BPE Smart Mode d’emploi

AC EV ChargeDepot 22kW

Smart

Socket

User & Installation Manual

1. Safety Information....................................................................1

1.1. Important safety instructions.....................................1

1.2. Notes..............................................................................2

2. Specication...............................................................................3

2.1. Data-sheet.....................................................................3

2.2. Features.........................................................................4

2.3. Dynamic Load Balancing.............................................4

3. Preparation for Installation....................................................5

3.1. Installation requirements............................................5

3.2. Electrical Wiring Diagram............................................6

3.2.1. 400V three phase.........................................6

3.3. Installation Considerations.........................................6

4. In the Box....................................................................................7

5. Installation Instructions..........................................................8

5.1. Step-by-Step Installation Instructions for:................8

5.1.1.BottomWiringConguration.....................8

5.1.2.TopEntryConguration.............................10

5.1.3.RearEntryConguration...........................12

5.2. Set the Operating Current .......................................14

5.3. Emergency Shutdown Button...................................14

5.4. Leakage Test...............................................................15

6. Operating Status......................................................................16

6.1. Power ON Checking...................................................16

6.2. LED Lights Instruction................................................16

6.3. Buzzer Prompt Description.......................................17

7. Maintenance Instructions.....................................................18

7.1. Product Servicing........................................................18

7.2. Warranty Description.................................................18

7.3. Safety Notice...............................................................18

7.4.RiskNotication..........................................................19

User Manual Contents......................................................1

App Setup .....................................................................................21

1.1 Download BPE App.........................................................21

1.2 Connecting the EV Charger............................................21

1.3 Scanning the QR Code...................................................22

1.4HomePage......................................................................23

1.5 Set Charging Times.........................................................24

1.6 Settings Page ..................................................................25

1.7 DLB Options.....................................................................26

1.8 Troubleshooting..............................................................27

BPE Smart App Setup.................................................................20

• Read this entire document before installing or using the EV Charger.

•Keep children away from operating the EV Charger.

•The EV Charger must be grounded through a permanent wiring

system or an equipment grounding conductor.

•Donotinstallthemountingbracketnearammable,explosive,harsh,

orcombustiblematerials,chemicals,orvapours.

•DonotexceedspeciedEVChargeroperatingparameters.

•Never spray water or any other liquid directly at the wall mounted EV

Charger. Never spray any liquid onto the charge handle or submerge

the charge handle in liquid. Store the charger connector above

thegroundtopreventunnecessaryexposuretocontaminationor

moisture.

•DonotuseEVChargerifitisdefective,appearscracked,frayed,

broken,orotherwisedamaged,orfailstooperate.

•Donotattempttodisassemble,repair,tamperwith,ormodifytheEV

Charger yourself. Any maintenance must be performed by authorised

technical personnel or our company’s technical support. Contact us for

anyrepairsormodication.

•Handle with care when transporting the EV Charger. Do not subject

ittostrongforce,impactorpull,twist,tangle,drag,orstepontheEV

Charger to prevent it or any components from damage.

•Do not touch the EV Charger’s end terminals with sharp metallic

objects,suchaswire,tools,orneedles.

•Do not insert foreign objects into any part of the EV Charger.

•UseoftheEVChargermayaectorimpairtheoperationofany

medicalorimplantableelectronicdevices,suchasanimplantable

cardiacpacemakeroranimplantablecardiovasculardebrillator.

Checkwithyourelectronicdevicemanufacturerconcerningtheeects

that charging may have on such electronic devices before using the EV

Charger.

This document contains important instructions and warnings that

must be followed for both installation and maintenance of the EV

Charger.

1.1. Important Safety Instructions

1. Safety Information

WARNING

• Do not use private power generators as a power source for

charging.

•Incorrect installation and testing of the EV Charger could

potentially damage either the vehicle’s battery and/or the

EVChargeritself.Anyresultingdamageisexcludedfrom

New Vehicle Limited Warranty and the EV Charger Limited

Warranty.

•Do not operate the EV Charger in temperatures outside its

operating range of -25°C to +55°C.

1.2. Notes

•Ensure that the EV Charger’s charging cable is positioned so it

willnotbesteppedon,drivenover,trippedon,orsubjectedto

damage or stress.

•Do not use cleaning solvents to clean any of the EV Charger’s

components.TheoutsideoftheEVCharger,thecharging

cable,andtheconnectorendofthechargingcableshould

be periodically wiped with a clean dry cloth to remove

accumulation of dirt and dust.

•Be careful not to damage the circuit board when removing the

power entry knock-out.

CAUTIONS

2.1 Datasheet

2. Specication

2.2. Features

•Built-inwithover-voltageprotection,over-currentprotection,

overtemperatureprotection,groundfaultdetection,CP

abnormal signal protection and Type ARCD for Europe

standard.

• Operating temperature range: -25°C - 55°C.

•IP65protectingrate,operatinghumidityrange0-95%forindoor

and outdoor.

•Built-intemperaturesensorforfireprotection.

• Easy cable storage.

• The ramp-down current mode protects the EV batteries.

• The EV charger can be wall-mounted or pole-mounted. There

arethreewiringconfigurationsfortheEVchargerbottom,top

and rear wiring.

• RFID card or auto-start charging modes.

• International CP mode or compatible modes.

•Ratedchargingcurrentcanbesetaccordingtodifferenthome

load conditions.

• Lightning protection ensures personal safety.

• Standard: EN IEC 61851-1 IEC 61851-21-2.

•Corrosionresistance:MeetGB/T10125-1997artificial

atmosphere corrosion test and salt spray test.

•Certificate:CE

2.3. Dynamic Load Balancing

Dynamic Load Balancing regulates the charging power to

harmonise with other household loads to avoid current overloading

the main breaker. This is achieved by reducing the current draw of

the EV charger so the system operates smoothly below the

property's limit. This optimises home power usage and avoids

tripping the breaker which would cause a power outage.

Installation of the EV Charger requires that you:

•Calculatetheexistingelectricalloadtodeterminethe

maximumoperatingcurrent.

• Calculate the distance to ensure minimal voltage drop.

• Obtain any necessary permits from the local authority that has

jurisdictionandconfirmthatthefollow-upinspectionhasbeen

scheduled by an electrician after the installation is complete.

• Use only copper conductors.

• Use conductors that are sized in accordance with local wiring

regulations. The selected cablesmust be able to sustain

periods of constant load of up to 40A.

• Use protective devices. The circuit protection device chosen

must incorporate a suitable residual-current device (RCD) and

over-current protection in relation to the electrical load

selected.

Choose the Best Location for the EV Charger:

• Determine the parking location of the vehicle to ensure that

the charge cable reaches the charge port.

• Determine the parking location of the vehicle to ensure

that the current charge cable reaches the charge port in an

enclosedgarage,typicallyonthevehicle’schargeportside.

•Inawell-ventilatedarea.Avoidinstallationinanenclosedbox,

or adjacent to hot appliances.

• 1.2m above the ground.

•190mmfromanyobstacletoallowcablecollected.

Note:

The EV Charger is approved for outdoor use. Protection from rain

is recommended but not required.

3. Preparation for Installation

3.1. Installation Requirements

3.2. Electrical Wiring

3.2.1. 400V Three-Phase

TheL1, L2, L3, PE, and Nshouldbewiredaccordingtolocal

requirements.Thephases usedmustmeasure 400V(±10%).

•WARNING: Each ground must be connected to neutral

atonlyonepoint,ortheEVchargercannotoperate.

•WARNING:BeforeinstallingtheEVcharger,identifythe

type of utility service connection available on site. If you

are unsure about the type of connection available at

theservicepanel,consultanelectricianforassistance.

3.3. Installation Considerations

Three congurations are available to install the EV Charger:

The location of the conduit determines which installation method to

follow.Iftheconduitrunsalongtheoororlowtothewall,usethe

bottomentryconguration.Iftheconduitcomesfrominsidethe

wall,usetherearentryconguration.Iftheavailableconduitcomes

fromtheceiling,usethetopentryinstallation.

Note: Throughoutthemanual,“conduit”isusedasthestandard

term for the protective tubing that houses the service wiring. In

regionswhereconduitisnotused(Europeforexample),acable

comprised of service wiring enclosed in a protective jacket may be

substituted for conduit if allowed by local regulations.

Here are some additional guidelines:

•Conduit openings are sized for 32mm conduit.

• Conduitneedstobemetalandameretardant.

•Use an appropriate circuit breaker.

• Tokeepthehousingwaterproof,usecableglands.
