation of your device and the precautions
to follow for your own safety. Ensure it is read carefully before rst use and keep it
handy for future reference.
• Risk of explosion and re! A battery being charged can emit explosive gas.
• The battery tester should only be connected to batteries with a rated output voltage of 12V.
• Do not use the battery tester if the cord or terminals are damaged.
• Do not use the battery tester if it has received a severe shock or has been damaged in
any way. Do not disassemble the device. Incorrect reassembly may result in a risk of
electric shock or re.
MAIN FEATURES
• For Lead Acid (flooded, AGM flat plate, AGM spirale, GEL, EFB) and Lithium batteries.
• For all 12V vehicle and motorcycle batteries.
• 5 battery tests: cold Cranking Amps, Voltage, Internal Resistance, Health, Starting.
• Vehicle charging and cranking system test.
• Easy to read thanks to the large LCD screen.
• Print function via PC printer.
• Multiple language: english, German,Spanish, French, Dutch, Italian.
• Short circuit and polarity reverse connection protections.
TOOL DESCRIPTION
Up / Down keys: select upwards or downwards via white
UP and DOWN keys.
Exit key: exit to previous menu via the EXIT key.
ENTER key: conrm the selection via the ENTER key.
Fn FN key: quick test key.
Mini-USB Socket (on the product side):
connect to computer for print via USB cable.
SPECIFICATIONS
• Test range: lead acid: 20~2000 CCA Lithium: 20~1000 CCA.
•
Rating system: SAE, CCA, BCI, DIN, EN, IEC, GB, CA/MCA, JIS (battery type No.).
See Cold Cranking Amps Measure range for more details (page 4).
• Operating Temperature: 0 to 50°C.
• Storage Temperature: -20 to 70°C.
• Power: provided via vehicle battery (8-30V DC).
• Wires length：: 100cm.
• Dimensions: 126x76x28mm.
• Weight: 200g.
