Brandt WFE0610K Manuel utilisateur

WASHING MACHINE

USER MANUAL

THE CONTENTS

SECTION 1:BEFORE USING 2

•Safety warnings 2

•Recommendations 2

SECTION 2: INSTALLATION 3

•Removal of the transportation screws 3

•Adjustment of feet 3

•Electrical connection 4

•Water supply connection 4

•Water drain connection 5

SECTION 3:TECHNICAL SPECIFICATIONS 6

SECTION 4:CONTROL PANEL 7

•On/Off button 7

•Signal light 7

•Function buttons 7

•Temperature adjustment knob 8

•Program knob 8

SECTION 5:WASHING YOUR LAUNDRY 12

•Before washing 12

•Running the machine 13

SECTION 6:MAINTENANCE AND CLEANING 14

•Water inlet filters 14

•Pump filter 15

•Detergent drawer 16

•Siphon plug 17

•The cabinet 17

•The drum 17

•Remove of your machine from lime 17

SECTION 7: PRACTICAL INFORMATION 18

SECTION 8: AVOIDING MINOR FAULTS 19

SECTION 9:INTERNATIONAL WASHING SIGNS 23

SECTION 1:BEFORE USING

SAFETY WARNINGS

•Do not use a multiple socket or extension cord.

•Do not insert a plug with damaged or broken cord into the socket.

•If the cord is damaged it should be replaced by the manufacturer or

appointed service agent in order to avoid a hazard.

•Never remove the plug from the socket by pulling from the cord

section. Remove the plug by holding.

•Do not plug the power supply with wet hands.

•Never touch the machine with wet hands or feet.

•Never open the detergent drawer while the device is running.

•Never force to open the door of the machine while the machine is

running.

•Since the machine can reach high temperatures while running, do not

touch the drain hose and water during draining.

•In case of any failure, first unplug the device and close the water tap.

Do not attempt to repair.Please apply to the nearest authorized

service station.

•Do not forget that the packing material of your machine may be

hazardous for children.

•Do not let your children play with the washing machine.

•Keep your pet away from your machine.

•Your machine should only be used by adults within the information

written in this manual.

•Your machine is designed for use in house environment. Warranty

will be invalid if you use it for commercial purposes.

RECOMMENDATIONS

•The detergent or softener in contact with air for a long time will dry

and stick to your detergent drawer.To avoid this put your detergent

and softener into the detergent drawer just before washing.

•It is recommended that you use pre-washing program for only very

dirty clothes.

•Please do not exceed the maximum loading capacity.

•If you will not use your machine for a long time, unplug your machine,

close the water supply and leave the door open in order to keep the

inside of the machine dry and for prevention from unpleasant odour.

•As a result of the quality control procedures, a certain amount of

water may remain in your machine. This is not harmful for your

machine.

SECTION 2: INSTALLATION

You must pay attention to the following issues before using your washing

machine.

REMOVAL OF TRANSPORTATION SCREWS

•Transportation screws, which are located at the back side of the

machine, must be removed before running the machine.

•Loosen the screws by rotating counterclockwise by a suitable wrench.

(DIAGRAM-1)

•Remove the screws by pulling them.(DIAGRAM-2)

•The plastic parts located in the interior part of your machine will fall

down under the device.

•Lift your machine up slightly, pick up the plastic parts.

•If all of the plastic parts of screw groups have not fallen down; open

the door of your machine,move the drum until all plastic parts fall

down. Collect the parts that have fallen to the floor.

•To the holes where the transport screws have been removed, insert

the plastic transport screw taps found in the accessories bag.

(DIAGRAM-3)

•The transportation screws, that have been removed from the machine

should be kept in hand for any other transportation necessities.

DIAGRAM-2

DIAGRAM-1 DIAGRAM-3

ADJUSTMENT OF FEET

•Do not install your machine on rugs or similar surfaces.

•For your machine to work silently and without any vibration, it should

be settled on a flat, non-slippery and tough ground.

•You can adjust the balance of your machine from its feet.

•First, loosen the plastic adjustment nut.

•Adjust by rotating the feet upwards or downwards.

•After the balance has been reached, tighten the plastic adjustment

nut again by rotating it upwards.

