BreezeACCESS 2.4

Base Station Equipment

Installation

Manual

Revision 3

November, 2000

Cat. No. 213125

Front Matter

BS Equipment Installation Manual ii BreezeACCESS 2.4 Series

No part of this publication may be reproduced in any material form without the written permission of

the copyright owner.

Trade Names

BreezeACCESS, BreezeNET, BreezeLINK, BreezeVIEW, BreezeMANAGE and WIX are trade

names of BreezeCOM Ltd. Other brand and product names are registered trademarks or trademarks of

their respective companies.

Statement of Conditions

The information contained in this manual is subject to change without notice. BreezeCOM shall not be

liable for errors contained herein or for incidental or consequential damages in connection with the

furnishing, performance, or use of this manual or equipment supplied with it.

Warranty

In the following warranty text, “the Company” shall mean:

• BreezeCOM Ltd., for products located outside the USA.

• BreezeCOM Inc., for products located in the USA.

This BreezeACCESS product is warranted against defects in material and workmanship for a period

of one year from date of purchase. During this warranty period the Company will, at its option, either

repair or replace products that prove to be defective.

For warranty service or repair, the product must be returned to a service facility designated by the

Company. Authorization to return products must be obtained prior to shipment. The buyer shall pay

all shipping charges to the Company and the Company shall pay shipping charges to return the

product to the buyer.

The Company warrants that the firmware designed by it for use with the unit will execute its

programming instructions when properly installed on the unit. The Company does not warrant that the

operation of the unit or firmware will be uninterrupted or error-free.

Front Matter

BreezeACCESS 2.4 Series iii BS Equipment Installation Manual

Limitations of Warranty

The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance

by the buyer, buyer supplied interfacing, unauthorized modification or misuse, operation outside of

the environmental specifications for the product, or improper site preparation or maintenance. No

other warranty is expressed or implied. The Company specifically disclaims the implied warranties of

merchantability and fitness for any particular purpose.

BreezeCOM shall not be liable to any person for any special or indirect damages, including, but not

limited to, loss of profits or revenues, loss of use or damage to any associated equipment, cost of

capital, cost of substitute products, facilities or services, downtime costs or claims resulting from any

cause whatsoever arising from or in any way connected with the manufacture, sale, handling, service,

repair, maintenance or use of the products. In no event shall the company’s liability exceed the

purchase price denoted on the invoice.

Electronic Emission Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation.

FCC Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for digital equipment,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his/her own expense.

Information to User

Any changes or modifications of equipment not expressly approved by the manufacturer could void

the user’s authority to operate the equipment.

Safety Considerations

For the following safety considerations, “Instrument” means the BreezeACCESS Base Station

equipment components and cables.

Front Matter

BS Equipment Installation Manual iv BreezeACCESS 2.4 Series

RF Warning

To comply with FCC RF exposure requirements in section 1.1307, a minimum separation distance of

2m (79 inches) is required between the antenna and all persons.

Line Voltage

Before connecting this instrument to the power line, make sure that the voltage of the power source

matches the requirements of the instrument.

Radio

The instrument transmits radio energy during normal operation. To avoid possible harmful exposure

to this energy, do not stand or work for extended periods of time in front of its antenna. The long-term

characteristics or the possible physiological effects of Radio Frequency Electromagnetic fields have

not been yet fully investigated.

Antenna Installation and Grounding

Be sure that the Outdoor unit, the antenna and the supporting structure are properly installed to

eliminate any physical hazard to either people or property. Verify that the antenna mast is grounded so

as to provide protection against voltage surges and static charges. Make sure that the installation of the

outdoor unit, antenna and cables is performed in accordance with all relevant national and local

building and safety codes.

BreezeACCESS 2.4 Series v BS Equipment Installation Manual

Table of Contents

1. INTRODUCTION.....................................................................................................................1

2. BASIC INSTALLATION .........................................................................................................2

2.1 Packing List – Modular Shelf Equipment.............................................................................2

2.1.1 BS-SH Base Station Shelf..............................................................................................2

2.1.2 AU-A/E-BS Access Units (up to six per shelf)..............................................................2

2.1.3 BS-PS Power Supply (one or two per shelf)..................................................................2

2.2 Packing List – Stand-alone AU-A/E-NI Access Unit...........................................................3

2.3 Other Items Required for Installation....................................................................................3

2.4 Guidelines for Selection of Equipment Location..................................................................3

2.5 Installing the Outdoor Radio Unit.........................................................................................6

2.5.1 Mounting the Outdoor Unit ...........................................................................................6

2.5.2 Connecting the Antenna Cable (AU-RE) ......................................................................8

2.5.3 Connecting the Ground and IF Cables...........................................................................8

2.6 Installing the Modular Shelf Indoor Equipment ...................................................................9

2.6.1 BS-SH Slot Assignments...............................................................................................9

2.6.2 The BS-AU..................................................................................................................10

2.6.3 The BS-PS....................................................................................................................12

2.6.4 Shelf and Modules Installation Procedure...................................................................13

2.7 Installing the AU-NI Indoor Unit........................................................................................14

3. CONFIGURING SYSTEM PARAMETERS........................................................................15

3.1 Getting Started with the Local Terminal.............................................................................15

3.2 Configuring Basic Parameters.............................................................................................17

3.3 Reset Unit............................................................................................................................18

