PRECAUTIONS

How to Handle Discs

• Handle a disc by its edges. Do not touch the playing side.

Precautions And Warnings

• To reduce the risk of fire, electric shock, and interference, do not attempt to repair this

unit yourself. Refer all service to a qualified technician.

• Keep the volume at a reasonable level to avoid distracted driving. High volume levels

may make it difficult to concentrate on traffic and road conditions while driving.

• If the car has been in direct sunlight for an extended period, you may need to reduce the

temperature inside the car before turning on and using the unit.

• The unit is designed to be installed in a level,horizontal position. For optimal performance,

avoid installing the unit at an angle.

• Before inserting a disc, wipe the disc outward from the disc center with a

clean, soft, dry and lint-free cloth. Do not use solvents or thinners such a

petrol/benzene or cleaners.

• After removing a disc from the disc slot, place the disc in a sleeve or case

to keep it clean and prevent scratches.

• Do not stick paper or tape on the disc surface. If there is glue (or adhesive)

on the disc surface, remove it before using the disc.

Lithium Battery Cell Warnings

• Cell leakage may cause damage to the remote control.

• Do not throw cells into as this may cause an explosion.

• Keep battery cells out of reach of children.

CAUTION

For coin/button battery used, please refer for further information to the user manual.

Attention should be drawn to the environmental aspects of battery disposal

CAUTION

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

The batteries (battery pack or batteries installed) shall not be exposed to excessive heat such

as sunshine, fire or the like.

WARNING

Do not ingest the battery (the remote control supplied with)! Chemical Burn Hazard!

This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it

can cause severe internal burns in just 2 hours and can lead to death.

Keep new and used batteries away from children. If the battery compartment does not close

securely, stop using the product and keep it away children. If you think batteries might have

been swallowed or placed inside any part of the body, seek immediate medical attention.

• The use of apparatus in moderate climates.

• The symbol indicates DC voltage.

INSTALLATION

Prepare Installation

1. First complete the electrical connections and then check for correctness of connection.

2. Disconnect the battery negative terminal of vehicle before beginning installation.

Installation Opening

This unit can be installed in any dashboard which

has an opening size as shown the right figure.

Important:

Remove 2 transport CD deck screws before use.

To Mount the Car Radio

Be sure you test all connections first, and then follow these steps to install this unit.

Before mounting the unit, remove the detachable front panel for panel protection. Press the release

button on the bottom right of the front panel then remove the detachable panel.

1. Make sure the ignition is turned off, and then disconnect the cable from the vehicle battery’s

negative (-) terminal.

2. Disconnect the wire harness and the antenna.

3. Lift the left or right top corner of the plastic outer trim ring then pull it out to remove it.

4. Insert the two bracket keys into the left and right side of the chassis, as shown the below

figure to remove the chassis from the mounting sleeve.

5. Insert mounting sleeve into the dashboard and bend the mounting tabs out with a screwdriver.

Make sure that the lock lever is flush with the mounting sleeve and is not projecting beyond.

6. Insert car radio into the mounting sleeve.

7. Use a metal strap to secure the rear part of the chassis using the hardware indicated.

8. Make wiring connections, as illustrated in the “Wiring Connections.”

9. Install the plastic outer trim ring.

2.05 inches

7.20 inches

Bracket key

Plastic trim out

Bracket key

INSTALLATION (CONT.)

INSTALLATION

DIAGRAM

Wiring Connections

Removal of the Main Unit

1. Remove the metal strap from the main unit.

2. Remove the plastic trim out from the main unit.

3. Insert a bracket key into the left and right side of the main unit and draw the unit out of

the mounting sleeve.

HEX BOLT

SPRING WASHER

PLAIN WASHER

TAPPING SCREW

HEX NUT

DASH BOARD

METAL MOUNTING STRAP

CONSOLE

MOUNTING SLEEVE

- Only use speakers with 4 ohms impedance.

- The maximum current of the Amp Remote trigger is 200mA.

- The equipment shall be protected by the circuit with max. 10 Amperes of the

front end of DC source.

