Britax Safe-nSound Manuel utilisateur

Convertible Child Restraint

with Adjustable Headrest or Backrest

Series No.7300/A/2010

IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT

INDEX

INTRODUCTION

WARNINGS

SHOULDER HEIGHT MARKERS AND A GROWING CHILD

SHOULDER HEIGHT MARKERS

SHOULDER HEIGHT MARKERS AND THE NEXT STEP

SPECIAL FEATURES - REARWARD FACING

SUITABLE FOR USE

HOW TO SETUP

HOW TO INSTALL

HOW TO USE

SPECIAL FEATURES - FORWARD FACING

SUITABLE FOR USE

HOW TO SETUP

HOW TO INSTALL

HOW TO USE

CARE AND MAINTENANCE

ACCESSORIES

TRAVELLING TIPS

INSTALLATION OF CAR ANCHOR FITTING

IN CASE OF ACCIDENT

Page

INTRODUCTION

This instruction book covers various models under the series number 7300/A/2010, 7300/D/2010

design. These child restraints are installed in the rear of the car and can be used either rearward facing

for infants or forward facing for older children. They are installed in the car using the car seatbelt and

the tether strap attached to the car's child restraint anchor tting.

To be used only in a rearward facing position for an infant until their shoulders reach the lower

shoulder height marker (approximately 12 months of age). Then to be used in forward facing position

until their shoulders reach the upper shoulder height marker (approximately 4 years of age).

Continue to use this child restraint until the child reaches this limit.

Do not use forward-facing until child's shoulders are above the lower shoulder height marker.

Infants are at risk of serious injury if they face forward too early.

Children are at risk of serious injury if they move to booster seats too early.

Children that have outgrown this restraint are safest in a booster seat until their shoulders reach the

upper shoulder height marker of the booster seat.

CAREFULLY READ ALL THE INSTRUCTIONS FOR INSTALLATION. IN THE EVENT OF DOUBT ABOUT

THE METHOD OF INSTALLATION, CONSULT BRITAX CHILDCARE OR AGENT OR A CHILD RESTRAINT

FITTING STATION AUTHORISED BY A RELEVANT TRANSPORT AUTHORITY OR, IN NEW ZEALAND,

THE AGENT FOR THE VEHICLE.

No child restraint can guarantee absolute protection from injury in every crash. However, to ensure

that your child gets all the protection designed into the restraint PLEASE READ AND FOLLOW THESE

INSTRUCTIONS EXACTLY and use only Britax Safe-n-Sound recommended parts and accessories.

THIS RESTRAINT MUST BE ATTACHED TO A CHILD RESTRAINT ANCHORAGE POINT IN THE CAR.

REFER TO CAR OWNER’S HANDBOOK FOR LOCATION OF ANCHORAGE POINTS. REFER TO A CHILD

RESTRAINT FITTING STATION IF NO ANCHORAGE POINTS ARE IN THE MOTOR CAR.

TO BE USED WITH A LAP-SASH OR LAP-ONLY SEATBELT IN THE BACK OF MOST CARS WITH

FORWARD FACING SEATS.

Always store the instruction book in the pocket provided on the side or back of the cover.

• Use the restraint exactly as shown in the instructions.

• Fit the restraint rmly to the car seat.

• Fit the harness rmly to the child.

• A loose restraint or harness is dangerous.

• Supervision of children is needed because they may be able to undo buckles and adjusters.

• DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.

• Do not alter or modify this restraint.

• Repairs must only be done by the manufacturer or agent.

• Do not allow the restraint to come into contact with polishes, oils, bleach and other chemicals.

• Destroy the restraint if it has been in a severe crash, even if no damage is visible.

• DO NOT USE THIS RESTRAINT WITHOUT A COVER.

• Regularly check the restraint components, straps & other tments for correct function and

condition. Seek prompt repair.

• To ensure baby’s back is evenly supported do not put more than one nappy on the baby and

make sure the nappy is not thickly folded at the back.

• DO NOT USE A REAR-FACING CHILD RESTRAINT WHERE AN AIRBAG IS FITTED IN THE FRONT

OF THE SEATING POSITION.

• If an airbag is tted in the desired seating position where the child restraint is to be tted, follow

the vehicle manufacturer's warnings and instructions.

• The restraint should not be purchased or sold as a second hand item. It is recommended not to

use child restraints older that 10 years as the protection in an accident may be reduced.

