Breville Vfj016 Manuel utilisateur

™

pro kitchen

whole fruit juicer

product safety

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

Check the sieve for damage every time you use the appliance. Do not use

the appliance if the rotating sieve is damaged.

Always disconnect the appliance from the mains supply socket if it is left

unattended and before assembling, disassembling or cleaning.

If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualied persons in order to avoid a hazard.

!Never use this appliance for anything other than its intended use. This appliance is for

household use only. Do not use this appliance outdoors.

!Always ensure that hands are dry before handling the plug or switching on the

appliance.

!Always use the appliance on a stable, secure, dry and level surface.

!This appliance must not be placed on or near any potentially hot surfaces (such as a

gas or electric hob).

!Never immerse any part of the appliance or power cord and plug in water or any other

liquid.

!Never let the power cord hang over the edge of a work top, touch hot surfaces or

become knotted, trapped or pinched.

!Do not use the appliance if it has been dropped, if there are any visible signs of

damage or if it is leaking.

!17

!Never use any accessory or attachment not recommended by the manufacturer.

!Switch off the appliance before changing accessories or approaching parts which move

during use.

!Allow moving parts to come to a stop before opening or cleaning.

!Never insert your ngers, utensils or any other object into the feeding tube. Always use

the food pusher.

!Never attempt to remove or replace any part of the appliance whilst it is in operation.

Ensure that the appliance is switched off and unplugged from the supply socket

if it is left unattended and before assembling, disassembling or cleaning.

Never immerse any part of the appliance or power cord and plug in water or any

other liquid.

Never use harsh, abrasive or caustic cleaners to clean this appliance.

1. Before using your juicer for the rst time, remove any packaging material and

promotional stickers and labels.

2. Ensure your juicer is switched off and the power cord is unplugged from the mains

supply socket.

3. Wash the bowl, stainless steel sieve, juicer cover, food pusher, pulp container and

juice jug and lid in warm, soapy water using a soft cloth.

4. Rinse and dry thoroughly. The motor base can be wiped with a damp cloth. Dry

thoroughly.

before first use

features

1 Food pusher

For safely pushing whole fruit and vegetables into the professional juicer’s feed

chute. Dishwasher safe.

2 Extra wide feed chute

Fits whole apples, carrots, tomatoes and peeled oranges. Makes juicing fruit and

vegetables fast and easy.

3 Juicer cover

Dishwasher safe, durable, clear cover.

4 Stainless steel, micro mesh sieve

Dishwasher safe.

5 Bowl

Dishwasher safe.

6 Large pulp container

Dishwasher safe.

7 Motor base

High performance, 1000W motor.

8 Cleaning brush

For cleaning the stainless steel sieve.

9 Juice jug lid

Dishwasher safe lid for the juice container.

10 Juice jug

Dishwasher safe, 1 litre jug with integrated handle for left or right handed use. Use it

with the lid on to store juice in the refrigerator.

11 Froth separator

For removing the froth from the juice when pouring.

12 3-position switch

This switch controls your juicer’s two speeds and off. Setting 1(low speed) is for

juicing soft fruits with high water content such as watermelon. Setting 2(high speed)

is for juicing hard fruits and vegetables. Setting 0is off.

Due to our policy of continuous improvement, the actual product may differ slightly from the one illustrated in these instructions.

assembling

Be careful when handling the stainless steel sieve. Do not touch the small sharp

blades inside the sieve.

Place the motor base on a at, dry surface such as your kitchen worktop. Ensure that the

3-position switch is in the off (0) position, then switch the appliance off at the power outlet

and unplug the cord.

1. Fit the bowl onto the motor base. The spout on the lter bowl should be on the same

side of the motor base as the safety locking arm.

2. Gently push the sieve down onto the motor base drive coupling until it clicks into

place. Make sure that the sieve is tted securely inside the bowl and onto the drive

coupling.

3. Place the juicer cover over the bowl. The feed chute should be positioned over the

stainless steel sieve.

