Safety Symbols

Safety is the most important consideration during installation, operation, and maintenance of the infrared

heater. You will see the following symbols and signal words when there is a hazard related to safety or

property damage.

Improper installation, adjustment, alteration, service, or maintenance can cause

property damage, serious injury, or death. Read and understand the installation,

operating, and maintenance instructions thoroughly before installing or servicing

this equipment. Only trained, qualiﬁed personnel with proper electrical experience

may install or service this equipment.

1.0 Safety •Safety Symbols •Applications

Applications

Commercial / Industrial (Indoors)

Infrared heaters are designed and certiﬁed for use in industrial and commercial buildings such as

warehouses, manufacturing plants, aircraft hangars, and vehicle maintenance shops. For maximum safety,

the building must be evaluated for potential hazards before installing the heater system. A critical safety

factor to consider before installation is the clearances to combustibles.

Garage Only

This heater is NOT approved for use in an indoor residential application. This includes, but is not limited to,

living quarters, solariums, home oﬃces, etc. Consult the local ﬁre marshal and/or insurance provider if

unsure of your application.

Not For Indoor Residential Use.

Installation of this infrared heater system in residential indoor spaces, RVs, mobile homes,

etc. may result in property damage, ﬁre, serious injury, or death.

1.0 Safety

Warning indicates a potentially hazardous situation

which, if not avoided, could result in death or injury.

Caution indicates a potentially hazardous situation

which, if not avoided, could result in minor or

moderate injury.

Notice indicates a potentially hazardous situation

which, if not avoided, could result in property

damage.

NOTICE

WARNING

CAUTION

WARNING

BAH Series Manual

Available Models and Operational Speciﬁcations

Model Number Designation Chart

Model Conﬁguration Examples:

BAH-25-B-10

1.0 Safety •Model Number Designation Chart • Available Models

Series Voltage;

Phase kW Watts Amp BTU/h Weight Length Width Height

BAH-18 -A-05 120; 1ph 0.5 500 4.2 1,700 8 lbs. 18”

6.75” 6.4”

BAH -25 - A-10 120; 1ph

1.0 1,000

8.3

3,400 10 lbs. 25”

BAH -25 - B -10 208; 1ph 4.8

BAH -25 - C -10 240; 1ph 4.2

BAH -35 - A-17 120; 1ph

1.7 1,750

14.0

5,900 13 lbs 35”

BAH -35 - B -17 208; 1ph 8.3

BAH -35 - C -17 240; 1ph 7.0

BAH -35 - G -17 480; 1ph 3.6

BAH-45-B-25 208; 1ph

2.5 2,500

12.0

8,500 16 lbs. 45”

BAH-45-C-25 240; 1ph 10.0

BAH-45-G-25 480; 1ph 5.2

BAH-60-B-30 240; 1ph

3.0 3,000

14.0

10,200 20 lbs. 60”

BAH-60-C-30 480; 1ph 12.0

BAH-60-G-30 240; 1ph 6.2

BAH-60-C-40 240; 1ph

4.0 4,000

16.5

13,500 20 lbs. 60”

BAH-60-G-40 480; 1ph 8.3

BAH-60-D-40 575; 1ph 7.0

Series Length Voltage Code Lamp Wattage Code

BAH

A = 120 VAC

B = 208 VAC

C = 240 VAC

G = 480 VAC

D = 575 VAC

05 = 500 W

10 = 1,000 W

17 = 1,750 W

25 = 2,500 W

30 = 3,000 W

40 = 4,000 W

BAH Series Manual

Combustible Items Include: Moving Objects Include:

• Wood • Overhead doors

• Paper • Vehicles on lifts

• Fabric • Cranes

• Chemicals • Hoists

• Wall or roof insulation • Car wash equipment

When installing the infrared heater system, the minimum clearances to combustibles must be maintained.

These distances are shown in Chart 1.1 and on page 6. If you are unsure of the potential hazards, consult

your local ﬁre marshal, ﬁre insurance carrier, or other qualiﬁed authorities on the installation of infrared

heaters for approval of the proposed installation.

A critical safety factor to consider before installation is the clearances to combustibles. Clearance to

combustibles is deﬁned as the

minimum distance you must have between the indicated surface and the

combustible item.

Considerations must also be made for moving objects around the infrared heater. The

following is a partial list of items to maintain clearances from:

Hazards Include:

For maximum safety the building must be evaluated for hazards before installing the heater system.

Examples include, but are not limited to:

• Gas and electrical lines

• Combustible and explosive materials

• Chemical storage areas

• Areas of high chemical fume concentrations

• Provisions for accessibility to the heater

• Adequate clearances around air openings

• Vehicle parking areas

• Vehicles with lifts or cranes

• Storage areas with stacked materials

• Lights

• Sprinkler heads

• Overhead doors and tracks

• Dirty, contaminated environment

Signs shall be posted specifying the maximum permissible stacking height in order to

maintain clearances to combustibles.

Placement of explosive objects, ﬂammable objects, liquids, and vapours close to the heater

may result in explosion, ﬁre, property damage, serious injury, or death. Do not store, or use,

explosive objects, liquids, and vapour in the vicinity of the heater.

