Bosch NWD-495V03-20P Manuel utilisateur

FlexiDomeDN IP

NWD-495V03-10 | NWD-495V03-20

en Operating Instructions

FlexiDomeDN IP | en 3

Bosch Security Systems Operating Instructions V 1.0 | 2006.12

Table of Contents

1 Introduction 15

1.1 Type number overview 16

1.2 Unpacking 16

1.3 System requirements 17

1.4 Overview of functions 17

1.4.1 Wide dynamic range 18

1.4.2 Day/Night function 18

1.4.3 Power-over-Ethernet 18

1.4.4 Receiver 18

1.4.5 Video encoding 18

1.4.6 Tri Streaming 19

1.4.7 Recording 19

1.4.8 Multicast 19

1.4.9 Encryption 19

1.4.10 Configuration 19

1.4.11 Tampering recognition and motion detectors 19

1.4.12 Snapshots 20

1.4.13 Backup 20

1.4.14 Intelligent Video Motion Detection 20

2 Disassembly 21

3 Mounting the unit 22

3.1 Attach the mounting plate 23

3.2 Make the connections 23

3.2.1 Power connection 24

3.2.2 Network (and PoE) connection 24

3.3 Mount the camera 24

4Cameraset-up 25

4.1 Camera positioning 25

4.2 Focal length and focus 26

4.3 Basic settings 26

4en | FlexiDomeDN IP

V 1.0 | 2006.12 Operating Instructions Bosch Security Systems

4.3.1 Install menu 27

4.3.2 Defaults 28

4.4 Closing the unit 28

5Networkconnection 29

5.1 System requirements 29

5.2 Establishing the connection 29

5.3 Secured network 31

6 Operation via the browser 32

6.1 Livepage 32

6.1.1 Processor load 32

6.1.2 Image selection 33

6.1.3 System log / Event log 33

6.1.4 Saving snapshots 33

6.1.5 Recording video sequences 33

6.1.6 Running recording program 34

6.2 Recordings page 35

6.2.1 Selecting recordings 35

6.2.2 Controlling playback 36

7 Configuration via the browser 39

7.1 Settings 39

7.2 General Settings 41

7.2.1 Camera identification 41

7.2.2 Password protection 42

7.2.3 Language selection 43

7.2.4 Date and time 43

7.2.5 Time server 44

7.3 Display Settings 45

7.3.1 Display stamping 45

7.4 Encoder Settings 46

7.4.1 Selecting an encoder profile 46

7.4.2 Changing profiles 48

7.4.3 JPEG posting 51

7.5 Camera settings 53

FlexiDomeDN IP | en 5

Bosch Security Systems Operating Instructions V 1.0 | 2006.12

7.5.1 ALC 53

7.5.2 Shutter/AGC 54

7.5.3 Day/Night 55

7.5.4 Enhance 56

7.5.5 Color 57

7.5.6 Back Light Compensation (BLC) 58

7.5.7 Installer options 59

7.6 Recording 59

7.6.1 Type 60

7.6.2 Storage information 60

7.7 iSCSI settings 61

7.7.1 iSCSI IP address 61

7.7.2 iSCSI LUN map 62

7.7.3 Target IP address 62

7.7.4 Target node 62

7.7.5 Target LUN 62

7.7.6 Target password 62

7.7.7 Initiator name 63

7.7.8 Initiator extension 63

7.7.9 Decoupling the drive used 63

7.7.10 Storage information 63

7.8 Partitioning 64

7.8.1 Creating a partition 64

7.8.2 Partition status 66

7.8.3 Editing a partition 66

7.8.4 Deleting partitions 69

7.9 Recording profile 69

7.10 Recording scheduler 72

7.10.1 Activating recording 73

7.10.2 Recording status 74

7.11 Alarm Settings 74

7.11.1 Alarm connections 74

7.12 VCA 77

7.12.1 Analysis 77

7.12.2 Analysis type 78

7.12.3 Motion detector 78

7.12.4 Sensitivity 79

6en | FlexiDomeDN IP

V 1.0 | 2006.12 Operating Instructions Bosch Security Systems

7.12.5 Tamper detection 80

7.13 Alarm e-mail 82

7.13.1 Send alarm e-mail 82

7.13.2 Mail server IP address 82

7.13.3 Layout 83

7.13.4 Destination address 83

7.13.5 Sender name 83

7.13.6 Send e-mail for testing 83

7.14 Service Settings 84

7.14.1 Network 84

7.14.2 Multicasting 87

7.14.3 Encryption 89

7.14.4 Version information 90

7.14.5 Livepage configuration 91

7.14.6 Licenses 93

7.14.7 Maintenance 94

7.15 Function test 96

8 Connections between video servers 97

8.0.1 Installation 97

8.0.2 Establishing the connection 97

8.0.3 Connect on alarm 97

8.0.4 Connecting with a Web browser 98

8.0.5 Closing the connection 98

9 Operation with decoder software 99

10 Maintenance 100

10.1 Testing the network connection 100

10.2 Repairs 100

10.2.1 Transfer and disposal 100

FlexiDomeDN IP | en 7

Bosch Security Systems Operating Instructions V 1.0 | 2006.12

11 Troubleshooting 101

12 Specifications 103

12.1 Dimensions (mm/inch) 105

12.2 Accessories 105

12.2.1 Power transformers 105

13 Glossary 106

8en | FlexiDomeDN IP

V 1.0 | 2006.12 Operating Instructions Bosch Security Systems

Important safety instructions

Read, follow, and retain all of the following safety instructions.

Heed all warnings on the unit and in the operating instructions

before operating the unit.

1. Cleaning - Unplug the unit from the outlet before cleaning.

Follow any instructions provided with the unit. Generally,