4. VERIFYING CORRECT OPERATION..............................................................................19

4.1 Verifying Correct Operation of the AU-A/E-BS ................................................................19

Table of Contents

BS Equipment Installation Manual vi BreezeACCESS 2.4 Series

4.2 Verifying Correct Operation of the AU-A/E-NI.................................................................19

4.3 Verifying Correct Operation of the Outdoor Unit...............................................................20

5. SPECIFICATIONS.................................................................................................................21

5.1 Radio...................................................................................................................................21

5.2 Outdoor Unit to Indoor Unit Communication.....................................................................21

5.3 Configuration and Management..........................................................................................22

5.4 Interfaces.............................................................................................................................22

5.5 Electrical .............................................................................................................................23

5.6 Mechanical..........................................................................................................................23

5.7 Environmental.....................................................................................................................23

5.8 Standards Compliance, General..........................................................................................23

APPENDIX A. USING TELNET

APPENDIX B. BASIC PARAMETERS

Table of Contents

BreezeACCESS 2.4 Series vii BS Equipment Installation Manual

Table of Figures

Figure 2-1. Holes/Grooves/Screw Holes...................................................................................6

Figure 2-2. AU-RE 3" Pole Mounting Installation Using the Special Brackets ......................7

Figure 2-3. AU-RA/AU-RE Radio Unit Bottom Panel..............................................................8

Figure 2-4. Shelf Slot Assignments...........................................................................................9

Figure 2-5. BS-AU Front panel...............................................................................................10

Figure 2-6. BS-PS Front Panel................................................................................................12

Figure 2-7. AU -NI Rear Panel ................................................................................................14

Figure 2-8. AU -NI Front Panel...............................................................................................14

Figure 3-1. Main Menu ...........................................................................................................16

Table of Tables

Table 2-1: IF Cables...................................................................................................................4

Table 2-2: BS-AU LEDs.........................................................................................................11

Table 2-3: BS-PS Power Supply LEDs....................................................................................12

Table 4-1: AU-NI LEDs...........................................................................................................19

Table 4-2: AU-RA/RE LEDs...................................................................................................20

Table 5-3. Hopping Sequences................................................................................................26

Introduction

BreezeACCESS 2.4 Series 1 BS Equipment Installation Manual

1. INTRODUCTION

This manual describes installation guidelines for BreezeACCESS 2.4 base station

equipment, including the stand-alone AU-E/A-NI-2.4 Access Units and the

modular AU-E/A-BS-2.4 Units with the BS-SH rack mounted shelf.

The BreezeACCESS IP Broadband Wireless Local Loop (WLL) system allows

access service providers to provide high-speed IP connectivity services to their

subscribers. To support IP-based services effectively BreezeACCESS systems

employ wireless packet data switching technology.

The BreezeACCESS 2.4 line of products uses Frequency Hopping Spread

Spectrum radios that operate in Time Division Duplex (TDD) mode in the

2.400GHz – 2.500GHz frequency range.

The AU-A/E-NI and the AU-A/E-BS Access Units are comprised of an indoor

unit and an outdoor unit. In the AU-A-NI and AU-A-BS products, the outdoor

unit (AU-RA) contains the radio module and an integral flat antenna. In the

AU-E-NI and AU-E-BS products, the outdoor unit (AU-RE) contains the radio

module and an interface to an external antenna (not included).

The indoor unit of the AU-A/E-NI is a stand-alone unit (AU-NI) that is powered

from the mains via its AU-PS power supply unit. The indoor unit of the AU-A/E-

BS is a module (BS-AU) that is designed for insertion into the BS-SH shelf. The

BS-SH, which is a 3U shelf suitable for installation in 19"racks, can contain up

to six BS-AU active modules and one or two BS-PS power supply modules. The

shelf is powered from a –48VDC power source. Power supply redundancy is

supported through the optional use of a second BS-PS power supply module.

The indoor unit provides the interface to the network. It also contains an IF

(Intermediate Frequency) module and is connected to the outdoor unit via a

50-ohm coaxial IF cable. The IF cable serves for transmission of the 440MHz IF

signal between the indoor and the outdoor units. It also serves for transferring

power (12VDC), management and control signals from the indoor unit to the

outdoor unit.

Note: The information contained in this manual is applicable to

BreezeACCESS 2.4 units with software release 2.5 and up.

Basic Installation

BS Equipment Installation Manual 2 BreezeACCESS 2.4 Series

2. BASIC INSTALLATION

2.1 Packing List – Modular Shelf Equipment

2.1.1 BS-SH Base Station Shelf

• BS-SH shelf (with blank panels)

• Rubber legs for optional desktop installation

Note: Unless ordered otherwise, each BS-SH will be shipped with one BS-PS

power supply installed.

2.1.2 AU-A/E-BS Access Units (up to six per shelf)

• Outdoor unit:

⇒ AU-RA with integral antenna

⇒ AU-RE with a connector to an external antenna (not included)

• Pole mounting kit for the outdoor unit (with two brackets, four sets of

screws, nuts and washers)

• BS-AU Network Interface module

• Monitor cable

2.1.3 BS-PS Power Supply (one or two per shelf)

• BS-PS Power Supply module

• Power cable

Table des matières

Autres manuels BreezeCOM Point d'accès sans fil

BreezeCOM

BreezeCOM SU-A-2.4 Series Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur
