V1160 Series

Day/Night Color to B/W

Switching Camera

•Mechanical IR Cut filter

switching from day to night mode

•1/3-inch format CCD imager

•On-screen menu programming

•Video, DC, or ESC iris modes

•Automatic backlight

compensation with selectable

area and sensitivity

•Automatic gain control

selectable

•Wide dynamic functions

selectable

•Programmable video motion

detector with 5 V pulse output

on the camera

•Flexible mounting options

The V1160 is a day/night camera that switches

automatically between color and black & white mode

whenever the environmental lighting conditions ask for

it. This switching is performed through a mechanical,

removable IR Cut filter. The camera is controllable via an

on-screen display menu using the navigation keys on the

back of the camera. Due to its outstanding

performance in any lighting condition and its high

resolution (520 lines in B/W and 480 lines in color) the

camera can be used in any security application one can

imagine. Its powerful backlight compensation, and

electronic iris ensure the clearest possible images under a

wide variety of conditions.

The OSD menu programming options:

•Camera IDentification

•BLC: OFF / ON (weight: 1 to 4)

•VMD: user adjustable area & sensitivity

•Lens: Manual / DC / Video (with brightness control)

•Shutter: ESC (brightness control) / Manual (11 speeds

selectable and flickerless mode)

•Gain: AGC with brightness & limit control or OFF

•White balance: ATW/AWC/Manual (red & blue)

•Colormode:On / Off / Auto1 / Auto2

•Sync.: internal

•Reset

CCTV | Day/Night color to B/W switching camera

Security you can rely on

2 | Day/Night color to B/W switching camera

Bosch Security Systems

P.O. Box 80002

5600 JB Eindhoven,

The Netherlands

www.boschsecuritysystems.com

Model No. V1160P PAL System

V1160N NTSC System

Power Input Voltage 12 VDC or 24 VAC (± 10 %)

Consumption 3.5 W (DC), 3.8 W (AC)

Video Pick-up Device PAL Model: 1/3-inch CCD imager; 795 (H) x 596 (V)

NTSC Model: 1/3-inch CCD imager; 768 (H) x 496 (V)

Scanning System 2:1 Interlace (Standard)

SYNC System INT/Line lock

Output 1 Vp-p Composite

Minimum Illumination 0.01 lux (B/W mode), 0.5 lux (color mode), both at F1.2

Color mode Auto1 / Auto2 / On / Off mode selectable

OSD Camera ID, adjust menu, motion detection …

AGC Built-in and adjustable

Backlight Compensation Off / On (selectable weight 1 to 4)

Lens & Iris Iris Mode Video/DC/ESC selectable

Iris Speed 1/50 - 1/10, 000 sec selectable 11 speeds and flickerless mode

Lens Mount Type C/CS-mount with adapter included

RS-232C Available

S/N Ratio > 48 dB (AGC Off)

Horizontal Resolution 520 lines in B/W mode, 480 lines in color mode

Housing Weight 0.40 kg (0.9 lb)

Dimensions (w/o lens) [H x W x D] 50mm x 57mm x 130mm (2.24 in x 2.17 in x 5.31 in)

Environment Operating Temperature -25.6°C to +50°C (-14°F to +122°F)
