3
Technical data of the motor
Torque 1.2 nm
Open/Close Speed 14 cm per sec.
Voltage Motor AC 100-240V
Max. Curtain Weight 40 kg
Radiofrequency 433.925MHz
Moisture and Dust Protection IP20
Storage Capacity Transmitters Up to 20 Channels
Temperature range of the motor Normal Use : -5°C to +55°C
Frequency 433Mhz 2.4Ghz (wifi)
Page 3
Works with the BREL HOME app
NOTE
Switching installation of the curtain motor
3
BG-980
Common = Blue
Live line = Brown
Earth line = Green Yellow
Motor
Power
plug
The BG980 motor is easy to operate with the BREL HOME app. The motor connects to the
BREL HOME app via WiFi and then the motor can be set via the app. The steps are as followed:
Step 1: Go to settings -> Wifi network -> choose the connection to your home network ->
disable the “automatic connection” to your home network.
Step 2: Download the BREL HOME App and create an account (SIGN UP)
Step 3: Click on add product and choose the Wifi motor
Step 4: Go through all the steps as indicated in the app.
Step 5: Close the app completely -> restart the app -> click on ADD ROOM and create the room
where the product is located.
Step 6: Go to the WiFi motor and link the newly created room to the WiFi motor.
If you want to install the motor by emitter, follow the instructions on the next pages.
433MHZ
Motor Reverse
Motor Forward
Motor Stops
Common
LED Programm button P1
Connection for Switch
