Unplug’D Quick Start Guide
360.464.2119 | www.boxlight.com
UNPLUG’D-IPro2 Quick Installation Guide
1.Package Contents
UNPLUG’D Box
UNPLUG’D USB Token
Power Adapter (DC +5V, 2.6A)
WiFi Antenna x 2
Wall-mount kit
Quick Installation Guide
Warranty Card
2.USB Token Contents
Windows Installer (UNPLUG’D Windows Installer)
Mac Installer (UNPLUG’D Mac Installer)
VAC Driver (For Windows XP Audio Projection)
VDD Driver (For Windows XP/Vista Virtual Extended Screen)
USBoIP Driver (For IWB feature)
User Manual
UNPLUG’D Execution File
SVS Driver (For Mac Virtual Extended Screen)
Utility
PtG Converter (For MobiShow PtG function)
SNMP Manager (For SNMP Management)
3.Physical Details
- -
2
- -
3
Front Panel
Rear Panel
Power
Power Jack
VGA Connector
RJ-45
Antenna
Audio Jack
HDMI
Antenna
USB Port
USB Port
UNPLUG’D-IPro2 Quick Installation Guide
UNPLUG’D-IPro2 Quick Installation Guide
Bottom Side
Reset Button
Screw hole
(Optional kit for Wall Mount)
- -
4
UNPLUG’D-IPro2 Quick Installation Guide
4.What You Might Need
Projector/Display with VGA/HDMI interface
Windows or Mac PC/Laptop
Apple iPhone, iPad or iPod-touch device
Android Phone or Tabl et device
Speaker (Optional, for audio projection feature)
USB Mouse and Keyboard (Optional, for remote desktop feature)
USB HID Touch Screen/IWB Device (Optional, for USB over IP feature)
5.UNPLUG’D Quick Installation
1) Connect UNPLUG’D device to Projector/Display through VGA/HDMI port and
turn on Projector/Display p o w e r.
2) Connect the power adaptor to UNPLUG’D device and press the power button
to turn on UNPLUG’D device. System will be ready when the LED light turns
to green.
It will show the default standby screen as below when system is ready.
- -
5
UNPLUG’D-IPro2 Quick Installation Guide
DoWiFi for Windows
1) Make sure your PC WiFi is enabled already, and connect your PC to
UNPLUG’D box through WiFi.
2) Open your browser and enter the Device Host Name (SSID) or IP address in
the browser. You can find the IP address and Host Name (SSID) on the
projector screen. (Default Host Name (SSID) is UNPLUG’D, Default IP is
192.168.100.10)
3) Download the client software for “XP/Vista/Windows 7 / 8” and install on
your PC. (You can also launch the application from PnS token directly.)
4) Launch UNPLUG’D client and connect to UNPLUG’D receiver.
(Make sure your personal firewall allows UNPLUG’D software to pass
through.)
5) Enter the CODE and you can see the Code on the projector standby screen.
- -
6
UNPLUG’D-IPro2 Quick Installation Guide
6) Click the button to start full screen projection, or choose one of the
numbers (1 to 4) to project to the split screen.
7) Connect the USB input devices to UNPLUG’D to select and control the
PC/Mac remotely.
- -
7
UNPLUG’D-IPro2 Quick Installation Guide
6.DoWiFi for Mac
1) Enable your WiFi and connect to UNPLUG’D WiFi network.
2) Open your browser and enter the Device Host Name (SSID) or IP address
on browser. You can find the IP address and Host Name (SSID) on the
projector screen. (Default Host Name (SSID) is UNPLUG’D, Default IP is
192.168.100.10)
3) Download the client software and run the installer.
- -
8
UNPLUG’D-IPro2 Quick Installation Guide
4) Launch UNPLUG’D software, connect the UNPLUG’D device and enter the
Code.
5) Click the button to start full screen projection, or choose one of the
numbers (1 to 4) to project to the split screen.
6) Connect the USB input devices to UNPLUG’D to select and control the
PC/Mac remotely.
- -
9
