Boundless CFX Manuel utilisateur
CFX VAPORIZER
Building off the powerful innovative
heating technology found in the CF,
The CFX takes vape innovation to
the next level. Featuring a full 1.7 inch
OLED Screen, The CFX easily
produces massive amounts of vapor
while simultaneously cooling down
the vapor being drawn.
With a true convection based heating
system, the CFX can produce a vapor
that has full flavor and a full body.
The CFX easily cools the vapor by
taking advantage of an innovative
bottom airflow path. Creating some of
the purest tasting vape usually
reserved for desktop vaporizers.
Patented Convection Airflow System With Display (CAS)
What’s in the Box：
1 CFX Dry Herb Vaporizer
1 Liquid/Wax Chamber (Organic Cotton)
3 Stainless Steel Screens
1 Packing Tool and Dabber
1 Cleaning Brush
1 USB Charger
1 DC Adapter
1 User Manual
What’s in the Box：
1.77’’ Colored Display with Full Range Temperature Control: 100˚F - 430˚F.
Next Generation Patented Convection-Airflow-System (CAS) Technology.
Portable Vaporizer that is Ergonomically Designed and Easy to Hold and Operate.
Non Combustion Vaporizer.
Fully Isolated Air Path allows for Clean and Pure Vaping.
Compact, Rugged Design.
Vibration Feedback for Operations.
Built with Medical and Food Grade Material.
Dual Charging: Fast Charging DC 12V 1.5A Port, Regular Charging Micro 5-Pin 5V 2A Port.
3.Mouthpiece
4. Mouthpiece Base
5. Housing
6. Display
7. USB Charge Port
8. DC Charging Port
9. Vaporizer Base
10. Liquid/Wax
Chamber
What’s in a CFX Vape?
1. Power Button
2. Temperature
Control Buttons
Product Configur
1. Power Button - On/Off with Vibration Feedback.
2. Temperature Control Buttons - Adjusting accurately by 1˚F per setting, 100˚F-430˚F.
3. Mouthpiece - Food Grade, Rotary 360°, Vape from any direction.
4. Mouthpiece Base - Made with different easy disassembled components.
5. Housing - Hot-Dissipation Design. Rugged and Ergonomically Designed.
6. Display - 1.77’’ TFT Colored Display indicates Temperature Information, Battery Status,
Duration Timer etc.
7. USB Charge Port - Regular Charging, Micro 5-Pin 5V 2A is best suggested.
8. DC Charging Port - Fast Charging, DC 12V 1.5A.
9. Vaporizer Base - Air Inflow.
10. Liquid/Wax Chamber - Fill your choice oil/waxy (not the same time)
How to LOAD
Remove mouthpiece from the CFX.
Insert Screen into ceramic heating camber.
Note: Screens (3 included) in the housing unit and heating
chamber can be changed periodically to ensure clean
vaping. Additional screens sold separately.
Attach CFX mouthpiece.
Load choice blend loosely into the ceramic heating
chamber. Tamp down with the dabber tool.
Do not over-fill. (note: do not turn on device while loading blend).
How to Use CFX with Dry Herbs?
ACTIVATE
wHo t
Rapidly press Power button five times within 2 seconds to power on CFX. The display will
turn on.
The display indicates the Temperature Information, Battery Status, Session Timer etc.
The Session time is 300 seconds (5 minutes). “S” is short for Starting, “F” is short for Finishing.
The Temperature Range is 100˚F-430˚F, shown as below:
sF
300SEC
400F
100
150
200 250 300
350
430
400
DISPLAY INDICATION
When setting the Temperature, the display is Red.
After Temperature is reached, the display turns Green. With Session Timer running.
SF
000S
139F
100
150
200 250 300
350
430
400
sF
300SEC
400F
100
150
200 250 300
350
430
400
LOAD
Oil
Fill oil/wax chamber with at least 5 drops of
(0.2 - 0.3ml) oil. Let oil settle for a few seconds.
Insert oil/wax chamber into ceramic
heating chamber
(note: do not turn on device while loading oil/wax chamber).
Wax
Place concentrated oil around the recess of the lid.
Screw lid on to oil/wax chamber.
Insert oil/wax chamber, with lid facing down
towards ceramic heating chamber (note: do not
turn on device while loading the oil/wax chamber.
How to Use CFX Vape with oil/wax
8
