the AquaStation™Chilled + Hot

Instruction Book - Suits all LWA600 Models

BREVILLE

RECOMMENDS

SAFETY FIRST

At Breville we are very safety

conscious. We design and

manufacture consumer

products with the safety of you,

our valued customer, foremost

in mind. In addition, we ask

that you exercise a degree of

care when using any electrical

appliance and adhere to the

following precautions. Misuse

can cause potential injuries.

MAIN TECHNICAL SPECIFICATIONS

Product Model LWA600BSS

Filter Model LWA063WHT

Filter Life 90 days or approximately

200L, whichever comes ﬁrst

Rated Voltage 220-240V

Rated Frequency 50Hz

Rated Power Consumption 1950-2300 Watts

Applicable Water Source Municipal tap water: 5~40°C

Product Dimensions

(LxWxH) Approx. 391 x 273x 455

Weight (kg) 10.28Kg

Tested against: NSF/ANSI Standard 42 for

the reduction of chlorine (taste and odour),

& NSF/ANSI 372, lead content.

Tested to remove/reduce microplastics, ﬂoating

particles/sediment, pesticides, chlorine, limescale

& heavy metals.

Testing was performed under standard laboratory

conditions. The contaminants or other substances

removed or reduced by this ﬁlter are not

necessarily in all users’ water. Filter performance

may vary based on local water conditions.

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE

FOR FUTURE REFERENCE

• Carefully read all instructions

before operating and save for

future reference.

• Remove and safely discard

any packaging material and

promotional labels before using

the AquaStation™ Chilled + Hot

for the ﬁrst time.

• Always ensure the appliance is

properly assembled before use.

2 Breville Recommends Safety First

8 Components

12 Features

14 Assembly

17 Operation

22 Tea Insights

23 Descaling

25 Care, Cleaning & Storage

27 Troubleshooting

Contents

Follow the instructions provided

in this book.

• The AquaStation™ Chilled +

Hot must be used only with

the Breville ﬁlter supplied or

replacement product code

LWA063.

• This appliance has been

designed speciﬁcally for the

purpose of ﬁltering and heating

drinking quality water only.

Under no circumstances should

this appliance be used to heat

any other liquids.

• Do not place the appliance

near the edge of a bench or

table during operation. Ensure

that the surface is level, clean

and free of water and other

substances.

• Do not operate the appliance on

a sink drain board.

• Do not operate the appliance in

an enclosed space, or within a

cupboard.

• Never immerse the appliance,

power cord or power plug in

water, or allow moisture to come

into contact with these parts.

• Do not move the appliance

while it is switched on.

• Always ensure the appliance

returns to standby mode, then

turn the power off at the power

outlet and remove the power

plug from the power outlet

before attempting to move the

appliance, when the appliance

is not in use and before

cleaning and storing.

• Do not remove the water tank

from the power base during

operation.

• If the water tank is removed

from the power base during

water dispensing, the appliance

will automatically stop.

• Always ﬁll the water tank with

water between the minimum

(MIN) and maximum (MAX)

as marked on the water tank.

• Too little water will result in the

appliance not operating and

‘Fill Tank’ will display on the

LCD screen. Filling above the

maximum mark (MAX) may

result in water splashing from

the water tank.

• Ensure the water level is

always above the MIN level for

optimum dispensing ﬂow rate.

• The lid should always be

correctly ﬁtted on the water

tank except when reﬁlling.

• Do not place the appliance

in direct sunlight. Colour

fading and discolouration

may occur when the appliance

is consistently exposed to

sunlight.

• Care should be taken when

handling the appliance during

and after use, ensuring that the

appliance's spout and other

parts and surface areas are not

touched as these may still be

hot due to residual heat after

hot water dispensing.

• Allow the appliance to cool

down before moving or

cleaning any parts.

• Use in a well ventilated area.

This appliance emits hot

steam.

• Condensation from steam may

form on the LCD screen and

control panel; this is normal.

• Use caution when using the

descale feature as hot steam

may be released. Before

descaling, ensure the drip tray

is emptied and repositioned.