4. Pivot the safety locking arm upwards until it engages with the two grooves in the

juicer cover. The safety locking arm should now be vertical and locked into place on

the top of your juicer. If the arm doesn’t t into place easily, don’t force it. Check that

you have tted the juicer cover correctly.

5. Tilt the large pulp container slightly and place it underneath the pulp outlet side of the

juicer cover.

6. Fit the lid onto the juice jug. Position the juice jug over the juice outlet spout on the

right hand side of your juicer.

7. Slide the food pusher into the feed chute. The food pusher has a groove in it which

must be lined up with the protrusion inside the feed tube.

using your whole fruit juicer

1. Wash your selection of fruit or vegetables ready for juicing.

2. Make sure that your whole fruit juicer is correctly assembled and that the stainless

steel sieve is thoroughly cleaned before each use (refer to care and cleaning). Place

the juice jug (or a glass) under the spout before starting to juice.

3. Connect the plug into a suitable electrical socket. Set the 3-position switch to either

1for low speed or 2for high speed depending on the type of fruit or vegetable being

juiced.

4. With your whole fruit juicer running, place the food into the feed chute. Using the food

pusher, gently guide the food down the feed chute. To extract the maximum amount

of juice, always push the food pusher down slowly. Juice will ow into the juice jug

and the separated pulp will accumulate in the pulp container.

Hints and tips

To minimize washing up, place a plastic freezer bag into the pulp container to collect the

pulp.

Most fruit and vegetables such as apples, carrots and cucumbers will not need to be cut

to size as these will t into the feed chute whole. When juicing carrots place the tip of the

carrot into the feed chute last.

Don’t allow the pulp container to overll as this may cause damage or prevent correct

operation.

The pulp container can be emptied during juicing by turning your whole fruit juicer off.

Carefully remove the pulp container, empty it then replace it before continuing to juice.

When juicing hard foods, we recommend a maximum quantity of 3kg with a

maximum operating time of 2 minutes. Switch your whole fruit juicer off for

approximately 10 minutes before resuming juicing.

Some very hard foods may make your juicer slow down or stop. if this

happens, switch off and unplug your juicer then unblock the sieve.

 Neveruseyourngerstopushfooddownthefeedchuteortoclearthefeed

chute. Always use the food pusher provided.

hints and tips

95% of the nutrient content of fruit and vegetables is found in the juice. Liquids extracted

from fresh fruits and vegetables form an important part of a well-balanced healthy diet.

Fresh fruit and vegetable juices are an easy way to introduce a source of vitamins and

minerals to your diet. Juices are rapidly absorbed into the blood stream therefore being

the quickest way in which the body can digest nutrients.

When you make your own juices, you have complete control over what you include

in them. You select the ingredients and decide if you need to use sugar, salt or other

avouring agents.

Freshly extracted juices should be consumed just after they have been made to avoid a

loss of vitamin content.

Purchasing and storing fruit and vegetables

• To save money and obtain fresher produce, purchase fruit or vegetables that are in

season—see the fruit and vegetable facts chart on page 12.

• Keep your fruit and vegetables ready for juicing by washing them before storing.

• Most fruits and hardier type vegetables can be stored at room temperature. The

more delicate and perishable items such as tomatoes, berries, leafy greens, celery,

cucumbers and herbs should be stored in the refrigerator until required.

Preparation of fruit and vegetable

• Always use fresh fruit and vegetables for juicing.

• Always wash fruit and vegetables before juicing.

• If you are using fruits with hard or inedible skins such as mangoes, guava, melons or

pineapple, always peel them before juicing.

• Citrus fruit can be juiced in your whole fruit juicer if peeled rst.

• All fruits with pits, hard seeds or stones such as nectarines, peaches, mangoes,

apricots, plums and cherries must be pitted or destoned before juicing.

• A small amount of lemon juice can be added to apple juice to prohibit browning.