•Never put cartons, wooden blocks or similar materials under the

machine to balance the irregularities on the level of the ground.

ELECTRICAL CONNECTION

•Your washing machine works with 220-240V and 60Hz.

•A special grounded plug has been attached to the network cable of

your washing machine. This plug must definitely be inserted to a

grounded socket with 10 ampere. The fuse flow value of the

electricity line attached to this should also be 10 ampere. If you have

no such sockets and fuses in your house, let it be made by a qualified

electrician.

•Our company will not be responsible for any damages that may

occur as a result of usage without grounding.

WATER SUPPLY CONNECTION

•Your machine has a single water (cold) inlet.

•To prevent from the leakages on the connection joints, 1 seal is

included in the hose packing.(Fit this seal on the end of the water

inlet hose at the tap side.)

•Connect the end with bracket of the water inlet hose to the water inlet

valve at the rear of the machine and the other end to your tap. In

situations where you are not assured, let a qualified plumber make

the connection works.

•Water pressure of 1-10 bars from your tap will enable your machine

to work more efficiently.(1 bar pressure means water flow of more

than 8 liters in 1 minute from a fully opened tap).

•After connections are completed, check for the non-leakage of the

connection joints by turning on your tap completely.

•Be sure that water inlet hoses are not folded, broken or crushed.

•Mount the water inlet hoses to a 3”/4, geared water tap.

Cold water inlet

WATER DRAIN CONNECTION

•Be sure that water inlet hoses are not folded, twisted, crushed or

elongated by stretching.

•Water drain hose should be mounted at a height of minimum 60 cm,

maximum 100 cm from the ground.

•The end of the water drain hose may directly be fitted to the dirty

water outlet hole or a special apparatus mounted on the outlet

bracket of the wash-stand.

•Never attempt to extend the water drain hose by adding extra parts.

SECTION 3:TECHNICAL SPECIFICATIONS

Maximum dry laundry capacity (kg) 5

Recommended loading (kg) 4,5

Height (cm) 85

Width(cm) 59,6

Depth (cm) 54

1 2 3

1-Top 5-Handle

2-Detergent drawer 6-Filter cover

3-Control panel 7-Kickplate

4-Door

SECTION 4:CONTROL PANEL

1 2 3 4

5 6

1-Detergent drawer 4-Program knob

2-Signal light 5-On/Off button

3-Temperature adjustment knob 6-Function buttons

ON/OFF BUTTON

Used to turn on and to shut off your machine and to start the

selected program.

WARNING!

Your machine should be in shut off status before selecting a

program or changing a continuing program.

SIGNAL LIGHT

It turns on when the on/off button is pressed and indicates that

your machine is ready to wash. It turns off when the on/off button

is repressed.

FUNCTION BUTTONS

Half load

By using this function, you can wash your clothes using less

energy and water.You must load your machine with half or less

than half of the quantity of clothes indicated in Table-1(see Pages

10-11) When this function is used, half of the quantity

recommended by the detergent producers should be used.

No spin

This program is recommended to be used for your sensitive

clothes which should not be spinned.By pressing this function

button, you prevent the spinning process which is included in the

program.

TEMPARATURE ADJUSTMENT KNOB

By the temparature adjustment knob, you can adjust the washing water

temparature of your clothes between (cold wash) and 90 °C. When you are

selecting the washing water temparature, pay attention to the international

washing signs on your clothes.

PROGRAM KNOB

By the program knob, you can select the program in which you desire to wash

your clothes. You can adjust the program selection process by rotating the

program knob clockwise. If your turn the reverse direction, you may give

damage to your machine.You must be careful that the adjustment sign comes

exactly on the program you wish to select. While your machine is running, the

program knob rotates automatically and follows the program steps. Do not

turn the program knob while the program is in operation. You may damage

your machine.

I Off

1 Cotton 90°(Prewash)

2 Intensive 90°

3 Normal 60°

4 Delicate 40°

5 Eco 30°

6 Synthetic intensive 60°

7 Synthetic normal 50°

8 Delicate normal 40°

9 Wool normal 40°

Softening

Rinsing

Spinning

Draining