using a dry cloth for cleaning is sufficient, but a moist fluff-

free cloth or leather shammy may also be used. Do not use

liquid cleaners or aerosol cleaners.

2. Heat Sources - Do not install the unit near any heat sources

such as radiators, heaters, stoves, or other equipment

(including amplifiers) that produce heat.

3. Water - Do not use this unit near water, for example near a

bathtub, washbowl, sink, laundry basket, in a damp or wet

basement, near a swimming pool, in an unprotected out-

door installation, or in any area classified as a wet location.

To reduce the risk of fire or electrical shock, do not expose

this unit to rain or moisture.

4. Object and liquid entry - Never push objects of any kind

into this unit through openings as they may touch danger-

ous voltage points or short-out parts that could result in a

fire or electrical shock. Never spill liquid of any kind on the

unit. Do not place objects filled with liquids, such as vases

or cups, on the unit.

5. Controls adjustment - Adjust only those controls specified

in the operating instructions. Improper adjustment of

other controls may cause damage to the unit. Use of con-

trols or adjustments, or performance of procedures other

than those specified, may result in hazardous radiation

exposure.

6. Overloading - Do not overload outlets and extension cords.

This can cause fire or electrical shock.

7. Power cord and plug protection - Protect the plug and

power cord from foot traffic, being pinched by items

placed upon or against them at electrical outlets, and its

exit from the unit. For units intended to operate with

FlexiDomeDN IP | en 9

Bosch Security Systems Operating Instructions V 1.0 | 2006.12

230 VAC, 50 Hz, the input and output power cord must

comply with the latest versions of IEC Publication 227 or

IEC Publication 245. For outdoor use the power cord must

comply to NEC400-4 (CEC Rule 4-010) and marked with

OUTDOOR, W, or W-A.

8. Power sources - Operate the unit only from the type of

power source indicated on the label. Before proceeding,

be sure to disconnect the power from the cable to be

installed into the unit.

– For battery powered units, refer to the operating

instructions.

– For external power supplied units, use only the rec-

ommended or approved power supplies.

–Forlimitedpowersourceunits, this power source

must comply with EN60950. Substitutions may dam-

age the unit or cause fire or shock.

– For 24 VAC units, voltage applied to the unit's power

input should not exceed 28 VAC. User-supplied wiring

must comply with local electrical codes (Class 2

power levels). Do not ground the supply at the termi-

nals or at the unit's power supply terminals.

– If unsure of the type of power supply to use, contact

your dealer or local power company.

9. Servicing - Do not attempt to service this unit yourself.

Opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified

service personnel.

10. Damage requiring service - Unplug the unit from the main

AC power source and refer servicing to qualified service

personnel when any damage to the equipment has

occurred, such as:

– the power supply cord or plug is damaged;

– exposure to moisture, water, and/or inclement

weather (rain, snow, etc.);

– liquid has been spilled in or on the equipment;

– an object has fallen into the unit;

– unit has been dropped or the unit cabinet is damaged;

10 en | FlexiDomeDN IP

V 1.0 | 2006.12 Operating Instructions Bosch Security Systems

– unit exhibits a distinct change in performance;

– unit does not operate normally when the user cor-

rectly follows the operating instructions.

11. Replacement parts - Be sure the service technician uses

replacement parts specified by the manufacturer, or that

have the same characteristics as the original parts. Unau-

thorized substitutions may cause fire, electrical shock, or

other hazards.

12. Safety check - Safety checks should be performed upon

completion of service or repairs to the unit to ensure

proper operating condition.

13. Installation - Install in accordance with the manufacturer's

instructions and in accordance with applicable local codes.

14. Attachments, changes, or modifications - Only use attach-

ments/accessories specified by the manufacturer. Any

change or modification of the equipment, not expressly

approved by Bosch, could void the warranty or, in the case

of an authorization agreement, authority to operate the

equipment.