Failure to comply with the published clearances to combustibles could result in personal

injury, death, and/or property damage.

The outside surfaces of the heater are hot during operation and after operation. If contact is

made, permanent skin damage may occur. Do not move, handle, or service the unit during

operation or while hot.

CAUTION

1.0 Safety •Clearances to Combustibles

Clearances to Combustibles

WARNING

BAH Series Manual

Side

Model

Wattage

Mounting

Angle Front Behind End Top Below

All Models

0° 18” (46) 18” (46) 24 (61) 12 (30) 24 (61)

20° 18” (46) 18” (46) 24 (61) 12 (30) 24 (61)

1.0 Safety •Clearances to Combustibles

Space Heating: Mount bottom of heater 8 feet above grade or ﬂoor.

** Mounting angles exceeding 0° must use the angle brackets or additional ﬁeld-supplied brackets,

spacers, chains, etc. as necessary to maintain clearances to combustables.

NOTE: Ensure that building materials with a low heat tolerance (i.e, awnings, fabrics, plastics, sprinklers,

insulation, etc.) are protected against degradation. This may require the heater to be mounted at a distance

in excess of the published clearances to combustibles. Contact the material manufacturer for speciﬁc

details.

SIDE

BELOW

TOP

Figure 1.1 •Clearances to Combustibles

SIDE

TOP VIEW •0°

SIDE

FRONT

BELOW

BEHIND

TOP

Chart 1.1 • Clearances to Combustibles in Inches (cm) (see Figure 1.1)

END VIEW

20° Mounting Angle

END VIEW

0° Mounting Angle

BAH Series Manual

CAUTION:

Use Supply Wires Suitable for 90°C

ATTENTION:

Employer des câbles électriques résistant à 90°C

BRANT RADIANT HEATER LIMITED

34SCOTT AVE., PARIS,ONTARIO, CANADA

MODEL/MODELE

VOLTS/VOLTS

AMPS/AMPERES

WATTS/WATTS

FREQUENCY/FREQUENCE

SERIAL/SERIE

CONFORMSTOUL STD 2021 CERTIFIED TO CSA STD C22.2#

CAUTION:Mountat least 12 inches from ceiling and 18 inches from verticle

walls.Aminimum of 24 inches must be maintained between the heater and

anycombustiblematerial directly radiated by the heater.

ATTENTION:Installeza au moins 12 pouces du plafond et 18 pouces des

mursverticaux.Un minimum de 24 pouces doit etre maintenu entre le

radiateuret tous materiaux.

BAH-35-A-17

120

13.8

1750

60Hz

MAY.21

5008644

CAUTION:Mount with bottom of heater at least 8 feet above

floor or grade.

ATTENTION:Installez a au moins 8 pieds du plancher.

Safety Signs and Labels

It is important to provide warnings to alert individuals to potential hazards and safety actions. Signs should

state the hazards for the particular application and be legible to the building occupants. Consult the

factory or a factory representative for additional information on signage compliance.

Safety warning labels must be maintained on the infrared heater. Illustrations of the safety labels, and their

locations, are pictured below. When no longer legible, they must be replaced. Contact either your local

distributor or the product manufacturer for obtaining replacement signs or labels.

1.0 Safety •Safety Signs and Labels

Top View

Rating Plate

SAMPLE

BRANT RADIANT HEATER LIMITED

34 SCOTT AVE., PARIS, ONTARIO, CANADA

MODEL/MODELE

VOLTS/VOLTS

AMPS/AMPERES

WATTS/WATTS

FREQUENCY/FREQUENCE

SERIAL/SERIE

CONFORMS TO UL STD 2021 CERTIFIED TO CSA STD C22.2#

CAUTION: Mount at least 12 inches from ceiling and 18 inches from verticle

walls. A minimum of 24 inches must be maintained between the heater and

any combustible material directly radiated by the heater.

ATTENTION: Installez a au moins 12 pouces du plafond et 18 pouces des

murs verticaux. Un minimum de 24 pouces doit etre maintenu entre le

radiateur et tous materiaux.

BAH-35-A-17

120

13.8

1750

60 Hz

MAY. 21

5008644

Mounting Label

Ground Screw Label

Wire Label

CAUTION: Mount with bottom of heater at least 8 feet

above floor or grade.

ATTENTION: Installez a au moins 8 pieds du plancher.

GROUND

SCREW

INSIDE

CAUTION:

Use Supply Wires Suitable for 90°C

ATTENTION:

Employer des câbles électriques résistant à 90°C

BAH Series Manual

1.0 Safety •Standards, Certiﬁcations, and Government Regulations

Standards, Certiﬁcations, and Government Regulations

Installation of this infrared heater must comply with all applicable local, province, and national

speciﬁcations, regulations, and building codes. Contact the local building inspector and/or ﬁre marshal for

guidance.

The heater must be electrically grounded in accordance with the following codes:

Canada: Refer to Canadian Electrical Code CSA C22.1 Part 1 (latest edition).