Refer to ‘Decaling’ section for

instructions.

• This appliance is intended to

ﬁlter tap water only. Do not put

water of unknow quality into

the appliance. Use only cold or

room temperature water.

Do not use for the preparation

of baby formula.

• Do not ﬁll the water tank with

hot water. Water added to the

water tank should not be less

than 5°C or more than 40°C.

If water in the tank is outside

these temperatures, discard

and ﬁll with cold tap water.

• Do not leave the appliance

unattended during operation.

• Do not remove ﬁlter whilst the

appliance is operating.

• Surface is subject to residual

heat after use.

WARNING

• Do not operate the appliance

on an inclined plane. Do not

move appliance unless the

appliance is turned off and

unplugged from the power

outlet.

• Keep the appliance and all

parts clean. Follow the cleaning

instructions provided in this

book.

• Any procedure not listed in

this instruction book should

be performed at an authorised

Breville Service Centre.

IMPORTANT SAFEGUARDS

FOR ALL ELECTRICAL

APPLIANCES

• Fully unwind the power cord

before use.

• Connect only to a 230V or

240V power outlet.

• The appliance must be used on

a properly grounded outlet. If

you are not sure, please consult

a qualiﬁed electrician.

• Do not, under any

circumstances, modify the

power plug or use a power plug

adapter.

• Do not place this appliance on

or near a heat source, such as a

hot plate, oven or heaters.

• Position the appliance at a

minimum distance of 20cm

away from walls, curtains and

other heat or steam sensitive

materials and provide adequate

space above and on all sides for

air circulation.

• Do not let the power cord hang

over the edge of a bench or

table, touch hot surfaces or

become knotted. Keep away

from hot gas or electric burners,

or where it could touch a heated

oven.

• This appliance is for household

use only. Do not use this

appliance for anything other

than its intended use. Do not

use in moving vehicles or boats.

Do not use outdoors. Misuse

may cause injury

• This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge

if they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved.

• Children should be supervised

to ensure that they do not play

with the appliance.

• Always turn the appliance to

the OFF position, switch off at

the power outlet and unplug

at the power outlet when the

appliance is not in use.

• Before cleaning, always turn the

appliance to the OFF position,

switch off at the power outlet,

unplug at the power outlet

and remove the power cord, if

detachable, from the appliance

and allow all parts to cool.

• To protect against electric

shock, do not immerse the

power cord, power plug or

appliance in water or any other

liquid or allow moisture to

come in contact with the parts,

unless it is recommended in

the cleaning instructions.

• Any maintenance other than

cleaning should be performed

at an authorised Breville

Service Centre

• It is recommended to regularly

inspect the appliance. To

avoid a hazard, do not use the

appliance if power cord, power

plug or appliance becomes

damaged in any way. Return the

entire appliance to the nearest

authorized Breville Service

Centre for examination and/or

repair.

• The installation of a residual

current device (safety switch)

is recommended to provide

additional safety protection

when using electrical

appliances. It is advisable that

a safety switch with a rated

residual operating current not

exceeding 30mA be installed in

the electrical circuit supplying

the appliance. See a qualiﬁed

electrician for professional

advice.

• During electrical storms,

the appliance should be

disconnected from the power

source at the wall socket to

prevent any electrical surges

that may arise during the storm

and which may inadvertently

cause damage to the appliance

and its electronic componentry.

• Cleaning and user maintenance

shall not be made by children

without supervision.

SPECIFIC INSTRUCTIONS

FOR WATER FILTER

• Filter cartridge should be kept

out of reach of children.

• Store any unused ﬁlter

cartridges in a dry place sealed

in the original packaging.

• Protect ﬁlter cartridges from

heat and direct sunlight. Only

remove from packaging before

using.

• Do not use a ﬁlter cartridge

that is damaged.

• Do not open ﬁlter cartridge

housing to access the material

inside.

• If you are absent for a

prolonged period of time,

empty and clean the water tank

and replace the ﬁlter cartridge

before next use.

• Refer to the ﬁlter installation

instructions found in the

'Assembly' section of these

instructions.