White

Front Left

Speaker

Rear Left

Speaker

Front Right

Speaker

Rear Right

Speaker

White/Black

ACC + (Red)

GND - (Black)

ANT + (Blue)

Power B+ (Yellow)

Gray/Black

Purple

Purple/Black

Green

Green/Black

Gray

1. AUX-L: AUX Input - Left CH (White)

2. AUX-R: AUX Input - Right CH (Red)

3. FL: Front Left PRE-AMP Output (White)

4. FR: Front Right PRE-AMP Output (Red)

5. RL: Rear Left PRE-AMP Output (White)

6. RR: Rear Right PRE-AMP Output (Red)

10A

ANT F-R R-R

F-L

AUX-R

AUX-L R-L

CONTROL PANEL BUTTON LOCATIONS

Panel view (after removal of the detachable front panel

by pressing the release button )

(power) / SRC (source) button

Volume knob, (Push-To-Talk) button, menu selection button

BAND button, (answer call) button

(pause/play), Preset station 1 button

INT (intro), Preset station 2 button

RPT (repeat), Preset station 3 button

RDM (random), Preset station 4 button

-10 (previous 10 tracks, previous folder), Preset station 5 button

4. AMS (automatic store station, automatic preset scan, automatic music search) button

+10 (next 10 tracks, next folder), Preset station 6 button

11.

12. MUTE button, PTY (program types) button

10.

CLK (clock setting), (end call) button

13. (tune/ seek down, previous track, fast reverse) button

14. (tune/ seek up, next track, fast forward) button

15. Hands-free Microphone 16. EJECT button 17. Disc slot

18. IR remote sensor 19. LCD Display 20. USB Port

21. AUX IN (aux audio input) jack 22. Release button 23. Reset button

RESET

GENERAL OPERATION

Adjust Menu Options

to select setting items: BASS, TREBLE, BALANCE, FADER, EQ OFF / ROCK / POP / CLASS / FLAT,

LOUD ON/OFF, AUTO / BLUE / RED / CYAN / GREEN / PURPLE / YELLOW / WHITE, DX / LOCAL,

STEREO/MONO, VOL LAST / ADJ, AREA US/EU, CLOCK 12/24, BEEP ON/OFF, AF ON/OFF,

TA ON/OFF, EON ON/OFF, REG ON/OFF, VOLUME.

- BASS/TREBLE:-7, -6, ~, -1, 0, +1, ~, +6, +7

- BALANCE:L7, L6, ~, L1, 0, R1, ~, R6, R7

- FADER:R7, R6, ~, R1, 0, F1, ~ , F6, F7

- EQ(Equalizer) Setting: OFF / ROCK / POP / CLASS / FLAT

- Loudness: LOUD ON/OFF

- 7 color-changing illumination in buttons:

This car radio device is equipped 7 color-changing illumination in buttons.

The illumination color can be preset Auto(color automatically change one by one ), Blue, Red, Cyan,

Green, Purple, Yellow, White.

- DX/LOCAL: Enables or disables the local broadcast mode (LOCAL).

- Stereo/Mono: Switches between MONO and STEREO reception mode for radio frequencies.

- VOL(LAS/ADJ):This option allows user to preset a volume level as the power-on memory volume level.

- VOL LAST: In this mode,the unit switches on at the actual volume it had when it was last switched off.

- VOL ADJ: In this mode, the unit power on at the actual volume that you preseted constant switch-on

volume level.

Press the volume knob to enter the constant switch-on volume adjusting mode and the “A-VOL XX”

will be shown on the LCD display.

Then you can adjust a constant switch-on volume level by rotating the VOL knob.

- AREA US/EU: This car radio is equipped the USA / Europe frequency.

Rotate the volume knob to switch between USA and europe frequency.

The system will change the frequecny setting in about 3 seconds.

- CLOCK 12/24:

This unit is equipped with two types of clock display formats, 12 and 24 hours.

Rotate the volume knob to choose 12 hours format or 24 hours format.

