Refill Instructions For Brother TN-1050,

HL-1110, HL-1112 normal

With this toner cartridge TN-1050, HL-1110, HL-1112, Brother has launched a very compact and

space-saving model on the market. Unfortunately, the price is not as small as the toner cartridge. To

print conveniently, you can refill your toner cartridge. In this guide, we will show you step by step

how to do it.

Preparation for filling Brother TN-1050, HL-1110, HL-1112:

To fill the toner cartridge, you must first cut off the small spot weld (Figure 1). After you have cut

this off, you can also remove the sealing plug. Take a small spatula or other flat tool and carefully pry

open the stopper (Figure 2) and set it aside.

Brother TN-1050, HL-1110, HL-1112 - Cut

Spotweld and remove the filler cap

Brother TN-1050, HL-1110, HL-1112 –

VERY IMPORTANT

Before you fill your toner cartridge, you have to remove the remaining toner. Shake the cartridge in

a sealed plastic bag or vacuum the residual toner with a toner vacuum cleaner. Due to different

physical and chemical properties, new and old toner can clump together and make the toner

cartridge useless.

Brother TN-1050, HL-1110, HL-1112 nachfüllen

Filling the Toner Cartridge Brother TN-1050, HL-1110, HL-1112:

Take the bottle of refill toner and shake it lightly. Remove the cap from the bottle and screw in a

funnel. Carefully pour the toner into the toner cartridge (Figure 3). When you have filled the

cartridge, you can replace the previously removed plug. After filling, you only need to insert the

reset lever or reset it to "full".

Brother HL-1110, HL-1112 - Refilling Toner Brother TN-1050, HL-1110, HL-1112 refill

Reset Lever to Brother TN-1050, HL-1110, HL-1112:

The reset lever is a mechanical device that counts down the toner level every time you print. You

need to insert the reset lever and a new side cover if you want to refill a starter cartridge (to be

used when buying a printer). Replenished toner cartridges already have the reset lever and the new

cover and only need to be reset in this case.

Loosen the two screws on the side cover (Figure 4). The side cover is now only attached with two

barbs. Loosen the two barbs (Figure 5 and 6) and remove the side cover. When you remove the

upper, right-hand gear (Figure 7), you can insert or reverse the reset lever (Figure 8). Make sure the

small plastic arm is pointing to the left. After inserting the reset lever, you can replace the previously

removed gear and replace the side cover

Brother TN-1050, HL-1110, HL-1112 Remove 2 Screws

Brother TN-1050, HL-1110, HL-1112 Remove Barbs

Brother TN-1050, HL-1110, HL-1112 Barbs Release

Brother TN-1050, HL-1110, HL-1112 Remove Gear

Brother TN-1050, HL-1110, HL-1112 Reset the lever to

position showed this will zero the count

Brother TN-1050, HL-1110, HL-1112 Replace The Gear

Inserting the new side cover:

After inserting the reset lever and returning it to full, you can replace the side cover. Please note

that you can not reuse the side of the starter cartridge and replace it with the new cover. The

difference between the old and the new cover is that the new cover has a recess for the reset lever.

As a result, the reset lever can perform its services without problems and reliably shows you when

the toner cartridge is "empty" again.

Take the new cover and replace it in the same position (Figures 10 and 11). Tighten the cover with

the two screws again. Now you can put your toner cartridge back in the printer and continue

printing as usual.

Brother TN-1050, HL-1110, HL-1112 insert new

cover

Brother TN-1050, HL-1110, HL-1112 New Cover

Used