United States: Refer to National Electrical Code®, ANSI/NFPA 70 (latest edition).

Wiring must conform to the latest edition of National Electrical

Code®, local ordinances, and any special diagrams from the manufacturer.

Brant Radiant Heaters Limited’s units comply or are certiﬁed by one or more of the following

organizations or standards:

• CSA STD 22.2

• UL STD 2021

BAH Series Manual

2.0 Installation •Design

Read and understand, the installation, operating and maintenance instructions

thoroughly before installing or servicing this equipment.

Design

To ensure a safe, properly designed heating system, a layout should be developed for the correct

placement of the infrared heater(s).

Aside from safety factors such as clearances to combustibles (see Chart 1.1 on page 6), you should also

take into consideration the environment (e.g., cold/drafty, average, protected), heat coverage (sq. ft.)

needed, heater centers, and the distance behind a person or work station(s). Also, the eﬀective infrared

surface temperature of a person or object may be diminished with wind above 5 mph. Wind barrier(s) may

be required. Most importantly, clearances to combustibles must always be maintained! Refer to hazards

on page 5.

When positioning the heaters, keep in mind combustible materials, lights, sprinkler heads, overhead doors,

storage areas with stacked materials, gas and electrical lines, parked vehicles, cranes, etc. Refer to Page

6 for minimum clearances to verify that a safe installation exists.

This installation manual, along with national, state, provincial, and local codes, address these issues. It is

critical that you read, understand, and follow all guidelines and instructions. Always inspect and evaluate

the mounting conditions, application, and wiring.

When heated, materials high in hydrocarbons (solvents, paint thinner, mineral spirits, formaldehydes, etc.)

can evaporate and/or degrade. This may result in odors or fumes being emitted into the environment. To

correct this problem, clean the area and/or introduce additional ventilation. Heaters installed and serviced

in accordance with the installation manual do not emit foul odors into the environment.

IMPORTANT: Fire sprinkler heads must be located at an appropriate distance from the heater to avoid an

inadvertent discharge. This distance may exceed the published clearances to combustibles. Certain

applications may require the use of high temperature sprinkler heads or relocation of the heaters.

Fire sprinkler systems containing propylene glycol, antifreeze, or other potentially ﬂammable substances

shall not be used in conjunction with this heater without careful consideration for and avoidance of

inadvertent discharge hazards. For further information consult NFPA 13. Always observe applicable

state and local codes.

CAUTION

2.0 Installation

WARNING

BAH Series Manual

2.0 Installation •Outdoor Application

Chart 2.1 • Outdoor Comfort Heating Application Chart

*Clearances to combustibles must be maintained at all times. If infrared heaters are mounted too low or too

high, they may result in discomfort or lack of heat.

Chart 2.2 • Indoor Spot Heating Application Chart

Heater installation shall comply with all IOPM, NEC, ANSI/NFPA-70, CEC, and local restrictions.

Figure 2.1 • Heating Application

When comfort heating people, two heaters should be used to heat both sides of the individual. Heater

installation shall comply with all IOPM, NEC, ANSI/NFPA-70, CEC, and local restrictions.

12 INCHES

18 INCHES

24 INCHES

Heat Pattern

Mounting

Height

Areas Heated in Feet

1 kW 1.75 kW 2.5 kW 3 & 4 kW

7 feet 8 x 10 8 x 11 8 x 12 8 x 13

8 feet 9½ x 11½ 9½ x 12 9½ x 13 9½ x 14½

9 feet 10½ x 12½ 10½ x 13 10½ x 14 10½ x 15½

10 feet - 11½ x 14½ 11½ x 15½ 11½ x 16½

11 feet - 12½ x 15 12½ x 16 12½ x 17½

12 feet - - 14 x 18 14 x 19

13 feet - - 15 x 18.9 15 x 20

14 feet - - - 16 x 21

15 feet - - - 17½ x 22½

Watts Density At Floor Level

Mounting

Height

Density in Watts

1 kW 1.75 kW 2.5 kW 3 kW 4 kW

7 feet 12.4 20.0 26.5 28.8 38.4

8 feet 9.2 16.1 20.1 22.0 29.4

9 feet 7.6 13.4 16.8 18.6 24.9

10 feet - 11.1 14.5 16.0 21.6

11 feet -9.3 12.5 14.0 18.7

12 feet - - 10.0 11.2 15.0

13 feet - - 8.8 10.0 13.3

14 feet - - - 8.9 11.9

15 feet - - - - 10.9

Estimating Required Loading

Type of Building Watts Required Per Square Foot At Floor Level

Insulated building 10

Uninsulated 16

Outdoor Sheltered 25-30

Outdoor Unsheltered 45

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Brant Radiant Heaters Chauffage

Brant Radiant Heaters

Brant Radiant Heaters AVS-40N Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DX2-20-60 Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters HL2 Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DX3L Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DES3-20-50 Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters HL3 Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DX2 Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DET3 Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DX3 Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters LD Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters HL2 Series Manuel utilisateur

Brant Radiant Heaters

Brant Radiant Heaters DES3 Series Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