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

BREVILLE ASSIST™ PLUG

• Your Breville appliance comes

with a unique Assist™ Plug,

conveniently designed with a

ﬁnger hole in the power plug

for easy and safe removal from

the power outlet. For safety

reasons, it is recommended

you plug your Breville

appliance directly into its own

electrical outlet on a dedicated

circuit separate from other

appliances. If the electric

circuit is overloaded with other

appliances, your appliance

may not function properly. Use

in conjunction with a power

strip or extension cord is not

recommended.

Components

A. Water tank lid

with easy-grip handle

B. The Activ360™ 4-Stage Filter

with pull ring for easy removal

C. Filter holder

D. Water tanks

Including a removable,

external 6L water tank plus an

internal 2L chilling chamber

(not shown)

NOTE - Total external tank capacity

is 6L, however, it is recommended

to always ﬁll the external water tank

with water between the minimum

(MIN- 2L) and maximum (MAX- 5L)

as marked on the water tank.

Filling above the maximum mark

(MAX-5L) may result in water

splashing from the water tank.

E. LCD screen

F. Cold button

G. Function Dial

H. Cold Favourite button

I. Start/Stop button

J. Hot Button

K. Hot Favourite button

L. Dispensing spout

M. Dispensing area with drip

tray holder

20cm cup clearance height

with tray in place, 23cm

height if drip tray removed,

14cm height if hooked to drip

tray holder

N. Detachable magnetic drip

tray

Attaches to the base or can be

hooked to the tray holder (M)

O. Removable tray grill for

cleaning

P. Non-marking, non-slip feet

Not Shown

• Breville Assist™ Plug

• Drain Plug & Cap (Located

underneath unit)

Control Panel

COLD

HOT

AMBIENT

°C

FUNCTION

FUNCTION DIAL/SELECT

Turn/Press FUNCTION dial to adjust/select

from the following:

MENU - When using HOT, turn dial to select

between pre-programmed menu options and

the custom setting; press the dial to conﬁrm

selection.

TEMP - when using Custom, turn dial

clockwise to increase temp and anti-clockwise

to decrease temperature; press the dial to

conﬁrm selection.

VOLUME - when using Ambient or Custom,

turn dial clockwise to increase volume and

anti-clockwise to decrease volume; press the

dial to conﬁrm selection.

NOTE

TEMP & VOLUME cannot be adjusted once

water dispensing commences.

NOTE

The FUNCTION dial light will illuminate

solid white when the unit is switched on at the

power (to indicate the unit is operational). The

light ring will turn off when water is dispensing

or when the unit enters standby mode after 5

minutes of non-use.

START | STOP

START/STOP BUTTON

Press to start or stop dispensing ﬁltered water

(ambient, chilled or hot water dispensing).

The water droplet light illuminates solid white

while dispensing, and will ﬂash if hot water is

selected as a reminder that dispensing will not

commence until START/STOP is pressed.

HOT

HOT WATER BUTTON

Press once to access the hot water menu. The

HOT button light will illuminate and the hot

water menu will appear on the LCD screen.

The hot beverage menu offers programmed

ideal brew temperatures recommended for

black, white, green tea, coffee and custom.

Custom allows for manual selection of

temperature (45-100° Celsius) and volume

(100mls to 1.2L).

COLD

COLD WATER BUTTON

Press once to access cold settings. The

COLD button light will illuminate and the cold

water settings will appear on the LCD screen.

The COLD setting allows for manual selection

of temperature (5° to 15° Celsius) and

volume (100mls to 500mls). The COLD

button light will continuously ﬂash when

reaching set temperature.

NOTE

The COLD button blue LED light ring will

continue to cycle on and off in AMBIENT/

COLD/HOT settings to indicate that the

compressor is turning on and off to maintain

the correct temperature.

NOTES

• Hot water temperature settings are measured

at the heating element, not the dispensed

temperature at the spout or in the cup.

• Cold water temperature settings are measured

in the chilling chamber, not the dispensed

temperature at the spout or in the cup.