• THIS RESTRAINT IS NOT SUITABLE FOR USE WHERE THE ANCHORAGE STRAP MAY FALL INTO

A SPLIT IN THE SEAT BACK (E.G. HATCHBACK OR WAGON).

DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.

• The restraint is not intended to be a substitute baby cot or bed. It is only designed to enable safe

transportation of children in motor vehicles. Do not leave a baby in the restraint for long periods

of time.

• Straps may be damaged by unsecured cargo in a collision. Secure or remove hazardous cargo

before using this strap. Hatchback or wagon: Do not use the child restraint where the upper

anchorage strap may fall into a split in the seat back.

• Protect all webbing from abrasion and cutting by sharp corners and edges.

• Do not lift the seat by the headrest.

• Do not store in areas that may get hot, like in car boots, roof space, beside shed walls which get

hot in summer. Do not place heavy items on top of the seat as this may distort the plastic.

SHOULDER HEIGHT MARKERS AND

A GROWING CHILD

Forward Facing

Rearward Facing

Newborn (Rearward-Facing)

Shoulder height

label (hidden)

Shoulder

height label

Label A

Older baby (Rearward-Facing)

Child Use (Forward-Facing)

Move to the next form of child restraint when

the child's shoulders reach the upper shoulder

height marker.

Shoulder Height Labels

Turn to forward facing when the child's

shoulders reach the lower shoulder height

marker.

Label A

Label B

SHOULDER HEIGHT MARKERS

Shoulder height markers are provided on this restraint for a visual indication that the child is safe to

ride in this restraint. Do not turn to forward facing until the child's shoulder's reach the lower marker.

Do not continue to use the restraint if the child's shoulders are above the upper marker.

LOWER SHOULDER HEIGHT MARKER : Label A

When the child's shoulders reach the lower marker, the child restraint must be turned to face towards

the front of the vehicle or move the child to another forward facing seat with in built harness.

Approximately 12 months of age.

UPPER SHOULDER HEIGHT MARKER : Label B

When the child's shoulders reach this upper marker, the child is now too big for the child restraint. It is

now time to move to the next child restraint. Approximately 4 years of age.

IMPORTANT: Follow this advice.

SHOULDER HEIGHT MARKERS AND

THE NEXT STEP

Convertible

Booster seat

used with built-

in harness until

approximately 4

years and then

as a booster

seat.

Booster seat

and accessory

Child Harness.

For the next child restraint choose from:

6 months to 6-8 years (approx).

• Convertible Booster Seat. Note: you can move to a

convertible booster seat once the child's shoulders

reach the lower shoulder height marker, this will be

lower than the lower shoulder height marker on the

child restraint covered on the previous page.

4 years to 6-8 years or 8-10 years (approx).

• Booster Seat and an accessory Child Harness

(A Child Harness must be used if the car is tted with

a lap only seatbelt in the desired seating position),

• Booster seat and lap-sash seatbelt.

Booster seat

with lap-sash

seatbelt.

REARWARD FACING

SPECIAL FEATURES - REARWARD-FACING

WITH HEADREST

To be used only in a rearward facing position until the infant's shoulders reach the lower shoulder

height marker (approximately 12 months of age).

1. Adjustable Headrest or Backrest with

HASSLE FREE HARNESS™

2. Fully adjustable 6 point Harness

3. Insert Pad (if tted)

(may vary in style)

4. Shoulder Pads (if tted)

5. Padded Cover for comfort

6. Release Buckle (Red button)

7. Stabilising Bar for Rearward Facing mode

8. Harness Adjustment Strap

9. Headrest Adjuster Latch

10. EZ Buckle System

11. Harness Tongue Holders

12. Shoulder Height Markers

13. Headrest Lever

Shoulder Height

Markers may be

hidden under headrest

in lowest position.

(Harness strap not shown)

Front of Vehicle

20. Messy Mat™ (if supplied)

21. Recline Position Indicator

22. Recline foot in Rearward Facing mode

23. Upper Lock-off (Forward Facing only)

24. Upper Anchorage Storage Band

25. Upper Anchorage Strap Adjuster

14. Adjustable Upper Anchorage Strap

15. Attachment Clip

16. Vehicle's Anchor Fitting

17. Harness Adjustment Lever (under trim ap)

18. Vehicle's seatbelt

19. Blue REARWARD FACING BELT PATH label

20 19

SPECIAL FEATURES - REARWARD-FACING

REARWARD FACING
