BOXLIGHT MimioPro 4 Manuel utilisateur

www.boxlight.com ©Boxlight 2022

MimioPro 4 Interactive

Display

Technical User Manual

Note: All the pictures in this manual are for reference only, subject to

our available products.

www.boxlight.com ©Boxlight 2022

Contents

Safety Warning ................................................................................... 1

Control Panel...................................................................................... 6

Connection and Settings .................................................................. 17

Simple Troubleshooting.................................................................... 22

Maintenance ..................................................................................... 27

www.boxlight.com ©Boxlight 2022

Safety Warning

Before operating, please read this manual thoroughly, and keep it for

future reference.

Images shown in this manual are only indicative. There may be

differences between the pictures and the actual product.

Placement

•Do not put heavy objects on top of the unit.

•Do not put the unit near appliances that generate magnetic

fields.

•Do not expose the unit to direct sunlight and other sources of

heat.

•Do not place the unit on an unstable cart, stand, tripod, bracket,

table, or shelf.

•Do not put any liquid near or on the unit, make sure to not spill

any liquid inside the unit.

www.boxlight.com ©Boxlight 2022

Power

Supply

•Keep power cable from physical or mechanical damage.

•Check and ensure AC source is connected to the ground.

•The power cable is exclusively for use with this device only.

•Unplug power supply during severe weather such as

thunderstorm and lightning storms.

•Check that the unit's operating voltage is identical with your local

power supply.

•Use the original power cable from the accessory bag. Do not

modify or lengthen it.

•Unplug power supply during school breaks or when the unit will

be in idle for a long time.

LED Screen

•Unplug the power cable before cleaning.

•Clean the screen with a soft, dustless, and dry cloth.

•For deep clean, please contact an authorized service center.

Never use water or the spray type detergent to clean the unit.

•Never use any other hard or sharp object to replace the touch

pen.

•To ensure the best display quality and extend the life of the

product, do not display overly bright images for extended

periods of time.

www.boxlight.com ©Boxlight 2022

Temperature

•Normal operating temperature is 0 ~ 40℃.

•Do not place the unit near or over a radiator or a heater.

•If your unit is suddenly moved from a cold to a warm place,

please unplug the power cable and do not turn it on for at least 2

hours, making sure the moisture inside the unit is all evaporated.

Humidity

•Do not expose the unit to rain, or place in high humidity area.

Please make sure indoor environment is dry and cool.

•Normal operating humidity is 10%~90%RH.

Ventilation

•Please put the unit in a well-ventilated place so the heating can

be released easily.

•Ensure that the unit has enough space for ventilation. Space

requirement: left, right and back >10cm, top> 20cm.

www.boxlight.com ©Boxlight 2022

Earphones

Before using earphones, be sure to turn down the volume. Listening

to loud sounds for a long time might affect the hearing.

Standby

The display will go to the standby mode but be sure not to turn off

the unit after pressing the standby key.

Battery

•Please make sure that batteries get proper disposal or recycle

after using.

•Please keep the battery away from children and do not throw the

battery into a fire.

•Caution risk of fire or explosion if the battery is replaced by an

incorrect type.

Notes for Cleaning

There are vents on back cover, so do not use any liquid or spray

directly during cleaning.

www.boxlight.com ©Boxlight 2022

Power Switch Status

“I” means power on, “O” means power off.

Notes for Maintenance

This machine can only be maintained by a certified engineer.

www.boxlight.com ©Boxlight 2022

Control Panel

1) Prepare to Install

Number Items

Loudspeaker

www.boxlight.com ©Boxlight 2022

Magnetic zone: Area for placing the absorptive

magnetic pen.

：Tap to enter energy-saving, press at least 2

seconds to enter standby mode.

Remote control signal receiver

Light sensor

3.1 : Support charging, data transmission,

extension for audio and video output interface, etc.

Note: The maximum rated power of the USB

Type-C port is 65W. When using this port to

charge electronic devices, the charging power of

the electronic device cannot exceed the rated

power of this port. If the charging power of

the electronic device exceeds the rated charging

power of this port,

please do not

directly use this

port for charging.

www.boxlight.com ©Boxlight 2022

HDMI 3

TOUCH 2

3.0

Microphone
