Boss Audio Systems Phantom P106DVC Manuel utilisateur

P106DVC

Box Volume : 1.0 Cu Ft

Port Frequency : 38 Hz

Port Diameter : 3 lnches

Port Length : 8 lnches

Box is given as internal air volume including driver displacement

Ported Enclosure

Frequency

P106DVC Amplitude Response(dB/Hz)

Box Volume : 0.6 Cu Ft

Box is given as internal air volume including driver displacement

Sealed Enclosure

Recommended Enclosures

Frequency

Please note : Our recommended box volumes are given for

internal air requirements.

P106DVC Amplitude Response(dB/Hz)

Sealed Enclosure

Ported Enclosure

0.491

4.427

0.552

1.283

0.246

1.8

1050W/2100W

0.922

4.597

1.153

1.52

0.246

3.6

1050W/2100W

0.489

4.592

0.548

1.424

0.246

7.2

1050W/2100W

2 4 8

10” (254mm) Subwoofer

(1050 Watts RMS Sealed Enclosure)

Not Use

2 ohms 4 ohms

8 ohms 4 ohms

Wiring

Please take every precaution to wire your DVC woofers

for the correct impedance

Not Used

+-+-

+-+-+-+

10” (254mm) BLACK METALLIC POLY INJECTION CONE

BUTYL RUBBER SURROUND

DUAL 2-1/2” (64mm) HIGH TEMPERATURE KAPTON

VOICE COIL

2100 WATTS PEAK/1050 WATTS RMS

FREQUENCY RESPONSE: 35 Hz-2.2 KHz

SENSITIVITY: 96dB (1 WATT/1 METER)

IMPEDANCE: DUAL 4 OHMS

MOUNTING DEPTH: 6-1/2” (165mm)

MOUNTING DIAMETER: 9-5/16” (236mm)

BOSS AUDIO CAR STEREOS CAR AUDIO SYSTEMS