- BEEP ON/OFF: Enables or disables the “BEEP” signal to confirm use.

- AF ON / OFF: Enables or disables the alternative frequency search mode (AF).

• ON: If a certain broadcast station has bad reception, the device switches automatically to a broadcast

station broadcasting the same program via the same RDS broadcast chain.

• OFF: The function is deactivated.

Turn Unit On/Off

• To turn on the unit, press the power button ( ) on the front panel (or on the remote control).

• To turn off the unit, press and hold the power button ( ) on the front panel or briefly press the power

button ( ) on the remote control.

Adjust Volume

Push-To-Talk

Press the button (volume knob) to access to smartphones voice assistant capability via Bluetooth.

Rotate the volume knob on the front panel or press the VOL /VOL button on the remote control to

increase or decrease the volume level.

1. Press and hold the volume knob to enter the setting menu. Then press repeatedly the volume knob

2. When a menu item is selected, rotate the volume knob or press the VOL /VOL button on the

remote control to change values.

GENERAL OPERATION

the unit switches to the radio station from a different mode (e. g. USB mode). The volume level is

adjusted to the figure set in the menu for transmitting traffic information.

- EON ON / OFF: The unit can receive RDS EON data. EON means the transmission of additional station

information within a station group. In the event of a traffic announcement (TA) it will switch within a

station group from a non-traffic broadcast to the corresponding traffic radio station of the station group.

• ON:The unit attempts to receive the EON TA information from a station within range and thus to

improve the reception quality.

• OFF: Prevents switching over to a station with too weak a signal level.

- REG ON / OFF: At certain times, some stations are segmenting their programs in regional programs

with different content.

• ON: Only the regional programs of the radio station will be played, or suggested as preferences when

tuning to a selected station.

• OFF: Play nationwide programs as well.

- VOLUME Level: 0~40

Set the Clock (CLK)

1. To set clock time, press and hold the CLK button and the hour will flash.

2. Rotate the volume knob to adjust the hour.

3. Press the CLK button on the front panel, the minutes will flash.

4. Rotate the volume knob to adjust the minute.

Change the Source (SRC)

Press the SRC button to switch between RADIO, DISC (with a CD/MP3 disc inside the disc slot), USB

(with USB device inserted), AUX-IN (auxiliary audio input) and BT (Bluetooth) modes.

Mute on/off

In power on mode, briefly press the MUTE button to toggle mute on or off. The muted state will be also

released when the volume knob is used.

USB port

Connect to a USB storage device for audio play, or charging of a mobilephone.

Release the detachable front panel

To protect the front panel or access the reset button, remove the detachable front panel by pressing the

release button on the bottom right of the front panel.

Hands-free Microphone

To receive your voice when you calling by using this Bluetooth hands-free system.

Aux Audio Input Jack

Connect to the headphone jack on an external device (e.g. a mobile phone or MP3 player) for audio play.

Reset System (Reset)

Remove the detachable front panel to access the RESET button, then push the RESET button with a thin

object with a pointed end to reset the unit. Reset the unit when the LCD does not display normally or

sound is distorted, or when any of controls are disabled.

- TA ON / OFF (Traffic announcement settings):

• OFF: The function is deactivated

• ON: TA is displayed if this function is activated. In the TA mode, once a traffic message is received,

To display clock time, press and hold the CLK button on the front panel or short press the CLK button

on the remote control.

RADIO OPERATION

Switch Between USA area and Europe area Frequency

In radio mode, press and hold the volume knob to enter setting menu, then press the volume knob

repeatedly to access the state of the USA and Europe frequency, then rotate the volume knob to switch

between USA and europe frequency. The system will change the frequency setting in about 3 seconds.

Change Bands (BAND)

Press the BAND button to switch between the FM1, FM2, FM3, AM1 and AM2 bands.

Each band stores up to six preset stations.

Manual Tuning ( / )

Press and hold the or button on the front panel (or PREV or NEXT on the remote control) to

enter manual tuning mode. In manual tuning mode, press the or button to move the radio

frequency number up or down one step.

