Bosch Use IP FLEXIDOME IP starlight 6000 VR Manuel utilisateur

FLEXIDOME IP starlight

6000 VR

NIN-63013 | NIN-63023

en Installation Manual

use

www.use-ip.co.uk

01304 827609

Table of contents

1Safety 5

1.1 Safety precautions 5

2Short information 7

3System overview 8

3.1 Performance 8

3.2 Using the camera 8

3.3 Application variants 10

4Planning information 11

4.1 Unpacking 11

4.2 Contents 11

5Installation 12

5.1 Preparation 12

5.2 Local storage 13

5.3 Wiring 13

5.3.1 Cable tree 14

5.3.2 Earthing 14

5.3.3 Network (and PoE power) 15

5.3.4 Auxiliary power 15

5.3.5 Alarm 15

5.3.6 Audio 16

5.3.7 Video 16

5.4 Mounting the camera module 17

5.4.1 Mounting flush to ceiling 17

5.4.2 Mounting to ceiling with SMB-IP 18

5.5 Camera positioning and field-of-view 20

5.5.1 Pan 21

5.5.2 Tilt 22

5.5.3 Twist 22

5.6 Local set-up 23

5.6.1 Using the install wizard 23

5.6.2 Reset 24

5.7 Mount inner and outer dome 25

FLEXIDOME IP starlight

6000 VR Table of Contents | en 3

Bosch Security Systems 2016.06 | v1.0 | AM18-Q0711

6Connection via web browser 27

7Configuration 28

8Troubleshooting 29

8.1 Resolving problems 29

8.2 Testing the network connection 31

8.3 Customer service 32

9Maintenance 33

9.1 Cleaning 33

9.1.1 Lens cleaning 33

9.2 Repair 33

10 Decommissioning 34

10.1 Transfer 34

10.2 Disposal 34

11 Technical data 35

4en | Table of Contents FLEXIDOME IP starlight

6000 VR

2016.06 | v1.0 | AM18-Q0711 Bosch Security Systems

Safety

Caution!

Indicates a hazardous situation which, if not avoided, could

result in minor or moderate injury.

Notice!

Indicates a situation which, if not avoided, could result in

damage to the equipment or environment, or data loss.

Safety precautions

Caution!

The Low Voltage power supply unit must comply with EN/UL

60950. The power supply must be a SELV-LPS unit or a SELV -

Class 2 unit (Safety Extra Low Voltage - Limited Power Source).

Caution!

Installation should only be performed by qualified service

personnel in accordance with the National Electrical Code

(NEC 800 CEC Section 60) or applicable local codes.

Read, follow, and retain for future reference all of the following

safety instructions. Follow all warnings before operating the

device.

1. Clean only with a dry cloth. Do not use liquid cleaners or

aerosol cleaners.

2. Do not install device near any heat sources such as

radiators, heaters, stoves, or other equipment (including

amplifiers) that produce heat.

3. Never spill liquid of any kind on the device.

4. Take precautions to protect the device from power and

lightning surges.

1.1

FLEXIDOME IP starlight

6000 VR Safety | en 5

Bosch Security Systems 2016.06 | v1.0 | AM18-Q0711

5. Adjust only those controls specified in the operating

instructions.

6. Operate the device only from the type of power source

indicated on the label.

7. Unless qualified, do not attempt to service a damaged

device yourself. Refer all servicing to qualified service

personnel.

8. Install in accordance with the manufacturer's instructions in

accordance with applicable local codes.

9. Use only attachments/accessories specified by the

manufacturer.

10. Protect all connection cables from possible damage,

particularly at connection points.

11. Connect the yellow/green earth wire of the camera to the

system earth of the installation to ensure correct safety and

EMC/RFI protection.

6en | Safety FLEXIDOME IP starlight

6000 VR

2016.06 | v1.0 | AM18-Q0711 Bosch Security Systems

Short information

http://www.boschsecurity.com/catalog_overview.htm

This manual has been compiled with great care and the

information it contains has been thoroughly verified. The text

was correct at the time of printing, however, the content can

change without notice. Bosch Security Systems accepts no

liability for damage resulting directly or indirectly from faults,

incompleteness or discrepancies between this manual and the

product described.

For more information please contact the nearest Bosch Security

Systems location or visit www.boschsecurity.com

All hardware and software product names used in this document

are likely to be registered trademarks and must be treated

accordingly.

FLEXIDOME IP starlight

6000 VR Short information | en 7

Bosch Security Systems 2016.06 | v1.0 | AM18-Q0711

System overview

Performance

This camera provides clear images 24/7 – even at night or under

low-light conditions.

The exceptional starlight sensitivity enables this camera to work

with a minimum of ambient light. The extended dynamic mode

provides detailed images in scenes with challenging lighting.

The camera is available in 1080p or 720p resolution versions

and provides up to 60 images per second.

The aesthetic vandal-resistant housing makes the camera

suitable for indoor or outdoor installation.

Using the camera

Use a web browser to access the camera features and to view

the camera streams live. Use the same browser interface to

access and change the camera configuration parameters and

recording/storage functions (including local alarm recording,

and recording to iSCSI-based systems).

Refer to the software manual for more information on the

browser interface.

The web browser is the most direct way of using the camera,

however, the Bosch download store provides several other free

applications (listed below) for viewing and controlling the

camera.

Download store

Download the latest applications and firmware from:

http://downloadstore.boschsecurity.com/

3.1

3.2

8en | System overview FLEXIDOME IP starlight

6000 VR

2016.06 | v1.0 | AM18-Q0711 Bosch Security Systems

Video Security Client

The Video Security Client is a free, easy-to-use video-surveillance

application provided by Bosch for local and remote monitoring

of IP cameras and appliances. The software supports up to 16

cameras.

Bosch Video Client

The Bosch Video Client is a free Windows application to view,

operate, control, and administer surveillance cameras and

installations at remote locations. It offers a user-friendly

interface for easy live viewing of multiple cameras, playback,

forensic search and export.

IP Helper

The IP Helper tool is a free PC application that makes it easy to

detect Bosch cameras and devices on your network.

Video security app

The Bosch video security mobile app has been developed to

enable Anywhere access to HD surveillance images allowing you

to view live images from any location. The app is designed to

give you complete control of all your cameras, from panning and

tilting to zoom and focus functions. It’s like taking your control

room with you.

This app, together with the separately available Bosch

transcoder, will allow you to fully utilize our dynamic

transcoding features so you can play back images even over low-

bandwidth connections.

FLEXIDOME IP starlight

6000 VR System overview | en 9

Bosch Security Systems 2016.06 | v1.0 | AM18-Q0711

Application variants

The camera has a choice of application variants that set up the

camera for optimum performance in a specific environment.

Select the application variant best suited to your installation.

The application variant must be selected before any other

changes are made, as the camera reboots automatically and

resets the factory defaults when the application variant is

changed.

This camera has the following application variants:

– Starlight mode (default) – to continue viewing in color at

very low light levels

– Extended Dynamic mode - simultaneously see details in

very bright and very dark objects in the same scene

3.3

10 en | System overview FLEXIDOME IP starlight

6000 VR

2016.06 | v1.0 | AM18-Q0711 Bosch Security Systems