• When dispensing ambient water, if START/

STOP is not pressed to stop water ﬂow,

dispensing will automatically stop after 60

seconds.

• Ambient water temperature will vary. The

temperature dispensed will be inﬂuenced by

the external factors surrounding the unit itself.

An increase in the air temperature will cause

water tank temperature to increase as well.

• If the water temperature in the tank becomes

too warm, discard and replace with cold tap

water. Water temperature in the tank should

not be dispensed if above 40°C.

HOT & COLD FAVOURITE BUTTONS

The HOT & COLD FAVOURITE settings allow you to save your most used setting.

At the press of a button, your favourite program can be accessed time after time.

LCD SCREEN PROGRAM TABLE

Function Water

Dispensing

Flow Rate

per Min

^Preset

Temp °C

^Temp

Range °C

Temp +/-

Increments

Preset

Volume

MLS

Volume

Range

MLS

Volume +/- Increments

from 100-250mL increase

by 25mL, from 250-500mL

increase by 50mL, from

500mL+ increase by 100mL

Cold 1L 55 to 15 1°C 250mL~ 100-500 25mL

Ambient# 1L Temp of Water

inside Water

Tank

Temp of Water

inside Water

Tank

N/A 250mL~ 100-500 25mL

Black Tea 400mL 100°C N/A N/A 250mL 100-500 25mL

Coffee 400mL 95°C N/A N/A 250mL 100-500 25mL

White Tea 400mL 85°C N/A N/A 250mL 100-500 25mL

Green Tea 400mL 80°C N/A N/A 250mL 100-500 25mL

Custom 400mL N/A 45-100 5°C 250mL 100-1200 25mL

^Temperature is measured at the heating element and chilling chamber not from the spout.

#Ambient water temperature will vary.

~Without setting volume, unit will automatically stop pouring after 1 minute.

LCD SCREEN DISPLAY MENU

COLD

Appears on the screen only when the COLD

button has been selected

HOT

Appears on the screen only when the HOT

button has been selected.

CUP VOLUME INDICATOR

Appears on the screen only when volume is

being set to visually show the level of water

that will be dispensed into the cup.

AMBIENT

Displays on the screen as the default setting

when in standby mode and when dispensing

ambient ﬁltered water.

FILTER RESET

Appears on the screen as a reminder to change

the ﬁlter cartridge once the ﬁlter life timer has

counted down.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Breville Cafetière

Breville

Breville Aroma Fresh BCM120 Manuel utilisateur

Breville

Breville Cafe Venezia BES250 Manuel utilisateur

Breville

Breville Aroma Style Electronic LCM700 Manuel utilisateur

Breville

Breville NESPRESSO MY MACHINE CREATISTA PRO Manuel utilisateur

Breville

Breville The Dynamic Duo BEP920 Manuel utilisateur

Breville

Breville Infuser BES840CRN Manuel utilisateur

Breville

Breville Barista Express BES860 Instructions de montage

Breville

Breville the YouBrew BDC600XL Manuel utilisateur

Breville

Breville Barista Express BES860 Manuel utilisateur

Breville

Breville ONE-TOUCH COFFEEHOUSE Manuel utilisateur

Breville

Breville Barista Express BES870BSS Manuel utilisateur

Breville

Breville Ikon BES400 Manuel utilisateur

Breville

Breville the Barista Pro BES878BSS4JAN1 Manuel utilisateur

Breville

Breville Barista Express BES870XL Manuel utilisateur

Breville

Breville Cafe Modena ESP6SXL Manuel utilisateur

Breville

Breville the Duo-Temp BES800XL Manuel utilisateur

Breville

Breville BES840XL Manuel utilisateur

Breville

Breville Dual Boiler BES920 Manuel utilisateur

Breville

Breville the Oracle BES980 Manuel utilisateur

Breville

Breville BES840XL Manuel utilisateur

Breville

Breville ESSENZA MINI Manuel utilisateur

Breville

Breville the Oracle BES980XL Manuel utilisateur

Breville

Breville Precision Brewer Thermal Manuel utilisateur

Breville

Breville NESPRESSO VERTUO NEXT Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