Auto Seek Tuning ( / )

In standby mode or while not in manual tuning mode, quickly press the or button to move to

the next/previous available station automatically.

To Store / Recall Preset Stations

The radio can store 6 preset stations for each band (FM1, FM2, FM3, AM1 and AM2) for a total of 30

preset stations.

- To memorize a station:

- Turn the radio on and select the desired band and station.

- Select a station by or button.

- Press and hold the desired preset button (numbered 1-6 on the face of the radio) for more than 2

seconds to save the station to that preset number.

- To recall a preset station:

- Select the desired band.

- Briefly press a preset button (numbered 1-6) to recall the corresponding preset station.

Automatic Store Preset station, Automatic Preset Scan (AMS)

Press and hold the AMS button to store 18 FM stations and 12 AM stations automatically.

Briefly press the AMS button to recall each preset station that stored in the memories in each band.

PTY Selecting the program type

Using the PTY function, user can select specific stations of a certain program type. The individual

program types are divided into two categories: Music (POP M) and Speech (NEWS).

• Press and hold the MUTE/PTY button to swtich between the category “Music” and “Speech”.

• When PTY group is on, pressing one of 6 mumber(1-6) buttons can select one of typed programs.

After selecting one of typed program, this receiver will automatically search for a respective station.

Music PTY Group

POP M, ROCK M

EASY M, LIGHT M

CLASSICS, OTHER M

JAZZ, COUNTRY

Numeric key Speech PTY Group

NEWS, AFFAIRS, INFO

2 SPORT, EDUCATE, DRAMA

3 CULTURE, SCIENCE, VARIED

4 WEATHER, FINANCE, CHILDREN

NATION(national), OLDIES

FOLK M

5 SOCIAL, RELIGION, PHONE IN

6 TRAVEL,LEISURE, DOCUMENT

Note:

• If PTY is selected, the radio starts to search for respective PTY information and stops when the

desired PTY information is found.

• If the desired program type is not found, the message “NO PTY” appears on the display.

Label Surface Up

DISC/USB OPERATION

To insert DISC / USB

• To play files on a disc, insert a disc with the label surface facing upward into the disc slot.

Playback will begin automatically.

• To play files in a USB device, open the USB port cover, then insert a USB device into the USB port.

Playback will begin automatically.

Eject Disc/USB

• To eject a disc, press the (eject) button to eject the disc and then remove it.

• Remove the USB device to eject a USB device.

Play/Pause

Press the (play/pause) button to pause or resume playback.

Next/Previous Track

To play the next track, press the button; To play the previous track, press the button.

Fast Forward/Backward

To fast forward, press and hold the button; To fast backward, press and hold the button.

Introduction Scan

Press the INT button to play the first 10 seconds of each track, press again to stop the introduction scan,

and play the current track.

Repeating the same track

Press the RPT button to toggle between RPT ONE (Continuously repeats current track), RPT FLR

(Continuously repeats all tracks in current folder), RPT ALL (Play all track).

Playing all tracks in random

Press the RDM button to play all tracks in random order, press again to cancel this function.

Track/Folder Navigation

• During a disc, USB mode, press the 5/-10 button to go backward 10 tracks.

Press the 6/+10 button to jump forward 10 tracks.

• During an MP3 disc, USB mode, press and hold the 5/-10 button to go back the previous folder.

Press and hold the 6/+10 button to go to the next folder.

You can repeat this function depending on the number and level of folders.

• These buttons have no this function if the USB device has no folders.

Table des matières

Autres manuels BOSSCO Récepteur

BOSSCO

BOSSCO 612UA Manuel utilisateur

BOSSCO

BOSSCO BE9ACP Manuel utilisateur

BOSSCO

BOSSCO BV8972 Manuel utilisateur

BOSSCO

BOSSCO Therm RF Series Manuel utilisateur

BOSSCO

BOSSCO MGV520B Manuel utilisateur

BOSSCO

BOSSCO ELITE BE7ACP-SD Manuel utilisateur

BOSSCO

BOSSCO MR634UAB Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
