Fire Alarm Systems | FMC‑210‑SM Single Action Call Points
The FMC‑210‑SM Single Action Call Points are used for
manual triggering, and can be used in the Local
SecurityNetwork LSN and LSN improved. The
FMC‑210‑SM Single Action Call Points are designed for
indoor deployment.
Functions
1 1
2
23
3
4
5
With single action call points, the alarm is triggered when
the glass plate (2) is broken and the button (3) springs
up.
This activates the microswitch for alarm triggering and the
indicator LED (4) blinks.
The call point (3) can be reset after inserting a new glass
pane (2) and closing the door of the single action call
point (1). The indicator LED (4) goes out.
This does not reset the alarm on the fire panel.
Individual call point identification with display of the call
point address on the fire panel ensures the quick location
of the triggered call point.
Certifications and Approvals
FMC‑210‑SM‑G‑R applies to
•EN 54‑11:2001/A1:2005
•EN 54‑17:2005
Region Certification
Germany VdS G 207008 FMC-210-SM-G-R
Europe CPD 0786-CPD-20316 FMC-210-SM-G-R
Installation/Configuration Notes
•Manual call points must be mounted visibly along
escape and rescue routes (e. g. exits, passageways,
stairwells) and be easily accessible.
•An installation height of 1400 mm ±200 mm, measured
from the middle of the manual call point to the floor,
must be maintained.
•Manual call points must be adequately illuminated by
sunlight or another light source (including emergency
lighting if present).
FMC‑210‑SM Single Action Call Points
▶Alarm triggering by breaking of the glass pane
▶Automatic or manual detector addressing via rotary
switch possible
▶Indicator LED for alarm or for inspection evaluation
▶Call point query routines with evaluation and multiple
transmission
▶Individual call point identification
▶Maintains LSN loop functions in the event of wire
interruption or short-circuit thanks to two integrated
isolators
www.boschsecurity.com
2 | FMC‑210‑SM Single Action Call Points
•The maximum number of LSN elements that may be
connected depends on their current consumption
from the LSN data line. The limit values should be
taken from the product information supplied with the
fire panel used.
•Further standards, guidelines and planning
recommendations regarding the installation location
etc., should also be taken into consideration (see Fire
Detection manual).
•The regulations of the local fire services must be
observed.
Installation notes in accordance with VdS/VDE
•The distance between manual call points should not
be more than 100 m according to DIN 14675 or 80 m
according to VdS.
•In high risk areas, manual call points should be
installed at a distance of max. 40 m (VDE 0833 Part 2,
Point 7.2.6).
Installation
•The cable duct can be surface-mounted or flush-
mounted.
•Installation in fire hose cabinets is possible in three
ways:
135 mm
140 mm
2,5 mm
2 mm
139 mm
1
2
3
149,5 mm
12,5 mm
Pos. Description
1 Installation depth version 1: ca. 40 mm
2 Installation depth version 2: 14 mm
3 Installation depth version 3: min. 30 mm
Parts Included
TypeNumber. Component
FMC‑210‑SM‑G‑B
Form G, Blue
Single Action Call Point for indoor use, direct trig-
gering (type A)
FMC‑210‑SM‑G‑R
Form G, Red
Single Action Call Point for indoor use, direct trig-
gering (type A
Note The key must be ordered separately.
Technical Specifications
Electrical
Operating voltage 15 V DC . . . 33 V DC
Current consumption 0.4 mA
Mechanics
Dimensions (H x W x D) 135 x 135 x 40 mm
Housing material Plastic, ASA
Colors
•FMC-210-SM-G-R Red, RAL 3001
•FMC-210-SM-G-B Blue, RAL 5005
Weight Approx. 235 g
FMC‑210‑SM Single Action Call Points | 3
Environmental Considerations
Protection class as per EN 60529 IP 52
Permissible operating temperature -10 °C. . . +55 °
Ordering Information
FMC‑210‑SM‑G‑B Form G, Blue
Single Action Call Point for indoor use, direct
triggering (type A), for LSN improved
FMC-210-SM-G-B
FMC‑210‑SM‑G‑R Form G, Red
Single Action Call Point for indoor use, direct
alarm triggering (type A), for LSN improved
FMC-210-SM-G-R
Accessories
FMX‑FSO‑LSN Punched, Self-adhesive Foil
Sets (Blank)
For the labeling field of manual call points of
the Series FMC‑210.
1 unit = 10 sheets
FMX-FSO-LSN
FMC‑FST‑DE Printed Labeling Foils for the
Upper Label Field
For yellow and blue manual call points of Ser-
ies FMC‑120 and FMC‑210, 1 unit = 5 sheets
FMC-FST-DE
FMC‑SPGL‑DEIL Spare Glasses
For manual call points of Series DM, DKM,
SKM, FMC‑120 and FMC‑210.
1 unit = 5 spare glasses
FMC-SPGL-DEIL
Key for Fire Detectors Types G and H
made of red plastic (ASA)
FMM-KEY-Form G/H
www.boschsecurity.com
4 | FMC‑210‑SM Single Action Call Points
Americas:
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: +1 800 289 0096
Fax: +1 585 223 9180
www.boschsecurity.us
Europe, Middle East, Africa:
Bosch Security Systems B.V.
P.O. Box 80002
5600 JB Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: +31 40 2577 330
www.boschsecurity.com
Asia-Pacific:
Robert Bosch (SEA) Pte Ltd, Security Systems
11 Bishan Street 21
Singapore 573943
Phone: +65 6258 5511
Fax: +65 6571 2698
www.boschsecurity.asia
Represented by
© Bosch Security Systems 2011 | Data subject to change without notice
T3892227979 | Cur: en-US, V16, 9 Jun 2011
